T&S B-1200 Series User manual

w/ Hex Key
Adjustable Outlet
015588-40 (1) 015589-40 (1)
w/ Valve Spring
Valve Assembly 015550-45 (1) Lever Arm Repair Kit
w/ Screw and Nut
B-1256
Glass Filler Repair Kit
2 Saddleback Cove / P.O. Box 1088
Product Specifications:
Item No.
T&S BRASS AND BRONZE WORKS, INC.
04/10/15 1 Scale:
Model No.
JHB
JBC Approved:Drawn: Checked: 1:1Date:
JRM Sheet:
Travelers Rest, SC: 800-476-4103 • Simi Valley, CA: 800-423-0150 • Fax: [phone] • www.tsbrass.com
1of
Travelers Rest, SC 29690
This Space for Architect/Engineer Approval
Job Name__________________________Date_________
Model Specified_____________________ Quantity______
Customer/Wholesaler______________________________
Contractor_______________________________________
Architect/Engineer_________________________________
Product Compliance:
NSF 61 - Section 9
NSF 372 (Low Lead Content)

Limited One Year Warranty
T&S warrants to the original purchaser (other
than for purposes of resale) that such product
is free from defects in material and workman-
ship for a period of one (1) year from the date
of purchase. During this one-year warranty
period, if the product is found to be defective,
T&S shall, at its options, repair and/or replace
it. To obtain warranty service, products must
be returned to…
T&S Brass and Bronze Works, Inc.
Attn: Warranty Repair Department
2 Saddleback Cove
Travelers Rest, SC 29690
Shipping, freight, insurance, and other
transportation charges of the product to T&S
and the return of repaired or replaced product
to the purchaser are the responsibility of the
purchaser. Repair and/or replacement shall be
made within a reasonable time after receipt by
T&S of the returned product. This warranty does
not cover Items which have received secondary
finishing or have been altered or modified after
purchase, or for defects caused by physical
abuse to or misuse of the product, or shipment
of the products.
Any express warranty not provided herein,
and any remedy for Breach of Contract which
might arise, is hereby excluded and disclaimed.
Any implied warranties of merchantability or
fitness for a particular purpose are limited to
one year in duration. Under no circumstances
shall T&S be liable for loss of use or any special
consequential costs, expenses or damages.
Some states do not allow limitations on
how long and implied warranty lasts or the
exclusion or limitation of incidental or conse-
quential damages, so the above limitations or
exclusions may not apply to you. Specific rights
under this warranty and other rights vary from
state to state.
P/N: 098-016883-45 Rev.2
Date: 04-26-12
Drawn: TEH
Checked: JRM 04-30-12
Approved: JHB 05-01-12
Installation and
Maintenance
Instructions
B-1200 Series
Soft-Touch Glass Fillers
B-1200
B-1210

Exploded View
6
3
5
1
2
7
14
16
17
13
21
4
9
19
10
8
18
20
15
11
12
2
Wall Flange
Repair Kit
Lever
Repair Kit
Deck Flange
Repair Kit
Valve Repair
Kit

Glass Filler Assemblies
Item
1
2
3
4
5
6
8
9
10
11
12
13
14
15
16
17
18
19
7
21
20
Description
Tailpiece, 1/4” Sweat
Locknut
Nut, Coupling
Nipple, 3/8” Supply
Washer
Body, Glass Filler
Glass Filler Lever Repair Kit
Lever Arm
Screw, Handle
Nut, Handle
Adapter, 3/8” NPT-M x 7/8-18-M / 3/8” NPT-F
Glass Filler Wall Flange Repair Kit
Adjustable Wall Flange
Locknut, B-1200
Pedestal, 4”, 8”, 10”, 12” or 16”, Varies by Model
Glass Filler Deck Flange Repair Kit
Flange, B-1210
Washer, Pedestal
Locknut, Shank
Nipple, 3/8” Close
Adapter, 3/8” NPT x 1/2” NPT
Glass Filler Valve Repair Kit
Spring, Valve Stem
Valve Assembly
Glass Filler Outlet Repair Kit
Sales No.
000852-20
000716-20
000715-20
000379-20
N/A
N/A
015550-45
N/A
N/A
N/A
N/A
016782-40
N/A
N/A
N/A
016783-40
N/A
N/A
N/A
002535-25
N/A
015589-40
N/A
N/A
015588-40
Part Number Guide
3
Specific items used for B-1200: 12, 13, 18
Specific items used for B-1202: 1-5, 11-13
Specific items used for B-1204: 19
Specific items used for B-1205: 18
Items 14-17 used for models: B-1210 - 8” Pedestal
B-1210-01 - 10” Pedestal
B-1210-12 - 12” Pedestal
B-1211 - 4” Pedestal
*B-1256 includes Lever, Valve and Outlet Repair Kits
*
*
*

4
Installation: (B-1200)
1. Turn off water supply and drain
lines. Hand tighten no.12 firmly
against no.6and remove no.13 from
no.11.
12
Installation: (B-1210)
1. Turn off water supply and drain
lines.
2. Unscrew and remove no.16 and
no.17 from no.14. Position no.15 to
cover threads of no.14.
3. Place no.14 through 7/8” hole in
countertop. Replace no.16 and no.17
onto no.14 and tighten with a wrench
at bottom side of countertop.
11 13
2. Drill 7/8” hole in sheet metal.
Insert no.6through hole and screw
no.13 on back of no.6, leaving no.12
free to turn.
3. Apply teflon tape or pipe joint
compound to threads of water supply
line. Connect no.6to water supply
line outlet, tightening as far as pos-
sible.
4. Tighten no.12 and no.13 so they
are flush against surface of sink back.
5. Turn on water supply and check
for leaks.
Flow Adjustment:
To adjust water flow, use included
T-45 Torx wrench & inserting it into
no.20 turn clockwise to increase
water flow, turn counterclockwise to
reduce water flow.
14
15
17
16
4. Apply teflon tape or pipe joint
compound to threads of no.14,
connect to water supply line inlet.
5. Turn on water supply and check for
leaks.
To adjust water flow see flow
adjustment note for B-1200 model.
6
General Instructions
sink back
6
20
20

For Retro-Fit of Glass Filler Only
1. Turn off water supply and drain lines.
2. Heat cube & unscrew glass filler from cube.
3. Apply Loctite 680, teflon tape or joint compound to the threads of no.6.
Screw into cube of no.14, then align and tighten no.6. Let Loctite 680 sit for 20
minutes.
4. Turn on water supply and check for leaks.
General Instructions
14
15
17
16
6
5
cube
For Glass Filler Valve Repair Kit
1. Unscrew no.21 with flathead screwdriver.
2. Remove no.7spring.
3. Place new no.21 and no.7into no.6.
4. Screw no.21 until flush with no.6.
6
7
21
