Teknion Dossier ZJRP Operating and maintenance instructions

Section:
Description: Page No:
Date:
Rev. No: 1
FLUGHT MOUNT, FLUSH PLATE
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
Feb 2023 1 of 7
DOS_006a
dossier Installation Guides
ZJRP, ZJRF, ZJUP, ZJUF, ZJBF, ZJBN, ZJNF, ZJNP, ZJEF, ZJEP Part and Product Identification
A - Run-Off Worksurface (ZJNP)
x 1
B - Credenza Top, Full Depth
(ZJAC) X 1
A
B
C - Flush Plate (AS 540) x 3
C
NOTE: Do not fasten Credenza
Top to Credenza if Flush
Run-Off is Specified.
D - #8 x 1" Pan Head Wood
Screw x 24
For Customer Support please contact
[email protected]
F - Modeze Clip (AS111) x 2
E - 1
2" Modular Screw (AS121) x 2

Section:
Description: Page No:
Date:
PULL CREDENZA TOP FLUSH PLATE TO BOTTOM OF CREDENZA TOP
DOS_006a
2 of 7
Feb 2023
FLUGHT MOUNT, FLUSH PLATE
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
dossier Installation Guides
STEP 1: Pull Credenza Top to expose enough area to fasten Flush Plates.
B
STEP 2: Fasten Flush Plates to underside of Credenza top using screws provided.
NOTE: To avoid damage do not flip Run-Off on finished top.
C
D

Section:
Description: Page No:
Date:
POSITION CREDENZA TOP ALIGN CREDENZA TOP
DOS_006a
3 of 7
Feb 2023
FLUGHT MOUNT, FLUSH PLATE
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
dossier Installation Guides
STEP 3: Place Credenza Top back to original Position. Align side edge of Crdenza Top to side
of Credenza and front edge of Credenza Top to front of Credenz.
C
B
B
Align
Align

Section:
Description: Page No:
Date:
MODEZE CLIP LOCATION DRILL HOLES AND SCREW
DOS_006a
4 of 7
Feb 2023
FLUGHT MOUNT, FLUSH PLATE
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
dossier Installation Guides
STEP 4: Using same measurements found on Run-Off, measure and mark off on Credenza STEP 5: Drill hole and insert Modular Screws (E)
Measure
Distance
Measure
Distance
Measure
Distance
A
Measure
Distance
Measure
Distance
Measure
Distance
B
F
E

Section:
Description: Page No:
Date:
RUN OFF TO CREDENZA TOP FASTEN FLUSH PLATE TO RUN-OFF
DOS_006a
5 of 7
Feb 2023
FLUGHT MOUNT, FLUSH PLATE
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
dossier Installation Guides
STEP 6: Bring Run-Off to Credenza Top resting on Flush Plate while inserting Modular Screw
into cavity of modisty panel to connect with Modeze Clip.
C
B
STEP 7: Fasten Flush Plate to underside of Run-Off using screws provided.
A
D
E

Section:
Description: Page No:
Date:
ALIGN CREDENZA TOP TO CREDENZAS
Feb 2023 6 of 7
DOS_006a
FLUGHT MOUNT, FLUSH PLATE
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
dossier Installation Guides
STEP 8: For Full Depth and Reduced Depth Credenza Top, line up Credenza Top front edge with the front surface of doors or drawers. Align side edge to the side of Credenza. Full Depth
Credenza Top back surface has to align with gable back edge. It is not applicable to the Reduced Depth Top. When placed on an Open Cabinet, Credenza Top front surface has an overlap 1".
NOTE: Refer to Install Guide No. DOS_102b for Credenza Top
Align
Align
Plan view - Reduce Depth Credenza Top
Plan view - Full Depth Credenza Top

Section:
Description: Page No:
Date:
EXAMPLE
Feb 2023 7 of 7
DOS_006a
FLUGHT MOUNT, FLUSH PLATE
DESKS, L-RETURNS, BRIDGE RETURNS, RUN-OFFS
dossier Installation Guides
NOTE: If there is adequate space, fasten the Credenza Top to the Credenzas before
Flush Plates are installed.
