Technogym Skillrun
Assembly Manual (4 Pieces)

10. Remove the 3 screws
(40), both on the right
and on the left side of the
equipment.(TOOL:8mm
Allenwrench)
The image is provid-
ed only as an exam-
ple. In this specic
case, the tread belt is
not installed in the
equipment.
SKILLRUN
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed Pag. 2

11.Removethescrew(41)
both on the left and on the
right side of the equip-
ment.(TOOL:8mmAllen
wrench)
The image is provid-
ed only as an exam-
ple. In this specic
case, the tread belt is
not installed in the
equipment.
SKILLRUN
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed
Pag. 3

8.10 DISASSEMBLING THE GUARDS - BOTTOM OF THE EQUIPMENT
8.10.1 DISASSEMBLING THE REAR SIDE GUARD
1. Remove the interlocked
guard (1), pulling it to-
wards the outside of the
equipment.
SKILLRUN
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed
Pag. 4
12. Remove the upright
unit with the incorporated
display from the equip-
ment, and place it on the
ground.
Protecttheoor.

2. Remove the screw (U).
(TOOL: medium Phillips
screwdriver)
3. Remove the interlocked
guard (2), pulling it to-
wards the outside of the
equipment.
4. Remove the screw (V).
(TOOL: medium Phillips
screwdriver)
5. Push the guard (3)
slightly towards the rear
side of the equipment. Re-
move the guard (3).
SKILLRUN
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed Pag. 5

8.10.2 DISASSEMBLING THE FRONT SIDE GUARD
1. Remove the inter-
locked guard (2), pulling
it towards the outside of
the equipment.
2. Remove the screw
(X). (TOOL: medium
Phillips screwdriver)
3. Push the guard (4)
slightly towards the
front side of the equip-
ment. Remove the guard
(4).
SKILLRUN
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed
Pag. 6

8.10.3 DISASSEMBLING THE FRONT GUARD
1. Remove the front side guard lateral, right and left, as described in paragraph “8.10.2 Disas-
sembling the front side guard”.
2. Remove the screw
(6). (TOOL: medium
Phillips screwdriver)
3. Remove the 2 front
screws (7) and (8).
(TOOL: medium Phil-
lips screwdriver)
SKILLRUN
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed Pag. 7

4. Remove the screw
(9). (TOOL: medium
Phillips screwdriver)
5. The front guard can now be removed.
The front guard could be as that shown in the paragraph “6.17.1 new front guard to arrange the
excess portion of cable - ASSEMBLY PROCEDURE”
8.11 DISASSEMBLING THE FOOTREST GUARD
8.11.1 DISASSEMBLING THE REAR SIDE FOOTREST GUARD
1. Remove the rear side guard as described in paragraph “8.10.1 Disassembling the rear side
guard”.
2. Loosen the 4
taptite screws (W).
(TOOL: medium
Phillips screwdriv-
er).
During reas-
sembly, tighten the
taptite screws (W)
with a tightening
torque of 3 Nm - 2.2
lbf-ft.
SKILLRUN
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed
Pag. 8

3. Push the foot-
rest guard towards
the rear part of the
equipment, to re-
lease the screws
from the eyelets.
4. Remove the foot-
rest guard (X).
SKILLRUN
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed Pag. 9

8.11.2 DISASSEMBLING THE FRONT SIDE FOOTREST GUARD
1. Remove the front side guard as described in paragraph “8.10.2 Disassembling the front side
guard”
2. Remove the 3 taptite
screws (Y). (TOOL: medi-
um Phillips screwdriver)
During reassembly,
tighten the taptite screws
(Y) with a tightening
torque of 3 Nm - 2.2 lbf-ft.
3. Remove the footrest
guard (5).
SKILLRUN
Technical Service Guide - Rev. 6.0
Uncontrolled copy if printed
Pag. 10
