Symmons Winslet SRT-5172 Reference guide

Important: Flush supply
lines clean before connecting
to control valves.
Hot supply
Cold supply
(main supply lines not included)
3/32"
finished deck,
front view
Step 2
Attach faucet
handles Step 7
Connect handspray
Step 1
Attach supply
valves
Step 3
Attach diverter
and faucet spout
Step 5
Flush and connect
supply hoses
Step 8
Run faucet and
check for leaks
Step 4
Attach handspray holder
Step 6
Connect handspray hose
Quick Install Guide Winslet Roman Tub Faucet, SRT-5172
Plumbers
Putty
Pipe
Sealant
3/32"
1 2 3 4
Model Number
SRT-5172 Roman Tub Faucet with
handspray
Alternate Finish Options
-STN Satin Nickel
- Chrome (standard)
Roman Tub Faucet SRT-5172
Installation Brief
Winslet®
Tools & Materials Need Help?
Symmons customer service:
Phone: [phone]
Email: [email protected]
Monday - Friday 7:30 am - 6:00 pm EST
www.symmons.com/service

Compliance
ASME A112.18.1/CSA B125.1

Finished deck thickness
1-3/8" (35 mm) max
8" (203 mm) min
16" (406 mm) max
9-1/8" (232 mm)
2-1/4" (57 mm) dia
Hole size
1-1/8" (29 mm) min
1-1/4" (32 mm) max
Note: Dimensions subject to change without notice.
Hole size
1-1/8" (29 mm) min
1-3/8" (35 mm) max
4-1/8"
(105 mm) 2-1/8" (54 mm)
5"
(127 mm) 3-1/4"
(83 mm)
7"
(178 mm)
2-1/4" (57 mm) dia
2-5/8" (66 mm)
4" (102 mm) min
3-1/8" dia
(79 mm)
1" (25 mm) dia
1/2" - 14 NPT
exible hose
handspray hose
supply outlet
handspray hose
supply inlet
Hole size
1-1/16" (27 mm) min
1-7/16" (37 mm) max
Dimensions Winslet Roman Tub Faucet, SRT-5172
aerator
removal key
Replacement Parts
Part Number Item
HOT & COLD
handles & screws
escutcheons (2)
RT-512L-KIT
*
nut, 1"-20 (2)
gasket (2)
RT-308
handspray hose,
0.20mm x 5 feet
handspray
washer
elbow mount
washer
hose
connection
base
gasket
nut
Handspray
Assembly
512W-51*
3/32"
KN-113E
identified
by groove
KN-114E (hot)
OFF = CW
KN-113E (cold)
OFF = CCW valve cartridge
handle kit
assembly*
(ref. table)
cartridge
(ref. table)
gasket
ange nut
1/2" hose
with 1/2-14
NPSM female
connectors
ow
regulator
(Hot & Cold
Handle Kit)
gasket
metal washer
brass nut
aerator
removal tool
spout, centerbody
diverter assembly
nut
o-ring
Ordering replacement parts:
Call Symmons customer service at [phone],
[phone] M-F 7:30 am - 6:00 pm EST or
check our website at www.symmons.com for a
list of Symmons distributors.
*NOTE:
Faucets with an optional decorative nish,
append appropriate three letter sufx code to part
numbers marked with an asterisk (
*
).
Parts Assembly Winslet Roman Tub Faucet, SRT-5172
