TECO TK Series Instruction Manual

TK GUIDELINE
WATER PROBE
REPLACEMENT
MODELS :
TK3000 – TK6000 – TK 9000
www.tecoonline.com | www.tecous.com

EQUIPMEMT
Tongs
www.tecoonline.com | www.tecous.com
7 black clamps
Screw-drivers
Thermostat Probe
with white connector
(spare part)

STEP n. 1
Disconnect the chiller form power supply.
Using the screw-driver, remove the screws indicated in the
picture here below (n°16 screws).
www.tecoonline.com | www.tecous.com

STEP n. 2
www.tecoonline.com | www.tecous.com
Disconnect ground wire from the cover
Remove the cover

STEP n. 3
www.tecoonline.com | www.tecous.com
Disconnect the white probe connector from
main board.
Cut the black clamps inside the chiller that
embrace the probe’s wire.

STEP n. 4
www.tecoonline.com | www.tecous.com
Proceed to cut all black clamps that
embrace the probe’s wire.
Extract the wire from circular passage.

STEP n.
www.tecoonline.com | www.tecous.com
Remove the ring nuts and the two screws.
Remove the metal black clamp.
Push the blue joints through holes

STEP n. 6
www.tecoonline.com | www.tecous.com
Remove the rubber cap positioned in
the chiller’s bottom side.
Remove the black probe’s insulation.
Then remove the probe from its
position, pulling it off from the wire.

STEP n. 7
www.tecoonline.com | www.tecous.com
-Insert the new probe inside the
exchanger. The probe has to touch the
pipe’s end part.
Take the probe’s insulation and put it
on the probe’s hole.
ATTENTION: there must not be any
air leakage !!
-Insert the cap in its place.
-Place probe wire in the small passage
under exchanger.

STEP n. 8
www.tecoonline.com | www.tecous.com
-Place the exchanger in the
correct position inserting
blue joints in the holes.
-Screw both ring nuts
-Place the big clamp
around the exchanger and
fix it to chiller metal wall

STEP n. 9
www.tecoonline.com | www.tecous.com
-Insert probe cable in circular passage
-Connect new probe connector to main board
-Take new seven black plastic clamps and
pinch the probe’s cable with the other cables
as it was at the beginning
-Place the chiller cover in its position and then
place the sixteen screws to close the chiller.
ATTENTION: remember to connect
ground wire to the cover before closing the
chiller.
CONNECT
