Technogym Artis Run User manual

ARTIS CARDIO
Run
User manual

2
Run Artis
Contents
Contents..................................................................................................... 2
Important safety instructions................................................................. 3
Personal safety ......................................................................................... 5
Manufacturer and equipment identication.......................................... 7
Description of the equipment.................................................................. 8
Technical data ......................................................................................... 10
Safety devices and warnings................................................................ 12
Place of installation ................................................................................ 16
Moving the equipment ........................................................................... 17
Levelling................................................................................................... 18
Electrical connection.............................................................................. 19
Connection to another device................................................................ 21
Routine maintenance............................................................................. 23
Aligning the treadmill .............................................................................26
Troubleshooting....................................................................................... 27
Technical assistance.............................................................................. 29
Storage .....................................................................................................30
Disposal of the equipment.....................................................................30
Switching on and o............................................................................... 31
Monitoring the heart rate....................................................................... 32
Using the equipment .............................................................................. 35

3
Run Artis
Important safety instructions
You should always consult a qualied and licensed medical professional or healthcare practitioner before starting any nutritional, diet, stretching or exercise
program. You are advised to investigate and inform yourself about any health-related actions and choices you make.
Please read all instructions before using the equipment. These instructions were written to ensure your safety and to protect the unit.
Run Artis is intended for commercial use.
When using an electrical appliance, basic precautions should be always followed, including the following.
D
To reduce the risk of electric shock, always unplug the unit from the electrical outlet immediately after using and before cleaning or
performing any maintenance tasks.
W
To reduce the risk of burns, re, electric shock or injury to persons, take the following precautions.
The equipment should never be left unattended when plugged in. Unplug the equipment from outlet when not in use, before cleaning it, and before tting or
removing electrical parts.
Do not allow unsupervised children close to the equipment.
Close supervision by qualied personnel is necessary when the equipment is used by or near children, invalids or disabled persons.
Use the equipment only for its intended use as described in the user manual. Only perform the exercises for which the equipment has been designed, following
the instructions given in the manual. Any other use of the equipment is to be considered improper and therefore dangerous.
Do not use accessories not recommended by Technogym.
Never operate the equipment if it has a damaged cable or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. In such
cases, contact the Technogym Technical Support service.

4
Run Artis
Important safety instructions
Do not drag the equipment by the power cable or use the cable cord as a handle.
Keep the power cable away from heated surfaces.
Keep hands away from moving parts.
Never drop or insert any object into any opening.
Do not use outdoors. Do not leave the equipment outdoors, exposed to the elements (rain, sun, wind, etc.). Do not expose the equipment to water jets.
Do not operate the equipment where aerosol (spray) products are being used or where oxygen is being handled.
To disconnect from the power supply, turn all controls to the o position, then remove plug from outlet.
SAVE THESE INSTRUCTIONS

5
Run Artis
Personal safety
Use of the equipment is subject to a medical examination in relation to the intended type of exercise, and compliance with the conditions of use laid down by
the manufacturer.
Persons suering from certain physical conditions may only use the equipment under the strict supervision of a specialist doctor.
If, during exercise, the message “HIGH HEART RATE” appears, your heart rate is too high and you should slow down the exercise.
Before starting an exercise, make sure your position on the equipment is correct, and be careful with any components that might constitute an obstruction.
Choose suitable exercises for your physical characteristics and state of health, starting out with light loads.
Do not overexert yourself or work to exhaustion. Incorrect or excessive exercise may cause serious physical harm or even death. If you feel any pain or abnormal
symptoms, stop your workout immediately and consult your physician.
Wear proper exercise clothing and shoes during a workout, no loose clothing. Tie long hair back. Keep garments or towels away from moving parts.
During use other people must remain at a safe distance.
Do not use the equipment in presence of small children or pets.
The person in charge of the gym must explain proper and improper use of the equipment to users.
Completely assemble the equipment before using it. Check the equipment before each use. Do not continue to operate the equipment when it is not working
properly.
Assemble and operate the equipment on a solid, level surface.
Keep all electrical components, such as the power cable and I/0 switch, away from liquids to prevent electric shocks.
Maintain the equipment in good working condition. If there are signs of wear, contact the Technogym Technical Support service.
Do not attempt to perform any service on the equipment yourself other than the operations described in the maintenance instructions found in the user manual.
The installation, maintenance and setting must be done by qualied Technogym sta or persons authorised by Technogym.
The electrical system must conform to the standards and legal requirements in the country of use.

