Targus Bluetooth Numeric Keypad User manual

AKP03CA / 410-1012-002D
30
Bluetooth®
Numeric Keypad
with PC
Multimedia Control
Bluetooth Qualified Product ID# B03885
USER GUIDE
MANUEL DE
L'UTILISATEUR
Visitez notre Site: www.targus.com/ca
Caractéristiques et spécifications sujettes à modification sans
préavis. ©2008 Targus Group International, Inc. et Targus, Inc.
Visit our Website at www.targus.com/ca
Features and specifications subject to change without notice.
©2008 Targus Group International, Inc. and Targus, Inc.
Clavier numérique
Bluetooth®
avec contrôle
multimédia PC

Table of Contents
English
Français
Bluetooth®Numeric Keypad with PC Multimedia Control.......2
Clavier numérique Bluetooth®avec contrôle multimédia PC...16
1

BLUETOOTH®NUMERIC
KEYPAD WITH PC
MULTIMEDIA CONTROL
Introduction
Congratulations on your purchase of the Targus Bluetooth Numeric
Keypad with PC Multimedia Control. This keypad has a set of built-in
media keys for easy wireless multimedia control. Its 33 feet / 10 meter
operating range of Class II Bluetooth allows seamless connection, and
is perfect for remote controlling your favorite media player.
• User Guide
• Bluetooth Media Keypad
• 2 x AA Batteries
Operating System
• Windows®2000 / XP
• Windows VistaTM
Hardware
• Bluetooth-enabled notebook or desktop PC
Contents
System Requirements
2

1 Remove the battery cover from the back of the keypad.
2 Insert the supplied battery, making sure that the positive (+) and
negative (-) ends match the polarity indicators inside the battery
housing.
NOTE: WHEN REPLACING THE BATTERY, YOU MAY USE ALKALINE OR OTHER
HEAVY-DUTY NIMH BATTERY.
AVOID MIXING NEW AND USED BATTERIES IN A DEVICE.
3 Slide the battery cover back into position until it “clicks” firmly into
place.
Keypad - back view
Installing the Battery
Targus Bluetooth Numeric Keypad with PC Multimedia Control
• To power on the device, use the on/off switch located on the back of
the keypad.
• To power off the device, use the on/off switch located on the back of
the keypad. This feature should be used when traveling to prevent
power loss.
Turning the Keypad On and Off
3

Targus Bluetooth Numeric Keypad with PC Multimedia Control
Enter
Using the Keypad
Definition of the Keys:
Function How to operate
Keys
Play, Pause
STOP
MUTE
Decrease Volume
Increase Volume
Skip to next track
Return to previous track
Fast forward
Reverse
Press to start or pause playing.
Press to stop playing.
Press this key to mute volume.
Press this key to turn down volume.
Press this key to turn up volume.
Press
this key to return to previous track.
Press this key to skip to next track.
Press this key to speed forward play.
Press
this key to speed backward play.
NOTE: THE MULITMEDIA KEYS ARE COMPATIBLE TO MEDIA PLAYERS COMPATIBLE
TO MICROSOFT’S API. PLEASE REFER TO YOUR SOFTWARE VENDOR FOR YOUR
MEDIA PLAYER’S COMPATIBILITY.
Launch default media player
Press this key to launch the default media player.
The default player can be set in the “Set Program Access
and Defaults” under the start menu or control panel.
4

Targus Bluetooth Numeric Keypad with PC multimedia control
Definition of the Keys:

$EL
.UM,OCKÖONÖÖINSERTSÖAÖDECIMALÖPOINT
.UM,OCKÖOFFÖÖDELETESÖAÖNUMBER

)NS
.UM,OCKÖONÖÖENTERSÖÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖEMULATESÖTHEÖ)NSERTÖKEY


.UM,OCKÖONÖÖENTERSÖgs
.UM,OCKÖOFFÖÖINSERTSÖAÖCOMMAÖÖÖ

%ND
.UM,OCKÖONÖÖENTERSÖÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖEMULATESÖTHEÖ%NDÖKEY
.UM,OCKÖONÖÖENTERSÖgsÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖMOVESÖTHEÖCURSORÖDOWNÖONEÖLINEÖ
OFÖTEXT

