Preface
If you have data security concerns, this document helps you to sanitize or remove
memory devices from the DPO2000/B and MSO2000/B Series Digital Phosphor
and Mixed Signal Oscilloscopes.
The DPO2000/B and MSO2000/B series products have data storage (memory)
devices and data output devices (USB ports). These instructions tell you how
to clear or sanitize the memory devices, and also tell you how to declassify an
instrument that is not functioning.
Instrument code and calibration settings reside in nonvolatile flash memory.
Instrument setups and reference waveforms may also be stored in flashmemoryor
on USB drives connected to the instrument.
If you have any questions, contact the Tektronix Technical Support Center at
www.tektronix.com/support.
Products The following Tektronix products are covered by this document:
DPO2002B
DPO2004B
DPO2012/B
DPO2014/B
DPO2022B
DPO2024/B
MSO2002B
MSO2004B
MSO2012/B
MSO2014/B
MSO2022B
MSO2024/B
Related Documents The DPO2000 and MSO2000 Series Digital Phosphor and Mixed Signal
Oscilloscopes Service Manual, part number 071-2331-XX, is available on the
Tektronix Web site at www.tektronix.com/manuals.
DPO2000/B and MSO2000/B Series Declassification and Security Instructions iii

Preface
Terms The following termsmaybeusedinthisdocument:
Clear. This removes data on media/memory before reusing it in a secured
area. All reusable memory is cleared to deny access to previously stored
information by standard means of access.
Erase. This is equivalent to clear.
Media storage/data export device. Any of several devices that can be used
to store or export data from the instrument, such as a USB port.
Nonvolatile memory. Data is retained when the instrument is powered off.
Power off. Some instruments have a “Standby” mode, in which power is
still supplied to the instrument. For the purpose of clearing data, putting the
instrument in Standby mode does not qualify as powering off. For these
products, you will need to either press a rear-panel OFF switch or remove the
power source from the instrument.
Remove. This is a physical means to clear the data by removing the memory
device from the instrument. Instructions are available in the product Service
Manual.
Sanitize. This eradicates the data from media/memory so that the data cannot
be recovered by other means or technology. This is typically used when the
device will be moved (temporarily or permanently) from a secured area to a
non-secured area.
Scrub. This is equivalent to sanitize.
User-modifiable. The user can write to the memory device during normal
instrument operation, using the instrument interface or remote control.
Volatile memory. Data is lost when the instrument is powered off.
iv DPO2000/B and MSO2000/B Series Declassification and Security Instructions

Clear and Sanitize Procedures
Memory Devices
The following tables list the volatile and nonvolatile memory devices in the
standard instrument and listed options.
Table 1: Volatile Memory Devices for the DPO2000/B and MSO2000/B Series
Type and minimum size Function User modifiable
Data input
method Location To clear or sanitize
CMOS, SDRAM, 32MX16,
512MB DDR2, 1.8V, 333MHZ;
MT47H32M16CC-3, FBGA84
DDR memory: contains
the analog channel
waveform acquisition
data during operation
Only by the
processor system
N/A Acquisition board Remove power from the
instrument for at least
20 seconds
CMOS, SDRAM, 32MX16,
512MB DDR2, 1.8V, 333MHZ;
MT47H32M16CC-3, FBGA84
DDR memory: contains
the digital channel
waveform acquisition
data during operation
Only by the
processor system
N/A Acquisition board
(MSO2000/B Series
only)
Remove power from the
instrument for at least
20 seconds
CMOS, SDRAM, 64MX16,
1G DDR2, 1.8V, 333MHZ;
MT47H64M16BT-3, FBGA84
DDR memory: contains
the instrument code and
data during operation
Only by the
processor system
N/A Acquisition board Remove power from the
instrument for at least
20 seconds
CMOS, SDRAM, 32MX16,
512MB DDR2, 1.8V, 333MHZ;
MT47H32M16CC-3, FBGA84
DDR memory: contains
the instrument code and
data during operation
Only by the
processor system
N/A Acquisition board
(4-channel products
only)
Remove power from the
instrument for at least
20 seconds
DPO2000/B and MSO2000/B Series Declassification and Security Instructions 1

