TECO JSDG2S Series User manual

1
First of all, thank you for choosing TECO Servo Drive JSDG2S Series (hereinafter referred to as
“JSDG2S”) and Servo Motor.
JSDG2S can be operated by the digital keypad, PC or human-machine interface, program to
provide various functions that enable the product to further address customers’ different application
requirements.
Before using JSDG2S, please read this Technical Manual; main contents of this Manual include:
 Inspection, installation and wiring procedures of the Servo System.
 The operating procedures, state display, error alarms and handling counter-measures
description of the digital panel manipulator.
 Servo System control function, trial run and adjustment steps.
 Description of all Servo Driver parameters.
 The rated specifications of the standard model.
In order to facilitate routine inspections and maintenance and to understand the cause of the error
and the counter-measures, please keep this Manual in a safe place for access at any time.
Note: Please deliver this Manual to the end user for the maximum effectiveness of the Servo
Driver.
Warnings and Pre-cautions:
Warnings
• Do not conduct wiring work when power is turned ON.
• Do not touch the circuit or replace parts after the input power is turned OFF but before the
state of the Servo Driver displays the CHARGE LED light is OFF.
• The output terminals U, V, W of the Servo Driver must not be connected to the AC power.
• Motor overheat protection is not provided.

2
Attention
• When the servo driver is installed in the control panel, if the ambient temperature is too
high, please install a cooling fan.
• Do not conduct pressure resistance test on the Servo Driver.
• Before the machine starts to operate, confirm whether or not the emergency stop switch can
be started at any time to stop the machine.
• Before the machine starts to operate, the user parameter setting value must be coordinated
with the machine. Failure to adjust to the matched correct setting values may result in a
loss of control or failure of the machine.
• Before the machine starts to operate, make sure to confirm the parameter Cn030: serial
model settings, and select the correct Driver and Motor matching combination! Confirm
the parameter Cn001 control mode selection.
Safety Pre-cautions:
Please read this Manual thoroughly before installing, operating, maintaining, and checking. Only
a professional qualified personnel can perform assembly line work.
The safety pre-cautions in the Manual are divided into two items: “Warnings” and “Pre-
cautions”.
Warnings :Indicating a dangerous situation that may result in death or serious injury
of personnel if ignored.
Pre-cautions :
Indicating a possible hazardous situation that may result in a less serious
or minor injury of personnel and damage of machinery equipment if not
resolved.
Therefore, this Technical Manual shall be read in detail before
using this Servo Driver.
