Technogym D847M User manual

User manual ............................................................................. 3
Manuale per l’utente ............................................................. 41
Manuel de l’utilisateur ........................................................... 79
Benutzerhandbuch .............................................................. 117
Gebruikershandleiding ........................................................ 155
Manual del usuario .............................................................. 193
Guia do usuário ................................................................... 231
ユーザーマニュアル ................................................................ 269
用户指南 ..........................................................................................307
Technogym®, The Wellness Company™, Excite™ and CPR ™ (figurative) are trademarks owned by
Technogym® s.p.a. in Italy and other countries.
“TGS Key” refers to the mark illustrated here registered by Technogym® s.p.a. in Italy and
other countries.
Copyright © Technogym® s.p.a., October 2008
Technogym® is committed to a policy of continuous improvement and reserves the right to modify its
products and documentation without prior notice.
Technogym®, The Wellness Company™, Excite™ e CPR ™ (figurativo) sono marchi di proprietà
Technogym® s.p.a. in Italia e altri Paesi.
La denominazione “chiave TGS” si riferisce al marchio di forma qui a fianco rappresentato
registrato da Technogym® s.p.a. in Italia e in altri Paesi.
Copyright © Technogym® s.p.a., ottobre 2008
Technogym® si riserva il diritto di modifiche ai prodotti e alla documentazione senza obbligo di preavviso.
0SM00427AE-M1_02.indd 1 02/07/2010 15.32.36

Technogym®, The Wellness Company™, Excite™ et CPR ™ (figurative) sont des marques appartenant à
Technogym® s.p.a. pour l’Italie et d’autres pays.
La désignation “clé TGS” se réfère à la marque de forme représentée ci-contre enregistré par
Technogym® s.p.a. pour l’Italie et d’autres pays.
Copyright © Technogym® s.p.a., octobre 2008
Technogym® se réserve le droit de modifier ses produits et leur documentation sans aucune obligation de préavis.
Technogym®, The Wellness Company™, Excite™ und CPR ™ (bildmarke) sind Markenzeichen von Technogym®
s.p.a. in Italien und anderen Ländern.
Die Bezeichnung “TGS-Schlüssel” bezieht sich auf das nebenstehend abgebildete Markenzeichen,
das von Technogym® s.p.a. in Italien und anderen Ländern eingetragen ist.
Copyright © Technogym® s.p.a., Oktober 2008
Technogym® behält sich das Recht vor, ohne Vorankündigung Änderungen an den Produkten und der
Dokumentation vorzunehmen.
Technogym®, The Wellness Company™, Excite™ en CPR ™ (figuratief) zijn het eigendom van Technogym®
s.p.a. in Italië en in andere landen.
Het merk “TGS-sleutel” heeft betrekking op een vormmerk dat hiernaast is weergegeven en door
Technogym® s.p.a. in Italië en in andere landen geregistreerd is.
Copyright © Technogym® s.p.a., oktober 2008
Technogym® behoudt het recht wijzigingen aan de producten en de documentatie aan te brengen zonder
voorafgaande berichtgeving.
Technogym®, The Wellness Company™, Excite™ y CPR™ (figurativa) son marcas de propiedad de Technogym®
s.p.a. en Italia y en otros países.
“Llave TGS” se refiere a la marca que se reproduce a la derecha registrada por Technogym® s.p.a.
en Italia y en otros países.
Copyright© Technogym® s.p.a., octubre 2008
Technogym® se reserva el derecho a modificar sin preaviso tanto sus productos como la documentación de
los mismos.
Technogym®, The Wellness Company™, Excite™ e CPR ™ (figurativo) são marcas de propriedade da
Technogym® s.p.a. na Itália e em outros países.
A denominação “chave TGS” refere-se à marca da forma aqui a lado representada registrada por
Technogym® s.p.a. na Itália e em outros Países.
Copyright © Technogym® s.p.a., outubro 2008
A Technogym® reserva-se o direito de modificar seus produtos e sua documentação sem aviso prévio.
Technogym®、The Wellness Company™、Excite™、及び CPR™ (図形商標) は、イタリア及び国外における
Technogym® s.p.a. の登録商標です。
「TGS キー」と呼ばれるこの立体商標は、イタリア及び国外における Technogym®s.p.a. の登録商
標です。
Copyright © Technogym® s.p.a., 2008年10月
Technogym® は、自社の製品及びマニュアル文書類を事前に予告の義務無く変更することができる権利を有します。
Technogym®、The Wellness Company™、Excite™ 和 CPR™ (图形商标)等名称是Technogym® s.p.a.公
司在意大利和其它国家拥有的商标。
“TGS钥匙”的名称指这里旁边所示的图形商标, 是Technogym® s.p.a.在意大利和其它国家的注
册商标。
Technogym® s.p.a.公司版权所有© 2008年10月
Technogym® 保留不预先通知而对产品和文件进行修改的权利。
0SM00427AE-M1_02.indd 2 02/07/2010 15.32.37

