TANDBERG Edge D13922.06 Assembly instructions

Installation Sheet
TANDBERG Edge
This box contains:
TANDBERG Edge unit
TANDBERG Precision HD camera
Edge unit wall mounting bracket
Precision HD camera bracket
Screwdriver (PH2)
Rubber feet and plug
Microphone and microphone cable
HD camera cables, 2m & 5 m
LAN cable
ISDN cables
DVI-I to DVI-I cable (for monitor connection)
DVI-I to VGA adapter
S-Video cable
RCA to RCA cable
DVI-I to VGA cable with mini-jack to stereo RCA Audio cable (for
PC connection)
Audio cable, RCA to 2× RCA
2 × RCA to stereo mini-jack adapter
Cable sleeve
Cable ties
Power supply with cables
TANDBERG Remote Control and batteries
User Guide on CD
Registration card
TANDBERG
Precision
HD Camera
The Camera must
be installed properly
by aligning the
camera on the
xing bolt and the
magnets on the
camera bracket.*
PC
* Installation of the camera bracket with the
TANDBERG Flat Panel Display Option.
A wall mounted screen must have minimum
140 mm distance from the front of the screen
to the wall.
LAN/Ethernet
Microphone
Monitor
Power Supply
Desktop Use
Touch tonesSnapsho t
Camer a Preset s
TIP
If the menu is not already present, press
the OK/Menu key on the remote control
to open the menu. Navigate in the menu
with arrow keys and OK.
Please read the user documentation for further details.
D13922.06 MARCH 2008
Using the unit out of the box
Placing the unit on a shelf
Put it on the desktop, connect cables as shown to the far
right and it is ready to use.
CAUTION! Never place the unit as shown without the base
mounted!
Unscrew the base, using the enclosed screwdriver.Put the Edge codec on its back.
Turn the unit upside down and mount the rubber
feet over the screws. Insert the rubber plug in
the hole that held the screw just unscrewed.
Place the unit on the shelf.
1 2
3 4 Connect cables as shown to the right.
5
DVI-I to DVI-I
Composite
S-video
(optional)
CAUTION! Do not screw the screw back in if
the base has been removed and the bracket
is not to be used. Doing so may damage the
codec’s interior and will void the warranty.
Use the enclosed rubber plug instead.
Rubber plug
D1392205_Edge_Installation_Sheet_Feb08.indd 1 10.03.2008 09:56:24

Installation Sheet
TANDBERG Edge Wall Mounting
Recommended
mounting
DO NOT MOUNT IT HERE!
Alternative
mounting
Alternative
mounting




Equipment needed:
Caution!
Remove the monitor. Make sure there
is space for all
cables when the
monitor is put back
in place. Also make
sure that the cable
connections will be
well hidden behind
the monitor.
Recommended
Alt. 1
Alt. 2
Unscrew the base using the
enclosed screwdriver.
Put the Edge
codec on its back.
Bracket with screw
(included).
Screwdriver to
remove the base and
mount the bracket
(included).
Suitable screws (at
least 4×15) to mount
bracket on wall (not
included). Each screw
must be able to sustain
at least 10kg when
bracket is mounted.
Screwdriver to mount
bracket on wall (not
included).
Decide where to mount the Edge codec.
1 2 3
45 6
7 8
Mount the Edge codec (with all the cables connected) onto the bracket using the screw of the wall bracket. Mount the monitor and camera (see instructions overleaf) back in place.
Hose (sleeve) to
accommodate the
cables between
the codec and
the monitor and
camera (included).
Use screws in
all four holes for
mounting. Do not
rely on the center
hole alone.
Connect cables as shown overleaf.
D13922.06 MARCH 2008
Mount the bracket on the wall.
CAUTION! Never use other screws than the 20mm screw already attached to the wall
bracket. Do not remove this screw. Using other screws may damage the codec’s interior
and will void the warranty.