6
Run Artis
Personal safety
Do not place anything on the frame or control panel.
Technogym is not responsible for any damages due to any failures or damage caused by unauthorized service, misuse, accident, negligence, improper assembly
or installation, debris resulting from any construction activities in the vicinity of the product, rust or corrosion as a result of the product’s location, alterations
or modications without Technogym’s written authorization or for failure on your part to use, operate and maintain the products as set out in this User Manual.
W
There are high voltages inside the equipment, therefore the guard must be removed by authorised personnel only.

7
Run Artis
Made in Italy
Technogym S.p.A.via Calcinaro 2861, Cesena (FC)
RUN ARTIS Model no. DBK0EU
U.S. Pat. 6,616,578
Maximum User’s Weight: 220 kg
Electric Class: I
Class: SB ISO EN20957-1 EN957-6
S/N DBK0EU16000001 06/16
200 - 240 Vac 10A Max 50/60 Hz
Contains FCC ID: Z64 - WL18DBMOD
XZRBD01793, XZRBRD01794
A
E
BH
F
C
DG
A- Manufacturer’s name and address
B- Description of product
C- Maximum weight of the user
D- Equipment classication
E- CE Mark
F- Tells you to consult the User Manual
G- Serial number and date of manufacture
H- Product code
The values stated in the illustration are purely indicative; refer to the label
attached to the equipment or the data in "Technical data" section for the correct
information.
Manufacturer and equipment identication

8
Run Artis
A
E
D
FF C
G
B
Description of the equipment
Control panel (A): it allows you to view and control information, settings and
contents both for workouts and for entertainment. The tablet-style touch screen
interfaceallowsyoutoincludethecontentsoeredbytheTechnogym App Store.
Please see the control panel's manual to see how it works.
Input for TGS key (B): the device reads the training data on the TGS key and
memorises the exercise results (optional).
Headphone connector (C): used to plug in headphones and listen to audio
content. A microphone function may also be used with the Unity headphones.
USB port (D).
Webcam (E): available with Unity.
Fast Track Control (F): for changing the treadmill speed and gradient during
the exercise.
Object holder (G): for standing the water bottle or other useful items on during
the workout.

9
Run Artis
L
M
N
OH
N
O
L
Description of the equipment
Treadmill (H): antistatic and vibration-dampened running surface.
Side hand grips (L): for stability when getting on and o the equipment or if
the user loses his/her balance; they can be held when walking with long strides.
The luminous signal ontheleft handgrip lights upatthebeginning ofthe exercise
to signal that the equipment is in use and the treadmill is moving; the signal
blinks at the end of the exercise to signal that the equipment will shortly be
available.
Central handgrip (M): can be held when walking with small strides.
Handsensor (N): themetal plate sensors permit constant heart rate monitoring.
Footrests (O): you can take a short rest by moving your feet from the treadmill
to the footrests, in the event of fatigue or danger.

10
Run Artis
Technical data
The maximum power values refer to a user weighing a maximum of 100 kg.
Model code DBK0EU... , DBK0EV... DBK0AU.. , DBK0AV...
Power supply 200-240 Vac 50/60 Hz 100-240 Vac 50/60 Hz
Peak motor power 5800 W (7.8 Hp) 5800 W (7.8 Hp)
Weight of equipment 215 kg (474 lb) 215 kg (474 lb)
Maximum user weight 220 kg (485 lb) 220 kg (485 lb)
Speed 100 Vac power supply
maximum power input _0.8-25 km/h (0.5-15.5 mph)
1600 VA
Speed 120 Vac power supply
maximum power input _0.8-25 km/h (0.5-15.5 mph)
2000 VA
Speed 200-240 Vac power suppply
maximum power input
0.8-25 km/h (0.5-15.5 mph)
2200 VA
0.8-25 km/h (0.5-15.5 mph)
2200 VA
Gradient 0-15% 0-15%
Noise level Less than 70 dB Less than 70 dB
Protection grade IP 20 IP 20
Operating temperature from +5°C to +30°C (from +41°F to +86°F) from +5°C to +30°C (from +41°F to +86°F)
Maximum capacity of water bottle-holder 2 kg (4 lb) 2 kg (4 lb)

11
Run Artis
885 mm
(35")
1605 mm
(63")
2060 mm
(81")
Technical data

12
Run Artis
B C
A
Safety devices and warnings
Fixed guard (A). Guards against access to the inside of the equipment.
STOP button (B). This button can be used to stop the equipment without having to use the normal controls.
Emergency switch (C). It has a cord with a peg to clip on to the user’s clothing as shown in the illustration below. Check that the peg grips onto clothing
suciently well to operate the emergency switch. The user operates the emergency switch if he/she moves too far away from the control panel, that is if the
cord becomes taught.
To restore all the equipment's functions after an emergency stop, reset the switch as shown in the illustration.
Before using the equipment, check that the stop device works correctly and attach the cord to your clothing with the clip provided.

