Taiden HCS-4100MC/50 User manual

Large-Scale Voting System
Installation and Operating Manual
V 1.4
Excellent solutions for conferences

I
Remark:
All rights reserved for translation, reprint or reproduction
Contents may change without prior announcement
All technical specifications are guideline data and not guaranteed features
Taiden Co., Ltd. is not responsible for any damage caused by improper use of this manual
The equipment must be connected to earth!
This product conforms to the rules of the European directive 2004/108/EC.
If any detailed information is needed, please contact your local agent or TAIDEN service center. Any feedback,
advice and suggestion about the products is appreciated.
In order to extend the life time of whole system, we strongly recommend that the congress system be
scheduled to shut down every day in the evening when not in use.
TAIDEN is the registered trademark of TAIDEN Co., Ltd.

II
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such
as vases, shall be placed on the apparatus.
6. The MAINS plug serving as a disconnection device
should be easy to operate.
7. The apparatus should be connected to the MAINS
socket-outlet with protective earth.
8. Clean only with dry cloth.
9. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
10. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
11. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade and the third prong are provided for your safety.
If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete
outlet.
12. Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
13. Only use attachments/accessories specified by the
manufacturer.
14. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
15. Unplug this apparatus during lightning storms or
when unused for long periods of time.
16. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
17. Do not place the equipment on any uneven or
unstable stand; original product package or
appropriate package should be used to avoid damage
caused by strong impacts during transportation.
18. Power supply cords:
AC 100 V - 120 V 60 Hz or AC 220 V - 240 V 50 Hz
19. The quantity of connected transceivers in one system
should not exceed prescribed quantity. For service,
please contact the nearest TAIDEN Service Center.
20. All TAIDEN products are guaranteed for definite time
(see the WARRANTY CARD for details) excluding the
following cases:
A. All damage or malfunction caused by human
negligence;
B. Damage or malfunction caused by improper
operating by operator;
C. Parts damage or loss caused by disassembling
the product by non-authorized personnel.
21. Use ONLY specified connection cable to connect the
system equipment.
22. Upon receipt of the product, please fill out the
Warranty Card enclosed and post it to TAIDEN
Service Center nearby in your region.
The lightning flash with an arrowhead symbol, with
an equilateral triangle, is intended to alert the user
to the presence of uninsulated ‘dangerous voltage’
within the products enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
CAUTION: To reduce the risk of electric shock,
DO NOT open covers, no useable serviceable
parts inside. Refer servicing to qualified service
personnel only.
CAUTION: DO NOT use alcohol, ammonia or
petroleum solvents or abrasive cleaners to
clean the devices.

III
Important Safety Instructions
The exclamation mark within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
Attention: Installation should be performed by
qualified service personnel only in accordance
with the National Electrical or applicable local
codes.
Power Disconnect: Units with or without ON – OFF
switch have power supplied to the unit whenever
the power cord is inserted into the power source;
however, the unit is operational only when the ON
– OFF switch is in the ON position. The power cord
is the main power disconnect for all units
WARNING: To reduce the risk of fire or
electric shock, DO NOT expose units to rain
or moisture.
WARNING: The apparatus should be
connected to a mains socket outlet with a
protective earthing connection.

