Sven Driver User manual

www.sven.fi
OPERATION
MANUAL
DRIVER
Game Racing Wheel

CONTENTS
1. DESCRIPTION ..................................................................................
2. SAFETY PRECAUTIONS ......................................................................
3. PACKAGE CONTENTS .......................................................................
4. SPECIAL FEATURES ...........................................................................
5. SYSTEM REQUIREMENTS ....................................................................
6. DESCRIPTION OF THE СONSTRUCTION ....................................................
7. CONNECTION AND INSTALLATION ........................................................
8. TROUBLESHOOTING .......................................................................
Congratulations on the purchase of Sven product!
Please read this Operation Manual before using the unit and retain this Operation Manual in safe
place for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The
information of this Manual is given on “as is” terms. The author and the publisher do not bear any
liability to a person or an organization for loss or damages which have arisen from the information,
contained in the given Manual.
UNPACKING
Unpack the device carefully. Make sure there are no accessories left in the box. Check up the
device for damages; if the product was damaged during transportation, address the firm which
carried out the delivery; if the product functions incorrectly, address the dealer at once.
1
2
2
2
2
3
5
8
Technical support is on www.sven.fi
ENG
1
Operation Manual driver

1. DESCRIPTION
DRIVER Game Racing Wheel is specially designed for PC. Ergonomic design with rubber coating
ensures optimal comfort with solid grip. Trendy and streamline wheel design guarantees real
gaming experience. 270 degree wheel rotation, adjustable sensitivity, vibration feedback function
and a built-in wind conditioner create a surreal racing experience that will satisfy any driving fan.
2. SAFETY PRECAUTIONS
• Do not disassemble or repair the device on your own. Maintenance and repairs should be carried out
by qualified staffof the service centre only.
• Protect the device from direct impact of high humidity, dust, strong magnetic fields, vibrations, high
temperatures, toxic liquids and gases.
• Instructions for device maintenance: for cleaning the case of the device please use clean soft
cloth. Do not use such solvents as gasoline or spirit for cleaning, since these solvents can damage
the surface of the device.
• Do not drop the device not to have it damaged.
3. PACKAGE CONTENTS
• Game Racing Wheel — 1 pc
• Pedal unit — 1 pc
• Fixation stand — 2 pcs
• Software CD disk —1 pc
• Operation manual — 1 pc
• Warranty card — 1 pc
4. SPECIAL FEATURES
•Compatibility with PC/PS2/PS3
•Ergonomic design of game racing wheel
•Wheel diameter – 10" (254 mm)
•Steering angle – 270 degrees
•Supports: DirectX 7.0 or higher, Windows XP/Vista/7/8
•USB Interface
•Built-in vibration feedback and cooling fan for more realistic effect
•Indication of accelerating and braking force
•Sensitivity control
•Two axes, D-Pad, Tiptronic lever for changing gears, 12 additional buttons
•Rubber coating of the wheel for comfortable driving
•6 rubber suction caps and 2 fixation stands for secure fixation to the table
• Digital and Analog Modes available
•Foot pedal unit included
•Comfortable location on the lap
5. SYSTEM REQUIREMENTS
•USB port available
•Operational System Windows XP/Vista/7/8
ENG
2
Game Racing Wheel

j
g
Red Orange OrangeGreen Green Red
m
o
p
q
n
l
Fig. 3. Key panel
7
5
1
1
1
2
6
8
MODE
9
10
Sensitivity
LO MID HI
Fig. 1. Front view
6. DESCRIPTION OF THE CONSTRUCTION
aRacing wheel
bRubber coating
cKeys 1, 4
dPaddle shifters
eVentilation grids
fKey panel
gBraking indication
hKeys 2, 3
iLever for changing gears
jAccelerating indication
kRubber suction
caps
lKeys 7–12
mD-Pad
nKeys 9–10
oMODE button
pON/OFF MODE
indication
qSensitivity control
rFoot pedal port
sHeadlights
tUSB Cable
uBrake pedal
vAcceleration pedal
wFoldable stand for feet
k
j
d
h
e
i
b
c
d
e
a
g
f
Fig. 2. Lever for changing gears
–
+
R
ENG
3
Operation Manual driver

Fig. 5. Foot pedal unit
v
u
w
Fig. 6. Fixation stands
Fig. 4. Back view
a
dd
i
r
k
t
s
k
f
ENG
4
Game Racing Wheel

7. CONNECTION AND INSTALLATION
•Install the device on an even surface (for
example, on a table) on its suction caps. If
necessary fasten it with the two fixation stands
(Fig. 6).
•Connect the pedal unit to the device (Fig. 5)
via the pedal unit cable to RJ-11 jack r, then
connect USB cable tof the device to the
available USB port of the computer.
•Insert the Software CD disk into the disk
drive of your PC and launch setup.exe to
install drivers on your PC. Go to the game
controller settings in the control panel and
Game Controllers window should appear on
the your PC (Fig. 7).
Wheel Test
•Axes Test. Pass to the “Test Page” bookmark
(see Fig. 8), rotate the wheel from left to right
and make sure that the X-axis (“+” cross-
cursor) in the “Axes Information” window
moves from left to right correctly. If the cross
cursor is not at the center of the window,
please enter “Calibration Page” to calibrate it.
•Button Test. Press the wheel buttons to see
if button 1 to 12 in the “Test Page” turns red for
each button action (see Fig. 8).
•D-PAD Test. Press each direction of the D-
PAD (UP, DOWN, RIGHT, LEFT and 45 degree
for each direction) to see if the cursor in
«Povinfo» is moving correctly (see Fig. 8).
•Wheel calibration. This option is only used
for calibrating wheel centering fault under
analog mode (the indicator LED turns red):
when the cross cursor is not centered in the
X/Y Axis as seen in the interface, please press
“Default” and then press “Set” (Fig. 9).
•Motors test. Enter “Effect Page” (see Fig. 10)
to test motors. Rotate the wheel and check if
the left motor vibrates. Press the left wing and
right wing dand check if the right motor vibrates. Vibration feedback force can be changed by
moving the cursor to the right or the left along the “RumbleIntensity” line (fig.10).
•Driver Uninstall (reinstall). Restart the driver installer. Click “No” to remove the driver. Click “Yes” to
reinstall the driver (see Fig. 11).
Fig. 7
Fig. 8
ENG
5
Operation Manual driver

