Sunny SF-E3889 SMART User manual

SMART ELLIPTICAL MACHINE
SF-E3889 SMART
USER MANUAL
IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your
satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE CONTACTED
US: [email protected] or 1-877-90SUNNY (877-907-8669).

1
IMPORTANT SAFETY INFORMATION
We thank you for choosing our product. To ensure your safety and health, please use this
equipment correctly. It is important to read this entire manual before assembling and using the
equipment. Safe and effective use can only be achieved if the equipment is assembled, maintained
and used properly. It is your responsibility to ensure that all users of the equipment are informed of
all warnings and precautions.
1. Before starting any exercise program, you should consult your physician to determine if you
have any medical or physical conditions that could put your health and safety at risk, or prevent
you from using the equipment properly. Your physician’s advice is essential if you are taking
medication that affects your heart rate, blood pressure or cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in your chest,
irregular heartbeat, shortness of breath, lightheadedness, dizziness or feelings of nausea. If you
do experience any of these conditions, you should consult your physician before continuing with
your exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for adult use only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor or carpet.
To ensure safety, the equipment should have at least 2 feet (60 CM) of free space all around it.
5. Ensure that all nuts and bolts are securely tightened before using the equipment. The safety of
the equipment can only be maintained if it is regularly examined for damage and/or wear and
tear.
6. Always use the equipment as indicated. If you find any defective components while assembling
or checking the equipment, or if you hear any unusual noises coming from the equipment during
exercise, discontinue use of the equipment immediately and do not use until the problem has
been rectified.
7. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may
become entangled in the equipment.
8. Do not place fingers or objects into the moving parts of the equipment.
9. The maximum weight capacity of this unit is 265 pounds (120 KG).
10.The equipment is not suitable for therapeutic use.
11.To avoid bodily injury and/or damage to the product or property, proper lifting and moving is
required.
12.Your product is intended for use in cool, dry conditions. You should avoid storage in extreme
cold, hot or damp areas as this may lead to corrosion and other related problems.
13.This equipment is designed for indoor and home use only. It is not intended for commercial use!

2
PRE-ASSEMBLY CHECK LIST
Before you start to assemble, please make sure all parts are included.

3
No.
Description
Spec.
Qty.
No.
Description
Spec.
Qty.
1
Main Frame
1
51L/R
Cover for Left Swing
Bar
1 PR.
2
Handlebar Post
1
52
Roller Cover
2
3
Rail Frame
1
54L/R
Pedal
1 PR.
4
Front Stabilizer
1
55
Nut Cap
S13
2
5L/R
Swing Bar
1 PR.
68
Meter
1
6
Fixed Handlebar
1
71
Adaptor
1
9L/R
Pedal Arm
1 PR.
78L/R
Cover for Right
Swing Bar
1 PR.
11L/R
Handlebar
1 PR.
A
Hardware Package
1
41
Bottle Holder
1
B
Manual
1
46
Long Axle
1
C
Thank You Card
1
50
Mast Cover
1
HARDWARE PACKAGE
Ordering Replacement Parts (U.S. and Canadian Customers only)
Please provide the following information in order for us to accurately identify the part(s) needed:
✓The model number (found on cover of manual)
✓The product name (found on cover of manual)
✓The part number found on the “EXPLODED DIAGRAM” and “PARTS LIST” (found near the end
of the manual)
Please contact us at [e-mail] or 1-877-90SUNNY (877-907-8669).

4
ASSEMBLY INSTRUCTION
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 1:
Remove the 2 Shipping Tubes (No. D),
8 Allen Bolts (No. 15), 8 Flat Washers
(No. 30)and 8 Spring Washers (No.
36) from the Main Frame (No. 1) by
Allen Wrench (No. 117).
Attach the Front Stabilizer (No. 4) and
Rail Frame (No. 3) onto the Main
Frame (No. 1) using 8 Allen Bolts (No.
15), 8 Flat Washers (No. 30), 8 Spring
Washers (No. 36) that were removed.
Tighten and secured with the Allen
Wrench (No. 117).
NOTE: You may discard 2 Shipping
Tubes (No. D) or save them to
repackage the item in the future.

