Mixed Signal Oscilloscopes
MSO2000 Series, DPO2000 Series Data Sheet
Features & Benefits
Key Performance Specifications
200, 100 MHz Bandwidth Models
2 and 4 Analog Channel Models
16 Digital Channels (MSO Series)
1 GS/s Sample Rate on All Channels
1 Megapoint Record Length on All Channels
5,000 wfm/s Maximum Waveform Capture Rate
Suite of Advanced Triggers
Ease of Use Features
Wave Inspector®Controls Provide Easy Navigation and Automated
Search of Waveform Data
FilterVu™ Variable Low-pass Filter Allows for Removal of Unwanted
Signal Noise while still Capturing High-frequency Events
29 Automated Measurements, and FFT Analysis for Simplified
Waveform Analysis
TekVPI®Probe Interface Supports Active, Differential, and Current
Probes for Automatic Scaling and Units
7 in. (180 mm) Widescreen TFT-LCD Color Display
Small Footprint and Lightweight – Only 5.3 in. (134 mm) deep and 7 lb.
14 oz. (3.6 kg)
Connectivity
USB 2.0 Host Port on the Front Panel for Quick and Easy Data Storage
USB 2.0 Device Port on Rear Panel for Easy Connection to a PC or
Direct Printing to a PictBridge®-compatible Printer
Optional 10/100 Ethernet Port for Network Connection and Video Out
Port to Export the Oscilloscope Display to a Monitor or Projector
Optional Serial Triggering and Analysis
Automated Serial Triggering, Decode, and Search Options for I2C, SPI,
CAN, LIN, and RS-232/422/485/UART
Mixed Signal Design and Analysis (MSO Series)
Automated Triggering, Decode, and Search on Parallel Buses
Multichannel Setup and Hold Triggering
Feature-rich Tools for Debugging Mixed
Signal Designs
Offering up to 200 MHz bandwidth and 1 GS/s sample rate, the
MSO/DPO2000 Mixed Signal Oscilloscope Series delivers advanced debug
features at an entry-level price. With up to 20 channels for analyzing analog
and digital signals, you can quickly find and diagnose problems in complex
designs. To capture long windows of signal activity while maintaining
fine timing resolution, the MSO/DPO2000 offers a deep record length of
1 Mpoints standard on all channels.
With Wave Inspector®controls for rapid waveform navigation and
automated serial and parallel bus analysis, the MSO/DPO2000
Oscilloscope Series from Tektronix provides the feature-rich tools you need
to simplify and speed debug of your complex design.

Data Sheet
Discover – A waveform capture rate of 5,000 wfm/s maximizes the probability of capturing
elusive glitches and other infrequent events.
Comprehensive Features Speed Every Stage
of Debug
The MSO/DPO2000 Series offers a robust set of features to speed every
stage of debugging your design – from quickly discovering an anomaly and
capturing it, to searching your waveform record for the event and analyzing
its characteristics and your device’s behavior.
Discover
To debug a design problem, first you must know it exists. Every
design engineer spends time looking for problems in their design, a
time-consuming and frustrating task without the right debug tools.
The MSO/DPO2000 Series offers complete visualization of signals,
providing fast insight into the real operation of your device. A waveform
capture rate of 5,000 waveforms per second enables you to see glitches
and other infrequent transients quickly, revealing the true nature of device
faults. A digital phosphor display with intensity grading shows the history
of a signal’s activity by intensifying areas of the signal that occur more
frequently, providing a visual display of just how often anomalies occur.
Capture – Triggering on a specific transmit data packet going across an RS-232 bus. A
complete set of triggers, including triggers for specific serial packet content, ensures you
quickly capture your event of interest.
Capture
Discovering a device fault is only the first step. Next, you must capture the
event of interest to identify root cause.
The MSO/DPO2000 Series provides a complete set of triggers – including
runt, logic, pulse width/glitch, setup/hold violation, serial packet, and parallel
data–tohe
lp quickly find your event. With up to a 1 Mpoint record length,
you can capture many events of interest, even thousands of serial packets,
in a single acquisition for further analysis while maintaining high resolution
to zoom in on fine signal details.
From triggering on specific packet content to automatic decode in
multiple data formats, the MSO/DPO2000 Series provides integrated
support for a broad range of serial buses – I2C,SPI,CAN,LIN,and
RS-232/422/485/UART. The ability to decode up to two serial and/or parallel
buses simultaneously means you gain insight into system-level problems
quickly.
To further help troubleshoot system-level interactions in complex embedded
systems, the MSO2000 Series offers 16 digital channels in addition to
its analog channels. Since the digital channels are fully integrated into
the oscilloscope, you can trigger across all input channels, automatically
time-correlating all analog, digital, and serial signals.
2www.tektronix.com

