Symmons Dia SLS3522PP Manual

Dia®
Model Numbers Feature Highlights
SLS3522PP
Single Handle Lavatory Faucet
Operation & Maintenance Manual
☐SLS3522PP Single Handle Lavatory Faucet
with A Push Pop Drain Assembly
• Single hole mount configuration
• Quarter turn ceramic cartridge
• 25 inch braided hose water supply connections
• 5" height
• Standard 1.0 gpm (3.8 L/min) flow rate
• Faucet shall be metal construction, plated in
standard polished chrome finish
Compliance
ASME A112.18.1/CSA B125.1
NSF/ANSI/CAN 61: Q<1, NSF/ANSI 372
WaterSense 1.0 gpm (3.8 L/min)
Certied by
IAPMO R&T
c
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
Warranty
Dimensions
CC JJ
LL
EE
Note: Dimensions subject to change without notice.
Measurements
C
Hole Size
Min. Ø 1-1/4", 32 mm
Max. Ø 1-1/2", 38 mm
EMin. 2-1/2", 64 mm
J
Deck Thickness Ref.
Min. 7/8", 22 mm
Max. 1-7/8", 47 mm
L3/8" compression fitting
WARNING: This product can expose you to chemicals
including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm.
For more information, go to www.P65Warnings.ca.gov.

2
Parts Breakdown
Tools Required
Adjustable Wrench
Allen wrench (2.5 mm)
Plumber Putty
Plumber Tape
Soft Jaw Pliers
PLUMBER
PUTTY
Aerator kits
1.0 gpm (3.8 L/min)
0.5 gpm (1.9 L/min)
Cartridge w/
Limit Stop
Part Number Item
Replacement Parts
Non-aerated laminar
ow outlet kits
1.0 gpm (3.8 L/min)
0.5 gpm (1.9 L/min)
LN-15-1.0-NA*
RL-019*
includes aerator, retainer & washer
includes aerator, retainer & washer
Handle kit
includes handle, allen
screw & RB button plug
requires 2.5 mm Allen wrench
Mounting hardware kit
threaded studs (2)
hex nut (2)
rubber washer (1)
metal washer (1)
LN-01660* 4” deck plate
RL324* Push Pop Drain Assembly
RL-066*
*Note: For decorative nish faucets append the
appropriate sufx code letters to part numbers
marked with an asterisk (
*
)
aerator
1.0gpm (3.8 L/min)
aerator retainer
base gasket
mounting gasket
mounting plate
mounting nut
ex supply hoses
SLS3522 length:
27-9/16"
(700 mm)
COLD: blue stripe
HOT: red stripe
3/8" compression
cap
retainer nut
cartridge
faucet body
handle
allen screw
button plug
2.5 mm wrench
included
RL-070
RL-059-1.0*
RL-059-0.5*
RL-070
RL-067*
Push Pop
Drain Assembly

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2023 Symmons Industries, Inc. ■symmons.com ■[e-mail] ■ZV-3719 REV 0 ■ 021523
Quick Install Guide
Hotter (+)
Colder (–)
13
22
HOT COLD
ON
OFF
Step 2
Connect supply hoses
HOT COLD
Step 4
Flush lines and
check for leaks
Step 1
Attach faucet assembly
Limit stop adjustment
Step 3
Push Pop Install: Insert drain body
(L) into drain opening. From below,
Tighten locking nut (O) with gasket
(M) and washer (N) to ange.
Tighten tail nut (Y) with washer (X)
to secure tail pipe (Q).
Do Not overtighten.
Push Pop Drain
Assembly
1
2
3
Plumbers Putty L
Q
X
N
Y
O
M
