Sunricher SR-1007 Series User manual

RF RGB Programmable Led Controller
Programmable
Control 4 zones
Model:SR-2810W with SR-1007 Series
Parameter
Wiring diagram
Product Size
Brief introduction of buttons
RF Remote control
Part No. Iuput Voltage Remarks
Current Output
SR-1007FA 12-36VDC Constant voltage
4x(60-180)W4x5A
Remote
Part No. Operation Voltage DIMENSIONS
ø/h (mm)
Operation
Frequency
SR-2810W 4.5VDC 55x120x17
434MHz/868MHz
Receiver
SR-1007FA3 12-36VDC Constant current
4x(4.2-12.6)W
4x350mA
Remarks
load 3pcs 7 AAA (1.5V)
batteries
Note:
One receiver can work with 1-8pcs SR-2810W
One SR-2810W control multiple receivers
The power supply chosen must be 20% higher than the actual load
Indicator: indicate the state of
remote control
ON/OFF button
1)Receiver Connection Diagram for Single Unit
2) Connection Diagram for Multiple UnitsReceiver
Power Supply
12-36VDC
LN
110V-230VAC
Power Supply
12-36VDC
LN
110V-230VAC
Color wheel, including white mixed by RGB
55.0
17.0
120.0
SR-1007FA7 12-36VDC Constant current
4x(8.4-25.2)W4x700mA
Programmable button
1-4 zones
Short press: choose zone
Long press: switch on/off
Step running mode
Brightness down
Brightness up
Speed down
B B+
Speed up
SR-1007FA
SR-1007FA
SR-1007FA
SR-1007FA
RGB & Mixed White color
3 Running modes
S-
M2
S+
M1 M3
Fade running mode Mix running mode

Operation
1.Learning receivers ID to remote
a. Press learning button on the receiver (the indicator will be on)
b. Choose a zone number on the remote
c. Touch the color wheel
Note:
The remote must be on before learning ID
Enable to assign multiple receivers to the same zone number, those receivers will be controlled
synchronously.
Long press the learning button over 5 seconds until the indicator off, the learned ID will be deleted.
2.How to program ?
a.Press “P”
b.Touch color wheel to choose a period of color or several colors you want
c.Choose the zone number on remote
d.Touch M1 or M2or M3 to choose the mode you want the colors to play
Note:
The remote must be on, when program
Default setting of mode speed is slowest, you can touch "S+" to speed up
Enable only to program 4 zones separately, can’t program 4 zones together at one time.
Safety & Warnings
Warranty Agreement
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
7) For update information please consult your supplier.
Please ensure that the cable is secured tightly in the connector
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
2) Limited Warrenty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
