Technogym Spazio Forma User manual

1
Spazio Forma
Contents
05092002_cs
1 Technical information
1.1 Equipment identification
The equipment identity label, with the serial number and bar code, is on the central riser.
ATechnogym s.p.a. address
BDescription of product
CElectrical specifications
DEquipment classification
ECE Mark
FSerial number and date of manufacture
GCertification mark for the USA
and Canada
HProduct code
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

2
Spazio Forma
Contents
05092003
2040 mm (80")
905 mm (36") 816 mm (32")
1651 mm (65")
1367 mm (54")
1.2 Description of the equipment
1.2.1 Technicaldata
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.2.1 Technical data
1.2.2 Main components
1.2.3 Accessories
1.2.4 Safety devices
and notices
1.3 Installation and assembly
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

3
Spazio Forma
Contents Europe-Asia USA-Canada
Power supply 230 Vac ± 10% 110 Vac ± 10%
Fuse 10 A 250 V (T)
Power input 1500 VA
Rated motor power 2000 W (2,75 Hp)
Weight of equipment 160 kg (352 lb)
Maximum user weight 130 kg (285 lb)
Speed (*) 0,8÷16 km/h ± 5%
(up to 2 km/h ± 0,1 km/h)
Gradient 0÷12% ± 1%
Time 0÷999 min ± 1%
Distance 0÷99,99 km ± 5%
Noise level Less than 80 dB
Protection grade IP 20
Operating temperature from +5°C to +35°C
European Directives 73/23/CE
89/336/CE
98/37/CE
Standards conformed to 55014-1
55014-2
55022
Electrical isolation class according to EN60601-1 Class I
Marks and certificates CE
ULUS
(*) Calculated with user of weight 85 kg (187 lb).
Normal, non-waterproofed equipment.
Equipment not suitable for use in the presence of anaesthetic mixtures inflammable in air, oxygen or nitrous
oxide.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.2.1 Technical data
1.2.2 Main components
1.2.3 Accessories
1.2.4 Safety devices
and notices
1.3 Installation and assembly
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

4
Spazio Forma
Contents
2
5
1
4
4
2
componenti princ_150_RGB
6
3
1.2.2 Main components
1-Control panel: controls all available functions, from setting up workout programs to viewing messages
and related workout information.
2-Side grips: a safe point for support when getting on to the equipment, or if you lose your balance.
3-Treadmill:a specially cushioned tread surface.
4-Footrests: for getting on and off Spazio Forma.
5-Central riser: supports the control panel and side grips.
6-Tray:for standing the water bottle or other useful items on during the workout.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.2.1 Technical data
1.2.2 Main components
1.2.3 Accessories
1.2.4 Safety devices
and notices
1.3 Installation and assembly
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

5
Spazio Forma
Contents
11 15
05092005
10 7
13 9
16 8
14
12
1.2.3 Accessories
The supplied kit includes the following accessories:
7- Set of wrenches for assembly and adjustment
8- Cloth for cleaning
9- Chest band with transmitter for heart rate monitor
10 - Spare fuses (2 x 10 A 250 V (T))
11 - User manual
12 - Warranty certificate
13 - Power supply cable
14 - Lubricating oil
15 - Water bottle
16 - Side grips fixing kit
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.2.1 Technical data
1.2.2 Main components
1.2.3 Accessories
1.2.4 Safety devices
and notices
1.3 Installation and assembly
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

6
Spazio Forma
Contents
A
05092006
1.2.4 Safety devices and notices
A - Snap-off safety switch: located under the control panel, it stops the equipment immediately should a
hazardous situation arise.
A cord connects the switch to a clamp that must be attached to the user's clothing. As a result, if the user
moves too far from the display, the switch pops out and stops the equipment without having to touch the
controls. The display then gives all the information needed to start the equipment again.
Danger
The snap-off safety switch must be removed from the Spazio Forma control panel at the end of the
workout and kept in a safe place, to prevent unsupervised use of the equipment (e.g. by children).
Warning
Check that the switch is in perfect working order before using the equipment.
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.2.1 Technical data
1.2.2 Main components
1.2.3 Accessories
1.2.4 Safety devices
and notices
1.3 Installation and assembly
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

7
Spazio Forma
Contents
C
B D
05092007
B - Fuse: protects the equipment's electrical parts. When the current reaches an excessive value, the fuse
melts thus protecting the internal electronics.
C - Beep: warns the user when the equipment is switched on, when the exercise starts or finishes or if the
heart rate is high.
D - Main switch: turns the equipment's power on and off.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.2.1 Technical data
1.2.2 Main components
1.2.3 Accessories
1.2.4 Safety devices
and notices
1.3 Installation and assembly
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

8
Spazio Forma
Contents
05092010
1 m 2 m
1.3 Installationandassembly
1.3.1 Place of installation
To make workouts on the equipment pleasant, productive and safe, the training space must satisfy certain
specific requirements. In particular, before deciding where to install the equipment, we recommend ensuring
that:
-thetemperature is between +10°C and +25°C;
- enough air is circulating to keep humidity during exercise to between 20% and 90%;
-thelighting is good enough to make the area safe and relaxing place to exercise in;
- there is a safety area of free space as shown in
the illustration;
- that the floor is flat, stable and vibration-free, and strong enough to bear the weight of the equipment plus
user.
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