3
中文
日本語
Br Es Nl De Fr It Uk
user manual
Contents
Introduction ...................................................................................................... 4
IMPORTANT SAFETY INSTRUCTIONS ............................................................ 5
1 Manufacturer and equipment identification ........................................... 8
2 Description of the equipment ................................................................. 9
3 Technical data ........................................................................................ 10
4 Safety devices and notices .................................................................... 13
5 Place of installation ................................................................................ 15
6 Unpacking and installation ..................................................................... 16
7 Moving the equipment ........................................................................... 17
8 Levelling ................................................................................................. 18
9 Electrical connection .............................................................................. 19
10 Grounding instructions ........................................................................... 21
11 Connection to another device ................................................................ 22
12 Routine maintenance ............................................................................. 23
13 Aligning the treadmill .............................................................................. 26
14 Troubleshooting ...................................................................................... 27
15 Technical assistance .............................................................................. 29
16 Storage ................................................................................................... 30
17 Disposing of the equipment ................................................................... 30
18 Switching on and off .............................................................................. 31
19 Using Run ............................................................................................... 33
20 Monitoring the heart rate ........................................................................ 35
21 Ergonomic positioning on the equipment .............................................. 38
0SM00427AE-M1_UK.indd 3 02/07/2010 9.49.34

4
Uk It Fr De Nl Es Br
日本語
中文
run excite
Introduction
The user manual has been written in the manufacturer’s original language and
translated into the language of the country in which the equipment is used. It forms
an integral part of the equipment, with which it should always be kept. The User
Manual should always accompany the equipment even in the event of relocation
or sale. The manual must be kept in a known, accessible place, protected against
dampness and heat.
The manual describes transport and maintenance procedures and contains valuable
information and useful suggestions about working methods; it is therefore a guide
for both professional users and beginners.
A number of symbols are used as a guide to reading the manual:
Warning
Points out important information, that must not be ignored.
Danger
Points out rules that must be strictly followed to avoid creating hazardous
situations for people or the equipment.
0SM00427AE-M1_UK.indd 4 02/07/2010 9.49.35

5
中文
日本語
Br Es Nl De Fr It Uk
user manual
IMPORTANT SAFETY INSTRUCTIONS
Please read all the instructions before using RUN. These instructions were written
to ensure your safety and to protect the equipment.
RUN with codes D847M, D847U are intended for medical use and have been desi-
gned and built for use in outpatient clinics, hospitals, clinics and sport centres, for
muscular therapy and rehabilitation.
When using an electrical appliance, basic precautions should always be followed,
including the following.
Read all instructions before using the equipment.
DANGER
To reduce the risk of electric shocks, always unplug the unit from the
electrical outlet immediately after using and before cleaning or performing any
maintenance tasks.
WARNING
To reduce the risk of burns, fire, electric shock or injury to person, take the
following precautions:
- Never leave RUN unattended when plugged in. Unplug from outlet when not in
use, before cleaning it and before putting on or taking off electrical parts.
- RUN can be used by or close to children, invalids, disabled persons or people
with evident physical problems only under close supervision of a doctor or a
qualified professional.
- Use RUN only for its intended use as described in the user manual; only
perform the exercises for which the equipment has been designed, following the
instructions given in the manual. Do not use attachments not recommended by
Technogym.
0SM00427AE-M1_UK.indd 5 02/07/2010 9.49.35

