Sunjoy SummerCove A102017700 User manual

Country of Origin: China Production Number: XXXXXXXXXX
Pais d’origine: Chine Numéro de fabrication: XXXXXXXX
ASSEMBLYINSTRUCTION
INSTRUCTIONS DE MONTAGE
Item/Article #：A102017700
WE HAVE YOU IN MIND, LET US SERVE YOU!
Nous pensons en vous, laissez nous vous aider!
Questions? Issues?/ Questions? Problèmes?
CONTACT US/ Contactez-nous
[e-mail]
www.sunjoyonline.com

2/ 41
Country of Origin: China
Pais d’origine: Chine
This product is intended for domestic outdoor use only.
The product should be placed on flat, horizontal ground.
Ensure enough clearance around the product. Before assembling the product, find level
ground not less than 6' (1.8 m) away from any structures or obstructions, such as fences,
garages, houses, overhanging branches, laundry lines, or electrical wires.
This gazebo is not to be regarded as part of a building/house structure. The gazebo is to be
anchored onto the ground for added safety. Do not assemble the gazebo onto soil/earth
ground. It is best advisable to have the gazebo built onto a wooden deck or concrete ground
for stability. If it is to be build onto a wooden deck/ground, do ensure that the wooden
deck/ground has a strong foundation. It is advisable to use appropriate floor plugs (not
provided) to anchor the gazebo onto the wooden/concrete ground.
Some structures may require two or more people to install safely. Check for underground
utilities before digging or driving stakes into the ground.
During installation, follow all safety warnings provided with your tools, and use safety glasses.
In case you set up more than one gazebo, keep a minimum distance of 10' (3 m) between the
gazebos.
Any assembly or maintenance of the product must be carried out by adults only.
Arrange necessary manpower when assembling or moving the product.
Some parts may contain sharp edges. Wear protective gloves if necessary.
Keep children and pets away while setting up the gazebo.
Check all nuts and bolts periodically to ensure bolts/nuts are tightened.
Repairing and replacing parts should be done by a qualified technician.
This gazebo is intended for decorative and sunshade purposes only, and it is not designed to
withstand harsh weather, including high winds, rain, and snow.
Do not light any fires inside or near the product！
Stay calm if fire breaks out. Search for the nearest exit. Do not return to the gazebo before
firemen allow you to do so.
Do not hang heavy weights on the roof frame.
Do not climb onto the roof of the gazebo. Falling off the gazebo can result in serious injury.
Retain the original packaging to store the gazebo
Important Safety Instructions
Warning! To reduce the risk of serious injury, read the following safety instructions
before assembling and using the gazebo.
Please check with your local governing authority/local municipal codes regarding
installation of structures before assembly.
Caution!
Proper placement of your gazebo is essential.
Do not place the product underneath electrical lines.
Keep children away during assembly.
This product contains small parts which can be swallowed by children.
Keep fingers away from the places where they can be pinched or trapped.
Do not attempt to assemble the gazebo if any parts are missing.

3/ 41
Country of Origin: China
Pais d’origine: Chine
Consignes de sécurité importantes
ATTENTION! 





Avertissement!



•
•
•



• 
 
 
 
 

•

•

• 

•
•
•
•
•

•
•

•
•

•
•

•

4/ 41
Country of Origin: China
Pais d’origine: Chine
•Please read and understand this manual before any assembly. Before beginning
assembly of product, make sure all parts are present. Compare parts with packaging
contents list.
•When assembling wooden parts, do not overtorque the bolts to avoid splitting the wood.
See image illustration.
•Place all parts from the box in a cleared area and position them on the floor in front of you.
•Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete.
•Read each step carefully before beginning any assembly and make sure you understand each
step. If you are missing a part, please email [email protected]m.
•Needed for assembly:（The following tools are not included）
IMPORTANT:
Cordless drill
Hammer
Screwdriver
Ladder
5 people

5/ 41
Country of Origin: China
Pais d’origine: Chine
IMPORTANT:
•

•
•

•

•





Utilisez un niveau


Véfifiez avec un équerre


Serrer les boulons Mesurer la distance




   5 personnes

6/ 41
Country of Origin: China
Pais d’origine: Chine
EXPLODED DRAWING/ DESSIN ÉCLATÉ

7/ 41
Country of Origin: China
Pais d’origine: Chine
Parts List
Label Part Number Description Qty Part Image
A P00020074001 Post 1 4
B P00610024601 Base Cover 12
C P00010049701 Post Base 12
D P00020074101 Post 2 4
E P00020074201 Post 3 4
F P00040138501 Long Cross Beam 4
G P00040138601 Short Cross Beam 4
J P00220039301 Cross Beam Cap 4
K P00050178001 Brace Connector 4 6
L P00630013801 Screen 8
M P00060219301 Joist Beam 4
N P00050177601
Joist Beam
Connector 2
P P00050177701 Brace Connector 1 2
Q P00050177801 Brace Connector 2 2
R P00050177901 Brace Connector 3 2
S P00500069701 Joist Beam Brace 1 2
T P00500070001 Joist Beam Brace 2 2
U P00500070101 Joist Beam Brace 3 2