9
Spazio Forma
Contents
05092009
If the equipment is to be installed in a public recreation area, the place of installation must comply with all
binding regulations.
Equipment not suitable for use in the presence of anaesthetic mixtures inflammable in air, oxygen or nitrous
oxide.
In order to guarantee the performance levels stated by Technogym, it is recommended not to use the equipment
in an area with a high presence of short waves or similar interference.
1.3.2 Unpacking
The equipment comes partially assembled in a crate on a pallet.
In the crate there is:
- the equipment, folded up and resting on the
pallet;
- the side grips.
The lifting and carrying can be done with normal lifting equipment.
To protect people and property, carefully assess what kind of lifting and carrying equipment would normally
be used in the place where Spazio Forma is to be located.
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

10
Spazio Forma
Contents
05092010
A
To unpack equipment delivered in a cardboard pack, remove the staples that attach the external packaging to
the pallet, and then lift up the pack.
Check the pack visually to make sure it is in a good, complete state.
To free the contents, remove the three reinforcement
frames (A) from around the equipment.
Information
You are advised to keep all packaging materials for re-use in case of a move.
Warning
Observe the legally stated urban waste disposal procedures when disposing of the packaging material.
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

11
Spazio Forma
Contents
05092011
Move the two side grips.
To take the equipment off the pallet, two people (at least two, given the equipment's weight) must lift the
frame from the rear and push it in the direction of the riser until the wheels touch the ground.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

12
Spazio Forma
Contents
05092012
B
C
B
A
1.3.3 Assembly
To assemble the side grips (A) firstly disassemble the control panel (B).
Unscrew the six screws (C) behind the control panel and raise the top part of the panel.
Warning
Be careful not to pull or disconnect the connected cables.
Fit the grip pins in the corresponding holes in the riser, two near the guard, at the bottom, and two under the
control panel.
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

13
Spazio Forma
Contents
05092013
C
D
E
Insert and tighten the grub screws (D), one for every grip.
Insert and tighten the screws (E), two for every grip.
Whilst repositioning the top part of the control panel, ensure that the cables fit correctly.
Tighten the screws (C) behind the control panel.
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

14
Spazio Forma
Contents
05092014
F
G
Slide back the two rubber sleeves (F) to uncover the
holes for the two grub screws (G) in the rubber lining.
Tighten up the two grub screws (G) with an Allen key.
Slide the two rubber sleeves back towards the control
panel so that it covers the grub screws and the whole
handgrip.
When the equipment is fully assembled on the floor, check that it is level; if it isn't, proceed with levelling.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

15
Spazio Forma
Contents
05092015
a
b
1.3.4 Levelling
Check that all four wheels of Spazio Forma are
touching the ground.
If they aren't, proceed with levelling.
Loosen the screw (a) with the hex wrench.
Turn the cam (b) with the supplied wrench.
Tighten the screw (a), holding the cam (b) still in
position.
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

16
Spazio Forma
Contents
05092016
ee
g
c
g
g
c
g
f
d
If the two feet (c) do not touch the ground, the lower
guard (d) must be removed (as described below) in
order to make the adjustment.
Fold up Spazio Forma.
Slacken the two screws (e), one on either side, and
raise the cover (f).
Unscrew the eight screws (g), four on each side, and
remove the guard (d).
cont.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

17
Spazio Forma
Contents
05092017_2
05092017
h
c
f
g
d
g
ee
Loosen the locknut (h).
Turn the foot (c) to adjust it.
Tighten the locknut (h).
After adjusting the foot, replace the lower guard (d)
and the cover (f), then tighten up the eight screws (g)
and the two screws (e).
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

18
Spazio Forma
Contents
05092019
1.3.5 Moving the equipment
Spazio Forma must be moved in the closed position,
holding it by the side grips.
If flooring conditions prevent use of the wheels, normal moving procedures must be employed.
Danger
Move the equipment with great care to avoid it tipping over.
Warning
After moving the equipment always check that it is level in order to guarantee the correct working.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

19
Spazio Forma
Contents
05092020
1.3.6 Electrical connection
Before connecting the equipment to the mains power supply, ensure that the electrical installation complies
to binding regulations. Check the information printed on the sticker next to the socket and on the power supply
cable.
Danger
The power supply socket must be grounded . If not, a ground connection must be installed by a
qualified electrician before connecting the equipment to the electricity mains.
The wall socket must be located in a place where the plugging and unplugging can be done easily and
safely. When plugging in, the switch on the equipment must be in the 0 position (i.e. the equipment
must be switched off).
Plug the power cable first into the equipment socket and then into the wall socket.
Warning
Check the state of the power supply cable periodically.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software

20
Spazio Forma
Contents 1.3.7 Grounding instructions
The product must be grounded. If it should malfunction or breakdown, grounding provides a path of least
resistance for electric current to reduce the risk of electric shock. The product is equipped with a cord having
an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet
that is properly installed and grounded in accordance with all local codes and ordinances.
DANGER
Improper connection of the equipment-grounding conductor can result in a risk of electrical shock. Check
with a qualified electrician or serviceman if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with the product; if it will not fit in the outlet, have a proper
outlet installed by a qualified electrician.
1 Technical information
1.1 Equipment identification
1.2 Description of the equipment
1.3 Installation and assembly
1.3.1 Place of installation
1.3.2 Unpacking
1.3.3 Assembly
1.3.4 Levelling
1.3.5 Moving the equipment
1.3.6 Electricalconnection
1.3.7 Grounding instructions
1.4 Maintenance
1.5 Easily solved problems
1.6 Technical assistance
1.7 Storage
1.8 Scrapping
2 Using the Spazio Forma
3 Spazio Forma software
