Task Force Tips Ultimatic User manual

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
MANUAL: HAND HELD AUTOMATIC
PRESSURE CONTROL NOZZLES
ULTIMATIC, MID-MATIC & HANDLINE
INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE
WARNING Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at www.tft.
com/serial-number
This instruction manual is intended to familiarize fi refi ghters and maintenance personnel with the operation, servicing and safety
procedures associated with the Ultimatic, Mid-Matic and Handline fi re fi ghting nozzles.
This manual should be kept available to all operating and maintenance personnel.
TASK FORCE TIPS, INC.
MADE IN USA • www.tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
MID-MATIC
with Lever Handle
ULTIMATIC
with Lever Handle
HANDLINE
with Lever Handle
ULTIMATIC
with IMPULSE Trigger
Valve System
MID-MATIC
with IMPULSE Trigger
Valve System

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
2
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
3.1 VARIOUS MODELS AND TERMS
3.2 SPECIFICATIONS
3.2.1 MECHANICAL
3.3 NOZZLE COUPLINGS
3.4 USE WITH SALT WATER
4.0 FLOW CHARACTERISTICS
4.1 NOZZLE FLOW CHARTS
4.2 REACH AND TRAJECTORY
4.3 ULTIMATIC INITIAL OPENING ADJUSTMENT
OPTION
5.0 NOZZLE CONTROLS
5.1 FLOW CONTROL
5.1.1 LEVER TYPE FLOW CONTROL
5.1.2 TIP ONLY
5.1.3 BALL SHUT-OFF
5.1.4 TWIST SHUT-OFF
5.1.5 IMPULSE TRIGGER FLOW CONTROL
5.1.5.1 IMPULSE TRIGGER LOCK
5.1.5.2 IMPULSE TRIGGER CLOSING
SPEED ADJUSTMENT
5.1.5.3 NORMAL OPERATING POSITION
5.2 PATTERN AND FLUSH CONTROL ADJUSTMENT
5.2.1 PATTERN CONTROL
5.2.2 FLUSH CONTROL
6.0 USE WITH FOAM
6.1 FOAM ASPIRATING ATTACHMENTS
7.0 USE OF NOZZLES
8.0 APPROVALS
9.0 COLOR CODED VALVE HANDLE AND PISTOL GRIP
9.1 IMPULSE TRIGGER VALVE SYSTEM NOZZLE COL-
ORED PISTOL GRIPS
10.0 WARRANTY
11.0 MAINTENANCE
11.1 FIELD LUBRICATION
11.2 IMPULSE TRIGGER VALVE LUBRICATION
11.3 SERVICE TESTING
11.3.1 HYDROSTATIC TESTING
11.3.2 FLOW TESTING
11.3.3 RECORDS
11.4 REPAIR
12.0 OPERATION and INSPECTION CHECKLIST
Table Of Contents
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Firefi ghting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Firefi ghting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufacturers and Service Association
P.O. Box 147, Lynnfi eld, MA 01940 • www.FEMSA.org

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
3
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identifi ed by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI standard Z535.6-2011, the defi nitions of the four signal words are as follows:
DANGER DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE NOTICE is used to address practices not related to physical injury.
SAFETY INSTRUCTIONS (or equivalent) signs indicate specifi c safety-related instructions of procedures
2.0 SAFETY
DANGER An inadequate supply of nozzle pressure and/or fl ow will cause an ineff ective stream and can
result in injury, death, or loss of property. See fl ow graphs or call 800-348-2686 for assistance.
WARNING The nozzle may be damaged if frozen while containing signifi cant amounts of water. Such
damage may be diffi cult to detect visually and can lead to possible injury or death. Any time the
nozzle is subject to possible damage due to freezing, it must be tested by qualifi ed personnel
before being considered safe for use.
WARNING This equipment is intended for use by trained personnel for fi refi ghting. Their use for other
purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
WARNING Failure to restrain nozzle reaction can cause fi refi ghter injury from loss of footing and/or stream
protection. Nozzle reaction will vary as supply conditions change: such as opening or closing
other nozzles, hose line kinks, changes in pump settings, etc. Changes in spray pattern or
fl ushing will also aff ect nozzle reaction. The nozzle operator must always be prepared in the
event of these changes.
WARNING If nozzle gets out of control or away from operator, retreat from nozzle immediately. Do not
attempt to regain control of nozzle while fl owing water. Injury from whipping can occur.
WARNING Water is a conductor of electricity. Application of water on high voltage equipment can cause
injury or death by electrocution. The amount of current that may be carried back to the nozzle
will depend on the following factors:
• Voltage of the line or equipment
• Distance from the nozzle to the line or equipment
• Size of the stream
• Whether the stream is solid or broken
• Purity of the water1
1 The Fire Fighter and Electrical Equipment, The University of Michigan Extension Service, Fourth Printing 1983. Page 47
CAUTION Fire streams are capable of injury and damage. Do not direct water stream to cause injury or
damage to persons or property.
3.0 GENERAL INFORMATION
The Task Force Tips Ultimatic, Mid-Matic and Handline nozzles are designed to provide excellent performance under most fi re
fi ghting conditions. Their rugged construction is compatible with the use of fresh water (see section 3.4 for saltwater use) as well as
fi re fi ghting foam solutions. Other important operating features are:
Slide valve for excellent stream quality at all valve positions
• Quick-acting pattern control from straight stream to wide fog
• Stainless Steel Spinning Teeth or Molded Rubber for full-fi lled fog pattern
• “Gasket grabber” inlet screen to keep large debris from entering nozzle
• Easily fl ushable while fl owing to clear trapped debris
• TFT’s fi ve-year warranty and unsurpassed customer service

