SWAGTRON T3 User manual

Swagtron UM-T3-Tri-Lingual-0624.indd 1 6/28/2016 4:42:21 PM

Swagtron UM-T3-Tri-Lingual-0624.indd 2 6/28/2016 4:42:21 PM

3Swagtron T3 Hands Free Smart Board English
Thank you for your purchase of the SWAGTRON® T3 Hands Free Smart Board by SWAGTRON®!
You’re about to take the next step in the evolution of transportation. The SWAGTRON® takes the fun of a
skateboard, the ease of an electric scooter, and tops it off with an extra bit of swag.
To ensure your safety and the safety of others, please read and follow the guidelines in this User Manual
carefully and thoroughly before riding.
If you have any questions regarding the SWAGTRON®, contact us at 1-844-299-0625 for further assistance.
Happy Riding!
-The SWAGTRON® Team
Swagtron UM-T3-Tri-Lingual-0624.indd 3 6/28/2016 4:42:21 PM

4 Swagtron T3 Hands Free Smart BoardEnglish
SWAGTRON® T3 User manual
Contents
I - GENERAL INFORMATION
—— 6
1.1 ABOUT THE SWAGTRON
®
—— 6
1.2 WHAT’S IN THE BOX —— 7
1.3 WHAT’S NEW? —— 7
1.4 SAFETY NOTICE —— 8
1.5 IMPORTANT INFORMATION —— 10
1.6 DISPOSAL AT END-OF-LIFE —— 11
II - PRODUCT FEATURES —— 12
2.1 SWAGTRON
®
T3 DIAGRAM —— 12
2.2 SWAGTRON
®
SENTRYSHIELD™ – PATENTED MULTILAYERED PROTECTION —— 13
2.3 LEARNING MODE / STANDARD MODE / ADVANCED MODE —— 14
2.4 MOVEMENT INDICATORS —— 15
2.5 USING Bluetooth
®
—— 16
III – HOW TO RIDE —— 18
3.1 OPERATING STEPS ——18
Swagtron UM-T3-Tri-Lingual-0624.indd 4 6/28/2016 4:42:21 PM

5Swagtron T3 Hands Free Smart Board English
3.2 DIAGRAM OF OPERATION —— 20
3.3 CALIBRATION —— 21
IV – SAFE RIDING TECHNIQUES —— 23
V – BATTERY INFORMATION —— 25
5.1 CHARGING THE SWAGTRON
®
—— 25
5.2 BATTERY LEVEL INDICATOR —— 27
5.3 RANGE PER CHARGE —— 28
5.4 SAFETY WARNINGS —— 28
VI – MAINTENANCE —— 31
6.1 CLEANING —— 31
6.2 STORAGE —— 32
6.3 TRANSPORTATION —— 32
VII – SWAGTRON
®
SPECIFICATIONS —— 33
1 Year Limited Hardware Warranty —— 34
Swagtron UM-T3-Tri-Lingual-0624.indd 5 6/28/2016 4:42:21 PM

6 Swagtron T3 Hands Free Smart BoardEnglish
I - GENERAL INFORMATION
This User manual will guide you through the functions and usage of your SWAGTRON®. Before operating this
vehicle, read all the instructions for safe assembly, charging and operation.
Please inspect the SWAGTRON® unit upon unpacking for any signs of physical damage or defects.
Ensure that the SWAGTRON® unit is fully charged before calibrating and using.
To learn how to charge the SWAGTRON®, please see SECTION 5.1
If you have questions, or have misplaced the SWAGTRON® Manual or Safety Video, contact SWAGTRON® before
you attempt to use or return your SWAGTRON® board.
1.1 ABOUT THE SWAGTRON®
The SWAGTRON® is a self-balancing, personal transporter that uses gyroscopic technology to revolutionize the
way you travel. Steering and stopping are controlled by Dynamic Equilibrium all based on the shifting of your
body weight. It’s simple to operate, easy to control, and looks incredibly cool!
A zero emissions product, the SWAGTRON® is environmentally friendly and uses only the highest quality
components and industry-leading safety features.
Swagtron UM-T3-Tri-Lingual-0624.indd 6 6/28/2016 4:42:21 PM