•At the end in the appeared window “LS- USBMX1/2/3 steering…” (see Fig. 12) click “Finish” to
confirm and quit.
Button Programming (no memory)
•Program buttons 1, 2, 3, 4, 5, 6, 7 and 8, which by default assigned functions to gear stick i, left
wing and right wing d, gas pedal v, brake pedal u, buttons 11 and 12. Which, you define by
testing. If for some reason they need to be reprogrammed, to set other functions, do the following
guidelines:
Fig. 9 Fig. 10
Fig. 12Fig. 11
ENG
6
Game Racing Wheel

•Program Setup (no programming function under NEGCON Mode). Enter “Test Page” (see Fig. 8),
press button 9 and button 10 nat the same time. Hold for 3 seconds until program LED turns green.
Press the programmable button. Program LED starts blinking. Press program source button. Program
LED turns off. Program is set.
•Clear Single Program. Press button 9 and button 10 at the same time. Hold for 3 seconds and
program LED turns green. Press programmable button. Program LED starts blinking. Press program-
mable button again. Program LED turns off. Single program is cleared.
•Clear All Programs. Press button 9 and button 10 at the same time. Hold for 3 second until
program LED turns green. Release the buttons. Press button 10 and hold for 4 seconds. Program
LED turns off. All programmed buttons are cleared. Default is restored.
Wheel Sensitivity Adjustment (3 levels):
•Wheel sensitivity can be adjusted by a toggle switch Sensitivity q. There are 3 optional sen-
sitivities: “LO”, “MID”, “HI”.
•By using switch Sensitivity qcan be set three levels of sensitivity steering in position “LO” for the
full twist “wheels” to turn the steering wheel to lock, i.e., all 135 degrees. In the position “MID”
enough to turn the rudder to 2/3 speed, and in position “HI” maximum position is reached at the
third steering.
Mode Button Function:
•The game racing wheel has two operation modes: digital and analog.
In the digital mode the static maximum activation/deactivation of corresponding axes take place
during depressing the pedal, i.e. there is only “ON/OFF” position there. In the analog mode a signal is
transmitted depending on the pressure force of pedals, i.e. smoothly. The mode of buttons will not
2. Push the left direction button on the digital
block.
2. Press the DOWN button on the digital block.
For switching to the digital mode:
1. Press Select + Start (9+10) buttons and hold
them down within 3 seconds, the Mode
indicator will light green. Then release keys 9
and 10.
For switching to the analog mode:
1. Press Select + Start (9+10) buttons and hold
them down within 3 seconds, the Mode
indicator will light green. Then release keys 9
and 10.
ENG
7
Operation Manual driver

8. TROUBLESHOOTING
Problem
After installation of the software,
game controller does not work
normally.
Motors have no vibration
function in a racing game.
After entering game, some
analog axis will automatically
operate.
After entering the game,
vibration feedback operates
automatically.
During the game vibration
feedback is insufficient.
Solution
А. Check whether the controller’s link cable is strongly
connected to PC.
B. Make sure that status indication for Game Controller after
installation is Confirm.
C. Check whether controller’s settings have no conflicts with
other peripherals’ settings.
D. Restart your PC, if the controller still doesn’t work normally.
After exiting the game, disconnect the controller from the USB
port and connect it again. If it still can’t work normally, please
restart the computer.
The steering wheel hasn’t been calibrated or hasn’t been
confirmed after calibrations. Enter Option – Controllers – Dead
Zone to adjust the range of the dead zone, and make sure the
axes are in the range of the dead zone.
Enter Force Feedback and calibrate it.
Enter Force Feedback and set force of feedback.
If none of the above mentioned solutions removes the problem, please refer to nearest authorized
service center for consultation by qualified specialist. Never try to repair the device on your own.
Dead Zone Effect ZoneEffect Zone
Axes
Axes
function, when a certain mode has been already set on the console. LED indication of a mode tes-
tifies about any current active mode. The digital mode is enabled by default.
Operation without pedal unit:
•Game racing wheel is equipped with paddle shifters d, that substitute acceleration and brake pe-
dals: the left paddle shifter functions as a brake pedal, while the right paddle shifter functions as an
acceleration pedal.
Note. Game racing wheel is equipped with braking indication gand accelerating indication j
see. Fig. 1. With a smooth pressing the acceleration pedal indicator lights up green, picking
up speed indicator will light orange, then red. Depending on the smoothness of dropping
speed indicator lights green, orange and red colors.
ENG
8
Game Racing Wheel

Модель: DRIVER
Импортер вРоссии: ООО «СКАНДИТРЕЛ»,
111024, РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация вРоссии: ООО «РТ-Ф»,
105082, г. Москва, ул. Фридриха Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
вгарантийном талоне или на сайте www.sven.fi
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, №02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано вКитае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
2.0 Multimedia Speaker System
Automatic Voltage Regulator
Стабилизатор напряженияСтабилизатор напряжения
Automatic Voltage Regulator
2.0 Multimedia Speaker System2.0 Multimedia Speaker System
SPS-619
DRIVER
Game Racing Wheel