IV
Contents
Installation & User Guide.......................................................................................................... VI
Chapter 1 Introduction................................................................................................................1
1.1 Summary...........................................................................................................................................................1
1.2 System technology............................................................................................................................................3
1.3 Functions ..........................................................................................................................................................5
1.4 Features............................................................................................................................................................6
Chapter 2 Congress main unit (CMU) ........................................................................................8
2.1 Functions and indications .................................................................................................................................9
2.1.1 Front panel ..................................................................................................................................................................9
2.1.2 Backside....................................................................................................................................................................10
2.2 Installation.......................................................................................................................................................11
2.3 Connection......................................................................................................................................................12
2.4 Configuration and operation ...........................................................................................................................13
2.4.1 Network .....................................................................................................................................................................15
2.4.2 Simultaneous interpretation.......................................................................................................................................15
2.4.3 System status............................................................................................................................................................15
2.4.4 Test (cannot work under “VOICE” and “PTT” mode) .................................................................................................15
2.4.5 System setting...........................................................................................................................................................17
2.4.6 Operation language setting .......................................................................................................................................28
2.4.7 System parameter backup/restore ............................................................................................................................28
2.4.8 Machine rename........................................................................................................................................................28
2.4.9 About .........................................................................................................................................................................28
2.4.10 Volume control.........................................................................................................................................................28
2.4.11 Power Management ................................................................................................................................................29
2.4.12 Connecting to PC ....................................................................................................................................................29
2.4.13 Configuration and operation - slave mode...............................................................................................................29
Chapter 3 Voting units ..............................................................................................................30
3.1 Overview .........................................................................................................................................................30
3.2 Functions and indications ...............................................................................................................................31
3.2.1 Front..........................................................................................................................................................................31
3.2.2 Back ..........................................................................................................................................................................31
3.3 Installation.......................................................................................................................................................33
3.3.1 Flush-mounting installation of voting unit ..................................................................................................................33
3.3.2 Installation of the protective cover of HCS-4368/50 series flush-mounting voting unit ..............................................35
3.4 Connection between voting units....................................................................................................................35
3.5 Operation ........................................................................................................................................................36
3.5.1 HCS-4368T/50 series................................................................................................................................................36
3.5.2HCS-4368SDT/FM/50, HCS-48U6DVOTTME ...........................................................................................................37
3.5.3 HCS-4368DME/FM/50 ..............................................................................................................................................37

V
Chapter 4 System connection and basic setup procedure .......................................................40
4.1 Overview .........................................................................................................................................................40
4.2 Connection principles......................................................................................................................................40
4.3 Connection between Large-Scale Voting System and video recording system.............................................41
4.4 Connection between Large-Scale Voting System and Conference Sign-in System ......................................42
4.5 Combine/split conference rooms easily ..........................................................................................................43
4.6 Total system hot spare....................................................................................................................................44
Chapter 5 Accessories .............................................................................................................45
Chapter 6 Working environment and maintenance ..................................................................46
6.1 Public areas ....................................................................................................................................................46
6.2 Technical rooms..............................................................................................................................................46
6.3 System operator room ....................................................................................................................................46
6.4 Ventilation .......................................................................................................................................................46
6.5 Cleaning..........................................................................................................................................................46
6.6 Storage............................................................................................................................................................46
Chapter 7 Technical specifications ...........................................................................................47
7.1 System specifications .....................................................................................................................................47
7.2 Congress system main unit.............................................................................................................................48
7.2.1. Physical characteristics ............................................................................................................................................48
7.2.2. Electrical characteristics...........................................................................................................................................48
7.3 HCS-4368/50 series wired voting unit ............................................................................................................49
7.3.1 Physical characteristics .............................................................................................................................................49
7.3.2 Electrical characteristics............................................................................................................................................50
7.4 Accessories.....................................................................................................................................................51
7.5 System connection..........................................................................................................................................51
7.5.1 Mains cables .............................................................................................................................................................51
7.5.2 Audio cables..............................................................................................................................................................51

