Teknion Interpret Operating and maintenance instructions

Solid End Gable Overlay - Single Sided (WWCBSS) Part and Product Identification
For Customer Support please contact
[email protected]
Section:
Description: Page No:
Date:
Rev. No: 03
Feb. 2017 1 of 4
INT_210b
interpret
A - End Gable Screen - Single Sided, Flush,
No Rail
(C05-7400) x1
or
End Gable Screen - Single Sided, Flush,
Top Rail
(N09-4495) x1
or
End Gable Screen - Single Sided,
Overhang, No Rail
(C05-8089) x1
or
End Gable Screen - Single Sided,
Overhang, Top Rail
(N09-4496) x1
B1 - End Gable Mounting Bracket, Interpret
(N09-4739) x1
B - Bracket Kit (X03-0250) x2
NOTE: Single Sided Frame and End
Gable Screen, Single Sided, Flush,
No Rail Shown as an example.
C - Clear Bumper, BS37, Self Adhesive,
.560"H
(E03-0574) x2
B2 - 1/4ID x 1/2OD A 1/8Thick SBR
Flat Washer BLK
(E03-0582) x4
Single Sided End
Gable Frame
B3 - 1/4-20x5/8" Machine screw quad.
Truss HD
(E01-0098) x4
B4 - 1/4-20x7/8 QUADREX, Truss
Head Mach. Screw, Zinc
(E01-0872) x1

Section:
Description: Page No:
Date:
ATTACH BRACKETS (L-HANDED SIDE SCREEN) MOUNT SCREEN
INT_210b
2 of 4
Feb. 2017
interpret
STEP 2: Mount Screen onto the End Gable Frame.
NOTE: Make sure to align the End Gable Screen with the Center Rail as shown on
Top View.
STEP 1: Fasten Brackets to Screen as shown.
NOTE: Left Handed Side Screen Bracket shown as an example.
Underside View
NOTE: Left Handed Side
Screen shown as an example.
Top
View of
Straight Leg
NOTE: Make sure to align
the End Gable Screen with
the Center Rail as shown.
Align
FRONT
Align
Top
View of
Angled Leg
B
B2
B3
AA
A

Section:
Description: Page No:
Date:
BUMPER LOCATIONS ATTACH CLEAR BUMPERS
INT_210b
3 of 4
Feb.2017
interpret
STEP 3: Pull Screen outward and attach Bumpers to the inside of the Screen as shown on the
illustration.
NOTE: Make sure Bumpers are on the location against the Legs and 1/4" away from
the edge of the Screen.
NOTE: Bumpers location illustration.
Front View
Side View Angled Leg
Side View Straight Leg
FRONT
NOTE: Make sure
Bumpers are on the
location against the Legs
and 1/4" away from the
edge of the Screen.
FRONT
A
A
A
B
C
A

Section:
Description: Page No:
Date:
SECURE SCREEN
Feb. 2017 4 of 4
INT_210b
interpret
STEP 4: Secure Brackets to the Frame with Screws provided.
B
B4
B
B4