Clear and Sanitize Procedures
Table 2: Nonvolatile Memory Devices for the DPO2000/B and MSO2000/B Series
Type and minimum size Function User modifiable
Data input
method Location To clear or sanitize
CMOS, FLASH; 16M X 8 OR
8M X 16, 128MBIT, 75NS, 3V;
PC28F128J3D-75, BGA64
FLASH: contains the
instrument firmware,
calibration constants,
reference waveforms,
and instrument setups
N/A N/A Acquisition board To clear: Not applicable
for calibration constants.
Use the TekSecure
featuretoerase
reference waveforms
and instrument setups.
Use the procedure to
disable the LAN Ethernet
and to clear information,
such as IP addresses.
(See page 5, Disable the
LAN Port and Clear LAN
Ethernet Settings.)
To sanitize: Remove
the acquisition board;
see the product service
manual for removal
instructions. Store the
removed board in a
secure area or destroy
it. Return the product
to Tektronix and a
new acquisition board
will be installed and
the instrument will be
repaired and adjusted as
necessary.
CMOS, CLOCK; SERIAL
REAL-TIME CLOCK,
CRYSTAL, 7 X 8 RAM, SPI,
3.3V; M41T93RMY, SO18.300
Real-time clock, with
battery backup
Only by the
processor system
N/A Acquisition board Not applicable; no user
data
CMOS, EEPROM; 128 X 8,
SERIAL; 24C01A, SOIC8
EEPROM: contains the
front end board serial
number and calibration
information
N/A N/A Front End Board Not applicable; no user
data
CMOS, MICROCONTROLLER;
8-BIT, 32K BYTES ON-CHIP
FLASH, MC9S08AW32CPUE,
LQFP64
Microcontroller with
FLASH: contains the
front panel processor
code and power status
for soft power switch
Only by the
processor system
N/A Front Panel Board Not applicable; no user
data
CMOS, EEPROM; 256 X 8,
SERIAL; 24C02, SO8.15
EEPROM: contains
the application module
firmware
N/A N/A DPO2000/B and
MSO2000/B application
module
Not applicable; no user
data
2 DPO2000/B and MSO2000/B Series Declassification and Security Instructions

Clear and Sanitize Procedures
Data Export Devices
The following table lists the data export devices.
Table 3: Data Export Devices
Type and minimum size Function User modifiable
Data input
method Location To disable
USB host port Supports the removable
USB flash drive; user
storage of reference
waveforms, screen
images, and instrument
setups
Yes Save USB host port on the
front of the instrument
Files can be deleted
or overwritten on the
instrument or a PC; the
USB flash drive can be
removed and destroyed.
The USB host port
cannot be disabled.
USB device port Supports remote control
and data transfer to a
PC
Yes Remote
control via
USBTMC
USB device port on the
rear of the instrument
Use the procedure to
disable the USB device
port. (See page 6,
Disable the USB Device
Port.)
DPO2000/B and MSO2000/B Series Declassification and Security Instructions 3

Built-In Security Features
Built-In Security Features
When to Use TekSecure
You can use the TekSecure function to erase setup and reference waveform data
stored in internal flash memory.
The DPO2000/B and MSO2000/B series models have a USB host port on the
front panel. Any USB flash devices can be removed, and stored or destroyed.
What TekSecure Does
The TekSecure function does the following:
Replaces all waveforms in all reference memories with null sample values
Replaces the current front-panel setup and all stored setups with the default
setup values
Calculates the checksums of all reference waveform memory and setup
memory locations to verify successful completion of waveform and setup
erasure
Displays a dialog indicating whether the secure erase was successful or
unsuccessful
NOTE. TekSecure does not erase or change factory calibration constants, user
protected data, or Ethernet settings.
To use TekSecure: 1. Push the front-panel Utility button.
2. Push the Utility Page lower-bezel button and use the Multipurpose a knob
to select Config.
3. Push the TekSecure Erase Memory lower-bezel button.
4.Push the OK Erase Setup & Ref Memory side-bezel button. Wait for the
“TekSecure operation complete” dialog box to display.
5. Push the Menu Off front-panel button to close the dialog box.
To reset the instrument
RAM:
1. Power off the instrument for at least 20 seconds.
2. Power on the instrument.
4 DPO2000/B and MSO2000/B Series Declassification and Security Instructions

