Swiss Madison Voltaire SM-VT324 User manual

INSTALLATION
INSTRUCTIONS
Voltaire Vanity Top Sink
www.swissmadison.com | 19 Stults Rd, Dayton, NJ 08810 | 1-434-623-4766 | [email protected]
Share your pictures for a feature!
using #SwissMadison
Swiss Madison
®

—1 —
Prior to Installation:
If you have any questions or concerns please contact us:
Inspect sink to ensure no damages have occurred while in shipping.
Observe all plumbing and building codes in accordance with your state and local requirements.
We recommend a professional for installation. Customer is responsible for damage to
countertop and/or sink during installation.
Additional oor and wall preparations may be necessary to avoid damage to the product.
1-434-623-4766
[email protected]om
General Recommendations: Read installation and maintenance instructions thoroughly before installing the sink.
Be sure to use proper tools and always wear proper personal safety accessories for your protection.
Vanity base must already be assembled and old sink should be removed.

—2 —
Thank you for purchasing a Swiss Madison Vanity Top Sink.
We appreciate your business and know you will enjoy your sink for many years to come.
If you have any questions or require assistance we would be happy to help,
please contact us at 1-434-6234766 or [email protected].
Thank you for your purchase
www.swissmadison.com
To learn more about our products, please visit:
Sincerely,
The Swiss Madison Team

*Matching drains are not included, please contact us if you wish to purchase one.
VANITY TOP SINK MODELS
—3 —
NOTE: Pictures may not dene contour of china and components.
SM-VT324
24” x 18 ⁄” x 6 ¾”
*Matching Drain: SM-PD23
6.75”
18.5”
24”
SM-VT324-3
24” x 18 ⁄” x 6 ¾”
*Matching Drain: SM-PD23
6.75”
18.5”
24”
SM-VT327
25 ⁄” x 22 ¼” x 7¼” 25 ⁄” x 22 ¼” x 7¼”
*Matching Drain: SM-PD23
7 ¼”
22 ¼”
25 ⁄”
SM-VT327-3
*Matching Drain: SM-PD23
7 ¼”
22 ¼”
25 ⁄”

*Matching drains are not included, please contact us if you wish to purchase one.
—4 —
NOTE: Pictures may not dene contour of china and components.
SM-VT328
31 ⁄” x 22 ¼” x 7 ¼”
*Matching Drain: SM-PD23
7 ¼”
22 ¼”
31 ⁄”
SM-VT328-3
31 ⁄” x 22 ¼” x 7 ¼”
*Matching Drain: SM-PD23
7 ¼”
22 ¼”
31 ⁄”
SM-VT329
37 ¼” x 22 ¼” x 7 ¼”
*Matching Drain: SM-PD23
7 ¼”
22 ¼”
37 ¼”
SM-VT330
49 ¼” x 22 ¼” x 7 ¼”
*Matching Drain: SM-PD23
7 ¼”
22 ¼”
49 ¼”
VANITY TOP SINK MODELS

NOTE: Specialized tools may be necessary to install Swiss Madison Vanity Top Sink.
VANITY TOP SINK INSTALLATION INSTRUCTIONS
SUGGESTED TOOLS AND MATERIALS
PARTS LIST
Swiss Madison Sink Drain (not included) Faucet (not included)
—5 —
Adjustable Wrenches Gloves
Safety Glasses Adhesive
The step-by-step guidelines in the installation instructions are a general reference for installing a Swiss Madison Sink.
Should there be any discrepancies, Swiss Madison cannot be held liable.
It is recommended to install all Swiss Madison products by hiring a licensed professional
1. Read the complete instruction manual before beginning installation.
2. Conrm that your model will t in intended location and plumbing xtures are
located where legally required before beginning installation.
3. Not all drawings on this manual are drawn to scale. Please refer to the model chart.
4. Two people are recommended to install and move this product.
Towel
L
H
W
Caulk

NOTE: Drawings may not exactly dene contour of china.
—6 —
2. Install Faucet and Drain
Following manufacturer's instructions, install drain and faucet onto vanity top.
1. Prep Installation Area
Disconnect water supplies.
If you are replacing an old vanity top be sure to have already removed the old sink.
If you are installing a new vanity make sure it is assembled as instructed by the manufacturer.
3. Apply Adhesive
Using your chosen adhesive, apply a bead of silicone around the rim of the vanity base.

NOTE: Drawings may not exactly dene contour of china.
—6 —
4. Secure Sink
Carefully lower sink into place so that it is resting on the vanity base.
Press sink rmly into place and wipe away excess sealant with a damp cloth.
Allow for adhesive to cure; this is dependent upon which adhesive you choose to use. Be sure to check the
instructions on your adhesive prior to use.
5. Install Plumbing Fixtures
Connect drain, trap to drain, and water supply connections to the faucet according to manufacturer’s instruction.
Run water and check for leaks.
6. Installing Plumbing Fixtures
Wipe away any excess.
Apply a bead of caulk along the back edge of the sink against the wall.

Swiss Madison® products are made with quality materials and excellent craftsmanship to provide the
customers a long lasting product. In the case of any defects in materials or craftsmanship under regular
use were inspected in the rst year of purchase, Swiss Madison® will provide replacement parts at no
charge, or at its option, replace any product or part of the product that is deemed defective, under
normal installation, use, service and maintenance. This warranty applies only to the original purchaser.
Proof of purchase will be required in the case of a claim.
Swiss Madison® recommends the installations to be made by a licensed, professional plumber.
Swiss Madison® will not be held responsible for any damage or product failure due to improper
installation, misuse, or failure to use a licensed professional. Swiss Madison® is not responsible for any
removal or installation cost.
This One Year Limited Warranty will be voided if:
•The installation recommendations were not followed.
•The product has been moved from it’s initial place of installation.
•The product has been modied.
•The product has been subjected to improper maintenance, abuse, misuse, excessive use of
chemicals, accident or other damages.
Swiss Madison® makes no implication that products comply with any or all local building or plumbing
codes. It is the consumer’s responsibility to determine local code compliance. This warranty extends to
the original purchaser and rst consumer.
Swiss Madison® is not liable for any incidental, consequential or special damages associated with the
return, replacement, installation or use of your product. This includes freight costs, labor, travel time, lost
prot, home damages and other contingent liabilities and costs (including, without limitation, costs
associated with experts, investigations, analyses, attorneys and other professionals and services).
The Swiss Madison® warranty is a comprehensive and explicit limit of liability, and all items outside of it
are not addressable by or the responsibility of Swiss Madison®. Certain states have variances regarding
implied warranties and in those situations we remain fully compliant.
In the case of any questions or a claim contact us directly at 1-434-MADISON (623-4766).
WARNING: Content may contain sharp and other possibly harmful pieces and may cause hazard to
children and adults, Swiss Madison® is not responsible in any way for personal damage.
ONE YEAR LIMITED WARRANTY
1-434-MADISON
(623-4766)
19 Stults Rd., Dayton, NJ 08810
www.swissmadison.com
Swiss Madison
®