8/ 41
Country of Origin: China
Pais d’origine: Chine
Liste de Pièces
Étiquette Numéro dela Pièce Description Quantité Numéro de la Pièce Diagramme
A P00020074001 Poteau 1 4
B P00610024601 Barde de la base 12
C P00010049701 Base du Poteau 12
D P00020074101 Poteau 2 4
E P00020074201 Poteau 3 4
F P00040138501 Traverse Longue 4
G P00040138601 Traverse courte 4
J P00220039301 Capuchon De la
Traverse 4
K P00050178001 Connexion de la
Contrefiche 4 6
L P00630013801 Façade 8
M P00060219301 Poutre de Solive 4
N P00050177601 Connexion de
la Poutrelle 2
P P00050177701 Connexion de la
Contrefiche 1 2
Q P00050177801 Connexion de la
Contrefiche 2 2
R P00050177901 Connexion de la
Contrefiche 3 2
S P00500069701 Renfort de la
Poutre de Solive 1 2
T P00500070001 Renfort de la
Poutre de Solive2 2
U P00500070101 Renfort de la
Poutre de Solive 3 2

9/ 41
Country of Origin: China
Pais d’origine: Chine
V P00060233801 Top Beam 2
W P00050178201
Top Beam
Connector 1 1
X P00050178301
Top Beam
Connector 2 1
Y P00060233201 Middle Beam 6
AA P00050178101
Middle Beam
Connector 6
AB P00500070301 Top Brace 2 2
AC P00500070201 Top Brace 1 3
AD P005800001 Hook 1
AE P00060233301 Small Top Beam 1 8
AF P00060233901 Panel Flashing 1 2
AG P00060234001 Panel Flashing 2 2
AJ P00060234101 Panel Flashing 3 2
AK P00060234201 Panel Flashing 4 2
AL P00220039401 Stator 4
AM P00060233601
Side Panel Flashing
1 2
AN P00060233701
Side Panel Flashing
2 2
AP P00060233401 Small Top Beam 2 4
AQ P00060233501 Small Top Beam 3 4
AR P00070106201 Big Roof Panel 10
AS P00080040001 Middle Roof Cap 1

10 / 41
Country of Origin: China
Pais d’origine: Chine
V P00060233801 Poutre Supérieure 2
W P00050178201 Connexion de la
Poutre Supérieure 1 1
X P00050178301 Connexion de la
Poutre Supérieure 2 1
Y P00060233201 Poutre centrale 6
AA P00050178101 Connexion de la
poutre centrale 6
AB P00500070301 Support supérieur 2 2
AC P00500070201 Support supérieur 1 3
AD P005800001 Crochet 1
AE P00060233301 Poutre du Petit
Toit 1 8
AF P00060233901 Panneau clignotant 1 2
AG P00060234001 Panneau clignotant 2 2
AJ P00060234101 Panneau clignotant 3 2
AK P00060234201 Panneau clignotant 4 2
AL P00220039401 Stator 4
AM P00060233601 Solin du Panneau
Latéral 1 2
AN P00060233701 Solin du Panneau
Latéral 2 2
AP P00060233401 Poutre du Petit
Toit 2 4
AQ P00060233501 Poutre du Petit
Toit 3 4
AR P00070106201 Panneau du
grand toit 10
AS P00080040001 Toiture du toit
central 1

11 / 41
Country of Origin: China
Pais d’origine: Chine
AT P00070112001 Left Small Roof
Panel 2
AU P00070112101 Right Small Roof
Panel 2
AV P00080040101 Side Roof Cap 2
AW P00220039501 Press Piece 1 8
AX P00220039601 Press Piece 2 4
AY P00560049401 Base Tail 8
BA P00050177501
Cross Beam
Connector 4

12 / 41
Country of Origin: China
Pais d’origine: Chine
AT P00070112001 Panneau gauche
du petit toit 2
AU P00070112101 Panneau droit
du petit toit 2
AV P00080040101 Toiture du
toit latéral 2
AW P00220039501 Pièce de
compression 1 8
AX P00220039601 Pièce de
compression 2 4
AY P00560049401 Extrémité de la base 8
BA P00050177501 Connexion de
la Traverse 4

13 / 41
Country of Origin: China
Pais d’origine: Chine
Hardware Pack
Label Part Number Description Qty Add Part Image
H1 H100010047 Bolt M6*20 238 12
H2 H100010095 Bolt M6*30 68 4
H3 H100010156 Bolt M10*45 32 2
H4 H100010074 Bolt M6*75 4 1
H5 H100010159 Bolt M6*115 4 1
H6 H050030001 Flat Washer
M6 4 1
H7 H040010004 Nut M6 4 1
HH H050050018 M6 Rubber
Washer 4 1
HS H070010003 Stake Φ8*180 24 0
HW1 H090010017 Wrench M6 2 0
HW2 H090010015 Wrench M10 1 0

14/ 41
Country of Origin: China
Pais d’origine: Chine
Liste de Pièces
Étiquette Numéro de
la Pièce Description Quantité Add Numéro de la Pièce Diagramme
H1 H100010047 Boulon M6*20 238 12
H2 H100010095 Boulon M6*30 68 4
H3 H100010156 Boulon M10*45 32 2
H4 H100010074 Boulon M6*75 4 1
H5 H100010159 Boulon M6*115 4 1
H6 H050030001 Rondelle
plate M6 4 1
H7 H040010004 Écrou M6 4 1
HH H050050018 Rondelle en
caoutchouc M6 4 1
HS H070010003 Piquet Φ8*180 24 0
HW1 H090010017 Clé M6 2 0
HW2 H090010015 Clé M10 1 0

15 / 41
Country of Origin: China
Pais d’origine: Chine
1

16/ 41
Country of Origin: China
Pais d’origine: Chine
2

17/ 41
Country of Origin: China
Pais d’origine: Chine
3

18/ 41
Country of Origin: China
Pais d’origine: Chine
4

19/ 41
Country of Origin: China
Pais d’origine: Chine
5

20 / 41
Country of Origin: China
Pais d’origine: Chine
4
6
d1=d2
Rt
∠
90