5
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 2:
Remove 6 Allen Bolts (No. 15), 6
Spring Washers (No. 36)and 6 Arc
Washers (No. 35)from the Main Frame
(No. 1).
Slide the Mast Cover (No. 50)onto the
Handlebar Post (No. 2).
Connect the Sensor Extension Wire 2
(No. 70) with the Sensor Extension
Wire 1 (No. 69).
NOTE: To avoid damaging the wires,
please put them into the Handlebar Post
(No. 2) before attaching the Handlebar
Post (No. 2) onto the Main Frame (No.
1).
Insert the Handlebar Post (No. 2) onto
the post of the Main Frame (No. 1),
secure in place with 6 Allen Bolts (No.
15), 6 Spring Washers (No. 36)and 6
Arc Washers (No. 35) that were
removed. Tighten and secured with the
Allen Wrench (No. 117).
NOTE: Please make sure to attach the
Handlebar Post (No. 2) onto the post of
the Main Frame (No. 1) straightly.
Slide down the Mast Cover (No. 50)and
fit in place.
Remove 2 Allen Bolts (No. 15), 2
Spring Washers (No. 36)and 2 Arc
Washers (No. 35) from the Handlebar
Post (No. 2) by Allen Wrench (No. 117).
Attach the Fixed Handlebar (No. 6) to
the Handlebar Post (No. 2) in place.
Secure it with 2Allen Bolts (No. 15), 2
Spring Washers (No. 36)and 2 Arc
Washers (No. 35) that were removed by
Allen Wrench (No. 117).

6
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 3:
Remove 2 Hex Bolts (No. 17),2
Spring Washers (No. 36),2Flat
Washers (No. 32)and 2Wave
Washers (No. 73)from the Long Axle
(No. 46).
Insert the Long Axle (No. 46)into the
Handlebar Post (No. 2), then insert 2
Wave Washers (No. 73)that were
removed to the both sides of Long Axle
(No. 46).
Attach the 2 Swing Bars (No. 5L/R) to
the both sides of the Long Axle (No.
46)using 2Flat Washers (No. 32), 2
Spring Washers (No. 36)and 2 Hex
Bolts (No. 17)that were removed.
Tighten with Spanner (No. 116) and
Spanner (No. 118).
NOTE: Do not tighten the Hex Bolts
(No. 17) during this step.

7
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [e-mail] or 1-877-90SUNNY
(877-907-8669).
STEP 4:
Attach the 2 Pedal Arms (No. 9L/R) to
2 Roller Arms (No. 7) with 2 Pedal
Hinge Bolts (No. 21), then put on 2
Flat Washers (No. 34) and 2 Nylon
Nuts (No. 22)to the end of 2 Pedal
Hinge Bolts (No. 21)by Allen Wrench
(No. 119) and Spanner (No. 115).
NOTE: Do not tighten the Pedal Hinge
Bolts (No. 21) during this step.
Attach 2 Pedal Arms (No. 9L/R) to 2
Swing Bars (No. 5L/R) respectively
with 2 Allen Bolts (No. 13) and 2 Flat
Washers (No. 30), then put on 2 Flat
Washers (No. 30) and 2Nylon Nuts
(No. 24) by Allen Wrench (No. 117)
and Spanner (No. 118).
NOTE: Do not tighten the Allen Bolts
(No. 13) during this step.
Attach 2 Pedals (No. 54L/R) to the
Pedal Arms (No. 9L/R) using 8 Phillips
Screws (No. 18) by Spanner (No. 116).
NOTE: Both Pedals (No. 54L/R) are
labeled: L for LEFT and R for RIGHT.
Now you can tighten Hex Bolts (No.
17) from STEP 3 by Spanner (No. 116)
and Spanner (No. 118).
Cover with the 2 Nut Caps (No. 55).
And then tighten and secured 2 Pedal
Hinge Bolts (No. 21)and 2 Nylon Nuts
(No. 22)by Allen Wrench (No. 119)
and Spanner (No. 115).
NOTE:Ensure that all bolts and
washers are in place and now you can
tighten Allen Bolts (No. 13) by Allen
Wrench (No. 117) and Spanner (No.
118).

