SWAGTRON Swagger Cali Drift User manual

USER MANUAL
In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials. Ver. 1.0 01/09/18
folding electric scooter

Thank you for your purchase of the Swagger Cali Drift Scooter by SWAGTRON®!
You’re about to take the next step in the evolution of transportation. The Cali Drift takes the power of electricity, the style of a
traditional scooter, adds them together, and tops it off with a bit of swag.
To ensure your safety and the safety of others, please read and follow the guidelines in this User Manual carefully and
thoroughly before riding.
If you have any questions or concerns, contact us at 1-844-299-0625 for further assistance.
Happy Riding!
-The SWAGTRON®Team

GENERAL INFORMATION
1.1 Important Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .01
1.2 Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .02
1.3 Disposal at End-of-Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .03
1.4 Main Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .04
PARTS & FEATURES
2.1 What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05
2.2 Cali Drift Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .05
SETUP & FOLDING
3.1 Setting Up the Scooter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .06
3.2 Folding the Scooter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07
CHARGING
4.1 How to Charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .09
4.2 Indicator Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
4.3 Battery Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
TABLE OF CONTENTS

USAGE
5.1 How to Ride . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
5.2 Practicing Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
MAINTENANCE
6.1 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
6.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
6.3 Transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
WARRANTY

SWAGTRON SWAGGER CALI DRIFT USER MANUAL 01
Section1
GENERAL INFORMATION
Before operating this vehicle, please read all instructions. This manual will guide you through the functions, usage, and proper
care of your Swagger Cali Drift. If you have any questions or cannot find the information you need in the manual, please contact
your place of purchase or our customer service at 1-844-299-0625. Before contacting customer service, please have your
purchase information ready as this may be needed during the call. This information may be recorded below.
Date of Purchase:
Place of Purchase:
It is important that you follow all safety warnings that appear throughout this manual and exercise good judgment
when using your Cali Drift scooter. Consult this manual before attempting to ride.
1.1 Important Information
Within this manual, “the Cali Drift”, “your Cali Drift”, “your scooter” and “the scooter” refer to the Cali Drift Electric Scooter.
The Cali Drift is a personal scooter that uses electrical power. By riding our Cali Drift, the user acknowledges and accepts
responsibility for all risks associated with the use of the Cali Drift which may include, but are not limited to, muscle injuries,
broken bones, lacerations, serious injury, and possible death, which may be sustained while using the Cali Drift.
To better insure your safety, ALWAYS USE APPROPRIATE PROTECTIVE GEAR, read and follow all instructions and
warnings in the User Manual.
Appropriate protective gear should include an ASTM F1492, F1447, F1492, Snell B-90A, B-95, N-942, or CPSC
approved helmet and other gear including knee and elbow pads.
Use the Swagger at your own risk. We are not responsible for mishaps due to lack of common sense.

02
1.2 Safety Warnings
When reading this manual, note these icons:
Notes with this icon MUST be read, understood, and obeyed to prevent injury or damage, etc.
Notes with this icon include relevant information.
Properly dispose of all packaging material. Some items may be packed in plastic bags or material and may
cause suffocation or injury to pets or children.
Verify that all parts of the product are accounted for. If any part is missing, call customer service.
If any ports or cables or surrounding parts are damaged, do not use the product.
Never insert objects into the product other than the cables etc. as described in this manual.
If the product is to be used by children, the caregiver should explain the contents of the user manual to the
children. The caregiver should provide adequate supervision to ensure that the device is being used as
explained in the user manual.
Use only the parts included in the original packaging or received from the manufacturer.
Risk of shock. Do not allow water and/or liquids to come in contact with any part of the product.
Use dry, non-abrasive cloth to remove debris or dust. Do not spray liquids onto the product.
Never submerge the product or any of the product’s components and/or accessories into water.
Do not ride over stairs.
Do not allow more than one person on the scooter at a time.
The product shall only be used as described in this manual.