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
4
3.1 VARIOUS MODELS AND TERMS
SERIES FLOW RANGE NOMINAL PRESSURE STANDARD COUPLING*
GPM L/min PSI BAR
ULTIMATIC
ULTIMATIC and IMPULSE
TRIGGER VALVE SYSTEM
10-125 40-500 100 7 1,1-1/2 NH or 1-1/2 NPSH
10-100 40-400 75 5 1,1-1/2 NH or 1-1/2 NPSH
MID-MATIC
MID-MATIC and IMPULSE
TRIGGER VALVE SYSTEM
70-200 260-760 100 7 1-1/2 NH
70-200 260-680 75 5 1-1/2 NH
70-180 260-680 55 3 1-1/2 NH
HANDLINE 95-300 360-1140 100 7 1-1/2 or 2-1/2 NH
95-250 360-950 75 5 1-1/2 or 2-1/2 NH
95-225 360-850 55 3 1-1/2 or 2-1/2 NH
* Other threads, coupling sizes, or connector styles can be specifi ed at time of order.
Ultimatic, Mid-Matic and Handline nozzles are available in several models. Some common models are shown in fi gure 1.
NOZZLE WITH VALVE
and INTEGRAL PISTOL GRIP
TIP ONLY NOZZLE
COUPLING
RUBBER
GASKET
PISTOL
GRIP
STREAM
SHAPER
ON
F
L
O
W
C
O
N
T
R
O
L
OFF
BARREL LABEL
NAME LABEL
VALPARAISOIN 46383-6040 +1.219.462.6161 800.348.2686
VALVE HANDLE
NOZZLE WITH VALVE TIP ONLY NOZZLE
WITH TWIST SHUTOFF
VALVE POSITION
LABEL
GASKET
GRABBER
INLET
SCREEN
DETENTS
VALVE RING
NOZZLE WITH IMPULSE TRIGGER VALVE SYSTEM
OFFON
TRIGGER
4 POSITION LOCK
Figure 3.1 COMMON MODELS AND TERMS

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
5
3.2 SPECIFICATIONS
3.2.1 MECHANICAL
Maximum nozzle inlet pressure with
valve shutoff
Ultimatic 800 psi 55 bar
Mid-Matic 300 psi 21 bar
Handline 300 psi 21 bar
Operating temperature range of fl uid 33 to 120º F 1 to 50º C
Storage temperature range -40 to 150º F -40 to 65º C
Materials used Aluminum 6000 series hard anodized
MIL8625 class 3 type 2, stainless steel
300 series, nylon 6-6, nitrile rubber
3.3 NOZZLE COUPLINGS
Many inlet couplings such as NH (National Hose) or NPSH (National Pipe Straight Hose) can be specifi ed at time of order.
CAUTION Nozzle must be mated to a hose line with matched threads. Mismatched or damaged threads may
cause nozzle to leak or uncouple under pressure and could cause injury.
CAUTION Dissimilar metals coupled together can cause galvanic corrosion that can result in the inability
to unscrew the threads or complete loss of thread engagement over time. Per NFPA 1962, if
dissimilar metals are left coupled together an anti-corrosive lubricant should be applied to the
threads. Also the coupling should be disconnected and inspected at least quarterly.
3.4 USE WITH SALT WATER
Use with saltwater is permissible provided nozzle is thoroughly cleaned with fresh water after each use. The service life of the nozzle
may be shortened due to the eff ects of corrosion and is not covered under warranty.
4.0 FLOW CHARACTERISTICS
The graphs in fi gure 4 show the typical performance of ULTIMATIC, MID-MATIC, and HANDLINE nozzles.
SPECIAL CONFIGURATIONS If nozzles are made according to the special marking or performance requirements of the fi re
department then the operating characteristics may diff er from the published data in this manual. Repair parts specifi c to each serial
number may diff er from those shown in the service procedure. The required parts for each serial number are available on-line by
entering www.tft.123456 with the numbers corresponding to the serial number engraved on the product.
FLOW (GPM)
NOZZLE PRESSURE (PSI)
0
20
40
60
80
100
120
140
02040 24060 80 100 120 140 160 180 200 220 260 280 300 320 340 360
MID-MATIC
ULTIMATIC
HANDLINE
MID-MATIC
FLOW RANGE
HANDLINE
FLOW RANGE
ULTIMATIC
FLOW RANGE
200 400 600 800 1000 1200
FLOW (GPM)
FLOW (LPM)
2
4
6
8
NOZZLE PRESSURE (BAR)
100 PSI (7 BAR) ULTIMATIC, MID-MATIC & HANDLINE

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
6
NOZZLE PRESSURE (PSI)
0
20
40
60
80
100
120
140
0 20 40 24060 80 100 120 140 160 180 200 220 260 280
HANDLINE
FLOW RANGE
200 400 600 800 1000
FLOW (GPM)
FLOW (LPM)
2
4
6
8
NOZZLE PRESSURE (BAR)
75 PSI ULTIMATIC 75 PSI MID-MATIC
ULTIMATIC
FLOW RANGE
MID-MATIC
FLOW RANGE
75 PSI HANDLINE
75 PSI (5 BAR) ULTIMATIC, MID-MATIC & HANDLINE
50
60
70
80
HMK and HK Series
0
10
20
30
40
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210
Nozzle Pressure (psi)
Flow (GPM)
Nozzle Pressure (bar)
Mid-Matic
Handline
2
4
5
3
1
Flow (l/min)
200 400 600 800
100 300 500 700
55 PSI (3 BAR) MID-MATIC & HANDLINE
Figure 4.0 - Flow Characteristic Graphs
4.1 NOZZLE FLOW CHARTS
The following charts give specifi c examples of maximum fl ow rates for particular situations. Friction losses may vary due to diff erences
in hose construction resulting in fl ows diff erent than those shown. For situations or lengths of hose not listed on the chart, approximate
fl ows can be calculated using conventional hydraulics.