VI
Installation & User Guide
About this manual
This manual is a comprehensive guide to the
installation and operation of the TAIDEN Large-Scale
Voting System. It includes the detailed description of
the functions and interfaces of the voting system
components, system connection and installation,
system set-up and operation.
The manual is divided into the following chapters:
Chapter 1：Introduction
An introduction to the voting system composition,
technology, functions and features.
Chapter 2：Congress main unit
Detailed descriptions of the functions and indications,
installation and connection, configuration and operation
of the voting system control main unit
(HCS-4100MC/50).
Chapter 3：Voting unit
Detailed descriptions of the functions and indications,
installation and connection, operation of the
Large-Scale Voting System contribution units.
Chapter 4：System connection
Detailed descriptions of the connection between
system devices.
Chapter 5：Accessories
An introduction to the voting system accessories.
Chapter 6：Environment and maintenance
An introduction to the work environment and the
maintenance of Large-Scale Voting System.
Chapter 7：Specifications
Main technical parameters of Large-Scale Voting
System.
This manual is applicable to:
Congress control main units
HCS-4100MC/50 fully digital standard congress
system main unit
discussion - voting - 256x32 LCD
Voting units
HCS-4368CT/50 fully digital voting system chairman
unit
tabletop - 3 voting keys - 256x32 LCD - waterproof – antistatic
15000 V - Chinese panel
HCS-4368CTE/50 fully digital voting system chairman
unit
tabletop - 3 voting keys - 256x32 LCD - waterproof – antistatic
15000 V - English panel
HCS-4368DT/50 fully digital voting system delegate
unit
tabletop - 3 voting keys - 256x32 LCD - waterproof – antistatic
15000 V - Chinese panel
HCS-4368DTE/50 fully digital voting system delegate
unit
tabletop - 3 voting keys - 256x32 LCD - waterproof – antistatic
15000 V - English panel
HCS-4368CT/FM/50 fully digital voting system
chairman unit
flush-mounting - 3 voting keys - 256x32 LCD - waterproof –
antistatic 15000 V – cover - Chinese panel
HCS-4368CTE/FM/50 fully digital voting system
chairman unit
flush-mounting - 3 voting keys - 256x32 LCD - waterproof –
antistatic 15000 V – cover - English panel
HCS-4368DT/FM/50 fully digital voting system
delegate unit
flush-mounting - 3 voting keys - 256x32 LCD - waterproof –
antistatic 15000 V – cover - Chinese panel
HCS-4368DTE/FM/50 fully digital voting system
delegate unit
flush-mounting - 3 voting keys - 256x32 LCD - waterproof –
antistatic 15000 V – cover - English panel
HCS-4368SDTE/FM/50 fully digital voting system
delegate unit
flush-mounting - 3 voting keys - waterproof – antistatic 15000 V –
cover - English panel

VII
HCS-48U6DVOTTME fully digital voting system
delegate unit
flush-mounting - 3 voting keys
HCS-4368DME/FM/50 fully digital voting system
delegate unit
flush-mounting - multi-parliamentary voting - 3 voting keys -
256x32 LCD - waterproof – antistatic 15000 V – cover – English
panel

1
Chapter 1 Introduction
1.1Summary
TAIDEN Large-Scale Voting System with embedded
high performance CPU ensures full duplex data
transmission speed up to 100 Mbps. High speed voting
and high accuracy due to Ethernet connection of CMU
and PC.
System design for high reliable redundancy and
hot-spare dual server structure. Electrostatic
prevention and water proof design, for worldwide
unrivaled reliability and safety.
Figure 1.1 System overview
This system consists of one or more of the following
items:
Congress control main unit
HCS-4100MC/50 fully digital standard congress
system main unit
discussion - voting - 256x32 LCD
Voting units
HCS-4368CT/50 fully digital voting system chairman
unit
tabletop - 3 voting keys - 256x32 LCD - waterproof – antistatic
15000 V - Chinese panel
HCS-4368CTE/50 fully digital voting system chairman
unit
tabletop - 3 voting keys - 256x32 LCD - waterproof – antistatic
15000 V - English panel
HCS-4368DT/50 fully digital voting system delegate
unit
tabletop - 3 voting keys - 256x32 LCD - waterproof – antistatic
15000 V - Chinese panel
HCS-4368DTE/50 fully digital voting system delegate
unit
tabletop - 3 voting keys - 256x32 LCD - waterproof – antistatic
15000 V - English panel

2
HCS-4368CT/FM/50 fully digital voting system
chairman unit
flush-mounting - 3 voting keys - 256x32 LCD - waterproof –
antistatic 15000 V – cover - Chinese panel
HCS-4368CTE/FM/50 fully digital voting system
chairman unit
flush-mounting - 3 voting keys - 256x32 LCD - waterproof –
antistatic 15000 V – cover - English panel
HCS-4368DT/FM/50 fully digital voting system
delegate unit
flush-mounting - 3 voting keys - 256x32 LCD - waterproof –
antistatic 15000 V – cover - Chinese panel
HCS-4368DTE/FM/50 fully digital voting system
delegate unit
flush-mounting - 3 voting keys - 256x32 LCD - waterproof –
antistatic 15000 V – cover - English panel
HCS-4368SDTE/FM/50 fully digital voting system
delegate unit
flush-mounting - 3 voting keys - waterproof – antistatic 15000 V –
cover - English panel
HCS-48U6DVOTTME fully digital voting system
delegate unit
flush-mounting - 3 voting keys
HCS-4368DME/FM/50 fully digital voting system
delegate unit
flush-mounting - multi-parliamentary voting - 3 voting keys -
256x32 LCD - waterproof – antistatic 15000 V – cover – English
panel