8
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 5:
Attach the 2 Handlebars (No. 11L/R) to
2 Swing Bars (No. 5L/R) respectively
with 4 Carriage Bolts (No. 12), 4 Arc
Washers (No. 35)and 4 Cap Nuts (No.
77) by Spanner (No. 116).
Remove 4 Phillips Tapping Screws
(No. 27)from 2 Cover for Left Swing
Bar (No. 51L/R) and 2 Cover for Right
Swing Bar (No. 78L/R) respectively by
Spanner (No. 116).
Remove 2 Phillips Tapping Screws
(No. 26)from 2 Swing Bars (No. 5L/R)
by Spanner (No. 116). Then attach 2
Cover for Left Swing Bar (No. 51L/R)
and 2 Cover for Right Swing Bar (No.
78L/R) to 2 Swing Bars (No. 5L/R)
respectively with 4 Phillips Tapping
Screws (No. 27)and 2 Phillips
Tapping Screws (No. 26) that were
removed. Tighten and secured with
Spanner (No. 116).
NOTE: Both Cover for Left Swing Bar
(No. 51L/R) and Cover for Right
Swing Bar (No. 78L/R) are labeled: L
for LEFT and R for RIGHT.
Remove 2 Phillips Tapping Screws
(No. 26)from 2 Roller Arms (No. 7) by
Spanner (No. 116). Then attach 2
Roller Covers (No. 52) to 2 Roller
Arms (No. 7) respectively with 2
Phillips Tapping Screws (No. 26) that
were removed. Tighten and secured
with Spanner (No. 116).

9
We value your experience using Sunny Health and Fitness products. For assistance with parts or
troubleshooting, please contact us at [email protected] or 1-877-90SUNNY
(877-907-8669).
STEP 6:
Remove 4 Phillips Screws (No. 74)
from the Meter (No. 68) by Spanner
(No. 116).
Plug the Pulse Wire (No. 72) to the
designed socket at back of the Meter
(No. 68). Then Connect the Sensor
Extension Wire 2 (No. 70)with Meter
Wire A (No. 68a).
Attach the Meter (No. 68) to the bracket
of Handlebar Post (No. 2) with 4
Phillips Screws (No. 74)that were
removed. Tighten and secured with
Spanner (No. 116).
NOTE: To avoid damaging the wires,
please put them into the Handlebar
Post (No. 2) before attaching the Meter
(No. 68) onto the bracket.
Remove 2 Phillips Screws (No. 25)
and 2 Flat Washers (No. 28) from the
Handlebar Post (No. 2) by Spanner
(No. 116). Then attach the Bottle
Holder (No. 41) to the Handlebar Post
(No. 2) with 2Phillips Screws (No. 25)
and 2 Flat Washers (No. 28) that were
removed. Tighten and secured with
Spanner (No. 116).
Insert the jack from Adaptor (No. 71) to
adaptor input on the front of Main
Frame (No. 1), then plug the Adaptor
(No. 71)into an outlet.
The assembly is complete!

10
ADJUSTMENT GUIDE
HOW TO MOVE THE ELLIPTICAL
There are transportation wheels located on the
Front End Caps (No. 56L/R). Hold the
Handlebar (No. E) of the Rail Frame (No. 3) and
pull forward to lift the rear of the elliptical off the
floor. Now you can move the elliptical.
ADJUSTING THE BALANCE
In order to achieve a smooth and comfortable
ride, you must ensure that the elliptical is stable
and secured. If you notice that the elliptical is
unbalanced during use, you should adjust the
Adjustable Pads (No. 49)located beneath the
Rear End Caps (No. 57L/R). To do so, simply
rotate the Adjustable Pads (No. 49) until the
elliptical becomes levelled with the floor surface.
CLEANING
The elliptical can be cleaned with a soft, clean, damp cloth. Do not use abrasives or solvents on
plastic parts. Please wipe your perspiration off the elliptical after each use. Be careful not to get
excessive moisture on the meter display panel as this might cause electrical hazard or electronics
to fail.
Please keep the elliptical, especially the meter, out of direct sunlight to prevent screen damage.
Please inspect all assembly bolts and pedals on the elliptical for proper tightness every week.
STORAGE
Store the elliptical in a clean and dry environment, away from children.