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
7
4.1 NOZZLE FLOW CHARTS
ULTIMATIC 125 Flow Chart
150 ft. 150 ft. 150 ft.200 ft. 200 ft. 200 ft.250 ft. 250 ft. 250 ft.
125
350
600
300
500
250
450
225
400
200
175
150
PUMP DISCHARGE PRESSURE (PSI)
3/4" HOSE 1" HOSE 1 1/2" HOSE
100 PSI 100 PSI 100 PSI100 PSI 100 PSI 100 PSI 100 PSI100 PSI100 PSI75 PSI 75 PSI 75 PSI 75 PSI 75 PSI75 PSI75 PSI75 PSI75 PSI
10
16
20
23
26
29
34
38
42
46
49
55
—
13
17
20
22
25
29
33
36
39
42
48
—
11
15
18
20
22
26
29
32
34
37
42
23
34
42
50
56
62
72
80
90
98
105
120
20
29
36
42
48
52
62
70
78
84
90
100
18
26
32
38
42
46
54
62
68
74
80
90
70 60 50
100
125
85
110
125
75
95
110
125
————
—————
————— —
————— —
————— —
————— —
——
——— —
————— —
————— —
22
25
27
30
32
34
38
42
45
52
57
49
19
21
24
26
28
30
33
37
39
42
45
50
17
19
21
23
25
27
30
33
35
38
40
44
53
61
68
75
82
88
99
109
117
—
—
—
47
54
60
66
71
77
86
95
103
110
117
—
42
49
55
60
65
69
78
85
93
99
106
117
108
125
89
106
118
—
97
114
—
(1) Number in each box indicates flow (GPM). (2) Flows may vary with brand or condition of hose.
(3) Flows are approximate and do not reflect losses in preconnect piping.
FLOW (GPM)
= 75 PSI ULTIMATIC= 100 PSI ULTIMATIC 75 PSI100 PSI
ULTIMATIC 125 Flow Chart
45M 45M. 45M60M 60M 60M75M 75M 75M
8.6
24
41
21
34
17
31
15.5
28
14
12
10
PUMP DISCHARGE PRESSURE (BAR)
19mm HOSE 25mm HOSE 38mm HOSE
7 BAR 7 BAR5 BAR
(1) Number in each box indicates flow (LPM). (2) Flows may vary with brand or condition of hose.
(3) Flows are approximate and do not reflect losses in preconnect piping. (4) 1 BAR = 100 KPA
FLOW (LPM)
= 7 BAR ULTIMATIC = 6 BAR ULTIMATIC
5 BAR
7 BAR
40
60
75
85
100
110
130
145
160
175
185
210
85
95
100
115
120
130
145
160
170
185
195
215
----
50
65
75
85
95
110
125
135
150
160
180
70
80
90
100
105
115
125
140
150
160
170
190
----
40
55
70
75
85
100
110
120
130
140
160
65
70
80
85
95
100
115
125
130
145
150
165
7 BAR 5 BAR5 BAR 7 BAR 7 BAR 7 BAR 7 BAR 7 BAR 7 BAR5 BAR 5 BAR 5 BAR 5 BAR 5 BAR 5 BAR
75
110
135
160
180
195
235
265
295
320
340
380
180
205
225
250
270
290
325
360
390
415
445
----
85
130
160
190
210
235
275
305
340
370
395
455
200
230
255
285
310
335
375
415
445
----
----
----
70
100
120
145
160
175
205
235
255
280
305
340
160
185
210
225
245
260
295
320
350
375
400
445
265
380
475
----
----
----
----
----
----
----
----
----
410
475
----
----
----
----
----
----
----
----
----
----
225
320
415
475
----
----
----
----
----
----
----
----
365
430
----
----
----
----
----
----
----
----
----
----
190
285
360
415
475
----
----
----
----
----
----
----
335
400
445
----
----
----
----
----
----
----
----
----

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
8
(1) Number on top in each box indicates flow (GPM), and number on bottom indicates nozzle reaction (LBS).
(2) Flows may vary with brand or condition of hose. (3) Flows are approximate and do not reflect losses in preconnect piping.
150 ft. 150 ft. 150 ft.200 ft. 200 ft. 200 ft.250 ft. 250 ft. 250 ft.
50
225
200
175
150
125
100
75
21
31
65
93
117
140
162
183
8
13
30
45
59
72
84
94
49
61
86
115
141
165
187
208
16
24
37
51
63
73
81
88
21
29
59
84
105
124
141
158
7
12
27
40
52
63
73
82
48
59
77
101
123
142
160
176
15
23
33
44
55
63
71
78
21
28
55
77
96
112
128
142
7
12
25
37
47
57
65
73
46
57
71
92
110
128
143
157
14
21
30
40
49
57
64
70
21
23
72
108
141
174
204
---
8
14
34
54
72
90
105
---
51
65
102
142
178
214
---
---
17
27
45
63
79
90
---
---
21
32
67
97
125
151
175
198
8
14
32
48
63
78
91
102
50
62
91
124
153
179
204
222
16
25
40
55
68
79
87
95
21
31
63
91
114
136
157
176
7
13
29
44
57
70
81
91
49
60
84
111
137
159
179
198
16
24
36
49
61
70
79
86
22
36
84
135
196
---
---
---
8
15
41
69
101
---
---
---
52
69
137
216
---
---
---
---
18
29
61
91
---
---
---
---
22
35
79
122
168
212
---
---
8
15
38
62
87
109
---
---
52
68
120
175
221
---
---
---
18
28
53
77
95
---
---
---
22
34
75
113
151
187
222
---
8
15
36
57
78
97
113
---
51
66
108
155
195
224
---
---
17
27
48
69
85
98
---
---
PUMP DISCHARGE PRESSURE (PSI)
1 1/2" HOSE 1 3/4" HOSE 2" HOSE
100 PSI 100 PSI 100 PSI100 PSI 100 PSI 100 PSI 100 PSI100 PSI100 PSI75 PSI 75 PSI 75 PSI 75 PSI 75 PSI75 PSI75 PSI75 PSI75 PSI
FLOW (GPM)
REACTION
(LBS)
= 100 PSI MID-MATIC 75 PSI100 PSI = 75 PSI MID-MATIC
250 202
104
221
96
174
90
198
79
155
80
179
69
---
---
---
---
---
---
---
---
---
---
---
---
218
112
---
---
194
100
215
91
---
---
---
---
Flow & Nozzle Reaction Chart
MID-MATIC
Flow & Nozzle Reaction Chart
MID-MATIC
7 BAR 7 BAR7 BAR7 BAR 7 BAR 7 BAR 7 BAR 7 BAR5 BAR 5 BAR 5 BAR 5 BAR5 BAR 5 BAR 5 BAR 5 BAR 5 BAR
(1) Number on top in each box indicates flow (LPM), and number on bottom indicates nozzle reaction (KG).
(2) Flows may vary with brand or condition of hose. (3) Flows are approximate and do not reflect losses in preconnect piping.
45M 45M 45M60M 60M 60M75M 75M 75M
PUMP DISCHARGE PRESSURE (BAR)
38mm HOSE 45mm HOSE 50mm HOSE
7 BAR
FLOW (LPM)
REACTION
(KG)
3.5
5.2
7
8.6
10
12
14
15.5
17
= 5 BAR MID-MATIC
5 BAR
7 BAR = 7 BAR MID-MATIC
80
115
245
350
445
530
615
695
765
4
6
14
20
27
33
38
43
47
210
350
460
540
615
680
740
790
835
8
14
19
24
28
31
35
40
44
80
110
225
320
395
470
535
600
660
3
5
12
18
24
29
33
37
41
190
315
405
475
540
600
655
705
750
7
12
16
20
24
27
30
33
36
80
105
210
290
365
425
485
535
585
175
285
365
430
490
540
590
635
680
3
5
11
17
21
26
30
33
36
6
11
15
18
21
24
26
29
31
80
85
275
410
535
660
770
----
----
245
420
540
650
740
805
----
----
----
4
6
15
25
33
41
48
----
----
10
17
24
30
35
41
----
----
----
80
120
255
365
475
570
660
750
825
225
380
490
575
660
725
785
835
----
4
6
15
22
29
35
41
46
51
9
15
20
25
30
35
39
44
----
80
115
240
345
430
515
595
665
735
205
345
445
520
600
660
715
770
815
3
6
13
20
26
32
37
41
45
8
14
18
23
26
30
34
38
41
85
135
320
510
740
----
----
----
----
310
535
695
805
----
----
----
----
----
4
7
19
31
46
----
----
----
----
12
23
33
41
----
----
----
----
----
85
130
300
460
635
800
----
----
----
285
485
630
750
----
----
----
----
----
4
7
17
28
40
50
----
----
----
11
20
29
36
43
----
----
----
----
85
130
285
430
570
710
840
----
----
255
450
580
690
775
845
----
----
----
4
7
16
26
35
44
51
----
----
10
19
25
32
38
45
----
----
----