13
Run Artis
Safety devices and warnings
After nishing working out, put the emergency switch peg back into its slot, as
shown in the illustration.

14
Run Artis
G
D
E
F
D
Safety devices and warnings
Main switch (D). Turns the equipment’s power on and o.
Circuit breaker (E). Protects the electrical components of the equipment. When power surges, the protection device opens, thus preventing damage to the
electronics inside.
To access the circuit breaker, open panel (F): insert your ngers into the holes and pull.
The label (G) which can be attached to the power supply cable states the electrical specications for the cable.
W
Please read the adhesive labels on the equipment, which provide information about possible risks and hazards.

15
Run Artis
L
H
H
Safety devices and warnings
Marking on the treadmill belt (H)
The marking on the two sides of the treadmill belt indicates if the treadmill is
moving.
In motion light (L)
The luminous red signal located on the left handle shows that the treadmill is
moving.
Do not climb onto the product while the treadmill is moving.
User Present Function
The user present function is a safety function which stops the belt if it is moving
without any person walking or running on it.
This function is activated if the belt is at a speed greater than or equal to 3 km/h.
If no user is detected for 30 seconds when at a speed of 3 km/h or more, the
belt stops and the exercise is paused.
At minimum speed, the user is detected only if they weigh at least 50 kg.

16
Run Artis
1 m 2 m
Place of installation
To ensure that exercising with the equipment is easy, safe and eective, the place where it is used should comply with certain specic requirements; in particular,
before choosing the place where the equipment will be installed, please ensure that the following conditions are satised:
- the temperature is between +10°C and +25°C;
- enough air is circulating to keep humidity during exercise to between 20% and 90%;
Do not expose the equipment to direct sunlight.
Do not install the equipment in areas with high humidity levels, for example close to swimming pools, whirlpools or saunas.
The place of installation must comply with all the suitability requirements laid down in current legislation on this matter.
In order to guarantee the performance indicated by the manufacturer, you are advised against using the equipment in areas where there are high short-wave
or similar emissions.
- the lighting is good enough to make the area a safe and relaxing place to
exercise in;
- plenty of free space all around each item of equipment and a free space of
2x1 m in front of the equipment, as shown in the illustration;
- the oor is at, stable and vibration-free, and strong enough to bear the
weight of the equipment plus user.

17
Run Artis
Moving the equipment
The equipment has two xed front wheels. To move the equipment, lift it up
slightly, as shown in the illustration, and push it forwards and backwards.
To make it easier to move the equipment, we recommend adjusting the belt to
its highest gradient.
Do not lift the equipment too high, as this may damage the front frame.
Given the weight of the equipment, we recommend that more than one person
be involved in moving it.
If wheels cannot be used on the oor, move the equipment with normal lifting
and transport methods.
W
When lifting the equipment, do not grip the rear plastic housing,
but the frame under the side housings.
Move the equipment with great care to prevent it from tipping
over.

18
Run Artis
B
A
Levelling
The equipment is levelled by adjusting the rear foot on the side shown in the
illustration:
- loosen the locknut (B);
- tighten or loosen the screw (A) until the frame is in a stable position;
- tighten the lock nut (B) after adjusting.

19
Run Artis
A
Electrical connection
Before connecting the equipment to the
mains power supply, ensure that the
electrical system specications comply
with current regulations. Check the mains
power supply specications on the label
next to the switch.
Open panel (A) to reach the label and
connector: put your ngers into the holes
and pull.
Plug the power cable first into the
equipment socket and then into the wall
socket.
Fix the cable into the channel provided using the cable clamps supplied. Close panel (A) again, threading
the cable through the slot provided.

20
Run Artis
Electrical connection
W
Check the state of the power supply cable periodically.
The wall socket must be located in a place where plugging and unplugging can be done easily and safely.
When plugging in, the switch on the equipment must be set to position 0 (the equipment must be switched o).
The power supply socket must be grounded . If not, an earth connection must be installed by a qualied electrician before connecting the
equipment to the electricity mains.
The product must be earthed. If it malfunctions or breaks down, earthing provides a path of least resistance for electric current to reduce the risk of electric
shock. The product is equipped with a cable tted with an earth wire and earthed plug. The plug must be plugged into an appropriate outlet that is properly
installed and earthed in accordance with all local codes and ordinances.
W
Improper connection of the earth wire can result in a risk of electrical shock. Check with a qualied electrician or serviceman if you are
in doubt as to whether the product is properly earthed. Do not modify the plug provided with the product; if it does not t in the outlet,
have a proper outlet installed by a qualied electrician.