Mixed Signal Oscilloscopes — MSO2000 Series, DPO2000 Series
Search–I
2C decode showing results from a Wave Inspector search for Address value
50. Wave Inspector controls provide unprecedented efficiency in viewing and navigating
waveform data.
Search
Finding your event of interest in a long waveform record can be time
consuming without the right search tools. With today’s record lengths
pushing to a million data points, locating your event can mean scrolling
through thousands of screens of signal activity.
The MSO/DPO2000 Series offers the industry’s most comprehensive
search and waveform navigation with its innovative Wave Inspector®
controls. These controls speed panning and zooming through your record.
With a unique force-feedback system, you can move from one end of your
record to the other in just seconds. User marks allow you to mark any
location that you may want to reference later for further investigation. Or,
automatically search your record for criteria you define. Wave Inspector
will instantly search your entire record, including analog, digital, and serial
bus data. Along the way it will automatically mark every occurrence of your
defined event so you can quickly move between events.
Analyze – FFT analysis of a pulsed signal. A comprehensive set of integrated analysis
tools speeds verification of your design’s performance.
Analyze
Verifying that your prototype’s performance matches simulations and meets
the project’s design goals requires analyzing its behavior. Tasks can range
from simple checks of rise times and pulse widths to sophisticated power
loss analysis and investigation of noise sources.
The MSO/DPO2000 Series offers a comprehensive set of integrated
analysis tools including waveform- and screen-based cursors, 29
automated measurements, and FFT analysis. Specialized application
support for serial bus analysis is also available.
For extended analysis, National Instrument’s LabVIEW SignalExpress™
Tektronix Edition provides over 200 built-in functions including time and
frequency domain analysis, limit testing, data logging, and customizable
reports.
www.tektronix.com 3

Data Sheet
Wave Inspector controls provide unprecedented efficiency in viewing, navigating, and
analyzing waveform data. Zip through your 1 Mpoint record by turning the outer pan
control (1). Get from the beginning to end in seconds. See something of interest and want
to see more details? Just turn the inner zoom control (2).
Wave Inspector®Navigation and Search
A 1 Mpoint record length represents thousands of screens of information.
The MSO/DPO2000 Series enables you to find your event in seconds with
Wave Inspector, the industry’s best tool for navigation and search.
Wave Inspector offers the following innovative controls:
Zoom/Pan
A dedicated, two-tier front-panel control provides intuitive control of both
zooming and panning. The inner control adjusts the zoom factor (or zoom
scale); turning it clockwise activates zoom and goes to progressively higher
zoom factors, while turning it counterclockwise results in lower zoom factors
and eventually turning zoom off. No longer do you need to navigate through
multiple menus to adjust your zoom view. The outer control pans the zoom
box across the waveform to quickly get to the portion of waveform you are
interested in. The outer control also utilizes force-feedback to determine
how fast to pan on the waveform. The farther you turn the outer control, the
faster the zoom box moves. Pan direction is changed by simply turning the
control the other way.
Play/Pause
A dedicated Play/Pause front-panel button scrolls the waveform across the
display automatically while you look for anomalies or an event of interest.
Playback speed and direction are controlled using the intuitive pan control.
Once again, turning the control further makes the waveform scroll faster and
changing direction is as simple as turning the control the other way.
Search step 1: You define what you would like to find.
Search step 2: Wave Inspector automatically searches through the record and marks each
event with a hollow white triangle. You can then use the Previous and Next buttons to
jump from one event to the next.
User Marks
Press the Set Mark front-panel button to place one or more marks on
the waveform. Navigating between marks is as simple as pressing the
Previous (←)andNext (→) buttons on the front panel.
Search Marks
The Searchbutton allows you to automatically search through your long
acquisition looking for user-defined events. All occurrences of the event
are highlighted with search marks and are easily navigated to, using the
front-panel Previous (←) and Next (→) buttons. Search types include
edge, pulse width/glitch, runt, logic, setup and hold, rise/fall time parallel
bus, and I2C, SPI, CAN, LIN, and RS-232/422/485/UART packet content.
4www.tektronix.com

Mixed Signal Oscilloscopes — MSO2000 Series, DPO2000 Series
Digital phosphor technology enables a 5,000 wfm/s waveform capture rate and real-time
intensity grading on the MSO/DPO2000 Series.
The MSO Series provides 16 integrated digital channels enabling you to view and analyze
time-correlated analog and digital signals.
Digital Phosphor Technology
The MSO/DPO2000 Series’ digital phosphor technology provides you with
fast insight into the real operation of your device. Its waveform capture rate
of 5,000 wfm/s gives you a high probability of quickly seeing the infrequent
problems common in digital systems: runt pulses, glitches, timing issues,
and more.
Waveforms are superimposed with one another and waveform points that
occur more frequently are intensified. This quickly highlights the events
With the color-coded digital waveform display, groups are created by simply placing digital
channels together on the screen, allowing the digital channels to be moved as a group.
You can set threshold values for each pod of eight channels, enabling support for up to
two different logic families.
that over time occur more often or, in the case of infrequent anomalies,
occur less often.
With the MSO/DPO2000 Series, you can choose infinite persistence
or variable persistence, determining how long the previous waveform
acquisitions stay on-screen. This allows you to determine how often an
anomaly is occurring.
Mixed Signal Design and Analysis
(MSO Series)
The MSO2000 Series Mixed Signal Oscilloscopes provide 16 digital
channels. These channels are tightly integrated into the oscilloscope's user
interface, simplifying operation and making it possible to solve mixed-signal
issues easily.
Color-coded Digital Waveform Display
The MSO2000 Series has redefined the way you view digital waveforms.
One common problem shared by both logic analyzers and mixed-signal
oscilloscopes is determining if data is a one or a zero when zoomed in far
enough that the digital trace stays flat all the way across the display. The
MSO2000 Series has color-coded digital traces, displaying ones in green
and zerosinblue.
www.tektronix.com 5