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
9
(1) Number on top in each box indicates flow (GPM), and number on bottom indicates nozzle reaction (LBS).
(2) Flows may vary with brand or condition of hose. (3) Flows are approximate and do not reflect losses in preconnect piping.
150 ft. 150 ft. 150 ft.200 ft. 200 ft. 200 ft.250 ft. 250 ft. 250 ft.
50
225
200
175
150
125
100
75
1 1/2" HOSE 1 3/4" HOSE 2" HOSE
100 PSI 100 PSI 100 PSI100 PSI 100 PSI 100 PSI 100 PSI100 PSI100 PSI75 PSI 75 PSI 75 PSI 75 PSI 75 PSI75 PSI75 PSI75 PSI75 PSI
FLOW
(GPM)
REACTION
(LBS)
= 100 PSI HANDLINE 75 PSI100 PSI = 75 PSI HANDLINE
250
150 ft. 200 ft. 250 ft.
2-1/2" HOSE
100 PSI 100 PSI100 PSI 75 PSI 75 PSI75 PSI
PUMP DISCHARGE PRESSURE (PSI)
47
59
85
100
126
142
165
185
201
16
25
42
50
55
75
87
98
106
49
64
96
123
145
166
185
201
217
17
26
41
55
65
76
85
94
102
46
58
69
90
111
130
146
161
174
15
23
31
45
55
66
75
85
92
47
60
84
109
127
145
160
176
189
15
24
35
44
56
65
73
81
87
45
56
65
82
101
117
134
146
157
14
30
30
40
49
60
67
86
83
45
57
75
98
116
130
145
157
170
15
23
32
43
51
58
65
72
79
50
60
82
120
150
178
203
227
247
18
26
40
61
78
95
109
124
135
51
72
115
147
177
204
222
250
269
18
31
50
67
82
95
105
119
123
49
59
76
107
128
156
177
197
216
17
25
36
55
65
83
94
106
116
50
66
102
130
156
174
198
216
233
17
27
45
57
68
78
94
101
110
47
58
72
97
122
142
160
177
194
16
25
35
108
63
75
84
94
103
48
63
92
118
141
160
180
194
209
16
25
40
54
64
73
74
90
98
52
63
100
142
197
239
275
310
320
19
27
50
74
106
130
151
172
180
53
90
148
198
240
278
296
314
330
20
39
66
93
114
134
152
174
190
51
62
91
137
175
210
243
270
295
18
34
58
80
98
115
130
146
163
18
26
45
71
93
113
123
148
164
51
80
127
175
210
242
271
290
305
50
61
85
126
149
190
218
242
265
18
25
41
65
79
101
118
132
145
51
75
120
157
190
217
244
267
285
18
32
53
72
88
102
115
127
140
53
65
135
245
323
351
375
---
---
20
30
70
134
182
217
252
---
---
54
122
255
300
327
352
376
---
---
20
55
121
155
187
220
247
---
---
52
65
127
223
312
340
362
---
---
19
30
65
120
175
204
231
---
---
53
115
222
290
317
340
364
---
---
20
51
105
146
177
203
252
---
---
52
65
122
205
281
330
352
373
394
19
30
63
110
155
190
217
245
270
53
110
205
280
307
330
352
375
395
20
44
108
135
165
191
219
247
275
Note: For Nozzles with Serial # TFT-H465101
and/or Manufactured after 12/01/2003
HANDLINE Flow & Nozzle Reaction Chart
(1) Number on top in each box indicates flow (LPM), and number on bottom indicates nozzle reaction (KG).
(2) Flows may vary with brand or condition of hose. (3) Flows are approximate and do not reflect losses in preconnect piping.
45M 45M 45M60M 60M 60M75M 75M 75M
3.5
15.5
14
12
10
8.6
7
5.2
38mm HOSE 45mm HOSE 50mm HOSE
7 BAR 7 BAR 7 BAR7 BAR 7 BAR 7 BAR 7 BAR7 BAR7 BAR5 BAR 5 BAR 5 BAR 5 BAR 5 BAR5 BAR5 BAR5 BAR5 BAR
FLOW
(LPM)
REACTION
(KG)
= 7 BAR HANDLINE 5 BAR7 BAR = 5 BAR HANDLINE
17
45M 60M 75M
65mm HOSE
7 BAR 7 BAR7 BAR 5 BAR 5 BAR5 BAR
PUMP DISCHARGE PRESSURE (BAR)
178
223
322
379
477
538
625
700
761
7
11
19
23
29
34
40
44
48
185
242
363
466
549
628
700
761
821
8
12
19
25
29
34
38
43
46
174
220
261
341
420
492
553
609
659
7
10
14
20
25
30
34
39
42
178
227
318
413
481
549
606
666
715
7
11
16
20
25
29
33
37
39
170
212
246
310
382
443
507
553
594
6
13
14
18
22
27
30
39
38
170
216
284
371
439
492
549
594
644
7
10
15
20
23
26
29
33
36
189
227
310
454
568
674
768
859
935
8
12
18
28
35
43
49
56
61
193
273
435
556
670
772
840
946
1018
8
14
23
30
37
43
48
54
56
185
223
288
405
625
591
670
746
818
8
11
16
25
29
37
37
48
53
189
250
386
492
591
659
700
818
882
8
12
20
26
31
35
43
46
50
178
220
273
367
462
538
606
670
734
7
11
16
49
29
34
38
42
47
182
238
348
447
534
606
681
734
791
7
11
18
25
29
33
38
41
44
197
238
379
538
746
905
1041
1173
1211
9
12
23
34
48
59
68
78
82
201
341
560
750
908
1052
1120
1189
1249
9
18
30
42
52
61
69
79
86
193
235
344
519
662
795
920
1022
1117
8
15
26
36
44
52
59
66
74
8
12
20
32
42
51
56
67
74
193
303
481
662
795
916
1026
1098
1155
189
231
322
477
564
719
825
916
1003
8
11
19
29
36
46
54
60
66
193
284
454
594
719
821
924
1011
1079
8
15
24
33
40
46
52
58
64
201
246
511
927
1223
1329
1420
---
---
9
14
32
61
83
98
114
---
---
204
462
968
1136
1238
1332
1423
---
---
9
25
55
70
85
100
112
---
---
197
246
481
844
1181
1287
1370
---
---
9
14
29
54
79
93
105
---
---
201
435
840
1098
1200
1287
1378
---
---
9
21
48
66
80
92
114
---
---
197
246
462
776
1064
1249
1332
1412
1491
9
14
29
50
70
86
98
111
122
201
416
776
1060
1162
1249
1332
1420
1495
9
20
49
61
75
87
99
112
125
HANDLINE Flow & Nozzle Reaction Chart
Note: For Nozzles with Serial # TFT-H465101
and/or Manufactured after 12/01/2003
The previous charts are specifi c examples of maximum fl ow rates for particular situations. Friction losses may vary due to diff erences
in hose construction resulting in fl ows diff erent than those shown. For situations or lengths of hose not listed on the chart, approximate
fl ows can be calculated using conventional hydraulics.