SWAGTRON SWAGGER CALI DRIFT USER MANUAL 03
Cover the product to protect it from dust. Do not store in a dusty environment as, with all electronic devices,
this may cause damage over time.
WARNING- RISK OF FIRE - No user serviceable parts
AVERTISSEMENT - Risque d’incendie - Aucune des pièces ne peut être réparée par l’utilisateur
1.3 Disposal at End-of-Life
This product must not be disposed of by incineration, landfilling, or mixing with household trash. Improper disposal of the
battery contained within this product may result in the battery heating up, rupturing, or igniting which may cause serious
injury. The substances contained inside the battery present chemical risks to the environment. The recommended disposal
for SWAGTRON®Swagger Cali Drift Scooter at its end-of-life is to dispose of the entire unit at or through an e-waste recycling
center, program, or facility. Local regulations and laws pertaining to the recycling and disposal of lithium-ion batteries and/or
products containing them will vary according to country, state, and local governments. You must check laws and regulations
corresponding to where you live in order to dispose of the battery and/or unit properly. It is the user’s responsibility to dispose
of their waste equipment properly in accordance with local regulations and laws.
For additional information about where you should drop off your batteries and electrical or electronic waste, please contact
your local or regional waste management office, your household waste disposal service, or your point-of-sale.

04
1.4 Main Specifications
Indicators Items Parameters
Dimensions Folded Size 40.7 x 13.5 x 10 in
Opened Size 34.3 x 13.5 x 41.3 in
Weight Vehicle Weight 22 lbs / 10 kg
Riding Requirements
Weight Limit 66 - 264.5 lbs / 30 - 120 kg
Max. Incline 8°
Suitable Terrain Hard Surfaces, Flat roads, Inclines under 8°
Working Temp. 77°F / 25°C
Storage Temp. 14°F to 122°F / -10°C to 50°C
Power
Motor Power 250W
Speed Up to 25 km/h / 15.5 mph, based on terrain
Range Up to 9.3 mile / 15 km
Tires Front Tires Hard Rubber; Passive
Rear Tire Hard Rubber; Motorized
Battery
Type Rechargeable Lithium -Ion
Management Balance, Over-charge, Under-voltage, Overheating automatic shutoff
Voltage 36V 4.4Ah
Watt Hours 158.4
Charger
Model FY-4202000
Input Voltage 100-240V 50/60Hz 2.5A
Output Voltage 42V 1.5A
Charging Time 2.5~3.5 hours
Manufactured By Shenzhen Fuyuandian Power Co.,Ltd
8F, Building A9, TianRui Industrial Park, 1st Fuyuan Road, Xinhe, Fuyong, Baoan 518103

SWAGTRON SWAGGER CALI DRIFT USER MANUAL 05
Section 2
PARTS & FEATURES
Please read the user manual in its entirety before using the Cali Drift so that you may fully understand its parts and functions and
be able to operate it safely.
2.1 What’s in the Box?
■1 x Swagger Cali Drift Electric Scooter
■1 x Allen Key
■1 x Charger
■1 x User Manual
2.2 Cali Drift Diagram
1. Throttle 9. Handle
2. Indicator 10. Stem
3. Handbrake 11. Front Wheels
4. Stem Lock 12. Trucks
5. Latch Grip 13. Footbrake
6. Folding Latch 14. Rear Motorized Wheel
7. Deck 15. Charging Port
8. Power Switch
4
8
9
10
11
12
14
13
7
5
6
21
3
15

06
Section 3
SETUP & FOLDING
Ensure the scooter is off before working with any of its parts. The scooter comes pre-assembled within the package and features
a stem which can be adjusted to accommodate different heights. For your convenience, the scooter can also be folded. All parts
and tools are included.
Before folding, unfolding, or making any adjustments to the scooter, bring it to a complete stop and turn it off.
Before riding the scooter again, lean the scooter off the kickstand and push the kickstand up.
3.1 Setting Up the Scooter
Step 1. Use the included Allen Key to loosen the Stem Lock.
Step 2. Grasp the Handle or Stem and turn it so that the Handbrake
faces the deck. (fig. a)
Step 3. Grasp the Handle and pull or push it up or down to raise or
lower it. (fig. b)
DO NOT raise the Handle past the Stem’s safety
line. Ensure the last line meets the Stem Lock.
Step 4. Use the included Allen Key to tighten the Stem Lock and
secure the Stem in place.
Raising the Stem past the safety line may result in
breakage or damage to the Stem or the scooter.
(fig. a) (fig. b)
Safety Line
Deck
Handbrake
Allen Key