Data Sheet
White edges indicate additional information is available by acquiring at a higher sample
rate.
The P6316 MSO probe offers two eight-channel pods to simplify connecting to your
device.
The multiple transition detection hardware of the MSO2000 Series will
show you a white edge on the display when the system detects multiple
transitions. This acts as a visual reminder that increasing the sample rate
on the next acquisition will reveal higher frequency information than your
previous settings could acquire.
The MSO2000 Series simplifies channel setup by allowing you to group
digital waveforms and enter waveform labels by using a USB keyboard.
By simply placing digital waveforms next to each other, they form a group.
Once a group is formed, you can position all the channels contained in that
group collectively. This greatly reduces the normal setup time associated
with positioning channels individually.
P6316 MSO Probe
This unique probe design offers two eight-channel pods, simplifying the
process of connecting to the device-under-test. When connecting to square
pins, the P6316 can connect directly to 8×2 square pin headers spaced
on tenth-inch centers. When more attachment flexibility is required, you
can use the included flying lead sets and grabbers to clip onto surface
mount devices or test points. The P6316 offers outstanding electrical
characteristics applying only 8 pF of capacitive loading with 101 kΩinput
impedance.
Output of DAC Signal – Notice how FilterVu™ clearly shows the noise-free steps of the
DAC in the foreground trace (yellow) which has removed all frequencies above 5.5 kHz.
FilterVu also captures and displays high-frequency glitches up to the full bandwidth of the
oscilloscope in the background trace (orange).
FilterVu™ Variable Low-pass Filter
Tired of being limited to a 20 MHz bandwidth filter in your oscilloscope?
Simply turn on FilterVu and adjust the variable low-pass noise filter. Unlike
other variable low-pass filters, FilterVu filters out the unwanted noise from
your signal while still capturing glitches and other signal details up to the full
bandwidth of the oscilloscope. It does this by showing two waveforms: a
waveform that can be filtered (foreground waveform) and a glitch capture
waveform (background waveform).
The filtered waveform uses a variable low-pass filter to block out noise,
yielding a cleaner waveform to more precisely locate signal edges
and amplitude levels. The result is improved confidence in you cursor
measurements and cleaner documentation of important signal attributes.
When the noise filter is adjusted to the lowest available noise-cutoff
frequency, no more than 1% of high-frequency content that could cause the
oscilloscope to alias will pass through the filter.
The glitch capture waveform shows signal details up to the full bandwidth of
the oscilloscope. The oscilloscope captures pulses as narrow as 5 ns, using
peak-detect min/max sampling, protecting you from missing unexpected
glitches or other high-frequency events.
FilterVu is ideal for repetitive, nonrepetitive, and single-shot events.
6www.tektronix.com

Mixed Signal Oscilloscopes — MSO2000 Series, DPO2000 Series
Triggering on a specific data packet going across an I2C bus. The yellow waveform is
clock and the blue waveform is data. A bus waveform provides decoded packet content
including Start, Address, Read/Write, Data, and Stop.
Serial Triggering and Analysis (Optional)
On a serial bus, a single signal often includes address, control, data, and
clock information. This can make isolating events of interest difficult. The
MSO/DPO2000 Series offers a robust set of tools for debugging serial
buses with automatic trigger, decode, and search for I2C, SPI, CAN, LIN,
and RS-232/422/485/UART.
Serial Triggering
Trigger on packet content such as start of packet, specific addresses,
specific data content, unique identifiers, etc. on popular serial interfaces
such as I2C, SPI, CAN, LIN, and RS-232/422/485/UART.
Bus Display
Provides a higher-level, combined view of the individual signals (clock, data,
chip enable, etc.) that make up your bus, making it easy to identify where
packets begin and end and identifying subpacket components such as
address, data, identifier, CRC, etc.
Bus Decoding
Tired of having to visually inspect the waveform to count clocks, determine
if each bit is a 1 or a 0, combine bits into bytes, and determine the hex
value? Let the oscilloscope do it for you! Once you’ve set up a bus, the
Event table showing decoded Identifier, DLC, DATA, and CRC for every CAN packet in
alongacquisition.
MSO/DPO2000 Series will decode each packet on the bus, and display the
value in hex, binary, decimal (LIN only), or ASCII (RS-232/422/485/UART
only) in the bus waveform.
Event Table
In addition to seeing decoded packet data on the bus waveform itself, you
can view all captured packets in a tabular view much like you would see in
a software listing. Packets are time stamped and listed consecutively with
columns for each component (Address, Data, etc.).
Search
Serial triggering is very useful for isolating the event of interest, but once
you’ve captured it and need to analyze the surrounding data, what do
you do? In the past, users had to manually scroll through the waveform
counting and converting bits and looking for what caused the event. With
the MSO/DPO2000 Series, you can have the oscilloscope automatically
search through the acquired data for user-defined criteria including serial
packet content. Each occurrence is highlighted by a search mark. Rapid
navigation between marks is as simple as pressing the Previous (←)and
Next (→)buttons on the front panel.
www.tektronix.com 7