3
1.2 System technology
zMCA-STREAM digital audio processing and
transmission technology
TAIDEN proprietary MCA-STREAM technology is the
essential data transmission technology in the voting
system, e.g. transmitting control and other information
data over a single dedicated 100 Mbps high speed
6-pin cable. Every unit - congress main unit, voting unit
- is equipped with a high performance CPU as the
kernel of the advanced technology infrastructure.
zSystem hardware structure
Voting system hardware is an embedded structure
based on dual high performance CPUs. Even in
stand-alone mode, voting is competent for the
management of electronic voting.
zModular system structure
Any kind of configuration can be set up just by
daisy-chaining Large-Scale Voting System voting units.
The modular system structure of the voting system is
applicable to any kind of conference and provides an
accurate and efficient solution. Additional voting units
can be added when needed. More system functions
are available in connection with a PC and control
software.
zDual main unit hot spare
The voting system hardware systems can be operated
on hot standby with a master and a backup main unit. If
the master main unit fails, the backup unit starts to
operate automatically as master and takes over the
meeting. Thus continuation of the conference is
guaranteed.
zSystem software infrastructure
The voting system software is designed for the
prevalent Client/Server structure. Client and server
communicate with each other by using TCP/IP network
protocol, ensuring both data security and transmission
efficiency. Client and server software can run on the
same computer as well as on different computers in the
same LAN, enabling the operator to manage the
conference more flexibly.
System software imports the hot-spare dual server
structure by using a main server and a back-up server.
While the main server is processing, data are stored
real time on the back-up server to prevent conference
related information from loss in case of a crash of the
main server. As a result, security and reliability of the
conference system are improved vitally.
zDuplicate and backup connection via
“Closed Loop - Daisy Chain” connection
For important meetings, especially those which
consider connection reliability as their leading point,
Large-Scale Voting System adopts advanced “Closed
Loop - Daisy Chain” connection topology, connecting
the last unit in the loop back to the congress main unit.
Therefore, any congress unit in the loop has two
connection paths to the congress main unit. As a result,
breakdown or replacement of a congress unit and
connection failure of a cable will not influence other
congress units. As such the system features the
advantages of a daisy chain connection system with its
simpleness of cabling as well as the improvement of
the system reliability through duplicate and backup
connection functions. In Large-Scale Voting System,
only the congress main unit supports “Closed Loop -
Daisy Chain” connection topology, and only one ring
connection allows.
zAdvanced TCP/IP communication protocol in
PC control
In a PC controlled system, the congress main unit and
the PC use the advanced TCP/IP protocol.
Theoretically, the communication distance between the
PC and the CMU can be infinite. This is decisively
different to traditional RS-232 connection modes where
the distance between the PC and the CMU cannot
exceed 15 meters. TCP/IP enables remote control,
remote diagnosis and remote update.
By using network techniques, conference systems are
linked tightly to the rapidly developing internet
technology, computer science and communication
technology. Users enjoy the convenience of the
contemporary leading techniques, e.g. by using the
compatible wireless LAN techniques (802.11) - such as
PDAs - which can be used to control a conference
system wirelessly. The import of network topology also
makes the conference system merge with intelligent
building networks.

