SuperATV RF-P-GEN4-001 User manual

© 2017 SuperATV.com®. All Rights Reserved. Rev IN-RF-P-GEN4-001 7/10/2018
INSTALLATION INSTRUCTIONS
Roof: for Polaris General™ 4
(Kit Contents continue on following page)
Front
Cleaning:
- Donotusewindowcleaninguids(Windex,409,etc)oranysolvents(gasoline,denaturedalcohol,acetone,etc).
- Neveruseabrasivecleaners,abrasivepads,orgrittycloths.
- Neveruserazorblades,scrapers,sqeegees,brushes,etc.
1.ThouroughlyrinseRooftooato󰀨dirtandmud.
2.Usingasoftcloth,ormicrobercloth,cleanRoofwithwarmwaterandagentledetergent.Babyshampooorhandwashing
soap are recommended.
3.Topreventwaterspots,useachamoistoblotRoofdry.
Rear
Bracket
Small Clamp x 10
Large Clamp x 4
2753 Michigan Road • Madison, Indiana 47250 • 855-743-3427
Thank You
For Choosing
Read instructions and view illustrations before beginning.
Need help with your installation?
www.superatv.com
8:00am - 9:00pm EST M-Th
8:00am - 7:00pm EST Friday
9:00am - 2:00pm EST Saturday
[e-mail]
1-855-743-3427

2IN-RF-P-GEN4-001
M6-1.0 Nylock Nut24x
(Kit Contents continued)
M6-1.0 x 25mm Lg. BHCS
24x
M6 Sealing Washer24x
Use hand tools only when assembling.
Do not use power tools.
When installing components, do not tighten
any hardware completely unless noted.
remove hardware from Visor Panel
Seal
Gasket
Flat Seal
Rubber must face Roof when
installing Sealing Washer

3IN-RF-P-GEN4-001
Soak in hot water before cutting or installing to increase exibility.
- InstallSealstoRoofhalfsasshown.
Front
Rear
Seal
Seal
Seal
Seal
Bulb portion of Seal to always
face towards vehicle
Seal
Seal
- InstallonecontinuouspieceofSealaroundRoofasshown.

4IN-RF-P-GEN4-001
(driver side)
- Install Small Clamps to Front with hardware shown.
- InstallBrackettoFrontwithhardwareshown.
Front
Bracket
Small Clamp x 3
(per side)
Gasket - InstallGaskettoinsideofVisorPanelasshown.
Use hardware shown
when installing.
M6x 25mm
M6 Nut
Sealing Washer
Flat Seal

5IN-RF-P-GEN4-001
- Place Front on machine and secure Small Clamps around Frame as shown.
- Do not tighten.
(driver side)
Front
