Sunlighten Signature II User manual

E1x Floor
G1x Left Wall H1x Back Wall I1x Right Wall J1x Front Wall with Glass door
F1x Roof
2x
15x 24x 3
5 x
A1x B1x C
1x
4
D1x Bench
UK ASSEMBLY INSTRUCTIONS SIGNATURE II
11sunlighten.com/gb-en

1.1 Attach the feet pegs with supplied Allen
wrench and bolts to the underside of floor .
1.2 Cut the zip ties holding the floor grate. The
fabric will adhere to the Velcro on the
underside of the grate.
TIP: One side of the fabric adheres better
NOTE: Make sure the floor panel is on a surface
that is perfectly level and relatively smooth.
2 E
A
Unpack each wall segment from the shipping material. Stage each
wall segment in the room you will be assembling the unit.
STEP 1
Place the back wall on the back of the floor panel .
Be sure you have two people assisting with this step.
This is the side with the sauna information label
on the bottom edge.
STEP 2
PRE-STEPS
A
2
4
1.1
1.2
HE
230V,1650 watts.
3m cord exits from back left of roof.
See USER MANUAL or spec sheet for additional
specs.
E
E
E
H
12sunlighten.com/gb-en

I
STEP 3
As you insert each wall segment, you will insert the
U-clips in the pre-drilled holes in the corner.
This will keep the walls sealed together.
The front wall will be inserted next. Be careful
of the glass door and panel as you insert the wall.
Place right wall on the right side of floor panel .
This wall panel should sit flush once properly seated.
Make sure no gaps are visible in the corner of the two
walls as you insert it. It should be inserted flush.
NOTE: The right wall of the sauna includes wire
connections underneath which will lead into
the floor panel (see illustration 3.2 below).
STEP 4
J
I E
3.2
3
3
I
E
J
13
Connect floor
heaters
If you have not yet done so, the floor heaters
will need to be connected to the right wall wires.
The diagram to the left shows where the connection
is made. You will need to remove the floor grate and
a small hatch covering the harness.
sunlighten.com/gb-en

STEP 5
Once all the U-clips have been inserted in the
corners, the next step will be to place the roof
on top. Make sure the side the main power cord
receptacle faces the back.
After securing the U-clip , the left wall will
be the last to be inserted. Make sure it is flush and
no gaps are showing in the corners.
NOTE: If you ever have trouble getting a U-clip
to slide in, this can be resolved by tapping it with
a hammer.
STEP 6
3 G
3
3
3
F
G
F
14sunlighten.com/gb-en

C
B
1
4
STEP 7
Please make all connections on roof of sauna as
illustrated.
STEP 8
With the bench installed, the heater
panel frames can be inserted back into
their respectable walls.
The door handles come with the hard-
ware and can easily be screwed right in.
A second person should hold the handle
while the other screws the bolts in
with the Allen wrench. The dust
cover should also be replaced.
Before the bench is placed, make
sure the heater frames are taken out to
allow the bench to be placed on its
support.
Left Wall Heaters
Back Wall Heaters
Right Wall Heaters
Control Panel
Front Heater
D
D
heater frame
heater frame CONGRATULATIONS, your sauna is now ready to enjoy!
If you have any questions, please call
Sunlighten Customer Support at 0330.808.1203.
Speakers and Lights
04122022
15sunlighten.com/gb-en
