Teknion complements YTH Operating and maintenance instructions

Section:
Date: Feb 2022
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Rev. 3
Page: 1 of 14
COM_154
Note: YTH 2952 is Shown as Example
15
9
Navigate Freestanding Gable Leg Table (YTH)

Section:
Date: Feb 2022
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 2 of 14
COM_154
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 N09-8759\29\52
NAVIGATE HEIGHT ADJ. GABLE LEG
BASE STANDARD RANGE
1
2 B02-0736 Power Bar Hole Cover 1
3 N09-8157
INTEGRATED POWER BAR FOR
NAVIGATE TABLE
1
4 YEYA01 COMPLEMENTS CABLE ORGANIZER 1
4.1 N09-9012
Small Cable Organizer With Felt
Cover
1
5 YEYS01
COMPLEMENTS PLASTIC TRAY CABLE
MANAGEMENT, DUAL TRAYS &
POWERBAR
1
8 YEYS02
COMPLEMENTS PLASTIC TRAY CABLE
MANAGEMENT, DUAL TRAYS
1
10 N09-8737
NAVIGATE INTEGRATED POWER
BOX WITH IEC OUTLET
2
11 a16-3888 vertical wire manager cover 1
12 N01-5110\34
VWC - Navigate Freestanding,
Std. Range & Counterbalance
1
12.1 N01-4577-X
VERTICAL WIRE CARRIER -
CONNECTOR ASSY.
1
12.1.1 N01-6034-X
VERTICAL WIRE CARRIER
ASSEMBLY
1
12.1.1.1 B02-0843 LINK - VERTICAL WIRE CARRIER 35
12.1.2 B02-0844
VERTICAL WIRE CARRIER,
WORKSURFACE CONNECTOR
1
12.1.3 B02-0845
VERTICAL WIRE CARRIER, LEG
CONNECTOR
1
12.2 X01-3932
VWC HW. KIT - NAVIGATE
STRUT/WS MOUNT
1
12.2.1 E04-0087 ST_#12_0.875_BA_PN_QD 2
12.2.2 B02-0545 E-CHAIN CABLE TIE (740614) 1
12.2.3 E01-1251 M5X0.8, 10mm SHCS, ZINC 2
12.3 N09-8470
E-CHAIN VERTICAL COVER &
PAD ASSY, YEEE1 & YEEE10
1
12.3.1 A16-3888
VERTICAL WIRE MANAGER
COVER (S180005)
1
12.3.2 B05-0081
HALF CIRCLE CORK PAD, 1/32”
THICK, ADHESIVE ONE SIDE
(74WK03CC\S1)
6
ITEM
NO.
PREVIEW DESCRIPTION PART NO. QTY
1 CROSS BEAM A16-7182-X 1
2
Navigate Programed P-
CBD6SP00020A-109 Control
Box
N09-8185X 1
2.1
ANTI-COLLISION
DONGLE
I04-0104 1
3 CONTROL BOX COVER B02-0739 1
4 OR
NAVIGATE DIGITAL OR
SIMPLE SWITCH
N09-8183
OR N09-8192
1
5
2 STAGE GABLE LEG
ASSEMBLY T-LEG STYLE
N09-8598-X 2
6
MOTOR CABLE PVC FREE,
500MM N09-8402\05
1
7
MOTOR CABLE PVC FREE,
1000MM N09-8402\10
1
ITEM
NO.
PREVIEW DESCRIPTION PART NO. QTY
8. Navigate Gable Table Hardware Kit - X05-0428 x1
8.1
SCRW 1/4-20X5/8 ZNC PN
QD MCHN (690150) E01-0992
8
8.2
M6x1, 14mm HEX DRIVE,
FLAT HEAD SCREW, ZINK
FINISH
E01-
1249 16
8.3
(690247) #10 PAN QUAD
SCRW, 2 IN L
E01-
1009 2
8.4
(P-2184) GROMMET
BUSHING, LIVELLO
HEYCO P/N: P-2184SP
B02-
0557 2
8.5
#8 X 1 1/4 WOOD SCREW,
PAN HEAD, QUADREX
DRIVE, ZINC
E04-
0074 2
9
NAVIGATE HEIGHT ADJ.
TABLE WORKSURFACE
C07-
4240\29\52NN
1
10
(P-E320-029) 16 FT POWER
CORD
N09-5615 1
11 Power Bar Hole Cover B02-0736 1
12
#8 x 3/8" PAN HD
QUADREX TYPE B ZINC
E07-0158 2
ITEM
NO.
PREVIEW DESCRIPTION PART NO. QTY
1.10.1
VERTICAL WIRE CARRIER
- CONNECTOR ASSY.
N01-4577-X 1
1.10.1
.1
VERTICAL WIRE CARRIER
ASSEMBLY
N01-6034-
X
1
1.10.1
.1.1
LINK - VERTICAL WIRE
CARRIER
B02-0843 35
1.10.1
.2
VERTICAL WIRE CARRIER,
WORKSURFACE
CONNECTOR
B02-0844 1
1.10.1
.3
VERTICAL WIRE CARRIER,
LEG CONNECTOR
B02-0845 1
1.10.2
VWC HW. KIT -
NAVIGATE STRUT/WS
MOUNT
X01-3932 1
1.10.2
.1
ST_#12_0.875_BA_PN_QD E04-0087 2
1.10.2
.2
E-CHAIN CABLE TIE
(740614)
B02-0545 1
1.10.2
.3
M5X0.8, 10mm SHCS, ZINC E01-1251 2
1.10.3
E-CHAIN VERTICAL
COVER & PAD ASSY,
YEEE1 & YEEE10
N09-8470 1
1.10.3
.1
VERTICAL WIRE
MANAGER COVER
(S180005)
A16-3888 1
1.10.3
.2
HALF CIRCLE CORK PAD,
1/32” THICK, ADHESIVE
ONE SIDE (74WK03CC\S1)
B05-0081 6
1.11
NAVIGATE INTEGRATED
POWER BOX WITH IEC
OUTLET
N09-8737 1
2 vertical wire manager cover a16-3888 1
3
NAVIGATE INTEGRATED
POWER BOX WITH IEC
OUTLET
N09-8737 1
4 ST_8x0.375_ST_ZN_PN_QD E07-0158 2
Part & Product Identification

