SuperATV WBM-P-RAN User manual

© 2015 SuperATV.com®. All Rights Reserved. IN-WBM-P-RAN 12/3/2015
INSTALLATION INSTRUCTIONS
Read instructions and view illustrations before beginning.
Need help with your installation?
1-812-574-7777
[e-mail] www.superatv.com
8:00am - 9:00pm EST M-Th
8:00am - 7:00pm EST Friday
9:00am - 2:00pm EST Saturday
Wakeboard Speaker Mount:
for Polaris Ranger® (Full and Mid size)
Liability Statement
SuperATV’s® products are designed to best t user’s ATV/UTV under stock
conditions. Adding, modifying, or fabricating any factory or aftermarket parts will
void any warranty provided by SuperATV®and is not recommended. SuperATV’s®
products could interfere with other aftermarket accessories. If user has aftermarket
products on machine, contact SuperATV® to verify that they will work together.
Although SuperATV® has thousands of satised customers, user should be aware
that installing lift kits, long travel, or suspension kits, tires, etc. will change the ride
of machine and may increase maintenance and part wear. Operating any off-road
machine while, or after, consuming alcohol and/or drugs increases risk of bodily
harm or death. No warranty or representation is made as to this product’s ability to
protect user from severe injury or death. SuperATV®urges operators and occupants
to wear a helmet and appropriate riding gear at all times.
By purchasing and installing SuperATV®products, user agrees that should damages
occur, SuperATV®will not be held responsible for loss of time, use, labor fees,
replacement parts, or freight charges. SuperATV®, nor any 3rd party, will not be held
responsible for any direct, indirect, incidental, special, or consequential damages
that result from any product purchased from SuperATV®. The total liability of seller to
user for all damages, losses, and causes of action, if any, shall not exceed the total
purchase price paid for the product that gave rise to the claim.
SuperATV®will warranty only parts provided by SuperATV®. Any damage or
problems with OEM housings, bearings, seals, or other manufacturers’ products will
not be covered by SuperATV®. SuperATV®parts and products are not warrantied if
item was not installed properly, misused, or modied.
8x M8-1.25 x 16mm Lg. FHCS
M8-1.25 Nylock Nut
8x M8 Flat Washer
8x
Extension
Tube, R
Bracket, R
Bracket, L
Tube, L
Wedge Clamp Assembly:
- Set Screw
- Clamp Top
- Clamp Bottom
(Ranger® XP 900 will not require Brackets)
Thank You
For Choosing
2753 Michigan Road • Madison, Indiana 47250 • 812-574-7777

2IN-WBM-P-RAN
- Install Bracket, L to Cab Frame with hardware shown.
- Repeat for opposite side.
(Driver Side) Cab Frame
(Driver Side)
Bracket, L
Bracket, L
(2) each
M8 Flat Washer
M8 Nylock Nut
M8 x 16mm
front
(Ranger® XP 900 will not require Brackets)

3IN-WBM-P-RAN
See following page for model specic congurations
front
(2) each
M8 Flat Washer
M8 Nylock Nut M8 x 16mm
Bracket, L Tube, L
(Driver Side)
- Install Tube, L to Bracket, L with hardware shown.
Tube, L
Ranger®XP 900: Install directly to Cab Frame with hardware shown.
M8 x 16mm
2x
(Driver Side)

4IN-WBM-P-RAN
Wedge Clamp halves
Set Screw
Wedge Clamp Installation:
- Install into Tube or Extension.
- Tighten provided Set Screw.
- Install Tube, R to Bracket, R with provided M8 hardware.
- Align assembly to machine and tighten all hardware completely.
Installed on Ranger®XP 900
( SuperATV p/n MTX-TS speakers not included)
Mid-Size Conguration
Tube, L
Tube, R
Wedge Clamp
front
Full-Size Conguration
Tube, L
Tube, R
Wedge Clamps
Extension (Passenger Side)