Data Sheet
The MSO/DPO2000 is designed to make your work easier. The bright, widescreen display
shows a long time window. Dedicated front-panel controls simplify operation. A USB host
port on the front panel allows you to easily transfer screenshots, instrument settings, and
waveform data to a memory stick.
Designed to Make Your Work Easier
Bright, Widescreen Display
The MSO/DPO2000 Series features a 7 inch (180 mm) widescreen,
TFT-LCD display for seeing intricate signal details.
Dedicated Front-panel Controls
Per-channel vertical controls provide simple and intuitive operation. No
longer do you need to share one set of vertical controls across all four
channels.
Connectivity
A USB host port on the front panel enables easy transfer of screenshots,
instrument settings, and waveform data to a USB thumb drive. The rear
panel contains a USB device port for controlling the oscilloscope remotely
from a PC or for connecting a USB keyboard. The USB device port can also
be used to print directly to a PictBridge®-compatible printer. An optional
10/100 Ethernet port enables easy connection to networks and an optional
Video Out port allows the oscilloscope display to be exported to an external
monitor or projector.
Compact Form Factor
A compact, portable form factor allows the MSO/DPO2000 Series to be
easily moved between labs and, with a depth of just 5.3 inches (134 mm),
it saves you valuable space on your test bench.
The MSO/DPO2000 Series’ compact form factor frees up valuable space on your bench or
desktop.
TekVPI probe interface simplifies connecting your probes to the oscilloscope.
TekVPI®Probe Interface
The TekVPI probe interface sets the standard for ease of use in probing.
TekVPI probes feature status indicators and controls, as well as a probe
menu button right on the comp box itself. This button brings up a probe
menu on the oscilloscope display with all relevant settings and controls for
the probe. TekVPI probes can be controlled remotely through USB, GPIB,
or Ethernet, enabling more versatile solutions in ATE environments.
8www.tektronix.com

Mixed Signal Oscilloscopes — MSO2000 Series, DPO2000 Series
NI LabVIEW SignalExpress™ Tektronix Edition is a fully interactive measurement
acquisition and analysis software developed jointly with National Instruments and
optimized for the MSO/DPO Series.
Extended Analysis
Acquiring data and measurements from the MSO/DPO2000 Series is as
simple as connecting a USB cable from the oscilloscope to your PC. Key
software applications – NI LabVIEW SignalExpress™ Tektronix Edition
LE, OpenChoice®Desktop, and Microsoft Excel and Word toolbars – are
included standard with each oscilloscope to enable fast and easy direct
communication with your Windows PC.
OpenChoice®Desktop software enables seamless connection between the oscilloscope
and your PC.
NI LabVIEW SignalExpress Tektronix Edition LE enables you to instantly
acquire, generate, analyze, compare, import, and save measurement data
and signals using an intuitive drag-and-drop user interface that does not
require any programming. The optional Professional Version offers over
200 built-in functions that provide additional signal processing, advanced
analysis, sweeping, limit testing, and user-defined step capabilities.
For simple tasks, the included OpenChoice Desktop enables fast and easy
communication between the oscilloscope and your PC through USB, GPIB,
or LAN for transferring settings, waveforms, and screen images.
www.tektronix.com 9