Section:
Date: Feb 2022
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 3 of 14
COM_154
ITEM NO. PREVIEW DESCRIPTION PART NO. QTY
1 CROSS BEAM A16-7182-X 1
2 CONTROL BOX N09-8185X 1
3 CONTOL BOX COVER B02-0739 1
4 OR NAVIGATE DIGITAL OR SIMPLE SWITCH N09-8183 OR N09-8192 1
5 2 STAGE GABLE LEG ASSEMBLY T-LEG STYLE N09-8598-X 2
6 MOTOR CABLE PVC FREE, 500MM N09-8402\05 1
7 MOTOR CABLE PVC FREE, 1000MM N09-8402\10 1
ITEM NO. PREVIEW DESCRIPTION PART NO. QTY
13. VERTICAL WIRE MANAGER
13.1 VERTICAL WIRE MANAGER ASSEMBLY N01-5110 1
13.2 CABLE MANAGER RETAINER CLIP A16-3890 1
13.3 CABLE TIE B02-0543 1
13.4
10-32 X 1/2 THREAD SCRE W
E07-0110 2
13.5 VERTICAL WIRE MANAGER COVER A16-3888 1
14
NAVIGATE INTEGRATED POWER BOX WITH IEC
OUTLET
(OPTIONAL)
N09-8737 1
ITEM NO. PREVIEW DESCRIPTION PART NO. QTY
1.10.1 VERTICAL WIRE CARRIER - CONNECTOR ASSY. N01-4577-X 1
1.10.1.1 VERTICAL WIRE CARRIER ASSEMBLY N01-6034-X 1
1.10.1.1.1 LINK - VERTICAL WIRE CARRIER B02-0843 35
1.10.1.2
VERTICAL WIRE CARRIER, WORKSURFACE
CONNECTOR
B02-0844 1
1.10.1.3 VERTICAL WIRE CARRIER, LEG CONNECTOR B02-0845 1
1.10.2 VWC HW. KIT - NAVIGATE STRUT/WS MOUNT X01-3932 1
1.10.2.1 ST_#12_0.875_BA_PN_QD E04-0087 2
1.10.2.2 E-CHAIN CABLE TIE (740614) B02-0545 1
1.10.2.3 M5X0.8, 10mm SHCS, ZINC E01-1251 2
1.10.3
E-CHAIN VERTICAL COVER & PAD ASSY, YEEE1 &
YEEE10
N09-8470 1
1.10.3.1 VERTICAL WIRE MANAGER COVER (S180005) A16-3888 1
1.10.3.2
HALF CIRCLE CORK PAD, 1/32” THICK, ADHESIVE
ONE SIDE (74WK03CC\S1)
B05-0081 6
1.11
NAVIGATE INTEGRATED POWER BOX WITH IEC
OUTLET
N09-8737 1
2 VERTICAL WIRE MANAGER COVER A16-3888 1
3
NAVIGATE INTEGRATED POWER BOX WITH IEC
OUTLET
N09-8737 1
4 ST_8X0.375_ST_ZN_PN_QD E07-0158 2
ITEM NO. PREVIEW DESCRIPTION PART NUMBER QTY.
13. COMPLEMENTS CABLE ORGANIZER - OPTIONAL (YEYA01)
13.1 PET Wire Manager Mounting Bracket A16-6737 1
13.2 PET WIRE MANAGER COVER B02-0777 1
13.3 SCREW M5X20, PHILLIPS, TRUSS HEAD, BLACK E07-0203 4
14. COMPLEMENTS PLASTIC TRAY CABLE MANAGEMENT, DUAL TRAYS & POWERBAR - OPTIONAL (YEYS01)
14.2 NAVIGATE POWERBAR WITH UNDERSURFACE MOUNT N09-8354 1
14.3 ST_#12_0.875_BA_PN_QD E04-0087 6
14.4 #8 WOOD SCREW FS8-5-8-PB 2
6.4 WIRE MANAGER (PB02-E179) B02-0746 2
Part & Product Identification