0G$N
.UM,OCKÖONÖÖENTERSÖgsÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖEMULATESÖTHEÖ0AGEÖ$OWNÖKEY
Ö

.UM,OCKÖONÖÖENTERSÖgsÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖMOVESÖONEÖCHARACTERÖTOÖTHEÖLEFTÖ
OFÖTHEÖCURSORÖPOSITION
.UM,OCKÖONÖÖENTERSÖÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖ.OÖFUNCTION
.UM,OCKÖONÖÖENTERSÖÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖMOVESÖONEÖCHARACTERÖTOÖTHEÖ
RIGHTÖOFÖTHEÖCURSORÖPOSITION

(OME
.UM,OCKÖONÖÖENTERSÖÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖEMULATESÖTHEÖ(OMEÖKEY
.UM,OCKÖONÖÖENTERSÖÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖMOVESÖTHEÖCURSORÖUPÖONEÖLINEÖOFÖ
TEXT

0G5P
.UM,OCKÖONÖÖENTERSÖgsÖONÖTHEÖDISPLAY
.UM,OCKÖOFFÖÖEMULATESÖTHEÖ0AGEÖ5PÖKEY
5

Targus Bluetooth Numeric Keypad with PC Multimedia Control
Establishing a Communications Link
Initial Configuration
Before you can begin using Bluetooth connectivity on your
computer and other Bluetooth devices, you must set up your
Bluetooth connection correctly. The Targus Bluetooth Media
Keypad is designed to work with the three major software stack
(protocol) standards: WIDCOMM, Toshiba and Microsoft. Please
check your computer’s documentation to see which software stack
your computer has. Please contact your system vendor if your
system does not support one of the following Bluetooth software
standards.
Connecting with Bluetooth Software:
WIDCOMM or Microsoft (XP & Vista)
1. Go to the Bluetooth Places icon located on your desktop or in the
system tray and double click, then click Add a Bluetooth Device.
(Windows XP) (Windows Vista)
6

Targus Bluetooth Numeric Keypad with PC Multimedia Control
2. The Bluetooth Wizard screen will prompt. Please follow the on-
screen instructions.
3. Please turn on the keypad and press the connection ID button
located at the bottom of the keypad until the LED above the “Num Lock”
blinks green light (discoverable mode). Click Next to continue pairing
and the computer will search for the keypad.
(Windows XP) (Windows Vista)
(Windows XP) (Windows Vista)
7

Targus Bluetooth Numeric Keypad with PC Multimedia Control
4. The confirmation window will appear after the computer finishes
detecting the Bluetooth devices. Select the Targus Keypad and click
Next to continue. (There may be one or more different Bluetooth
devices detected.) If the keypad is not detected, please make sure the
power is on and in discoverable mode. Press Search Again to re-pair
the device.
5. A passkey is required to pair the Bluetooth keypad. Please follow the
on-screen instuctions to finish installing the device.
(Windows Vista)
(Windows Vista)
(Windows XP)
(Windows XP)
8

Targus Bluetooth Numeric Keypad with PC Multimedia Control
6. After the pairing keys are entered correctly, the computer will
complete the installation. Please wait until the setup is finished.
Connecting with Bluetooth Software:
TOSHIBA
1. Double click on the Bluetooth Manager icon in the system tray, and
then click “Add New Connection.”
(Windows XP)
(Windows Vista)
9

Targus Bluetooth Numeric Keypad with PC Multimedia Control
2. Please turn on the keypad and press the connection ID button
located at the bottom of the keypad until the LED above the “Num
Lock” blinks green light (discoverable mode). Click Next to continue
pairing and the computer will search for the keypad.
3. The computer will now search for the Bluetooth keypad and other
Bluetooth devices. Please wait until the search is completed. Choose
the device you wish to connect.There may be more than one Bluetooth
device detected. Select Targus Bluetooth keypad and click Next to
continue. If the keypad is not detected, please make sure the keypad is
in discoverable mode and click Refresh.
10