7Swagtron T3 Hands Free Smart Board English
1.2 WHAT’S IN THE BOX
+SWAGTRON® T3 Hands Free Smart Board
+Charging Unit / Adapter
+User manual
+Rubber Bumper
1.3 WHAT’S NEW?
The SWAGTRON® Hands Free Smart Board contains
the latest technology from SWAGTRON®, including
all new features that make riding safer and more
fun.
+New proprietary custom-designed hard

+High grade aluminum rimmed wheels with
superior traction tires.
+Wider, non-slip foot pedals for more comfortable riding.
+Upgraded motor and gear stabilization at high speeds for tighter control and downhill traction.
+Battery level indicator – no more guessing on how much power is left!
Swagtron UM-T3-Tri-Lingual-0624.indd 7 6/28/2016 4:42:21 PM

8 Swagtron T3 Hands Free Smart BoardEnglish
+Color-coded LED lights illuminate when you stop, go, or turn.
+Learning Mode and Standard Mode allow you to tailor your
riding experience.
+Built-in carrying strap on the bottom of the unit for easy
transportation.
Additional safety features make SWAGTRON® the most trusted brand
for riders:
+Patented “SWAGTRON® Sentryshield™” aluminum alloy housing

hazards.
+Flame retardant materials used in the fabrication of SWAGTRON®.
+Silicone coating used to seal the PCB board and connections to protect against moisture and heat.
+Smart Battery Management within “SWAGTRON® Sentryshield™” system protects the SWAGTRON® from
overheating or damage to the battery from overcharging.
+Open wheel well design allows for better wheel rotation clearance and maintenance.
1.4 SAFETY NOTICE
The SWAGTRON® has been designed with the utmost safety in mind for its riders. Extra precautions have been
taken to protect the user from product hardware malfunctions through our meticulous design and engineering.
Swagtron UM-T3-Tri-Lingual-0624.indd 8 6/28/2016 4:42:22 PM

9Swagtron T3 Hands Free Smart Board English
However, like any riding product, the SWAGTRON® has inherent hazards associated with its use (for example:
losing control, falling off or riding it into a hazardous situation). Therefore it is important to read and follow all
instructions and warnings in the User Manual and use good judgment in order to ride safely.
By riding the SWAGTRON®, the user acknowledges and accepts personal responsibility of all risks
associated with the use of the SWAGTRON® Hands Free Smart Board, which may include, but are
not limited to, muscle injuries, broken bones, lacerations, or other serious injuries that may be
sustained while using the SWAGTRON®.
IF YOU ARE EVER IN AN ACCIDENT, PLEASE CONTACT EMS / DIAL 911 IMMEDIATELY.
Maximum Weight 220 lbs / 100 kg
Minimum Weight 44 lbs / 20 kg
Maximum Speed 8 MPH / 12.8 km/h
Max Incline 30°
Please see SECTION IV for safe riding techniques and additional safety information.
Swagtron UM-T3-Tri-Lingual-0624.indd 9 6/28/2016 4:42:22 PM

10 Swagtron T3 Hands Free Smart BoardEnglish
1.5 IMPORTANT INFORMATION
CAUTION
TO PREVENT ELECTRIC SHOCK, MATCH THE WIDER PRONG OF PLUG TO WIDE SLOT IN OUTLET.
FULLY INSERT.
expressly approved by the manufacturer could void the user’s authority to operate this equipment.
CAUTION
the unit to other equipment. To prevent electromagnetic interference with electric appliances
such as radios and televisions, use shielded cables and connectors for connections.
DECLARATION OF CONFORMITY:
FCC RELATED INFORMATION:
Swagtron UM-T3-Tri-Lingual-0624.indd 10 6/28/2016 4:42:23 PM
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more ofthe following measures:
+Reorient or relocate the receiving antenna.
+Increase the separation between the equipment and receiver.

11Swagtron T3 Hands Free Smart Board English
1.6 DISPOSAL AT END-OF-LIFE
disposal of the battery contained within this product may result in the battery heating up, rupturing, or igniting
which may cause serious injury. The substances contained inside the battery present chemical risks to the
environment. The recommended disposal for any Swagtron® at its end-of-life is to dispose of the entire unit
at or through an e-Waste recycling center, program, or facility. Local regulations and laws pertaining to the
recycling and disposal of lithium ion batteries and/or products containing them will vary according to country,
state, and local governments. You must check laws and regulations corresponding to where you live in order to
properly dispose of the battery and/or unit. It is the user’s responsibility to dispose of their waste equipment
properly with accordance with local regulations and laws.
For additional information about where you should drop off your batteries and electrical or electronic waste,
point-of sale.
Swagtron UM-T3-Tri-Lingual-0624.indd 11 6/28/2016 4:42:23 PM
+Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
+Consult the dealer or an experienced radio/TV technician for help.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to
this equipment. Such modifications could void the user’s authority to operate the equipment.
This device complies with Industry Canada licenseÿexempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
IC statement