4
zCMU and EMU
The congress main unit forms the core of the entire
conference system. It provides power supply to all
voting units and serves as key component to link
system hardware to application software. One CMU
has two (6P-DIN) trunk-line cable outlets, If more
congress units are needed, additional extension main
units (EMU) HCS-8300ME are required. Each EMU
has four (6P-DIN) trunk-line cable outlets. Large-Scale
Voting System maximum capacity: 4096 voting units.
zVoting units
Voting units are units used by participants to contribute
to a conference and include: voting chairman units,
voting delegate units. The voting unit has voting facility
and graphic 256x32 LCD with back-lighting. Depending
on the option, voting units can be divided into tabletop,
flush-mounted. Each style consists of various products,
which enriches significantly users’ choices.
Low power consumption design is adopted for voting
units, convenient for wiring and installation. All voting
units of the voting system are supplied by the main
unit’s 6P-DIN interface. Since the power capacity of the
6P-DIN interface is limited, it must be ensured during
installation that the added up values of a) the total
power consumption of all congress units connected in
each path and b) the power loss in extension cables do
in no case exceed the maximum possible value
delivered by each 6P-DIN interface. Otherwise the
system will not work properly or automatic protection
will be triggered (see 4.2 connection principles).
zApplication software
Large-Scale Voting System application software is
comprehensive, reliable and user-friendly. It is also an
easy-care software system which helps the operator to
manage the conference efficiently from the very
beginning of a meeting until the post-meeting work.
Once the PC installed and the application software
integrated into the Large-Scale Voting System, the
operator manages centrally all aspects of the
conference. The operation turns out to be easy and
efficient.
The voting system application software is modular
software with various functional modules: System
Setup Management Module, Voting Management
Module, Multi-user Conference Control Management
Module, Dual PC Server Hot Spare Module, Agenda
Control Module, Dual System Main Unit Hot Spare
Module, etc.
zInstallation and transportation
Easy installation is another vital feature of Large-Scale
Voting System. All voting units are equipped with a
1.5-meter-6P-DIN cable (with a male connector) and a
0.6-meter- 6P-DIN cable (with a female connector). All
voting units are connected together in a daisy chain
configuration and connected to the main unit by the
dedicated extension cable.

5
1.3 Functions
zVoting
Cooperating with corresponding software
modules, multiform voting can be implemented:
For/Against
Parliamentary: YES/NO/ABSTAIN
Appraisal:
Satisfied (three keys voting:
satisfied/basically satisfied/unsatisfied)
(two keys voting: satisfied, unsatisfied)
Qualified (three/two keys voting)
Competent (three/two keys voting)
Multi-parliamentary voting that includes up to 15
items in a topic can be implemented by
HCS-4368DME/FM/50.
zKey-press sign-in
zInformation display
By using the information display module of the
application software, conference title, content,
conference related information as well as
meeting related notice can be displayed on a
large screen display (or projector)
Voting units equipped with graphic 256x32 LCD
show :
Delegates’ signed-in and voting results, etc.
Messages (messages from the system
administrator to all or part of participants)
Multilingual (simplified/traditional Chinese and
English, etc) menu
zVideo recording system
Video record can be carried out if video switch unit and
camera are installed.
zComprehensive conference management
The routine and trivial conference steps are
handled in perfect order by the conference
management software. Meanwhile various
information is processed and published real-time.
Powerful control functions for venue
circumstances, conference procedure and
delegate arrangement, etc.
zRemote control and remote diagnosis
Using advanced TCP/IP network protocol in the
communication between the PC and the CMU - to
implement remote control, remote diagnosis and
remote update for the conference system - for easy
central control of a multi-room configuration.
zMulti-room configuration function
Several main units can be operated as several
independent conference systems or be combined
together easily as a large multi-room conference
system configuration.
zSeamlessly Integrated with conference
sign-in system and central control system
The seamless integration of Large-Scale Voting
System with the TAIDEN Conference Sign-in System
and the intelligent central control system provides
comprehensive conference system solutions. Besides
the basic conference management, it also provides
conference sign-in and access control for the
conference participants. Furthermore, it gives complete
facilities to manage the conference system’s power
supply and the peripheral multimedia equipment,
surrounding lights, projector display and sound
equipment. The easy incorporation of peripheral
components upgrades the system into an advanced
intelligent conference system with integrated solutions
for conferencing, audio, lighting control etc.
zDetection facilities
Built-in self-detecting functions in each voting unit
for automatic detection of voting keys.

