Tektronix 6 series Installation and maintenance instructions

6 Series B Mixed Signal Oscilloscopes
Declassification and Security Instructions
(MSO64B, MSO66B, MSO68B)
Warning: The servicing instructions are for use by qualified personnel only. To avoid personal injury, do not perform any servicing unless you are qualified
to do so. Refer to all safety summaries prior to performing service.
Supports Product Firmware V1.28 and above
Register now!
Click the following link to protect your product.
www.tek.com/register
077-1694-00

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or
suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered
by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published
material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
• In North America, call 1-800-833-9200.
• Worldwide, visit www.tek.com to find contacts in your area.

Table of Contents
List of Tables.................................................................................................................................................................................iv
Preface.......................................................................................................................................................................................... v
Clear and sanitize procedure ....................................................................................................................................................... 1
Memory device table terminology.......................................................................................................................................... 1
Memory devices.....................................................................................................................................................................1
Media and data export devices.............................................................................................................................................. 7
Option 6-SEC for a secure instrument................................................................................................................................... 7
Overwriting the user password.............................................................................................................................................. 8
Clearing or sanitizing SSDs.......................................................................................................................................................... 9
Clearing the Linux SSD..........................................................................................................................................................9
Sanitizing the SSD................................................................................................................................................................. 9
Troubleshooting ..........................................................................................................................................................................10
How to sanitize a non-functional instrument........................................................................................................................ 10
Repair charges.....................................................................................................................................................................10
Change log ................................................................................................................................................................................. 11
6 Series B MSO Declassification and Security Instructions document change log..............................................................11
Table of Contents
6 Series B Mixed Signal Oscilloscopes Declassification and Security Instructions iii

List of Tables
Table 1: Volatile memory............................................................................................................................................................... 1
Table 2: Non-user-accessible memory..........................................................................................................................................2
Table 3: Media and Data export devices ...................................................................................................................................... 7
List of Tables
6 Series B Mixed Signal Oscilloscopes Declassification and Security Instructions iv

Preface
This document helps customers with data security concerns to sanitize or remove memory devices from their instrument.
This series of instruments contains an open architecture PC with removable mass storage. You can order additional
removable mass storage devices to swap in and out of the instrument as needed for security reasons.
These products have data storage (memory) devices and data export interfaces (USB ports, Ethernet, and eSATA). These
instructions describe how to clear or sanitize the memory devices and disable the data output interfaces. The instructions
also describe how to declassify an instrument that is not functioning.
Reference
The procedures in this document are written to meet the requirements specified in:
• NISPOM, DoD 5220.22–M, Chapter 8
• ISFO Process Manual for Certification & Accreditation of Classified Systems under NISPOM
Products
The following Tektronix products are covered by this document:
• MSO64B
• MSO66B
• MSO68B
Terms
The following terms may be used in this document:
•Clear. This eradicates data on media/memory before reusing it in a secured area. All reusable memory is cleared to
deny access to previously stored information by standard means of access.
•Erase. This is equivalent to clear.
•Media. Storage/data export device. A device that is used to store or export data from the instrument, such as a USB
port/USB flash drive.
•Sanitize. This removes the data from media/memory so that the data cannot be recovered using any known technology.
This is typically used when the device will be moved (temporarily or permanently) from a secured area to a nonsecured
area.
•Scrub. This is equivalent to sanitize.
•Remove. This is a physical means to clear the data by removing the memory device from the instrument. Instructions
are available in the product service manual.
•User Accessible. User is able to directly retrieve the memory device contents.
•User-Modifiable. The memory device can be written to by the user during normal instrument operation, using the
instrument user interface or remote control.
•Volatile memory. Data is lost when the instrument is powered off.
•Non-user-accessible memory. Data is retained when the instrument is powered off.
•Power off. Some instruments have a “Standby” mode, in which power is still supplied to the instrument. For the purpose
of clearing data, putting the instrument in Standby mode does not qualify as powering off. For these products, you must
remove the power source from the instrument.
•Instrument Declassification. A term that refers to procedures that must be undertaken before an instrument can be
removed from a secure environment. Declassification procedures include memory sanitization and memory removal,
and sometimes both.
Preface
6 Series B Mixed Signal Oscilloscopes Declassification and Security Instructions v

Preface
6 Series B Mixed Signal Oscilloscopes Declassification and Security Instructions vi

Clear and sanitize procedure
Memory device table terminology
The following terms are used in the tables in this section:
•User data. Describes the type of information stored in the device. Refers to waveforms or other measurement data
representing signals connected to the instrument by users.
•User settings. Describes the type of information stored in the device. Refers to instrument settings that can be changed
by the user.
•Both. Describes the type of information stored in the device. It means that both user data and user settings are stored in
the device.
•None. Describes the type of information stored in the device. It means that neither user data or user settings are stored
in the device.
•Directly. Describes how data is modified. It means that the user can modify the data.
•Indirectly. Describes how data is modified. It means that the instrument system resources modify the data and that the
user cannot modify the data.
Memory devices
The following tables list the memory devices in the instrument.
Table 1: Volatile memory
Type &
min. size
Function Type of
user info
stored
Backed
up by
battery?
Method of
modificati
on
Data
Input
method
Location User
accessibl
e
To clear To
sanitize
SDRAM
≥ 32 GB
Host
processor
memory
Both No Directly Written by
processor
system
Module
socket
(SODIMM)
on
processor
module
board
Yes Remove
power from
the
instrument
for a
minimum of
30 seconds.
Remove
power
from the
instrument
for a
minimum
of 30
seconds.
SDRAM
≥4 GB
Holds
active
acquisition
data
User data No Indirectly Applicatio
n software
operations
Module
socket
(SODIMM)
on
acquisition
board
No Remove
power from
the
instrument
for a
minimum of
30 seconds.
Remove
power
from the
instrument
for a
minimum
of 30
seconds.
SDRAM
≥512 MB
Holds
video
graphics
data
User data No Indirectly Applicatio
n software
operations
Acquisitio
n board
No Remove
power from
the
instrument
for a
minimum of
30 seconds.
Remove
power
from the
instrument
for a
minimum
of 30
seconds.
Table continued…
Clear and sanitize procedure
6 Series B Mixed Signal Oscilloscopes Declassification and Security Instructions 1