12 Swagtron T3 Hands Free Smart BoardEnglish
II - PRODUCT FEATURES
2.1 SWAGTRON® T3 DIAGRAM
LED Movement Indicators
Power Button
Charging Port
*Rubber bumper protector is included
Battery Level Indicators
System Status Indicators
Wider, Anti-slip Foot Pedals
Reinforced Body with polycarbonate Fire Retardant Shell
Upgraded Motor and Stabilizers
with dierent gear technology
Swagtron UM-T3-Tri-Lingual-0624.indd 12 6/28/2016 4:42:23 PM

13Swagtron T3 Hands Free Smart Board English
2.2 SWAGTRON®SENTRYSHIELD™ – PATENTED MULTILAYERED PROTECTION
Your safety is our top priority. That’s why the SWAGTRON® utilizes a premium quality lithium ion battery pack

you peace of mind.
The housing for the “SWAGTRON® Sentryshield™” is made of aluminum, which provides an airtight seal
Built-in Carrying Strap for Easy Transportation
Built-in Bluetooth® Speaker
Swagtron UM-T3-Tri-Lingual-0624.indd 13 6/28/2016 4:42:24 PM

14 Swagtron T3 Hands Free Smart BoardEnglish
enclosing the battery. This adds a level of protection for the mainboard from overheating. A protective silicone
gel layer on the PCB mainboard maintains consistent temperatures and avoids short circuiting.
Topping it all off is a Smart Battery Management System (BMS) that constantly monitors the following areas for
your utmost safety:
+Overvoltage
+Temperature increases
+Overcharging of the battery
+Overcurrent and short circuit protection

2.3 LEARNING MODE / STANDARD MODE / ADVANCED MODE
The SWAGTRON® T3 includes three riding modes in order to provide all kinds of riders with the best experience
possible.
Directly from your smart board, easily switch between Learning Mode and Standard
Mode. After pressing the power button to power on the board, quickly press the

changes modes.
Modes can also be changed via the SWAGTRON® app which is available in both the
App Store and Google Play Store. The Advanced Mode can only be activated through
the SWAGTRON® app.
Swagtron UM-T3-Tri-Lingual-0624.indd 14 6/28/2016 4:42:24 PM

15Swagtron T3 Hands Free Smart Board English
2.4 MOVEMENT INDICATORS
The SWAGTRON® includes new movement indicators to let others know when you’re on the move. Always keep a

Movement Indicator Color Action
Red
BRAKING – Red lights indicate slowing/stopping, unexpected pauses,
or sudden movements.
Lights illuminate on the rear of the board when coming to a stop from
forward motion. Lights illuminate on the front of the board when
coming to a stop from backward motion.
Blue ACCELERATION – Blue lights on the front of the board indicate forward
motion.
Green TURNING – Flashing green lights on the front of the board indicate
turning direction.
NOTE: Indicators cannot be turned off.
Swagtron UM-T3-Tri-Lingual-0624.indd 15 6/28/2016 4:42:25 PM

16 Swagtron T3 Hands Free Smart BoardEnglish
2.5 USING Bluetooth®
1. Power on the SWAGTRON® to automatically turn on Bluetooth®. The SWAGTRON® will make a sound to
indicate that Bluetooth® is on and awaiting possible connection.
2. Using your mobile device, turn on Bluetooth®, make it “discoverable” if needed, then search. The device
names “Swagtron” & “Swagtron music” should appear.
3. Select “Swagtron music” to begin connecting if you would like to play music on your T3. Connect to
“Swagtron” through your SWAGTRON app with default password (000000) to switch modes and monitor
your SWAGTRON T3 battery status. The SWAGTRON® will make a sound to indicate that the devices
have been successfully connected and/or paired.
4. After successfully connecting and/or pairing your SWAGTRON® and your device/app, you may begin
playing music or using SWAGTRON® app at any time.
5. To end the connection between the devices, turn off Bluetooth® on your mobile device. The
SWAGTRON® will make a sound to indicate that the devices have been successfully disconnected.
Be able to connect to APP via Bluetooth V4.0 BLE to check the battery, speed, mileage and battery details.
Bluetooth® V2.1+EDR