6
Uk It Fr De Nl Es Br
日本語
中文
run excite
- Workouts controlled by an external device must be performed only with a
continuous supervision of a doctor or qualified professional.
- Never operate RUN, if it has a damaged cord or plug, if it s not working properly,
if it has been dropped or damaged, or dropped into water. In this case, contact
the Technogym Technical Support service.
- Do not pull RUN by supply cord or use cord as handle.
- Keep the cord away from heated surfaces.
- Keep hands away from moving parts.
- Never drop or insert any object into any opening.
- Do not use outdoors. Do not leave the equipment outdoors, exposed to the
elements. Do not expose the equipment to water jets.
- Do not operate where aerosol (spray) products are being used or where oxygen
is being administered.
- To disconnect, turn all controls to the off position, then remove plug from
outlet.
WARNING
Connect RUN to a properly grounded outlet only. Read the grounding
instructions.
SAVE THESE INSTRUCTIONS
0SM00427AE-M1_UK.indd 6 02/07/2010 9.49.35

7
中文
日本語
Br Es Nl De Fr It Uk
user manual
Personal safety
Assemble RUN completely before using. Check the equipment before each use. Do
not continue to operate RUN when it is not working properly.
Position and operate RUN on a solid, level surface.
Keep all electrical components, such as the power cable and 0N/OFF (I/0) switch,
away from liquids to prevent shock.
Do not set anything on the frame or control panel.
Do not use accessory attachments that are not recommended by Technogym; such
attachments might cause injury.
Maintain RUN in good working conditions. If there are signs of wear, contact the
Technogym Technical Support service.
Do not attempt to service RUN yourself other than the maintenance instructions
found in the user manual.
Before starting an exercise, make sure your position on the equipment is correct,
and be careful with any components that might constitute an obstruction.
Wear proper exercise clothing and shoes during a workout, no loose clothing. Tie
long hair back. Keep garments or towels away from moving parts.
Choose suitable exercises for your physical characteristics and state of health and
by following the indications provided by your physician or qualified personnel.
Do not overexert yourself or work to exhaustion. If you feel pain or abnormal
symptoms, stop your workout immediately and consult your physician.
WARNING
Use the safety devices described in the Safety devices and notices section
correctly.
0SM00427AE-M1_UK.indd 7 02/07/2010 9.49.35

8
Uk It Fr De Nl Es Br
日本語
中文
run excite
1 Manufacturer and equipment identification
A - Manufacturer’s name and address
B - Description of product
C - Electrical specifications
D - Equipment classification
E - CE Mark
F - Part applied: type B
G - Serial number and date
of manufacture
H - Certification mark for the USA
and Canada
I - Product code
L - Tells you to consult the user manual
M - European mark
The values stated in the illustration are purely indicative; refer to the label attached
to the equipment or the data in Technical data section for the correct information.
03056007
03143001
TECHNOGYM S.p.A. Gambettola (FC) - MADE IN ITALY
RUN MED CE
200-240 Vac 2200 VA 50/60 Hz
PesoMax: 150kg
class: .IA
200-240 Vac 2200 VA 50/60 Hz
MAN.TECHNOGYM
LI
BA
C
H
G
D
F
03143001
TECHNOGYM S.p.A. Gambettola (FC) - MADE IN ITALY
RUN MED CE
200-240 Vac 2200 VA 50/60 Hz
PesoMax: 150kg
class: .IA
200-240 Vac 2200 VA 50/60 Hz
MAN.TECHNOGYM
MI
BA
C
G
D
F
E
L
E
0SM00427AE-M1_UK.indd 8 02/07/2010 9.49.36

9
中文
日本語
Br Es Nl De Fr It Uk
user manual
2 Description of the equipment
A Control panel: controls all available
functions, from setting up workout
programs to viewing messages and
related workout information.
B Treadmill: made entirely of rubber,
antistatic and vibration-dampened.
C Side handgrips: can be held when
walking with large strides.
D Central handgrip: can be held when
walking with small strides. It contains
the sensors (F) (hand sensor) to
monitor the heart rate.
E Footrests: you can take a short
rest by moving your feet from the
treadmill to the foot rests, in the event
of fatigue or danger.
G Reading stand: for standing
magazines or books on.
H Tray: for standing the water bottle
or other useful items on during the
workout.
I TGS key reader: for the TGS key
(optional).
L Joystick: for changing the treadmill
speed and gradient during the
exercise. Not available in 500
version.
G
B
E
C
A
02082002
E
H
F
H
F
I
D
02082106
L
L
0SM00427AE-M1_UK.indd 9 02/07/2010 9.49.36

