Sunny SGM Series User manual

Test
USER MANUAL
Self-Contained Emergency Light SGM Series
Status Indicators and Testing Buttons
Indicates that the unit is receiving a power supply
Indicates that the unit is receiving a power /
Indicates if the unit is performing a self-test
Indicates that the unit’s battery is charging
or is a problem with the battery
Light datector sensor
LED AC
LED On/Test
LED Charge/Fail
LDR
Switch O/Test
1. The unit can be installed on leveled ground or hung up.
2. Install properly and securely to prevent accidents that could cause damage to the unit or
other people and property.
3. Plug the unit into a power socket with a 230VAC power supply. The emergency lamp will remain
on for about 2 seconds before turning o, Notice the LED will show the status as follows.
3.1 The LED “AC” will turn on indicating that the unit is receiving power.
3.2 LED “On/Test” lit or flashing slowly indicates the status of the unit ready to use.
3.3 The LED “Charge/Fail“ will be on when the battery is charging.
3.4 The LED “Charge/Fail” will be o when the battery is fully charged.
4. When the unit is operational, tests can be performed.
4.1 Pressing the “O/Test” switch the emergency lamp will remain on for about 5 seconds before
turning o.
4.2 Unplug the unit from the 230VAC socket and the emergency light should turn on automatically
and plugging the unit back in should cause the emergency lamp will remain on for about 5 seconds.
5. During normal power conditions, if the surrounding area is dimmer than 5 Lux and the unit
detects a person walking by, it will automatically provide illumination using mains power.
Installation and Operation
Press to turn o the lamp and the system of the unit
(while the power is o or the unit is not plugged in)
Press to test the device’s availability
(during normal circumstance and the unit is plugged in)
Test
Model: SGM209CD3

1. The emergency lighting unit should be installed indoors, out of direct sunlight and humidity.
It should not be installed in environment with temperatures higher than 40 degrees Celsius.
2. The unit should be stored in temperatures under 25 Degree Celsius and the battery should
be charged every 3 months to maintain its operational life.
3. Please always read the manual carefully prior to operating the unit for the saftest and most
eective use of the product.
Important Note on Using the Unit
Caution: Please always read the manual prior to installation and operation.
Indication
Lights Display Meaning
- A continuous orange light
- The orange light turns o
- A continuous green light
- Fast blinking green
light every 1 seconds
- A continuous red light
- The red light turns o
- A red light blinks four
times every 15 seconds
- The unit is receiving a normal AC power supply.
- The unit is not receiving an AC power supply.
- The unit is turned on and operational.
- The unit is performing a battery test (Manual Test).
- The battery is charging.
- The battery is fully charged.
- “Charging fail” When the battery charging system does
not charge, the charge does not reach full capacity,
or the charging does not cut o.
On/ Test
Indicators
AC
Charge/Fail
6. During power outages the emergency light should automatically turn on and will turn o
automatically and start charging the battery once power is restored.

Initial Trouble Shooting
Problem Cause What to do
- Power not getting to the unit
after plugging in. The LED AC
light does not turn on.
- Emergency light does not turn
on after the power went out.
- Emergency light only turns on
for a short time after the power
went out.
- The power socket might not have any
power.
- The plug or socket is loose.
- The AC.230V fuse is blown.
- Check the 230VAC power supply.
- Check the plug and socket.
- Contact customer service.
- The battery is not fully charged.
- The battery is past its operational
lifetime or has deteriorated
- Take the emergency light unit to
charge until the “LED Charge/Fail”
indicator turns o.
- Contact customer service to
replace the battery
- The lamp is faulty
- The circuit's wiring is loose.
- The DC fuse is blown
- Contact customer service.
- Contact customer service.
- Contact customer service.
Dimension (mm)
FRONT VIEW BACK VIEW
138
SIDE VIEW
215
70
215
210
Test

For any further questions about your product
please feel free to contact SUNNY’s customer
service department.
Tel. [phone]
E-mail: [email protected]
1. The product will only be under warranty if the customer fills in the “warranty card”
and return the “return part” to the company within 7 days of purchasing the product.
If this is not done within the specified time then the warranty will be considered void.
2. The warranty only covers the unit’s internal parts for the duration specified by the
company counting from the date of purchase.
3. Please show the warranty card every time when contacting our service department
or the dealer you purchased the unit from.
4. The warranty will be considered void in the following cases.
The unit has been used outside of its intended use specified in the manual.
The unit has been used with equipment that does not meet the specifications
specified within the manual.
The unit has been damaged from impact, for example parts are dented, scratched
missing or distorted.
The unit has been modified or repaired by people not ocially certified by our
company.
The Sticker Warranty Void has been removed or torn.
The unit is damaged from negligence or incompetent use, for example, the
battery is swollen, the batter has been overcharged, the battery has been
damaged from quick charging, the battery has been short-circuited, the battery’s
charged has been completely drained.
The unit has been stored improperly, for example, it was exposed to moisture
causing rust and damage to the internal circuitry.
Damaged was caused by a malfunction in the AC power supply.
Damage from natural disaster such as fire, moisture, submersion in liquids,
chemical damage or from unavoidable circumstances.
Damage from animals or insects.
Note : Please read the manual carefully before installation and operation to understand
how to properly operate the unit.
Terms for Warranty and Service
IsOn Import-Export Co., Ltd.
2915-2917 Ladprao Road, Klongjan,
Bangkapi, Bangkok 10240