Data Sheet
Characteristics
Vertical System Analog Channels
Characteristic MSO2012
DPO2012
MSO2014
DPO2014
MSO2024
DPO2024
Input Channels 244
Analog Bandwidth (-3 dB)*1100 MHz 100 MHz 200 MHz
Calculated Rise Time 3.5 ns 3.5 ns 2.1 ns
Hardware Bandwidth Limits 20 MHz
Input Coupling AC, DC, GND
Input Impedance 1MΩ±2%, 11.5 pF ±2 pF
Input Sensitivity Range 2mV/divto5V/div
Vertical Resolution 8bits
Maximum Input Voltage, 1 MΩ300 VRMS with peaks ≤±450 V
DC Gain Accuracy (with offset set to 0 V) ±3% for 10 mV/div to 5 V/div
±4%for2mV/divto5mV/div
Channel-to-Channel Isolation
(Any Two Channels at Equal Vertical Scale)
≥100:1 at ≤100 MHz 100:1 at ≤200 MHz
*1Bandwidth is 20 MHz at 2 mV/div, all models.
Offset Range
Range 1MΩ
2mV/divto200mV/div ±1 V
>200 mV/div to 5 V/div ±25 V
Vertical System Digital Channels
Characteristic All MSO2000 Models
Input Channels 16 Digital (D15 to D0)
Thresholds Threshold per set of 8 channels
Threshold Selections TTL, CMOS, ECL, PECL, User Defined
User-defined Threshold
Range
±20 V
Maximum Input Voltage ±40 V
Threshold Accuracy ±(100 mV +3% of threshold setting)
Maximum Input Dynamic
Range
80 Vpk-pk (threshold setting dependent)
Minimum Voltage Swing 500 mVpk-pk
Input Impedance 101 kΩ
Probe Loading 8 pF
Vertical Resolution 1 bit
Horizontal System Analog Channels
Characteristic MSO2012/2014
DPO2012/2014
MSO2024
DPO2024
Maximum Sample Rate
(all channels)
1GS/s
Maximum Record Length
(all channels)
1Mpoints
Maximum Duration of
Time Captured at Highest
Sample Rate
(all channels)
1ms
Time-base Range (s/div) 4 ns to 100 s 2 ns to 100 s
Time-base Delay Time
Range
-10 divisions to 5000 s
Channel-to-Channel
Deskew Range
±100 ns
Time-base Accuracy ±25 ppm
Horizontal System Digital Channels
Characteristic All MSO2000 Models
Maximum Sample Rate
(when using any of
channels D7-D0)
1 GS/s (1 ns resolution)
Maximum Sample Rate
(when using any of
channels D15-D8)
500 MS/s (2 ns resolution)
Maximum Record Length
(all channels)
1 Mpoints
Minimum Detectable
Pulse Width
5ns
Channel-to-Channel
Skew
2nstypical
10 www.tektronix.com

Mixed Signal Oscilloscopes — MSO2000 Series, DPO2000 Series
Trigger System
CharacteristicDescription
Main Trigger Modes Auto, Normal, and Single
Trigger Coupling DC, HF reject (attenuates >85 kHz), LF reject
(attenuates <65 kHz), noise reject (reduces
sensitivity)
Trigger Holdoff
Range
20nsto8s
Trigger Signal
Frequency Counter
Provides a higher accuracy means of identifying
the frequency of trigger signals. Trigger Signal
Frequency counter resolution is 6 digits.
Trigger Sensitivity
CharacteristicDescription
Internal DC Coupled 0.4 divisions from DC to 50 MHz
0.6 divisions > 50 MHz to 100 MHz
0.8 divisions > 100 MHz to 200 MHz
External
(Auxiliary Input)
200 mV from DC to 100 MHz, 1X attenuation
Trigger Level Range
Characteristic Description
Any Channel ±4.92 divisions from center of screen
External
(Auxiliary Input)
±6.25 V, 1X attenuation
±12.5 V, 10X attenuation
Trigger Modes
Mode Description
Edge Positive or negative slope on any channel or front-panel auxiliary input. Coupling includes DC, AC, HF reject, LF reject, and noise reject.
Pulse Width Trigger on width of positive or negative pulses that are >, <, =, or ≠a specified period of time.
Runt Trigger on a pulse that crosses one threshold but fails to cross a second threshold before crossing the first again.
Logic Trigger when any logical pattern of channels goes false or stays true for specified period of time. Any input can be used as a clock to look for the
pattern on a clock edge. Pattern (AND, OR, NAND, NOR) specified for all analog and digital input channels defined as High, Low, or Don’t Care.
Setup and Hold Trigger on violations of both setup time and hold time between clock and data present on any of the input channels.
Rise/Fall Time Trigger on pulse edge rates that are faster or slower than specified. Slope may be positive, negative, or either.
Video Trigger on line number, all lines, odd, even, or all fields on NTSC, PAL, and SECAM video signals.
I2C (optional) Trigger on Start, Repeated Start, Stop, Missing ACK, Address (7 or 10 bit), Data, or Address and Data on I2C buses up to 3.4 Mb/s.
SPI (optional) Trigger on SS, MOSI, MISO, or MOSI and MISO on SPI buses up to 10.0 Mb/s.
CAN (optional) Trigger on Start of Frame, Frame Type (data, remote, error, overload), Identifier (standard or extended), Data, Identifier and Data, End of
Frame, Missing ACK, or Bit Stuffing Error on CAN signals up to 1 Mb/s. Data can be further specified to trigger on ≤,<,=,>,≥,or≠aspecific
data value. User-adjustable sample point is set to 50% by default.
RS-232/422/485/UART
(optional)
Trigger on Tx Start Bit, Rx Start Bit, Tx End of Packet, Rx End of Packet, Tx Data, Rx Data, Tx Parity Error, and Rx Parity Error.
LIN (optional) Trigger on Sync, Identifier, Data, Identifier and Data, Wakeup Frame, Sleep Frame, Errors such as Sync, Parity, or Checksum Errors.
Parallel (available
on MSO models
only)
Trigger on a parallel bus data value.
www.tektronix.com 11