10
Uk It Fr De Nl Es Br
日本語
中文
run excite
3 Technical data
03056004
2190 mm
936 mm
1493 mm
0SM00427AE-M1_UK.indd 10 02/07/2010 9.49.36

11
中文
日本語
Br Es Nl De Fr It Uk
user manual
Run Med version 200÷240V
Model code D847M
Power supply 200÷240 Vac 50/60 Hz
Power input 2200 VA
Weight of equipment 194 kg (428 lb)
Maximum user weight* 220 kg (485 lb)
Speed 0,4÷25 km/h
Gradient 0÷18%
Noise level Less than 80 dB
Protection grade IP 20
Operating temperature from +5°C to +30°C
Maximum capacity of water bottle-holder 2 kg (4 lb)
Electric isolation class Type I
Part applied Type B
Part applied of the heart rate monitor transmitter Type BF
* The stated performance data are guaranteed for users up to a weight of 120 kg (265 lb).
0SM00427AE-M1_UK.indd 11 02/07/2010 9.49.37

12
Uk It Fr De Nl Es Br
日本語
中文
run excite
Run Med version 100÷240V (version UL)
Model code D847U
Power supply 100÷240 Vac 50/60 Hz
Power input with 100÷120 Vac power supply 16A
Power input with 200÷240 Vac power supply 12,5A
Motor peak power 4400W (6Hp)
Weight of equipment 194 kg (428 lb)
Maximum user weight* 220 kg (485 lb)
Speed with 100 Vac power supply 0.4÷16 km/h (0.25÷10 mph)
Speed with 120 Vac power supply 0.4÷19 km/h (0.25÷12 mph)
Speed with 200÷240 Vac power supply 0.4÷25 km/h (0.25÷13.7 mph)
Gradient 0÷18%
Noise level Less than 80 dB
Protection grade IP 20
Operating temperature from +5°C (+41°F)
to +30°C (+86°F)
Maximum capacity of water bottle-holder 2 kg (4 lb)
Electric isolation class Class I
Part applied Type B
Part applied of the heart rate monitor transmitter Type BF
* The stated performance data are guaranteed for users up to a weight of 120 kg (265 lb).
0SM00427AE-M1_UK.indd 12 02/07/2010 9.49.37

13
中文
日本語
Br Es Nl De Fr It Uk
user manual
4 Safety devices and notices
A Fixed guard: guards against access to the inside of the equipment.
B Emergency button: stops the equipment immediately in the event of an
emergency. If a dangerous situation arises, this button can stop the equipment
without having to use the normal controls. According to the equipment’s country
of destination, there can either be the pushbutton alone, or the pushbutton plus
a cord with a peg to clip on to the user’s clothing. In the second case, the user
trips the emergency button if he/she either goes too far from the control panel
or pulls the cord.
C Beep: warns the user when the equipment is switched on, when the exercise
starts or finishes or if the heart rate is high; or also that the equipment is waiting
for commands from an external protocol.
D Main switch: turns the equipment’s power on and off.
E Circuit breaker: protects the electrical components of the equipment. When
power surges, the protection device opens, thus preventing damage to the
electronics inside.
A
02082013
02082014
B
C
D
03056005 E
0SM00427AE-M1_UK.indd 13 02/07/2010 9.49.37

14
Uk It Fr De Nl Es Br
日本語
中文
run excite
Warning
Please read the adhesive labels on the equipment, which provide
information about possible risks and hazards.
F The label for attachment to the power
supply cable states the electrical
specifications.
02082062
F
0SM00427AE-M1_UK.indd 14 02/07/2010 9.49.37