Built-In Security Features
To overwrite protected
user data
This procedure overwrites everything that is stored in the protected user data area.
Send the following commands to the oscilloscope:
:PASSWORD “XYZZY” (or current password if not “XYZZY”)
:NEWPASS “ANYTHING”
:PASSWORD “ANYTHING”
*PUD #3300xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx[repeat
for a total of 300 x’s]
Disable the LAN Port and Clear LAN Ethernet Settings
To disable the LAN port and clear LAN Ethernet settings, such as IP addresses,
follow these steps:
CAUTION. If you need to restore network connectivity at a later date, make sure to
write down all setting values before clearing them.
1. Remove the network cable from the LAN port on the rear of the instrument.
2. Push the front-panel Utility button.
3. Push the Utility Page lower-bezel button and use the Multipurpose a knob
to select I/O.
4. Push the Ethernet Network Settings lower-bezel button.
5. Push the Change Instrument Settings side-bezel button.
6. Pushthe↑or ↓arrow side-bezel button to position the cursor on the User
Password information.
7. Push the Clear lower-bezel button.
8. Push the ↓arrow side-bezel button to position the cursor on the Instrument
IP Address information.
9. Push the Clear lower-bezel button.
10. Push the ↓arrow side-bezel button to position the cursor on the Domain
Name information.
11. Push the Clear lower-bezel button.
12. Push the ↓arrow side-bezel button to position the cursor on the DNS IP
Address information.
13. Push the Clear lower-bezel button.
DPO2000/B and MSO2000/B Series Declassification and Security Instructions 5

Built-In Security Features
14. Push the ↓arrow side-bezel button to position the cursor on the Gateway IP
Address information.
15. Push the Clear lower-bezel button.
16. Push the ↓arrow side-bezel button to position the cursor on the Subnet Mask
information.
17. Push the Clear lower-bezel button.
18. Push the OK Accept side-bezel button.
The LAN system is disabled and no longer allows data traffic in or out. The
relevant LAN Ethernet settings are also cleared.
Disable the USB Device Port
To disable the USB device port, follow these steps:
1. Remove any USB cable or device from the USB device port on the rear of the
instrument.
2. Push the front-panel Utility button.
3. Push the Utility Page lower-bezel button and use the Multipurpose a knob
to select I/O.
4. Push the USB lower-bezel button.
5. Push the Disabled (Off Bus) side-bezel button to disable the USB device port.
The USB device port is disabled and no longer allows data trafficinorout.
6 DPO2000/B and MSO2000/B Series Declassification and Security Instructions

Clear and Sanitize a Non-Functional Instrument
Clear and Sanitize a Non-Functional Instrument
If your instrument is not functioning and you need to clear or sanitize it, proceed
as follows:
Acquisition board Only qualified personnel should perform service procedures. Read the Service
Safety Summary and the General Safety Summary in the DPO2000 and MSO2000
Series Digital Phosphor and Mixed Signal Oscilloscopes Service Manual before
performing any service procedures.
Remove the Acquisition board and return the product to Tektronix. A new
Acquisition board will be installed, and the instrument will be repaired and
adjusted as necessary.
For removal instructions, refer to the service manual, part number 071-2331-XX,
available on the Tektronix Web site at www.tektronix.com/manuals.
After removal of the Acquisition board, refer to your company's internal policies
regarding handling or disposal of the board.
USB Flash Drive Remove the USB flash drive and return the instrument to Tektronix for repair.
AfterremovaloftheUSBflash drive, refer to your company's internal policies
regarding handling or disposal of the flash drive.
Charges Replacement of any missing hardware will be charged according to the rate at
the time of replacement.
DPO2000/B and MSO2000/B Series Declassification and Security Instructions 7