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
10
4.2 REACH AND TRAJECTORY
Care must be taken to avoid dents or nicks in the nozzle tip because they can seriously aff ect the stream reach.
All reach testing was taken in still air conditions at an elevation of 30 degrees.
MODEL
BGH-125
SHOWN
100 psi/ 7 bar Version
ULTIMATIC 100 PSI (7BAR) VERSION
Automatic Pressure Control Flow Range:
10-125 gpm @ 100 psi
40-500 l/min @ 7 bar
Ultimatic 100 psi (7 bar) Version
Curve A B C D E F A B C D E F
Flow (gpm) 10 25 50 75 100 125 (l/min) 38 95 189 284 379 473
Pressure (psi) 28 69 84 91 110 122 (bar) 1.9 4.8 5.8 6.3 7.6 8.4
Reaction (lbs) 3 1023365370 (kgf) 1 5 10 16 24 32
ULTIMATIC 75 PSI (5 BAR) VERSION
Automatic Pressure Control Flow Range:
10-100 gpm @ 75 psi
40-400 l/min @ 5 bar
75 psi/ 5 bar Version
Ultimatic 75 psi (5 bar) Version
Curve A B C D E A B C D E
Flow (gpm) 10 25 50 75 100 (l/min) 38 95 189 284 379
Pressure (psi) 26 46 59 69 80 (bar) 1.8 3.2 4.1 4.8 5.5
Reaction (lbs) 3 9 19 31 45 (kgf) 1 4 9 14 20

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
11
MODEL
HM-VPGI
SHOWN
100 psi/ 7 bar Version
MID-MATIC 100 PSI (7 BAR) VERSION
Automatic Pressure Control Flow Range:
70-200 gpm @ 100 psi
260-760 l/min @ 7 bar
Mid-Matic 100 psi (7 bar) Version
Curve A B C D E F A B C D E F
Flow (gpm) 70 95 125 150 175 200 (l/min) 265 360 473 568 662 757
Pressure (psi) 83 89 93 95 98 96 (bar) 5.7 6.1 6.4 6.6 6.8 6.6
Reaction (lbs) 32 45 61 74 87 99 (kgf) 15 20 28 34 39 45
MID-MATIC 75 PSI ( 5 BAR) VERSION
Automatic Pressure Control Flow Range:
70-200 gpm @ 75 psi
260-760 l/min @ 5 bar
75 psi/ 5 bar Version
Mid-Matic 75 psi (5 bar) Version
Curve A B C D E F A B C D E F
Flow (gpm) 70 95 125 150 175 200 (l/min) 265 360 473 568 662 757
Pressure (psi) 68 74 75 78 77 82 (bar) 4.7 5.1 5.2 5.4 5.3 5.7
Reaction (lbs) 29 41 55 67 78 91 (kgf) 13 19 25 30 35 41

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
12
MODEL
HM-VPGI
SHOWN
MID-MATIC 55 PSI (3 BAR) VERSION
Automatic Pressure Control Flow Range:
70-180 gpm @ 55 psi
260-680 l/min @ 3 bar
55 psi/ 3 bar Version
Mid-Matic 55 psi (3 bar) Version
Curve A B C D A B C D
Flow (gpm) 70 125 150 180 (l/min) 265 473 568 681
Pressure (psi) 38 47 52 64 (bar) 2.6 3.2 3.6 4.4
Reaction (lbs) 22 43 55 73 (kgf) 10 20 25 33
MODEL
H-VPGI
SHOWN
HANDLINE 100 PSI (7 BAR) VERSION
Automatic Pressure Control Flow Range:
95-300 gpm @ 100 psi
360-1150 l/min @ 7 bar
100 psi/ 7 bar Version
Handline, 100 psi (7 bar) Version
Curve A B C D A B C D
Flow (gpm) 95 125 200 300 (l/min) 360 473 757 1136
Pressure (psi) 91 100 100 126 (bar) 6.3 6.9 6.9 8.7
Reaction (lbs) 46 63 101 170 (kgf) 21 29 46 77