Data Sheet
Acquisition Modes
Mode Description
Sample Acquire sampled values.
Peak Detect Captures glitches as narrow as 3.5 ns at all sweep
speeds.
Averaging From2to512waveformsincludedinaverage.
Roll Scrolls waveforms right to left across the screen at
sweep speeds slower than or equal to 40 ms/div.
Waveform Measurements
Measurement Description
Cursors Waveform and Screen.
Automatic
Measurements
29, of which up to four can be displayed on-screen
at any one time. Measurements include: Period,
Frequency, Delay, Rise Time, Fall Time, Positive
Duty Cycle, Negative Duty Cycle, Positive Pulse
Width, Negative Pulse Width, Burst Width, Phase,
Positive Overshoot, Negative Overshoot, Peak
to Peak, Amplitude, High, Low, Max, Min, Mean,
Cycle Mean, RMS, Cycle RMS, Positive Pulse
Count, Negative Pulse Count, Rising Edge Count,
Falling Edge Count, Area and Cycle Area.
Gating Isolate the specific occurrence within an acquisition
to take measurements on, using either the screen,
or waveform cursors.
Waveform Math
Characteristic Description
Arithmetic Add, subtract, and multiply waveforms.
FFT Spectral magnitude. Set FFT Vertical Scale
to Linear RMS or dBV RMS, and FFT Window
to Rectangular, Hamming, Hanning, or
Blackman-Harris.
Software
Product Description
NI LabVIEW
SignalExpress™
Tektronix Edi tion
A fully interactive measurement software
environment optimized for the MSO/DPO2000
Series, enables you to instantly acquire,
generate, analyze, compare, import, and save
measurement data and signals using an intuitive
drag-and-drop user interface that does not require
any programming.
Standard MSO/DPO2000 Series support for
acquiring, controlling, viewing, and exporting
your live signal data is permanently available
through the software. The full version (SIGEXPTE)
adds additional signal processing, advanced
analysis, mixed signal, sweeping, limit testing, and
user-defined step capabilities and is available for a
30-day trial period standard with each instrument.
OpenChoice®
Desktop
Enables fast and easy communication between
a Windows PC and the MSO/DPO2000
Series. Transfer and save settings, waveforms,
measurements, and screen images. Included
Word and Excel toolbars automate the transfer
of acquisition data and screen images from
the oscilloscope into Word and Excel for quick
reporting or further analysis.
IVI Driver Provides a standard instrument programming
interface for common applications such as
LabVIEW, LabWindows/CVI, Microsoft .NET, and
MATLAB.
eScope Enables control of the MSO/DPO2000 Series over
a network connection through a standard web
browser. Simply enter the IP address or network
name of the oscilloscope and a web page will be
served to the browser.
12 www.tektronix.com

Mixed Signal Oscilloscopes — MSO2000 Series, DPO2000 Series
Display Characteristics
CharacteristicDescription
Display Type 7 in. (180 mm) liquid crystal TFT color display.
Display Resolution 480 horizontal × 234 vertical pixels (WQVGA).
Waveform Styles Vectors, Dots (In Video Trigger mode), Variable
Persistence, Infinite Persistence.
Graticules Full, Grid, Cross Hair, Frame.
Format YT and XY.
Maximum Waveform
Capture Rate
Up to 5,000 wfm/s.
Input/Output Ports
Port Description
USB 2.0 High-speed
Host Port
Supports USB mass storage devices and
keyboards. One port available on front panel.
USB 2.0 High-speed
Device Port
Rear-panel connector allows for
communication/control of oscilloscope through
USBTMC or GPIB with a TEK-USB-488, and direct
printing to all PictBridge-compatible printers.
LAN Port RJ-45 connector, supports 10/100Base-T (requires
DPO2CONN).
Video Out Port DB-15 female connector, connect to show the
oscilloscope display on an external monitor or
projector (requires DPO2CONN).
Auxiliary Input Front-panel BNC connector. Input Impedance
1MΩ±2%. Max input 300 VRMS CAT II with peaks
≤±450 V.
Probe Compensator
Output
Front-panel pins
Amplitude: 5 V
Frequency: 1 kHz
Kensington Style
Lock
Rear-panel security slot connects to standard
Kensington-style lock.
Power Source
Characteristic Description
Power Source
Voltage
100 to 240 V ±10%
Power Source
Frequency
45 to 65 Hz (90 to 264 V)
360 to 440 Hz (100 to 132 V)
Power Consumption 80 W maximum
Optional TekVPI®
External Power
Supply (119-7465-xx)
Output Voltage: 12 V
Output Current: 5 A
Power Consumption: 50 W
Physical Characteristics
Dimensions mm in.
Height 180 7.1
Width 377 14.9
Depth 134 5.3
Weight kg lb.
Net 3.6 7.9
Shipping 6.2 13.7
Rackmount Configuration 4U
Cooling Clearance 2 in. (50 mm) required on left side and rear
of instrument
Environmental
Characteristic Description
Temperature
Operating 0 ºC to +50 ºC
Nonoperating -40ºCto+71ºC
Humidity
Operating High: 30 ºC to 50 ºC, 5% to 60% Relative Humidity
Low: 0 ºC to 30 ºC, 5% to 95% Relative Humidity
Nonoperating High:30ºCto55ºC,5%to60%RelativeHumidity
Low: 0 ºC to 30 ºC, 5% to 95% Relative Humidity
Altitude
Operating 3,000 meters (9,843 feet)
Nonoperating 12,000 meters (39,370 feet)
Random Vibration
Operating 0.31 GRMS from 5 to 500 Hz, 10 minutes each axis,
3 axes, 30 minutes total
Nonoperating 2.46 GRMS from 5 to 500 Hz, 10 minutes each axis,
3 axes, 30 minutes total
Regulatory
Electromagnetic
Compatibility
EC Council Directive 2004/108/EC
Safety UL61010-1:2004;
CAN/CSA C22.2 No. 61010.1-04;
EN61010-1:2001;
Complies with the Low Voltage Directive
2004/108/EC for Product Safety.
www.tektronix.com 13

