SuperATV RTA-CA-COM-4 User manual

C
D
E
© 2014 SuperATV.com. All Rights Reserved. Rev IN-RTA-CA-COM-4 2/9/2016
INSTALLATION INSTRUCTIONS
Item Description Qty
ATrailing Arm, Passenger 1
BTrailing Arm, Driver 2
C CV Guard Brackets 2
D Brake Line Clips 2
E CV Guard Clips 2
A
B
(kit contents continue on following page)
Thank You
For Choosing
2753 Michigan Road • Madison, Indiana 47250 • 855-743-3427 Trailing Arms: for Can-Am Commander
Read instructions and view illustrations before beginning.
Need help with your installation?
www.superatv.com
8:00am - 9:00pm EST M-Th
8:00am - 7:00pm EST Friday
9:00am - 2:00pm EST Saturday
[e-mail]
1-855-743-3427

IN-RTA-CA-COM 2
(kit contents continued)
M5-.80 x 25mm Lg. PHMSQty (4)
M5-.80 x 16mm Lg. PHMSQty (10)
M5-.80 Nylock NutQty (2)
M5 Wide Flat WasherQty (4)
M10-1.50 x 40mm Lg. FHCSQty (8)
Liability Statement
SuperATV’s®products are designed to best fit user’s ATV/UTV under stock conditions. Adding, modifying, or fabricating any factory or aftermarket parts will void any warranty
provided by SuperATV®and is not recommended. SuperATV’s® products could interfere with other aftermarket accessories. If user has aftermarket products on machine, contact
SuperATV®to verify that they will work together.
Although SuperATV®has thousands of satisfied customers, user should be aware that installing lift kits, long travel, or suspension kits, tires, etc. will change the ride of machine
and may increase maintenance and part wear. Operating any off-road machine while, or after, consuming alcohol and/or drugs increases risk of bodily harm or death. No
warranty or representation is made as to this product’s ability to protect user from severe injury or death. SuperATV®urges operators and occupants to wear a helmet and
appropriate riding gear at all times.
By purchasing and installing SuperATV®products, user agrees that should damages occur, SuperATV®will not be held responsible for loss of time, use, labor fees, replacement
parts, or freight charges. SuperATV®, nor any 3rd party, will not be held responsible for any direct, indirect, incidental, special, or consequential damages that result from any
product purchased from SuperATV®. The total liability of seller to user for all damages, losses, and causes of action, if any, shall not exceed the total purchase price paid for the
product that gave rise to the claim.
SuperATV®will warranty only parts provided by SuperATV®. Any damage or problems with OEM housings, bearings, seals, or other manufacturers’ products will not be covered
by SuperATV®. SuperATV®parts and products are not warrantied if item was not installed properly, misused, or modified.
Installing, adding, modifying, or fabricating any factory or aftermarket product to your ATV/UTV may violate certain local, state, and federal laws. Be advised that laws vary
depending on town, city, county, state, etc. Use of certain products on public streets, roads, or highways may be in violation law. The Buyer is solely and exclusively legally and
personally responsible for any violation of the law by the installation or use of the product. You must abide by all local, state, and federal laws, including but not limited to vehicle
safety, traffic laws, and ordinances. It is your responsibility to know the laws and how they apply to you.
The Buyer is responsible to fully understand the capability and limitations of his/her vehicle according to manufacturer specifications, warnings and instructions and agrees to
hold SuperATV®harmless from any damage resulting from failure to adhere to such specifications, warnings and/ or instructions. The Buyer is also responsible to obey all
applicable federal, state, and local laws and ordinances when operating his/her vehicle while using this product, and the Buyer agrees to hold SuperATV®harmless from any
violation thereof.

IN-RTA-CA-COM 3
(Driver Side)
(Hub)
(Trailing Arm)
(Driver Side)
Unbolt Sway Bar from Trailing Arms
and remove from machine.
Remove:
- Shocks from Trailing Arms
- Caliper and Rotor (right side)
- Hubs
- Axles
- Trailing Arms from Frame
Removal: Keep all components removed from machine.

IN-RTA-CA-COM 4
(driver side)
Hub
new Axle
B
stock hardware
(driver side)
B
SuperATV recommends setting Adjustments
Bearings to position shown as starting point
Adjustment Bearing
Installation: Do not tighten hardware completely unless noted.
- Install new Axle.
- Set Adjustment Bearing position and install Trailing Arm (A) or (B) to Frame with stock hardware.

IN-RTA-CA-COM 5
(driver side)
Sway Bar
B
(passenger side)
stock
A
(passenger side)
D
M10 x 40mm
4x
Installation continued:
- Reinstall Sway Bar to Trailing Arm with hardware shown.
- Reinstall Shock to Trailing Arm with stock hardware.
- Repeat steps for opposite side.
- Reinstall Rotors, Calipers, and Hubs.
- SEE FOLLOWING PAGE: Reroute Passenger Side Brake Line. Install Brakeline Clips (D)
to Brake Line and secure to Trailing Arm (A) with hardware shown.
M5 x 16mm
2x

IN-RTA-CA-COM 6
- Remove Bracket from Stud.
- Pass Caliper through location
shown. Brake Line may need
removal. Caliper will now be
under Frame.
- Route to Spindle and secure
Caliper.
- Secure Brake Lines and ensure
that no binding or interference
can occur.
(passenger side)
Remove Bracket
from Stud
Brake Line
Frame
Frame
Pass Brake Caliper
under Frame.
Trailing Arm
Brake Caliper through here.
Brake Line may need to be removed.
+
D
M5 x 16mm

IN-RTA-CA-COM 7
(passenger side)
CV Guard
B
C
E
2x
M5 x 25mm
(driver side)
CV Guard here
CV Guard here
M5 Washer
M5 Washer
M5 Nut
M5 x 16mm
Installation continued:
- Install CV Guard Clips (E) to Trailing Arms (A)(B) with hardware shown.
- Install CV Guard Brackets (C) to Trailing Arms (A)(B) with hardware shown.
- Install stock CV Guards as shown.
- Set camber. See last page. M5 x 16mm
2x

IN-RTA-CA-COM 8
Rear Camber Adjustment:
Bearing in this position provides
positive camber (tire out at top)
Bearing in this position provides
negative camber (tire in at top)
Trailing Arm, Passenger (A) shown off machine for clarity
(passenger side)
A
loosen Trailing Arm hardware
use provided wrench to
make adjustments