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
13
MODEL
H-VPGI
SHOWN
HANDLINE 75 PSI (5 BAR) VERSION
Automatic Pressure Control Flow Range:
95-250 gpm @ 75 psi
360-950 l/min @ 5 bar
75 psi/ 5 bar Version
Handline, 75 psi (5 bar) Version
Curve A B C D A B C D
Flow (gpm) 95 125 200 250 (l/min) 360 473 757 946
Pressure (psi) 68 72 78 81 (bar) 4.7 5.0 5.4 5.6
Reaction (lbs) 40 54 89 113 (kgf) 18 25 40 51
MODEL
H-VPGI
SHOWN
HANDLINE 55 PSI (3 BAR) VERSION
Automatic Pressure Control Flow Range:
95-225 gpm @ 55 psi
360-850 l/min @ 3 bar
55 psi/ 3 bar Version
Handline, 55 psi (3 bar) Version
Curve A B C D A B C D
Flow (gpm) 95 125 175 225 (l/min) 360 473 662 852
Pressure (psi) 48 52 60 71 (bar) 3.3 3.6 4.1 4.9
Reaction (lbs) 33 46 68 96 (kgf) 15 21 31 44

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
14
4.3 ULTIMATIC INITIAL OPENING ADJUSTMENT OPTION
Initial opening is the small gap between the back of the baffl e and the front of the nozzle’s discharge opening (barrel cone). This
small gap provides a small amount of fl ow until line pressure/fl ow reaches a point to starting moving the automatic control unit and
the baffl e forward allowing the rated fl ow range of the nozzle.
If no initial opening is desired the initial opening can be adjusted back to zero. Looking inside the inlet end of the nozzle there is a
small plastic screw. A long 7/32” hex wrench can be insert into the inlet end of the nozzle through the center of the debris screen then
down into the hex of the plastic screw. Turn the screw ¼ turn counterclockwise (unthreading it slightly from the valve plug) to set the
initial opening to approximately a zero gap size.
WARNING Once this adjustment is made the nozzle will fl ow little to no water at low pump pressures when
the valve handle is in the open position.
ADJUST INITIAL OPENING
SCREW HERE
BARREL CONE
BAFFLE
INITIAL OPENING GAP
Figure 4.3
ULTIMATIC Cut-A-Way

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
15
5.0 NOZZLE CONTROLS
Nozzle control valves must be opened slowly to eliminate unnecessary strain on the hose and couplings and reduce pressure surges.
5.1 FLOW CONTROL
5.1.1 LEVER TYPE FLOW CONTROL
On models that use a lever type valve handle, the nozzle is shut off when the handle is fully forward. The valve handle has detented
fl ow positions. These detent positions allow the nozzle operator to regulate the fl ow of the nozzle depending on the need or what
can be safely and eff ectively handled. TFT recommends the use of a pistol grip for easier handling. For additional stress reduction, a
hose rope or strap may also be used. This permits more eff ective use and ease of advancement, while minimizing strain and fatigue.
Nozzles attached to an in-service hose shall be stored in the off position
5.1.2 TIP ONLY
Tip only nozzles have NO shut-off valve within the nozzle and MUST be used
with a separate ball valve attached to the nozzle. Using a nozzle without a
shutoff is an unsafe practice and should never be done.
VALPARAISOIN 46383-6040 +1.219.462.6161 800.348.2686
5.1.3 BALL SHUTOFF
A separate ball valve for use with Tip Only nozzles is shut off when the valve handle is fully forward. Pulling back on the handle
opens the valve. Open valve slowly to avoid sudden changes in nozzle reaction. Close valve slowly to prevent water hammer. Note:
In partially open positions a ball valve will cause turbulence and adversely aff ect stream quality. Nozzles attached to an in-service
hose shall be stored in the off position.
5.1.4 TWIST SHUTOFF
On models that use a twist fl ow control, the valve is opened or closed by
rotating the valve ring. Rotating the ring clockwise (as seen from the operating
position behind the nozzle) closes the valve, while counterclockwise rotation
opens it. Detents are provided at four intermediate positions and the position
of the valve is shown by the exposed valve position label. Nozzles attached to
an in-service hose shall be stored in the off position.
5.1.5 IMPULSE TRIGGER FLOW CONTROL
NOTE: THE TRIGGER RETURNS TO OFF
IF NOT HELD OR LOCKED
OFFON
TRIGGER
LOCK
WARNING Do not intentionally release the nozzle while fl owing and trust the valve to shut off automatically.
The trigger nozzle’s ability to shut off by itself represents an extra level of safety when following
normal nozzle handling procedures. To rely on it as the sole means of safety increases the risk of
injury from an out of control nozzle. Release nozzle when fl ow has stopped.

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
16
5.1.5.2 TRIGGER FLOW CONTROL SPEED ADJUSTMENT
The IMPULSE valve contains a slow close mechanism to prevent the nozzle from slamming off if the trigger is suddenly released.
The closing speed is set at the factory to be slow enough to reduce water hammer, (“water hammer” is always present in any valve
when it is shut off . The slow close mechanism will reduce this but cannot eliminate it completely) but fast enough to reduce the
potential danger of hose whipping from a dropped nozzle. The closing speed may be adjusted as shown in the fi gure.5.1.5.2.
Slower
Close
Faster
Close
Do not unscrew the adjuster past the end of the hand grip (to unscrew it too far could result in the loss of dampening fl uid.)
WARNING As the closing time is increased so does the risk of injury from an out of control nozzle. A fl owing
nozzle can cause injury within the fi rst second of lost control. Use caution when adjusting the
closing speed and always verify performance after adjustment.
5.1.5.1 IMPULSE TRIGGER LOCK
Use an 1/8” (3mm) punch to push out pin
and remove lock if the lock is not desired.
LOCK
TRIGGER
LOCK PIVOT PIN
To Lock: Push on the lock while pulling back the trigger to
engage one of the four locked positions.
To Release: Pull back slightly on trigger without any pressure
on the lock. The spring loaded lock should automatically move to
the unlocked position.
WARNING When the trigger lock is engaged, the nozzle will not shut off if dropped. Always shut off nozzle
before releasing the pistol grip to avoid injury from an out of control nozzle.