6
1.4 Features
zGlobal leadership in high-speed large-scale voting
systems
zBandwidth 100 Mbps, voting time for 1000 voting
units less than 1 ms, display time less than 0.5s.
zSystem reliability
System reliability, as described below, has always been
the guiding principle while designing Large-Scale
Voting System:
Voting system resistive to 12 kV static, excels
IEC CISPR 24
Waterproof facility of voting units, equipped with
ferromagnetic cover to protect the unit from
damage during the adjournment
Specially designed application software for
large-scale meetings, multiple operating error
protection and debug mechanism
Dual congress main unit hot spare
System software imports the hot-spare dual
server structure by operating the main server and
the back-up server at the same time. While the
main server is processing, data are stored real
time on the back-up server to prevent conference
related information from loss in case of a crash of
the main server, thus improving security and
reliability of the conference system remarkably.
“Closed Loop - Daisy Chain” connection topology:
breakdown or replacement of a voting unit and
connection failure of a cable will not influence
other voting units.
Built-in communication auto termination function
to prevent system collapse if the TCP/IP cable is
pulled out
Auto recovery function, supports PnP
If PC malfunction happens, the CMU will return to
control status automatically and take over control
of the meeting, ensuring continuation of the
meeting process
Built-in detection facilities: detect the unit’s LEDs
and voting keys prior to start the meeting.
zTechnological progress
Large-Scale Voting System - based on TAIDEN’s
proprietary development digital processing and
transmitting technologies MCA-STREAM - adopts
embedded hardware structure based on high
performance dual CPUs. System software is based on
Client/Server and hot-spare dual server structure. CMU
and PC use advanced TCP/IP protocol for
communication, perfectly integrated to benefit from
modern technologies.
Furthermore, Conference Sign-in System and
intelligent central control system can be integrated into
TAIDEN Large-Scale Voting System to provide the first
complete and efficient solution in the world.
zSystem operability
CMU controls efficiently without the intervention of an
operator.
With a PC and system software, more functions can be
achieved. Large-Scale Voting System can also be set
up according to user requirements.
Large-Scale Voting System adopts Client/Server
structure - the process of the meeting is controlled by
the operator from any PC within the same LAN. If PC
malfunction occurs, CMU will return to control status
automatically and take over control of the meeting,
ensuring continuation of the meeting.
zOutstanding expandability
Large-Scale Voting System supports a maximum of
4096 voting units.
The voting system is modular: just daisy-chain voting
units to set-up a configuration. If extra system capacity
is needed, units can be connected easily, starting from
any access point.

7
zEconomical and convenient installation
In virtue of the fully digital techniques of Large-Scale
Voting System, system installation becomes simple
and economical, especially in conjunction with the
economical and durable system dedicated 6-PIN cable
(substitutable by shielded Cat.5 cable). The cable is
suitable for the requirements of any kind of meeting.
Every delegate unit is assigned an individual ID for
convenient setup and perpetual prevention of double
ID allocation.
System connection reliability is improved by the
professional 6P-DIN standard plug and clasp which
facilitates system installation as well as disassembly.
As a result of the daisy-chain design of the contribution
units, insertion into the system can be done at any
desired point, simplifying significantly equipment
extension and maintenance.
zSystem maintenance
TAIDEN system software provides testing functions for
online testing the operating conditions such as validity
of the keys and LCD.
A detailed test report is issued for quick and simple
maintenance of the system device.

8
Chapter 2 Congress main unit (CMU)
The Congress main unit (CMU) forms the core of the
Large-Scale Voting System, and provides power
supply to all voting units, meanwhile, serving as the key
component to link up hardware with application
software. In stand-alone mode without a PC, the CMU
only carries out basic management facilities; while
more comprehensive management facilities can be
implemented in PC-controlled mode.
The devices that can be controlled by CMU includes:
voting units. By cascade connecting EMUs, the voting
system can reach its maximum capacity: 4096 voting
units.
Product types:
HCS-4100MC/50
fully digital standard congress system main unit
(with discussion - voting - 256x32 LCD)

9
2.1 Functions and indications
2.1.1 Front panel
Figure 2.1 Front panel of HCS-4100MC/50 CMU
Figure 2.1
1. Power light
a. Switches to red in standby mode;
b. Switches to blue when operating.
2. “STANDBY” button
3. “MENU” button
a. The LCD displays the initial user interface:
press this button to enter the LCD set-up
menu;
b. The LCD displays the set-up user interface:
press this button to select the highlighted item
or enter the submenu;
c. The LCD displays the network configuration:
press this button to select/deselect the numeric
value.
4. “Õ” (Left) button
In standby state, press this button to display
current input audio spectrum;
In the set-up interface of the LCD menu, press
this button to cursor to the left.
5. “Ö” (Right) button
In standby state, press this button to select the
number of maximum active microphones.
In the set-up interface of the LCD menu, press
this button to cursor to the right.
6. “EXIT” button
In standby state, press this button to select the
operation mode of the microphones.
In the set-up interface of the LCD menu, press
this button to exit current menu.
7. LINE IN 1 electric level adjustment knob
8. A type USB interface
To plug-in a USB stick.
9. Mini USB interface
For connecting to PC.
10. “MASTER VOLUME”
Knob to adjust the master volume of the floor
audio channel for the congress units
11. Monitoring earphone interface
Earphone jack (Ø 3.5 mm).
12. Microphone operation mode indicator (“OPEN”/
“OVERRIDE”/ “VOICE”/ “APPLY”/ “PTT”)
Corresponding indicator lights up according to
selected mode.
13. Menu display
256×32 LCD displays main unit status and
configuration menu.