15
中文
日本語
Br Es Nl De Fr It Uk
user manual
5 Place of installation
To ensure that exercising with RUN is easy, safe and effective, the place where it is
used should comply with certain specific requirements; in particular, before choosing
the place where the equipment will be installed, please ensure that the following
conditions are satisfied:
- the temperature is between +10°C and +25°C;
- enough air is circulating to keep humidity during exercise to between 20% and
90%;
- the lighting is good enough to make the area safe and relaxing place to exercise
in;
- plenty of free space around each item of the equipment and a free space of
2x1 m in front of the treadmill, as shown in the illustration;
- that the floor is flat, stable and vibration-free, and strong enough to bear the
weight of the equipment plus user.
Equipment not suitable for use in the presence of anaesthetic mixtures inflammable
in air, oxygen or nitrous oxide.
In order to guarantee the performance indicated by the manufacturer, you are advised
against using the equipment in zones with high short-wave presence or similar.
1 m 2 m
02082063
0SM00427AE-M1_UK.indd 15 02/07/2010 9.49.37

16
Uk It Fr De Nl Es Br
日本語
中文
run excite
Depending on the country of destination,
RUN can either come partially assembled
in a cardboard pack attached to a
pallet; or fully assembled, wrapped in a
transparent plastic sheet and attached
to a pallet.
The packed material can be lifted and
carried with normal lifting equipment.
The instructions are printed directly on
the pack.
In order to ensure the safety of persons
and property, you should think carefully
about what lifting and transport
equipment to use, in relation to the
equipment’s place of destination.
The unpacking instructions are printed
directly on the pack.
Unpacking and assembly must be
performed exclusively by personnel
authorized by Technogym.
Warning
Observe the legally stated urban
waste disposal procedures when
disposing of the packaging
material.
02082016
6 Unpacking and installation
0SM00427AE-M1_UK.indd 16 02/07/2010 9.49.37

17
中文
日本語
Br Es Nl De Fr It Uk
user manual
The equipment has two fixed front
wheels. To move the equipment, lift it up
slightly, as shown in the illustration, and
push it forwards and backwards. Do not
lift the equipment to high, as this may
damage the front frame.
Given the weight of the equipment, we
recommend that more than one person
be involved in moving it.
If wheels cannot be used on the floor,
move the equipment with normal lifting
and transport methods.
Danger
When lifting, it is recommended
to grip the frame and not the
plastic parts.
Move the equipment with great
care to avoid it tipping over.
02082031
02082054
7 Moving the equipment
0SM00427AE-M1_UK.indd 17 02/07/2010 9.49.38

18
Uk It Fr De Nl Es Br
日本語
中文
run excite
The equipment is levelled by adjusting
the rear foot on the side shown in the
illustration:
A - screw or unscrew the foot until the
frame is in a stable position;
B - tighten the lock nut after adjusting.
02082032
02082033
8 Levelling
0SM00427AE-M1_UK.indd 18 02/07/2010 9.49.38

19
中文
日本語
Br Es Nl De Fr It Uk
user manual
9 Electrical connection
Before connecting the equipment to the mains power supply, ensure that the electrical
system specifications comply to binding regulations. Check the mains power supply
specifications on the identification plate (A), described in the Manufacturer and
equipment identification section.
Danger
The power supply socket must be grounded . If not, a ground
connection must be installed by a qualified electrician before connecting
the equipment to the electricity mains.
The wall socket must be located in a place where the plugging and
unplugging can be done easily and safely.
When plugging in, the switch on the equipment must be in the OFF (0)
position (i.e. the equipment must be switched off).
Plug the power cable first into the equipment socket and then into the wall socket.
Warning
Check the state of the power supply cable periodically.
A
0SM00427AE-M1_UK.indd 19 02/07/2010 9.49.38

20
Uk It Fr De Nl Es Br
日本語
中文
run excite
The label above the main switch shows the on and off positions.
A - Shows where the switch is.
B - Shows which sides the ON and OFF (I and 0) positions are. The ON (I) / OFF (0)
positions may vary according to the equipment version. The correct positions
are given on the label on the equipment.
C - Shows the type of switch (two fixed positions).
When switching on for the first time you are requested to specify the power supply
voltage: the “voltage code: 230” message scrolls in the control panel. Type the
power supply voltage that the equipment is connected to with the number keys, as
indicated in the table below; then press ENTER to confirm and proceed.
Value to enter Rated power supply voltage
100 100 Vac
120 120 Vac
230 200÷240 Vac
03056007
03056009
A B C
0SM00427AE-M1_UK.indd 20 02/07/2010 9.49.38