11
IMPORTANT ELLIPTICAL INFORMATION
WARNING:
This elliptical requires a power source of 1 amp (100-240V) in order to properly operate. For your
safety, as well as the safety of others, please verify that the power source is correct before
plugging in the equipment. Any power source above or below this level could cause significant
damage to the equipment and or user.
OPERATING INSTRUCTIONS
Plug the adaptor into the elliptical and into the outlet.
The meter will turn on.
The meter will turn off if there is no activity for 4 minutes. Press any
key on the meter to turn it on again.
NOTE: You can still use the elliptical when it is not plugged in.
However, the meter will not be working and you cannot adjust the
resistance level or use any of the functions.
EXERCISE METER
KEY FUNCTIONS:
BUTTON
FUNCTION
START/STOP
Start and pause workouts
Start body fat measurement
DOWN
Lower the resistance level during workout.
Decrease value of selected parameter
UP
Increase the resistance level during workout.
Increase value of selected parameter
ENTER
Input the value or mode
RECOVERY
Enter Recovery function when the meter displays the heart rate value.
Recovery displays F1-F6
F1 is excellent recovery heart rate
F6 is poor recovery heart rate
MODE
During workout, switch display from RPM to SPEED, ODO to DIST and
WATT to CALORIES
Hold for 3 seconds to reset all function values to zero, except ODO.
WORKOUT SELECTION:
After turning the meter on by plugging in the adaptor or if already plugged in, pressing any button
on the meter, use the UP or DOWN button to make a selection. Then press ENTER button to
choose the desired mode.
There are 7 basic workout modes:
Manual, Pre-set Programs, Watt Program, Body Fat Program, Target Heart Rate Program, Heart
Rate Control Programs, and User Programs.
FUNCTIONS:
SPEED: Displays current training speed. Maximum speed is 99.9 MPH.
RPM: Displays current rotation per minute.

12
TIME: Accumulates the workout time from 0:00 to 99:59. Users can preset the target time they
want.
DIST (DISTANCE): Accumulates the workout distance from 0.00 to 999.9 Miles. Users can preset
the target distance they want to reach.
ODO (ODOMETER): Displays the total accumulated distance from 0 to 9999 Miles.
CAL (CALORIES): Accumulates the calories burned from 0 to 9999. Users can preset the target
calories they want to burn.
WATT: Displays current watt.
HEART RATE: Displays the current heart rate in beats per minute.
TARGET HR. (TARGET HEART RATE): Users can preset their Target Heart Rate.
PROGRAM: There are 24 different programs to choose for training.
LEVEL: The program has 10 columns of bars and 8 bars in each column. Each column represents
a 1-minute workout and each bar represents 2 resistance levels.
WORKOUT PARAMETERS:
TIME / DISTANCE / CALORIES / AGE / WATT / TARGET HEART RATE
SETTING WORKOUT PARAMETERS
After selecting the desired workout mode: Manual Programs, Pre-set Programs, Watt Control
Program, Body Fat Program, Target Heart Rate Program, Heart Rate Control Programs, and User
Programs. You may pre-set several workout parameters for desired results.
NOTE: SOME PARAMETERS ARE NOT ADJUSTABLE IN CERTAIN PROGRAMS. TIME AND
DISTANCE CANNOT BE SET UP AT THE SAME TIME.
Once a program has been selected, press ENTER button and TIME will flash.
Using the UP or DOWN button, you may select the desired time value. Press ENTER button to
input the values. The flashing prompt will move to the next parameter. Continue using the UP or
DOWN button. Press the START/STOP button to begin the workout.
MORE ABOUT SETTING WORKOUT PARAMETERS
Field
Setting
Range
Default
Value
Increment/
Decrement
Description
TIME
0:00~99:00
0:00
±1:00
1..When display is set as 0:00,
TIME will count up.
2..When TIME is set as 1:00-99:00,
it will count down to 0.00.
DIST
(DISTANCE)
0.00~999.0
0.00
±1.00
1..When display is set as 0.00,
DISTANCE will count up.
2..When DISTANCE is set as
1.00~999.0, it will count down
to 0.00.

13
CAL
(CALORIES)
0.00~9995
0.00
±5 .00
1..When display is set as 0.00,
CALORIES will count up.
2. When CALORIES is set as
5.00~9995, it will count down to
0.00.
WATT
50~250
100
±5
User can set watt value only in
the Watt Control Program.
AGE
10~99
30
±1
Target HR will be based on Age.
When Heart Rate exceeds Target
HR, the Heart Rate number will
flash.
TARGET
HEART
RATE
60~220
90
±1
Setting Parameters for Target
Heart Rate.
PROGRAM OPERATION:
MANUAL PROGRAM (P1)
Program Profile
SETTING PARAMETERS FOR MANUAL PROGRAM
1. Select Manual Program (P1) using the UP or DOWN button, then press ENTER button.
2. TIME will flash so the value can be adjusted using the UP or DOWN button.
3. Press the ENTER button to save the value and move to the next parameter to be adjusted.
NOTE: If you set up the target time for workout, then the next parameter of DISTANCE
cannot be adjusted.
4. Continue through all desired parameters and press the START/STOP button to begin the
workout.
NOTE: Once the workout parameter counts down to zero, it will beep and stop the
workout automatically. Press the START button to continue the workout to reach the
unfinished workout parameter.
PRE-SET PROGRAMS (P2~P13)
Program Profile