10
2.1.2 Backside
Figure 2.2 Backside of HCS-4100MC/50 CMU
Figure 2.2
14. Ethernet interface (LAN)
For communication between the conference main
unit and the PC under TCP/IP protocol to realize
remote controlling; furthermore, it enables remote
controlling by wireless touch panel through central
control system.
15. Extension interface
To connect CMU to EMU and interconnect with
audio input interface and audio output device;
devices cascadable.
16. Contribution units ring connection LED
When output works properly (≥1 contribution unit
connected), LED will flash;
When no contribution unit is connected, LED is off.
17. Contribution units output interface (1-2, two
routes)
18. Video switch interface
When cooperating with video switch and dome
camera, video recording can be realized.
19. Fire alarm linked trigger interface
+5 V voltage application : all conference units
will be switched off and display “ALARM”;
No voltage input or too low voltage: conference
units will return to the status preceding “ALARM”.
20. Power supply
21. Mains switch
22. “LINE OUT 2” (RCAx2 unbalanced output)
23. “LINE OUT 1” (3 cord XLR balanced output)
24. “LINE IN 2” (RCAx2 unbalanced input)
25. “LINE IN 1” (3 cord XLR balanced input)
26. RS-232C port x 2
“COM” port is used for connecting to a central
control system for central controlling, as well as for
system diagnosis;
“TEST” port is used for updating and monitoring.

11
2.2 Installation
The CMU can be fixed in a standard 19-inch cabinet. The
CMU is equipped with a pair of fixing brackets ①. First
unscrew the lateral screws ②from the housing. Then
fasten the brackets with these screws and put the CMU
in the cabinet. Finally fix the four holes ③up with
screws.
Figure 2.3 Installation of the CMU
In addition, 1U metal stripes are included as
decoration to be installed between the CMUs in the
cabinet. It is also good for the ventilation and cooling off.
Fix up the four holes ③with screws.
Figure 2.4 Decoration of cabinet

12
2.3 Connection
HCS-4100MC/50 has 2 outlet (6P-DIN) trunk-line cable
sockets for connecting to voting units. Voting units are
equipped with a cable with a standard 6P-DIN male
connector.
When connecting the CMU to the voting units, just
connect the male connector of the first unit to the
socket of the CMU.
For a longer distance between the voting unit and the
CMU/EMU, a CPL6PS extension cable can be used.
One end of this cable is equipped with a 6P-DIN male
connector; the opposite end is equipped with a female
connector. Just connect the female connector of the
cable to the voting unit, and connect the male
connector to the output of the main unit.
Figure 2.5 Voting unit connected to the CMU or the EMU
For “daisy chain - closed loop” connection, just connect
the last voting unit back to the CMU via a CBL6PP
extension cable (both ends of this cable are equipped
with a 6P-DIN male connector). In Large-Scale Voting
System, the congress main unit can realize a “Closed
Loop - Daisy Chain” connection, but only one –
extension units do not offer this feature.
Figure 2.6 “Daisy chain – closed loop” connection
topology
One HCS-4100MC/50 contains 2x 6P-DIN outlet
trunk-line cable connectors, and each outlet connector
can output 60W. Since the power capacity of a 6P-DIN
interface is limited, it must be ensured that, during the
installation, the sum of the total power consumption of
all the congress units connected to every single
6P-DIN interface plus the power loss in the extension
cables does not surpass the power limit of each
6P-DIN interface. Otherwise the system will not work
properly or automatic protection will occur (see 4.2
connection principles).