Type &
min. size
Function Type of
user info
stored
Backed
up by
battery?
Method of
modificati
on
Data
Input
method
Location User
accessibl
e
To clear To
sanitize
CMOS
RAM
≥256
Bytes
Holds
clock and
BIOS
configurati
on data
None Yes Indirectly BIOS
operations
Processor
module
board
Yes Remove
power from
the
instrument
and press
the CMOS
clear button
for a
minimum of
30 seconds.
Remove
power
from the
instrument
and press
the CMOS
clear
button for
a
minimum
of 30
seconds.
Table 2: Non-user-accessible memory
Type &
min. size
Function Type of
user info
stored
Method of
modificatio
n
Data Input
method
Location User
accessible
To clear To sanitize
Linux Solid
State Drive
≥256 GB
Host
instrument
Linux
operating
system and
application
software.
Holds user-
storable
data such
as
waveforms,
measureme
nt results,
and
instrument
settings.
Both Directly Written by
processor
system,
software
operations,
user input
2.5" SSD
that is
removable
and is
inserted in
the socket
on the
bottom of
the
instrument.
Yes Run the
TekSecure
function.
See
Clearing the
Linux SSD
on page 9
.
Remove the
SSD
assembly
from the
instrument
through the
trap door in
the bottom
of the
instrument.
Table continued…
Clear and sanitize procedure
6 Series B Mixed Signal Oscilloscopes Declassification and Security Instructions 2

Type &
min. size
Function Type of
user info
stored
Method of
modificatio
n
Data Input
method
Location User
accessible
To clear To sanitize
EEPROM
≥2 Kbit
Stores
factory
data,
maintenanc
e data, and
user
password
User
settings
User
password is
settable
using PI
commands
Indirect Factory
operations
and
programmat
ic
commands
Acquisition
board
Yes Overwrite
user
password.
(see
Overwriting
the user
password
on page 8
.) Clearing
entire
memory
device
would
disable
instrument
functionality.
Overwrite
user
password.
(see
Overwriting
the user
password
on page 8
.) Sanitizing
entire
memory
device
would
disable
instrument
functionality.
EEPROM
≥2 Kbit
Holds AFG
calibration
data
None Indirect Factory
operations
AFG riser
board
No Not
applicable,
does not
contain user
data or
settings.
Clearing
would
disable
instrument
functionality.
Not
applicable,
does not
contain user
data or
settings.
Sanitizing
would
disable
instrument
functionality.
EEPROM
≥64 Kbit
Holds the
front panel
USB
configuratio
n
None None Factory
operations
Front panel
LED board
No Not
applicable,
does not
contain user
data or
settings.
Clearing
would
disable
instrument
functionality.
Not
applicable,
does not
contain user
data or
settings.
Sanitizing
would
disable
instrument
functionality.
Table continued…
Clear and sanitize procedure
6 Series B Mixed Signal Oscilloscopes Declassification and Security Instructions 3

Type &
min. size
Function Type of
user info
stored
Method of
modificatio
n
Data Input
method
Location User
accessible
To clear To sanitize
EEPROM
≥1 Kb
depending
on model
Holds the
SODIMM
memory
configuratio
n data
(SPD)
None None Factory
operations
Module
socket
(SODIMM)
on
processor
module
board and
module
socket
(SODIMM)
on
acquisition
board
No Not
applicable,
does not
contain user
data or
settings.
Clearing
would
disable
instrument
functionality.
Not
applicable,
does not
contain user
data or
settings.
Sanitizing
would
disable
instrument
functionality.
Flash
Memory
≥16 Mbit
Two pieces
Holds a
portion of
the
Acquisition
FPGA
configuratio
n
None Indirect Application
software
operations
Acquisition
board
No Not
applicable,
does not
contain user
data or
settings.
Clearing
would
disable
instrument
functionality.
Not
applicable,
does not
contain user
data or
settings.
Sanitizing
would
disable
instrument
functionality.
Flash
Memory
≥128 Mbit
Stores
processor
BIOS
firmware,
BIOS
configuratio
n, and
embedded
controller
firmware.
The
Ethernet
MAC
address is
stored in
this device.
None Indirect BIOS
operations,
operating
system
operations
and factory
operations
Processor
module
board
No Not
applicable,
does not
contain user
data or
settings.
Clearing
would
disable
instrument
functionality.
Not
applicable,
does not
contain user
data or
settings.
Sanitizing
would
disable
instrument
functionality.
Table continued…
Clear and sanitize procedure
6 Series B Mixed Signal Oscilloscopes Declassification and Security Instructions 4