14
There are 12 pre-set programs ready for use. All program profiles have 16 levels of
resistance.
SETTING PARAMETERS FOR PRE- SET PROGRAMS
1. Select one of the Pre-set Programs using the UP or DOWN button, then press ENTER button.
TIME will flash so the value can be adjusted using the UP or DOWN key.
2. Press the ENTER button to save value and move to the next parameter to be adjusted. Continue
through all desired parameters, pressing the START/STOP button to begin the workout.
WORKOUT IN ANY PRE-SET PROGRAM
You can adjust the level of resistance by pressing the UP or DOWN button during the workout.
NOTE: If you set up the target time for workout, then the next parameter of DISTANCE
cannot be adjusted. Once the workout parameter counts down to zero, it will beep and stop
the workout automatically. Press the START button to continue the unfinished parameter.
WATT CONTROL PROGRAM (P14)
Program Profile
SETTING PARAMETERS FOR THE WATT CONTROL PROGRAM
1. Select Watt Control Program (P14) using the UP or DOWN button, then press ENTER button.
2. TIME will flash so the value can be adjusted using the UP or DOWN button.

15
3. Press ENTER button to save the value and move to the next parameter to be adjusted.
NOTE: If you set up the target time for workout, then the next parameter of DISTANCE
cannot be adjusted.
4. Continue through all desired parameters, pressing the START/STOP button to start the workout.
NOTE: Once the workout parameters count down to zero, it will beep and stop the
workout automatically.
5. Press the START button to continue the workout to reach the unfinished workout parameter.
The meter will adjust the resistance load automatically depending on the speed to
maintain the constant watt value. You can use the UP or DOWN button to adjust the watt
value during the workout.
BODY FAT PROGRAM (P15)
Program Profile
SETTING DATA FOR BODY FAT
Select BODY FAT Program (P15) using the UP or DOWN button, then press ENTER button.
“MALE” will flash so Gender can be adjusted using the UP or DOWN button. Press the ENTER
button to save gender and move to the next data.
“5’8 (inches)” of Height will flash so Height can be adjusted using the UP or DOWN button. Press
ENTER button to save the value and move to the next data.
“154 (lbs)” of Weight will flash so Weight can be adjusted using the UP or DOWN button. Press
ENTER button to save the value and move to the next data.
“30” of Age will flash so Age can be adjusted using the UP or DOWN button. Press ENTER button
to save the value.
Press the START/STOP button to start the measurement. Please also remember to grasp the hand
pulse sensors. After 15 seconds the display will show Body Fat %, BMR, BMI, & BODY TYPE.
BODY TYPES:
There are 9 body types divided according to the FAT % calculated.
Body Type
FAT %
Body Type
FAT %
Body Type
FAT %
Type 1
5% - 9%
Type 4
20% - 24%
Type 7
35% - 39%
Type 2
10% - 14%
Type 5
25% - 29%
Type 8
40% - 44%
Type 3
15% - 19%
Type 6
30% - 34%
Type 9
45% - 50%
BMR: Basal Metabolism Ratio
BMI: Body Mass Index
Press START/STOP button to return the main display.