Targus Bluetooth Numeric Keypad with PC Multimedia Control
4. The computer will begin connecting with the keypad.
11

Targus Bluetooth Numeric Keypad with PC Multimedia Control
5. An authentication is required for pairing the device, and a dialogue
will appear. Please correctly enter the passkey using the remote
keypad to continue setting up the device.
6. The connection is established and setup is complete. The keypad is
ready to use. If the connection is not successful, please click Back and
search the device again. You may want to continue to add other
Bluetooth devices or close the window.
12

Targus Bluetooth Numeric Keypad with PC Multimedia Control
What do I do if the keypad does not work?
• Make sure that the polarity of the battery is correct. The positive (+)
and negative (-) ends must match the positive (+) and negative (-)
connections in the battery housing.
• Make sure you have established a communications link. See
“Establishing a Communications Link.”
What do I do if the response time of the keypad is slow or it
intermittently stops working?
• Increase the distance between the receiver and the base units of
other wireless devices.
• Replace the battery.
Troubleshooting
13

Targus Bluetooth Numeric Keypad with PC Multimedia Control
Technical Support
For technical questions, please visit:
Internet: www.targus.com/support.asp
Email: [email protected]
Product Registration
Targus recommends that you register your Targus accessory
shortly after purchasing it. To register your Targus accessory, go
to: www.targus.com/registration.asp
You will need to provide your full name, email address, phone
number, and company information (if applicable).
Warranty
Targus warrants this product to be free from defects in materials
and workmanship for one year. If your Targus accessory is found
to be defective within that time, we will promptly repair or replace
it. This warranty does not cover accidental damage, wear and
tear, or consequential or incidental loss. Under no conditions is
Targus liable for loss of, or damage to a computer; nor loss of, or
damage to, programs, records, or data; nor any consequential or
incidental damages, even if Targus has been informed of their
possibility. This warranty does not affect your statutory rights.
Regulatory Compliance
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any
interference received, including interference that may cause
undesired operation.
14

Targus Bluetooth Numeric Keypad with PC Multimedia Control
FCC Statement
Te s t e d t o C o m p l y
This equipment has been tested and found to comply with the
limits of a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna;
• Increase the separation between the equipment and receiver;
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected;
• Consult the dealer or an experienced radio/TV technician for
help.
Changes or modifications not authorized by the party responsible
for compliance could void the user’s authority to operate this
product
Features and specifications subject to change without notice. All trademarks and
registered trademarks are the property of their respective owners.
WIDCOMM and the WIDCOMM logo are trademarks of WIDCOMM, Inc. Bluetooth
and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc., U.S.A. and
licensed to WIDCOMM, Inc..
Microsoft, Windows, Windows VIsta and Outlook are registered trademarks of
Microsoft Corporation. All other trademarks and registered trademarks are the
property of their respective owners.
15

CLAVIER NUMÉRIQUE
BLUETOOTH®
AVEC CONTRÔLE
MULTIMÉDIA PC
Introduction
Félicitations pour votre achat de ce Pavé numérique Bluetooth de
Targus avec commandes multimédia pour PC. Ce pavé possède un jeu
de touches multimédia incorporées pour le contrôle multimédia sans fil
facile. Sa portée de 33 pieds/10 mètres de Bluetooth Classe II permets
la connexion sans fil et s’avère parfaite pour la télécommande de votre
lecteur de médias préféré.
• Guide d’utilisateur
• Pavé numérique et multimédia Bluetooth
• 2 piles AA
Système d'exploitation
• Windows®2000 / XP
• Windows VistaMC
Matériel
• Ordinateur portable ou PC de bureau Bluetooth
Contenu
Configuration requise
16