Notes:
+The SWAGTRON® will make different sounds to indicate different states:
1.) On and awaiting connection,
2.) Connection/pairing successful and
3.) Connection terminated.
Swagtron UM-T3-Tri-Lingual-0624.indd 16 6/28/2016 4:42:25 PM

17Swagtron T3 Hands Free Smart Board English
+Powering on the SWAGTRON® will automatically enable Bluetooth® i.e. Bluetooth® will become enabled
and stay enabled as long as the SWAGTRON® is powered on.
+Some mobile devices immediately become “discoverable” once Bluetooth® is activated. Please check the
instructions of your Bluetooth®-enabled device for any trouble with this feature.
+As with most Bluetooth® devices, it is recommended to keep the connected devices within a reasonable
distance from one another. The connection may be terminated or fail to work properly if the connected
devices are too far apart.
Swagtron UM-T3-Tri-Lingual-0624.indd 17 6/28/2016 4:42:25 PM

18 Swagtron T3 Hands Free Smart BoardEnglish
III – HOW TO RIDE
Get ready to ride with swag! The below instructions
will ensure that you have a comfortable and safe riding
experience with your SWAGTRON® unit. Please read it
carefully as this information is very important.
3.1 OPERATING STEPS
Before you begin operation, charge your SWAGTRON®
unit with the included power adapter. Charge time can
take up to 2-3 hours. For detailed information on how
to charge your SWAGTRON®, see Section 5.1
1. Press the POWER BUTTON to turn on your
SWAGTRON® unit.
2. Step on one PEDAL to trigger the foot-switch.
The system will enter self-balancing mode.
Then step on the second pedal with your other
foot quickly.
3. Stand upright but relaxed. Do not make any
sudden or jerking movements.
The SWAGTRON® has 4 sensors below the pedals.
Power Button
Step 1
Press the Power Button to
turn on your Swagtron.
Step 2
Step on one PEDAL to trigger the foot-switch.
System will enter self-balancing mode with
system indicator light ashing.
Swagtron UM-T3-Tri-Lingual-0624.indd 18 6/28/2016 4:42:25 PM

19Swagtron T3 Hands Free Smart Board English
When the rider steps on a pedal, the SWAGTRON® will adjust itself to balance automatically.
If the SWAGTRON® does not enter self-balancing mode
when triggering the foot-switch, the warning LED will
light up. DO NOT operate the SWAGTRON® under these
conditions. Please power the unit off and back on again. If
this fails to work, please re-calibrate the SWAGTRON® by
following the calibration instructions on section 3.3.
If you are on a slope, move the SWAGTRON® to

light, contact SWAGTRON® technical support
immediately.
NOTE:
When riding the SWAGTRON®, you must make sure both feet
are touching the pedals for proper detection. Do not put
other objects on the pedals, as it could cause the system to
lock or self-drive.
NOTE:
+Do not tilt forward or backwards beyond 10 degrees, as the unit may malfunction.
+
+Avoid uneven or rocky surfaces as the SWAGTRON® may not function properly.
Swagtron UM-T3-Tri-Lingual-0624.indd 19 6/28/2016 4:42:25 PM

20 Swagtron T3 Hands Free Smart BoardEnglish
+Avoid hills or slopes of more than 30 degrees incline.
+When the operator exceeds the maximum speed, the SWAGTRON® will sound a warning alarm.
3.2 DIAGRAM OF OPERATION
The SWAGTRON® self-balances and moves because of
Dynamic Equilibrium. This is generated by the shifting
of your body weight and uses an internal gyroscope
with acceleration sensors to move based on your
center of gravity. When you lean forward, it will sense
your actions and accelerate. When you need to turn,
slow down and gently shift the weight on your left or
right foot to turn towards the opposite direction.
MOVE FORWARD
Shift your weight forward to move directly ahead.
STOP
Align your body to an upright, straight position.
TURNING LEFT
Shift your weight slightly on the RIGHT PEDAL to turn
left.
TURNING RIGHT
Forward
Shift your weight forward
within 10 degrees
Backward
Shift your weight backward
within 10 degrees
Stop
Align your body to an
upright, straight position.
Swagtron UM-T3-Tri-Lingual-0624.indd 20 6/28/2016 4:42:25 PM