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
17
5.2 PATTERN AND FLUSH CONTROL
5.2.1 PATTERN CONTROL
TFT’s nozzles have full pattern control from straight stream to wide fog. Turning the stream shaper clockwise (as seen from the
operating position behind the nozzle) moves the shaper to the straight stream position. Turning the shaper counterclockwise will
result in an increasingly wider pattern.
Since the stream trim point varies with fl ow, the stream should be “trimmed” after changing the fl ow to obtain the straightest and
farthest reaching stream. To properly trim the stream, fi rst open the pattern to narrow fog. Then close the stream to parallel to give
maximum reach. NOTE: Turning the shaper further forward will cause stream crossover and reduce the eff ective reach of the nozzle.
The nozzle reaction is greatest when the shaper is in the straight stream position. The nozzle operator must be prepared for a change
in reaction as the pattern is changed.
5.2.2 FLUSH CONTROL
Small debris passes through the debris screen (if equipped) and may get caught inside the
nozzle. This trapped material will cause poor stream quality, shortened reach, and reduced
fl ow. To remove small debris, the nozzle may be fl ushed as follows:
• While still fl owing water, rotate the shaper counterclockwise (as viewed from behind the
nozzle) to the fl ush position. (increased resistance will be felt on the SHAPER or RING
as the nozzle goes into fl ush) This will open the nozzle allowing debris to pass through.
• During fl ush the nozzle reaction will decrease as the pattern becomes wider and the
pressure drops. The nozzle operator must be prepared for an increase of nozzle
reaction when returning the nozzle from the fl ush position to retain control of the nozzle.
• Rotate the selector ring out of fl ush to continue normal operations.
FIGURE 3 - Debris Screen
WARNING Large amounts or pieces of debris may be unfl ushable and can reduce the fl ow of the nozzle
resulting in an ineff ective fl ow. In the event of a blockage, it may be necessary to retreat to a safe
area, uncouple the nozzle and remove debris.
5.1.5.3 NORMAL OPERATING POSITION
45°
15°
90°
45°
Horizontal
Slow Closer
Operating Range
Slow Closer
Operating Range
WARNING The Slow Close Feature relies on a fl uid and air combination in the pistol grip. For proper function,
the pistol grip should be within its normal operating position. The normal operating position
is with the nozzle horizontal or pointing up with the pistol grip within 45 degrees of vertical.
Releasing the trigger suddenly outside of the normal orientation will likely result in faster shut-off
causing a higher pressure spike and increasing the risk of a burst hose. Do not suddenly release
the trigger when operating outside of the nozzle’s normal orientation.

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
18
7.0 USE OF NOZZLES
IT IS THE RESPONSIBILITY OF THE INDIVIDUAL FIRE DEPARTMENT OR AGENCY TO DETERMINE PHYSICAL CAPABILITIES
AND SUITABILITY FOR AN INDIVIDUAL’S USE OF THIS EQUIPMENT.
Many factors contribute to the extinguishment of a fi re. Among the most important is delivering water at a fl ow rate suffi cient to absorb
heat faster than it is being generated. The fl ow rate depends largely on the pump discharge pressure and hose friction loss. It can be
calculated using a hydraulic equation such as:
PDP = NP+FL+DL+EL
PDP = Pump discharge pressure in PSI
NP = Nozzle pressure in PSI
FL = Hose friction loss in PSI
DL = Device loss in PSI
EL = Elevation loss in PSI
This manual is not intended to act as a training guide for safe
fi reground tactics and operations. For additional information visit
www.tft.com or contact customer service at 800-348-2686.
8.0 APPROVALS
Many nozzle confi gurations carry the FM Approval rating, NFPA certifi cation, or EN certifi cation.
9.0 COLOR CODED VALVE HANDLE AND PISTOL GRIP
TFT nozzles with lever type valve handles are supplied with black valve handle covers and pistol grips. The handle covers and pistol
grips are available from TFT in various colors for those departments wishing to color code the nozzle to the discharge controls. A
colored handle cover set will be sent upon receipt of the warranty card by TFT. Your department’s name can also be engraved on the
covers (see warranty card for more information).
Handle covers are replaceable by removing the four screws that hold the handle covers in place. Use a 3/32” allen wrench when
replacing screws. Pistol grip is replaceable by following TFT instruction sheet LTT-108.
For standardization NFPA 1901 (A-4-9.3) recommends the following color code scheme:
6.0 USE WITH FOAM
The nozzle may be used with foam solutions. Refer to fi re service training for the proper use of foam.
WARNING For Class B fi res, lack of foam or interruption in the foam stream can cause a break in the foam
blanket and greatly increase the risk of injury or death. Assure that:
• Application rate is suffi cient (see NFPA 11 or foam manufacturer’s recommendations)
• Enough concentrate is on hand to complete task (see NFPA for minimum duration time
requirements)
• Foam logistics have been carefully planned.
Allow for such things as:
• Storage of foam in a location not exposed to the hazard it protects
• Personnel, equipment and technique to deliver foam at a rapid enough rate
• Removal of empty foam containers
• Clear path to deliver foam, as hoses and other equipment and vehicles are deployed
WARNING Improper use of foam can result in injury or damage to the environment. Follow foam
manufacturer’s instructions and fi re service training to avoid:
• Using wrong type of foam on a fi re. i.e. Class A foam on a Class B fi re.
• Plunging foam into pools of burning liquid fi res.
• Causing environmental damage.
• Directing stream at personnel.
WARNING There are a wide variety of foam concentrates. Each user is responsible for verifying that any
foam concentrate chosen to be used with this unit has been tested to assure that the foam
obtained is suitable for the purpose intended.
WARNING Use of compressed air foam (CAF) with hand held nozzles can cause sudden surges in nozzle
reaction force resulting in risk of injury or death from loss of footing or hose whipping. Be
prepared for sudden changes in nozzle reaction caused by:
• Slug loading (Loss of foam concentrate sends slugs of air and water into the nozzle)
• Sudden release of built-up pressure in the hose when opening a nozzle
6.1 FOAM ASPIRATING ATTACHMENTS
Multi-expansion or low expansion aspirating attachments may be used with nozzles to increase the expansion ratio. These foam
tubes attach and detach quickly from the nozzle. As expansion ratio is increased, the reach of the nozzle will be decreased due to
the greater amount of bubbles in the stream and their ability to penetrate the air. Generally the straight stream reach with foam is
approximately 10% less than with water only. Actual results will vary based on brand of foam, hardness of water, temperature, etc.
For specifi c information, see LIA-025 (MANUAL: Foam Attachments for TFT Nozzles).