Data Sheet
Ordering Information
DPO2000 Models
Product Description
DPO2012 100 MHz, 1 GS/s, 1M record length,
2-channel digital phosphor oscilloscope
DPO2014 100 MHz, 1 GS/s, 1M record length,
4-channel digital phosphor oscilloscope
DPO2024 200 MHz, 1 GS/s, 1M record length,
4-channel digital phosphor oscilloscope
MSO2000 Models
Product Description
MSO2012 100 MHz, 1 GS/s, 1M record length,
2+16 channel mixed-signal oscilloscope
MSO2014 100 MHz, 1 GS/s, 1M record length,
4+16 channel mixed-signal oscilloscope
MSO2024 200 MHz, 1 GS/s, 1M record length,
4+16 channel mixed-signal oscilloscope
All Models Include: One TPP0200 200 MHz, 10X Passive Probe per Analog
Channel, User Manual and Translated Front-panel Overlay, Documentation CD
(063-4118-xx), OpenChoice®Desktop Software, NI LabVIEW SignalExpress™
Tektronix Edition LE Software, Calibration certificates document measurement
traceability to National Metrology Institute(s) and ISO9001 Quality System
Registration, Power Cord, and a three-year warranty. Please specify power plug and
manual version when ordering.
MSO Models also Include: One P6316 16-channel logic probe and accessory kit,
and accessory bag (016-2008-xx).
Application Modules
Modules Description
DPO2AUTO Automotive Serial Triggering and Analysis Module.
Enables triggering on packet-level information on
CAN bus and LIN bus as well as analytical tools
such as digital views of the signal, bus views,
packet decoding, search tools, and packet decode
tables with time stamp information.
DPO2COMP Computer Serial Triggering and Analysis Module.
Enables triggering on packet-level information on
RS-232/422/485/UART buses as well as analytical
toolssuchasdigitalviewsofthesignal,busviews,
packet decoding, search tools, and packet decode
tables with time stamp information.
DPO2EMBD Embedded Serial Triggering and Analysis Module.
Enables triggering on packet-level information on
I2C and SPI buses as well as analytical tools such
as digital views of the signal, bus views, packet
decoding, search tools, and packet decode tables
with time stamp information. Only two-wire SPI
support available on DPO2012, MSO2012 models.
14 www.tektronix.com