16
TARGET HEART RATE PROGRAM (P16)
Program Profile
SETTING PARAMETERS FOR TARGET HEART RATE PROGRAM
1. Select TARGET HR (P16) using the UP or DOWN button, then press ENTER button.
2. TIME will flash. The value can be adjusted using the UP or DOWN button.
3. Press the ENTER button to save the value and move to the next parameter to be adjusted.
NOTE: If you set up the target time to workout, then the next parameter of DISTANCE
cannot be adjusted.
4. Continue through all desired parameters, pressing START/STOP button to start workout.
NOTE: If heart rate is above the set TARGET HR, the Pulse value will flash to remind the
user.
HEART RATE CONTROL PROGRAM (P17-P20)
Program Profile
There are 4 selections for target pulse (HR):
HRC - 55% TARGET HR= 55% of (220-AGE)
HRC - 65% TARGET HR= 65% of (220-AGE)
HRC - 75% TARGET HR= 75% of (220-AGE)
HRC - 85% TARGET HR= 85% of (220-AGE)
SETTING PARAMETERS FOR HEART RATE CONTROL
1. Select one of the Heart Rate Control Programs using the UP or DOWN button, then press
ENTER button.
2. TIME will flash. The value can be adjusted using the UP or DOWN button.
3. Press the ENTER button to save the value and move to the next parameter to be adjusted.
NOTE: If you set up the target time to work out, then the next parameter of DISTANCE
cannot be adjusted.
4. Continue through all desired parameters, pressing the START/STOP button to start the workout.
NOTE: If heart rate is above or below (± 5) the TARGET HR, the meter will adjust the
resistance load automatically. It will check every 20 seconds approx. 1 resistance load
will increase or decrease (NOTE: each resistance load represents 2 levels of loading).
If one of the workout parameters counts down to zero, it will beep and stop the workout
automatically. Press the START/STOP button to continue the workout to reach unfinished
workout parameter.

17
USER PROGRAM
Program Profile (P21-P24)
The 4 user programs allow the user to set their own program that can be used immediately.
SETTING PARAMETERS FOR USER PROGRAM
1. Select the User Program using the UP or DOWN button then press ENTER button.
2. TIME will flash so the value can be adjusted using the UP or DOWN button.
3. Press the ENTER button to save the values and move to the next parameter to be adjusted.
NOTE: If you set up the target time to work out, then the next parameter of DISTANCE
cannot be adjusted.
4. Continue through all desired parameters.
5. After finishing the setup of the desired parameters, level 1 will flash. Use the UP or DOWN
button to adjust, then press the ENTER button until finished. (There are 10 times total). Press
the START/STOP button to begin the workout.
NOTE: Once the workout parameter counts down to zero, it will beep and stop the
workout automatically. Press the START/STOP button to continue the workout to reach
the unfinished workout parameter.
APP CONNECTION:
1. Scan the QR code below to enter the app store and download the SunnyFit app to your
mobile phone.
2. Ensure that the Bluetooth function is turned on from your phone.
3. If this is your first time using the SunnyFit app, follow the in-app instructions to register for
your free SunnyFit account and log in.
4. To connect the equipment to the SunnyFit app:
a. From the “Workout” tab, press on the “Search” button to search for your equipment.
b. Once your equipment appears on the list, tab on the “Select” button.
c. NOTE: If your equipment does not appear on the "Searching for Equipment" list, check the
EXERCISE METER on your equipment to ensure that it is not in sleep mode and your phone's
Bluetooth function is on, then tap "Retry" to search again.
d. Once your equipment shows up on the “Workout” tab as “Currently Selected”, your equipment
is now ready to display, track, and record your equipment’s workout stats on the app!

18
TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSE
CHECK
SOLUTION
E1-1
The motor couldn’t find
its start point.
Check if all the cables are
well plugged in or check if
the pins on the cables are
improperly inserted. Or
check if the motor is well
connected.
Plug in the cables again
and power on, then
press MODE and
ENTER buttons at the
same time to enter the
correction mode to
correct errors.
E1-2
The motor signal has
no induction.
Check if all the cables are
well plugged in or check if
the pins on the cables are
improperly inserted. Or
check if the motor is stuck.
Plug in the cables again
or change a new motor.
E1-3
The motor has
exceeded the
maximum resistance
level.
Check if all the cables are
well plugged in or check if
the pins on the cables are
improperly inserted.
Plug in the cables again
and power on, 1 second
later disconnect the
cables then re-plug in
the cables and power on
again, wait about 6
seconds let the motor
come back to its start
point, then press MODE
and ENTER buttons at
the same time to enter
the correction mode to
correct errors.
E2
No EEPROM data was
read.
Re-connect the meter.
The EEPROM data
reading error.
Power on the meter
again to re-read the
data.
E4
Hands aren’t put on the
two handle pulses
immediately after
pressing START
button.
Put the hands on the
two handle pulses
immediately after
pressing START button.
Body Fat Function
cannot receive the
signal for pulse.
Check if the handle pulse
wires are well connected.
Plug in the handle pulse
wires again or change
the handle pulse wires.
Check if the pulse is working
when not in Body Fat
Program.
Change the meter.
NOTE: If you are unable to resolve an issue using the troubleshooting guide above, please
contact Customer Service at [e-mail].

19
EXPLODED DIAGRAM 1