Section:
Date: Feb 2022
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 4 of 14
COM_154
5
1
8.2
ATTACH GABLE LEGS
STEP 1: Slide and Align the Gable Legs onto the Cross Beam as Shown. STEP 2: Install Screws as Shown above to Secure the Leg assembly.
SECURE GABLE LEGS

Section:
Date: Feb 2022
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 5 of 14
COM_154
12
14
STEP 3a: Attach the Power Bar if it is specified
ATTACH POWER BAR (IF POWER BAR IS SPECIFIED)

Section:
Date: Feb 2022
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 6 of 14
COM_154
12
11
STEP 3b: Attach the Power Bar Hole Cover as shown if Power Bar is not specified.
REMOVE OTHER SIDE PANEL AND ATTACH POWER BAR HOLE COVER (IF POWER BAR NOT SPECIFIED)
Date: Jan 2020

Section:
Date: Feb 2022
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 7 of 14
COM_154
6
2
2.1
14
7
NOTE: Make sure that the dongle is
connected to the Control Box
STEP 4a: Connect all the Electric wires onto the Control Box as shown.
INSTALL ELECTRIC WIRE (WITH POWER BAR)

Section:
Date: Jan 2020
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 8 of 14
COM_154
6
4
2
7
10
2.1
NOTE: Make sure that the dongle is
connected to the Control Box
INSTALL ELECTRIC WIRE (WITHOUT POWER BAR)
STEP 4b: Connect all the Electric wires onto the Control Box as shown. STEP 5a: Place the electric wires and components, Move the assembly to the Maximum
Height and remove the Access Door from Gable Leg assembly by pushing as Shown.
REMOVE ACCESS DOOR

Section:
Date: Jan 2020
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 9 of 14
COM_154
13.1
13.5
REMOVE SIDE PANEL
STEP 5b: Loosen the screws by rotating Counter-Clockwise and remove them. Slide and Pull
the Side Panel assembly as shown.
STEP 5c: Insert cable through the Vertical Wire Carrier, lower the manager into the cover
and place inside the Gable Leg. Tilt the Wire Cover and Install the Bottom Portion first and
then install the top Portion of the Wire Cover.
INSTALL VERTICAL WIRE CARRIER

Section:
Date: Jan 2020
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 10 of 14
COM_154
Vertical Wire
Carrier Top Link
Pilot Hole
NOTE: Power Cord Wire is hidden
for Illustration Purpose.
13.4
13.2
STEP 5d: Insert the Power Cord Wire through the Grommet Hole on the Cross Beam. Install Clip as shown and fasten with the screws provided.
WIRE MANAGEMENT

Section:
Date: Jan 2020
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 11 of 14
COM_154
10
13.5
NOTE: Other Components are
Hidden for Illustration Purpose.
WIRE MANAGEMENT
STEP 5e: Pull the Power Cord Wire through the Vertical Wire Carrier Cover and the Cut-
out.
STEP 6: Tilt and insert the top portion of the Access Door. Attach the Access door by
Pushing it Up and Inwards to Secure it.
ATTACH ACCESS DOOR

Section:
Date: Jan 2020
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 12 of 14
COM_154
NOTE: Top Gable Assembly and Vertical Wire
Manager are hidden for Illustration Purpose.
9
8.3
8.1
Worksurface Mounting Hole
STEP 7: Install Worksurface as Shown above. Secure Switch and Control Box Cover onto the Cross Beam.
INSTALL WORKSURFACE

Section:
Date: Jan 2020
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 13 of 14
COM_154
4
2
STEP 8: Mount Switch to the worksurface and Attach Control Box Cover onto the Cross Beam as shown.
MOUNT SWITCH AND CONTROL BOX COVER

Section:
Date: Jan 2020
HEIGHT-ADJUSTABLE TABLE
complements
Installation Guides
Page: 14 of 14
COM_154
Slot
STEP 9: Place the Side Panel of the Gable onto the provided slot and Secure it by fastening the Screws Clockwise.
REINSTALL SIDE PANEL