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
19
9.1 IMPULSE TRIGGER VALVE SYSTEM NOZZLE COLORED PISTOL GRIPS
The TFT Impulse Trigger Valve System nozzles are supplied with black pistol grip covers. The pistol grip covers are available from
TFT in various colors for those departments wishing to color code the nozzle to the discharge controls. Follow the steps below to
change the pistol grip cover.
Pistol Grip Cover
Cap
(1/2 in square drive)
Adjusting Screw
(3/16 in Allen Wrench)
1) Orient nozzle vertically. This keeps the dampening fl uid in the
pistol grip from spilling out.
2) Remove the Cap. (1/2 in square drive) The Adjusting Screw
(3/16 in Allen Wrench) may need to be turned in or removed
to be able to engage the square pocket in the cap. Note the
position of the Adjusting Screw before moving it.
3) Slide off the Pistol Grip Cover and install a new one. Be sure
the Pistol Grip Cover’s internal rib is toward the back of the
nozzle.
4) Reinstall the Cap until it bottoms out on its shoulder.
5) Reinstall or reposition the Adjusting Screw if it has been
moved from its original location.
6) Flow nozzle to check performance of slow closer. Adjust as
needed (see section 5.1.5.2).
10.0 WARRANTY
Task Force Tips, Inc., 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of
its nozzles (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and
workmanship during the fi ve (5) year period from the date of purchase.
TFT’s obligation under this warranty is specifi cally limited to replacing or repairing the equipment (or its parts) which are shown by
TFT’s examination to be in a defective condition attributable to TFT. To qualify for this limited warranty, the claimant must return the
equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA, within a reasonable time after discovery of the
defect. TFT will examine the equipment. If TFT determines that there is a defect attributable to it, TFT will correct the problem within
a reasonable time. If the equipment is covered by this limited warranty, TFT will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is
an intended or unintended benefi ciary of the equipment, shall not be entitled to recover from TFT any consequential or incidental
damages for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT. It is agreed
and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do not allow the
exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone
else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specifi c legal rights, and you may also have other rights which vary from state to state.
Preconnect #1 or Bumper Jump Line
Preconnect or discharge #2
Preconnect or discharge #3
Preconnect or discharge #4
Preconnect or discharge #5
Preconnect or discharge #6
Preconnect or discharge #7
Foam Lines
Orange
Red
Yellow
White
Blue
Black
Green
Red w/ White border (Red/White)
Other Colors Available:
• Gray
• Pink
• Purple
• Tan

©Copyright Task Force Tips, Inc. 2002 - 2016 LIN-030 May 19, 2016 Rev17
20
11.0 MAINTENANCE
TFT nozzles are designed and manufactured to be damage resistant and require minimal maintenance. However, as the primary
fi refi ghting tool upon which your life depends, it should be treated accordingly. To help prevent mechanical damage, do not drop or
throw equipment.
11.1 FIELD LUBRICATION
All Task Force Tips’ nozzles are factory lubricated with high quality silicone grease. This lubricant has excellent wash out resistance
and long term performance in fi refi ghting nozzles. If your department has unusually hard or sandy water, the moving parts of the
nozzle may be aff ected. Foam agents and water additives contain soaps and chemicals that may break down the factory lubrication.
The moving parts of the nozzle should be checked on a regular basis for smooth and free operation, and for signs of damage. IF THE
NOZZLE IS OPERATING CORRECTLY, THEN NO ADDITIONAL LUBRICANT IS NEEDED. Any nozzle that is not operating correctly
should be immediately removed from service.
The fi eld use of Break Free CLP (spray or liquid) lubricant will help to restore the smooth and free operation of the nozzle. However,
these lubricants do not have the washout resistance and long-term performance of the silicone grease. Therefore, re-application of
Break Free CLP will be needed on a regular basis. CAUTION: Aerosol lubricants contain solvents that can swell O-Rings if applied
in excess. The swelling can inhibit smooth operation of the moving parts. When used in moderation, as directed, the solvents quickly
evaporate without adversely swelling the O-Rings.
The nozzle can be returned to the factory for a complete checkup and re-lubrication with silicone grease
PART ONE — COUPLING DOWN
Position the nozzle at a 45-degree angle with the COUPLING end down.
CLOSE the valve handle and set the pattern to STRAIGHT STREAM. Then
spray a short burst into these areas:
#1 FRONT PATTERN CONTROL SEAL
Spray in between the pattern control and the barrel.
#2 PRESSURE CONTROL UNIT
Place check sticks behind baffl e while shaper is in fl ush. Cycle baffl e in and
out using check sticks several times to work lubrication into o-rings.
#3 FRONT SLIDER SEAL
a) Rotate shaper into FLUSH position.
b) Spray down the front end of the nozzle to dribble lubricant into the
clearances between the shaper and the valve body.
While holding nozzle at the angle, wait 30 seconds for the lubricant to penetrate into the clearances. Cycle the valve handle and
rotate the shaper from straight stream to full fl ush several times, and then proceed to the next section.
PART TWO — COUPLING UP
Position the nozzle at a 45-degree angle with the BUMPER end down.
OPEN the valve handle and set the pattern to FLUSH. Spray a short burst
in these areas:
#4 REAR SHAPER SEAL
Spray down the clearance between the label and the shaper guide.
#5 REAR SLIDER SEAL
Spray into the clearance between the slider and the valve body.
#6 FLUSH MECHANISM SEAL
a) With the handle on the top, spray down into the nozzle. The aerosol
extension tip will help direct the spray into clearances leading to the O-Ring.
b) Rotate nozzle so the valve is on the bottom and spray another short burst.
#7 DETENTS IN THE HANDLE
Spray a small amount on the detent followers located in the handle.
While holding nozzle at the angle, wait 30 seconds, then cycle the valve handle several times. Rotate the pattern control from straight
stream to full fl ush several times. The pattern control should move freely and easily. The barrel cone should move forward to within
1/16” of the baffl e before the shaper reaches straight stream position. Wipe off excess lubricant.
IF THIS PROCEDURE DOES NOT RESTORE SMOOTH AND FREE OPERATION OF ALL THE MOVING PARTS,
THEN FACTORY SERVICE IS NEEDED. • 24-HOUR HOT LINE — 800-348-2686 • www.tft.com