1 Enlèvent le couvercle des piles au dos du pavé.
2 Insérez les piles fournies, en s’assurant que les bouts positif (+) et
négatif (-) correspondent aux indicateurs de polarité à l'intérieur du
logement des piles.
NOTE : POUR REMPLACER LES PILES VOUS POUVEZ UTILISER DES PILES
ALCALINES OU AUTRES HEAVY-DUTY NiMH. ÉVITEZ DE MÉLANGER DES PILES
NOUVELLES ET UTILISÉES DANS UN DISPOSITIF.
3 Glissez le couvercle des pilles en arrière dans sa position initiale
jusqu'à ce qu'il « clique » fermement à sa place.
Pavé numérique - vue arrière
Installation des piles
Targus Bluetooth Numeric Keypad with PC Multimedia Control
• Pour alimenter le dispositif, utilisez le commutateur « Marche/Arrêt »
placé à l'arrière du pavé.
• Pour arrêter l’alimentation du dispositif, utilisez le commutateur «
Marche/Arrêt » placé à l'arrière du pavé. Cette fonction devrait être
utilisée pendant le voyage pour empêcher la perte d’énergie.
Mise en marche et arrêt du pavé
numérique
17

Targus Bluetooth Numeric Keypad with PC Multimedia Control
Enter
Utilisation du pavé
Définition des touches
Fonction
Touches
Lecture, pause
ARRÊT
SOURDINE
Volume -
Volume +
Piste suivante
Piste précédente
Avance rapide
Retour
Appuyez sur ce bouton pour lancer une lecture ou la mettre en pause.
Appuyez sur ce bouton pour arrêter la lecture en cours.
Appuyez sur ce bouton pour couper le son.
Appuyez sur ce bouton pour baisser le volume.
Appuyez sur ce bouton pour augmenter le volume.
Appuyez sur ce bouton pour sélectionner sur la piste précédente.
Appuyez sur ce bouton pour sélectionner la piste suivante.
Appuyez sur ce bouton pour effectuer une avance rapide.
Appuyez sur ce bouton pour effectuer un retour rapide.
NOTE : LES TOUCHES MULTIMÉDIA SONT COMPATIBLES AUX LECTEURS DE MÉDIAS
COMPATIBLES AVEC L’API DE MICROSOFT. POUR LA COMPATIBILITÉ AVEC VOTRE
LECTEUR DE MÉDIAS VEUILLEZ VOUS RÉFÉRER À NOTRE VENDEUR DE LOGICIEL
Lancement du lecteur de
médias par défaut
Appuyez sur cette touche pour lancer le lecteur de médias
par défaut. Le lecteur par défaut peut être fixé par
“Déterminer l'Accès des programmes et les défauts” dans
le menu Démarrer ou dans le panneau de configuration
18

Targus Bluetooth Numeric Keypad with PC multimedia control
Définition des touches du clavier :
.
Del
NumLock allumé - insertion du signe
décimal
NumLock éteint - supprime un chiffre
0
Ins
NumLock allumé - insère un « 0 » sur
l'afficheur
NumLock éteint - émule la touche Insertion
00
,
NumLock allumé - insère « 00 »
NumLock éteint - insère une virgule ( , )
1
End
NumLock allumé - insère un « 1 » sur
l'afficheur
NumLock éteint - émule la touche Fin (End)
2NumLock allumé - insère « 2 » sur
l'afficheur
NumLock éteint - déplace le curseur sur la
ligne inférieure
3
PgDn
NumLock allumé - insère un « 3 » sur
l'afficheur
NumLock éteint - émule la touche Page
suivante
4 NumLock allumé - insère un « 4 » sur
l'afficheur
NumLock éteint - déplace le curseur un
caractère à gauche
5
NumLock allumé - insère « 5 » sur
l'afficheur
NumLock éteint - aucune fonction
6NumLock allumé - insère « 6 » sur
l'afficheur
NumLock éteint - déplace le curseur un
caractère à droite
7
Home
NumLock allumé - insère « 7 » sur
l'afficheur
NumLock éteint - émule la touche Début
8NumLock allumé - insère « 8 » sur
l'afficheur
NumLock éteint - déplace le curseur sur la
ligne supérieure
9
PgUp
NumLock allumé - insère « 9 » sur
l'afficheur
NumLock éteint - émule la touche Page
précédente
19
