Teknion HWBCTF User manual

Double-Sided Spine Screen - Framed Fabric (HWBCTF) and Double-Sided Spine Screen - Solid (HWBCTS)
Section:
Description: Page No:
Date:
Rev. No: 0
DOUBLE SIDED SPINE SCREEN
HISPACE CASUAL SPACE DIVISON
Sept 2021 1 of 5
HABH_215
height adjustable bench Installation Guides
D2
D1
C
D3

Part and Product Identification
Section:
Description: Page No:
Date:
Rev. No: 0
DOUBLE SIDED SPLINE SCREEN
HISPACE CASUAL SPACE DIVISON
Sept 2021 2 of 5
HABH_215
height adjustable bench Installation Guides
B- Spine Screen Mounting Bracket Kit, For Fabric Screen (X01-4042)x1 A - Spine Screen Assembly
(N01-6008-X)x1
C - Double Sided Spine
Screen-Solid
(C07-8072X-X )
Double-Sided Spine Screen - For Framed Fabric(HWBCTF) x1
A - Double-Sided Spine Screen -
Framed Fabric
(N01-6008-X) x1
B1- Screen Mounting Bracket
(A25-0757) x4
B2- Screen Mounting Bracket Cover
(A25-0758) x4
B4- Spacer
(A16-10195) x4
B5- M6X1.0X16mm
(E01-1409) x4
B6- M6X1.0X18mm
(E03-1044) x4
B7- M6X1.0X25mm
(E03-1408) x4
B3- Bottom Spacer
(A16-9465) x2
D1- Screen Mounting Bracket
(A25-0757) x4
D2- Screen Mounting Bracket
Cover
(A25-0758) x4
D3- Bottom Spacer
(A16-9465) x2
D4- M6X1.0X16mm
(E01-1409) x4
D5- M6X1.0X18mm
(E03-1044) x4
D6- M6X1.0X25mm
(E03-1408) x4
C - Double-Sided Spine Screen
Solid
(C07-8072X-X) x1
Double-Sided Spine Screen - Solid (HWBCTF) x1
D- Spine Screen Mounting Bracket Kit, For Thick Screen (X01-3981)x1

Section:
Description: Page No:
Date:
ATTACH SPINE SCREEN MOUNTING BRACKET KIT
Sept 2021 3 of 5
HABH_215
DOUBLE SIDED SPINE SCREEN
HISPACE CASUAL SPACE DIVISON
height adjustable bench Installation Guides
STEP 3: Attach Mounting Bracket Cover on the Spine Screen and secure with fasteners as shown.
D1
D6
D5
D3
B1
B7
B6
B3
B4
A
C
NOTE: Spacer is used only for
Double Sided Spine Screen Framed
Fabric.
NOTE: Do not tight the screws.

STEP 5: Make sure screen is aligned properly, and tight screws as shown.STEP 4: Insert Bottom Spacer into Spine Screen with Mounting Bracket and attach to the
Frame as shown. Secure the screen with fasterners.
Section:
Description: Page No:
Date:
ATTACH SPINE SCREEN TO FRAME ATTACH SCREEN MOUNTING BRACKET COVER
HABH_215
4 of 5
Sept 2021
DOUBLE SIDED SPINE SCREEN
HISPACE CASUAL SPACE DIVISON
height adjustable bench Installation Guides
NOTE: Worksurface, Control Box, Mid
cable Riser are hidden for illustration
purpose
D4
D3
D6

STEP 7: Attach Screen Mounting Bracket Cover on Screen Mounting Bracket as shown.STEP 6: Fully tighten the screws after screen is aligned properly.
Section:
Description: Page No:
Date:
ATTACH SPINE SCREEN TO FRAME ATTACH SCREEN MOUNTING BRACKET COVER
HABH_215
5 of 5
Sept 2021
DOUBLE SIDED SPINE SCREEN
HISPACE CASUAL SPACE DIVISON
height adjustable bench Installation Guides
D4
D2