Mixed Signal Oscilloscopes — MSO2000 Series, DPO2000 Series
Instrument Options
Power Plug Options
Option Description
Opt. A0 North America
Opt. A1 Universal Euro
Opt. A2 United Kingdom
Opt. A3 Australia
Opt. A5 Switzerland
Opt. A6 Japan
Opt. A10 China
Opt. A11 India
Opt. A99 No power cord
Language Options*2
Option Description
Opt. L0 English manual
Opt. L1 French manual
Opt. L2 Italian manual
Opt. L3 German manual
Opt. L4 Spanish manual
Opt. L5 Japanese manual
Opt. L6 Portuguese manual
Opt. L7Simplified Chinese manual
Opt. L8 Traditional Chinese manual
Opt. L9 Korean manual
Opt. L10 Russian manual
Opt. L99 No manual
*2Language options include translated front-panel overlay for the selected language(s).
Service Options*3
Option Description
Opt. C3 Calibration Service 3 years.
Opt. C5 Calibration Service 5 years.
Opt. CA1 Provides a single calibration event, or coverage
for the designated calibration interval, whichever
comes first.
Opt. D1 Calibration Data Report.
Opt. D3 Calibration Data Report 3 years (with Opt. C3).
Opt. D5 Calibration Data Report 5 years (with Opt. C5).
Opt. R5 Repair Service 5 years (including warranty).
*3Probes and accessories are not covered by the oscilloscope warranty and Service Offerings. Refer to the
datasheet of each probe and accessory model for its unique warranty and calibration terms.
Recommended Probes
Probe Description
TAP1500*41.5 GHz TekVPI®single-ended active probe
TDP0500*4, 6 500 MHz TekVPI 42 V differential probe
TCP0030*4120 MHz TekVPI 30 Ampere AC/DC current probe
TCP0150*420 MHz TekVPI 150 Ampere AC/DC current probe
TCPA300/400*7Current measurement system amplifiers
TCP305 DC to 50 MHz, 50 Ampere current probe for use
with TCPA300
TCP404XL DC to 2 MHz, 500 Ampere current probe for use
with TCPA400
P5100A 2.5 kV, 500 MHz, 100X high-voltage passive probe
TMDP0200*4±750 V, 200 MHz high-voltage differential probe
THDP0200*4±1.5 kV, 200 MHz high-voltage differential probe
THDP0100*4±6 kV, 100 MHz high-voltage differential probe
ADA400A*4, 5 100X, 10X, 1X, 0.1X high-gain differential amplifier
Recommended Accessories
Accessory Description
DPO2CONN Adds Ethernet (10/100Base-T) and Video Out Port
071-2331-xx Service Manual (English only)
TPA-BNC*4TekVPI to TekProbe BNC adapter
TEK-DPG*4TekVPI Deskew Pulse Generator Signal Source
067-1686-xx Deskew and Calibration Fixture
196-3508-xx Digital Probe Leadset (8 channels)
119-7465-xx TekVPI®External Power Supply
SIGEXPTE NI LabVIEW SignalExpress Tektronix Edition
Software – Full Version
TEK-USB-488 GPIB-to-USB adapter
ACD2000 Soft Transit Case and Front Protective Cover
200-5045-xx Front Protective Cover
HCTEK4321 Hard Transit Case (requires ACD2000)
RMD2000 Rackmount Kit. Does not include slide-out rails.
*4Requires TekVPI external power adapter (119-7465-00); one per oscilloscope.
*5Requires TPA-BNC adapter.
*6Probes terminate into 50 Ωbut oscilloscope will automatically adjust to account for 1 MΩinput.
*7Requires 50 Ωfeed through termination between the oscilloscope input and the BNC cable.
Warranty
Three-year warranty covering all parts and labor, excluding probes.
Tektronix is registered to ISO 9001 and ISO 14001 by SRI Quality System Registrar.
Product(s) complies with IEEE Standard 488.1-1987, RS-232-C, and with Tektronix
Standard Codes and Formats.
www.tektronix.com 15

Data Sheet Contact Tektronix:
ASEAN / Australasia (65) 6356 3900
Austria 00800 2255 4835*
Balkans, Israel, South Africa and other ISE Countries [phone]
Belgium 00800 2255 4835*
Brazil [phone]
Canada 1 800 833 9200
Central East Europe and the Baltics [phone]
Central Europe & Greece [phone]
Denmark [phone]
Finland +41526
75 3777
France 00800 2255 4835*
Germany 00800 2255 4835*
Hong Kong 400 820 5835
India 000 800 650 1835
Italy 00800 2255 4835*
Japan 81 (3) 6714 3010
Luxembourg [phone]
Mexico, Central/South America & Caribbean 52 (55) 56 04 50 90
Middle East, Asia, and North Africa [phone]
The Netherlands 00800 2255 4835*
Norway 800 16098
People’s Republic of China 400 820 5835
Poland [phone]
Portugal 80 08 12370
Republic of Korea 001 800 8255 2835
Russia & CIS [phone]
South Africa [phone]
Spain 00800 2255 4835*
Sweden 00800 2255 4835*
Switzerland 00800 2255 4835*
Taiwan 886 (2) 2722 9622
United Kingdom & Ireland 00800 2255 4835*
USA 1 800 833 9200
* European toll-free number. If not accessible, call: [phone]
Updated 10 February 2011
For Further Information. Tektronix maintains a comprehensive, constantly expanding
collection of application notes, technical briefs and other resources to help engineers working
on the cutting edge of technology. Please visit www.tektronix.com
Copyright © Tektronix, Inc. All rights reserved. Tektronix products are covered by U.S. and foreign patents,
issued and pending. Information in this publication supersedes that in all previously published material.
Specification and price change privileges reserved. TEKTRONIX and TEK are registered trademarks of
Tektroni x, Inc. All other trade names referenced are the service marks, trademarks, or registered trademarks
of their respective companies.
06 Dec 2011 3GW-22048-3
www.tektronix.com
