Sunny SG-R Series User manual

AC
On/Test
Charge
Fail
IR
Off
Test
USER MANUAL
Self-Contained Emergency Light SG-R Series
Status Indicators and Testing Buttons
Indicates that the unit is receiving a power supply
Indicates that the unit is receiving a power /
Indicates that the unit is set to perform automatic self-tests /
Indicates if the unit is performing a self-test
Indicates that the unit’s battery is charging
or is a problem with the battery
Infrared signal receiver
LED AC
LED On/Test
LED Charge/Fail
IR
Switch Off/Test
1. The unit can be installed on recessing ceiling.
2. Install properly and securely to prevent accidents that could cause damage to the unit or
other people and property.
3. Connect the unit into a main power with a 220-240VAC power supply. The emergency lamp will
remain on for about 2 seconds before turning off, Notice the LED will show the status as follows.
3.1 The LED “AC” will turn on indicating that the unit is receiving power.
3.2 LED “On/Test” lit or flashing slowly indicates the status of the unit ready to use.
3.3 The LED “Charge/Fail“ will be on when the battery is charging.
3.4 The LED “Charge/Fail” will be off when the battery is fully charged.
4. When the unit is operational, tests can be performed.
4.1 Pressing the “Off/Test” switch the emergency lamp will remain on for about 5 seconds before
turning off.
4.2 Disconnect the unit from the 230VAC and the emergency light should turn on automatically
and connect the unit back in should cause the emergency lamp will remain on for about 5 seconds.
5. During power outages the emergency light should automatically turn on and will turn off
automatically and start charging the battery once power is restored.
Installation and Operation
Caution: Please always read the manual prior to installation and operation.
Press to turn off the lamp and the system of the unit
(while the power is off or the unit is not plugged in)
Press to test the device’s availability
(during normal circumstance and the unit is plugged in)
1

1. The emergency lighting unit should be installed indoors, out of direct sunlight and humidity.
It should not be installed in environment with temperatures higher than 50 degrees Celsius.
2. The unit should be stored in temperatures under 25 Degree Celsius and the battery should
be charged every 3 months to maintain its operational life.
3. Please always read the manual carefully prior to operating the unit for the saftest and most
effective use of the product.
Important Note on Using the Unit
Indication
Lights Display Meaning
- A continuous orange light
- The orange light turns off
- A continuous green light
- Slow blinking green
light every 2 seconds
- Fast blinking green
light every 1 seconds
- A continuous red light
- The red light turns off
- A red light blinks three
times every 15 seconds
- A red light blinks four
times every 15 seconds
- A red light blinks five
times every 15 seconds
- The unit is receiving a normal AC power supply.
- The unit is not receiving an AC power supply.
- When pressing “OFF” to turn off the automatic battery
test system (Auto Test) from the remote.
- When pressing “ON” to turn on the automatic battery
test system (Auto Test) from the remote.
- The unit is performing a battery test (Auto Test).
- The battery is charging.
- The battery is fully charged.
- “Battery Fail” When the emergency light unit supply
backs up the lighting for less than 120 minutes, or less
than the time tested with a remote control.
- “Charging fail” When the battery charging system does
not charge, the charger does not cut off, the charging
circuit cuts off, but the battery charge decreases too
quickly.
- “Lighting Fail” When the system encounters an
abnormality in the lighting system, such as loose lighting
cables, broken bulbs, etc.
On/ Test
Indicators
AC
Charge/Fail
2

Remote Testing
Button for testing the device's function for 5 seconds.
Button for testing the device's function for 30 minutes.
Button for testing the device's function for 60 minutes.
Button for turning on auto battery test system
Button for turning off auto battery test system
Button for canceling the test
Initial Trouble Shooting
Problem Cause What to do
- Power not getting to the unit
after plugging in. The LED AC
light does not turn on.
- Emergency light does not turn
on after the power went out.
- Emergency light only turns on
for a short time after the power
went out.
- The power socket might not have any
power.
- The junction of emergency lamp is
loose.
- The AC fuse is blown.
- Check the 220-240VAC power
supply.
- Check the junction.
- Contact customer service.
- The battery is not fully charged.
- The battery is past its operational
lifetime or has deteriorated
- Take the emergency light unit to
charge until the “LED Charge”
indicator turns off.
- Contact customer service to
replace the battery
- The lamp is faulty
- The circuit's wiring is loose.
- The DC fuse is blown
- Contact customer service.
- Contact customer service.
- Contact customer service.
Remote Testing
3

Step 1Step 2Step 3
Step 4Step 5
49
158
49
256
1010810
4
Drill holes in the ceiling
as shown in the picture.
Embed anchors bolt or fastening
devices and secure screws into
the ceiling.
Use a screwdriver to disassemble
the device as shown in the picture.
Secure the top cover onto
the ceiling.
Assemble the bottom cover
onto the top cover.
Installation Steps
*Units are in millimeters.

For any further questions about your product
please feel free to contact SUNNY’s customer
service department.
Tel. [phone]
E-mail: [email protected]
1. The Warranty will only be covered if the customer fills in the “warranty registration form” and
mail the return part back to the company within 7 days from the day of purchase. If this is not
carried out the warranty will be considered void.
2. The warranty only covers the unit’s internal parts. The conditions and durations for the warranty of
each part is as specified and the duration of the warranty is calculated from the date of purchase.
3. Please show your warranty card every time you contact our service center or the dealer you
purchased the product from.
4. Products that fall into the following category are considered not covered by the warranty.
The product was used in a way not specified in the manual.
The product was used with accessories not meeting the required specifications specified in
the manual.
The product seems to have been damaged from being dropped or from strong impact, for
example, the parts are loose, dented, scrapped or misshapen.
The product has been repaired or modified by personnel not authorized by our company.
The Warranty Void sticker is torn or removed.
The product is damaged from careless use or incorrect maintenance, for example, the battery
is swollen from overcharging, quick charging was used on the battery, the battery terminals
have been short-circuited, the unit was used until the battery was completely discharged and
not recharged immediately, the product was stored for long periods until the Battery Checker
warning activates and still it is not plugged-in to charge or taking the battery to normal
temperature conditions and not recharging it every 1 month.
The product was stored in an unsuitable environment, for example, a location with moisture
or water vapor.
The product was supplied with a faulty AC power supply such as electrical overvoltage,
electrical current surges, or lightning strikes entering the AC power line.
Damages from natural causes such as fire, being summered in fluids, humidity, chemicals or
force majeure.
Damages from insects or animals.
Note : Please read the manual carefully before installation and operation to understand how to
properly operate the unit.
