TCR801
Optical Clock Recovery Instrument
Installation and Safety Instructions
$
071-3732-01
TCR801型
光クロック・リカバリ・ユニット
インストールおよび安全に関する取扱説明書
TCR801
광학 클럭 복구 장비
설치및안전지침
TCR801
光学时钟恢复仪器
安装和安全手册

TCR801
Optical Clock Recovery Instrument
ZZZ Installation and Safety Instructions
xx
www.tek.com
071-3732-01
TCR801型
光クロック・リカバリ・ユニット
インストールおよび安全に関する取扱説明書
TCR801
광학 클럭 복구 장비
설치및안전지침
TCR801
光学时钟恢复仪器
安装和安全手册

Copyright © Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries
or suppliers, and are protected by national copyright laws and international treaty provisions.
Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication
supersedes that in all previously published material. Specifications and price change privileges reserved.
TEKTRONIX and TEK are registered trademarks of Tektronix, Inc.
Contacting Tektronix
Tektronix, Inc.
14150 SW Karl Braun Drive
P.O. Box 500
Beaverton, OR 97077
USA
For product information, sales, service, and technical support:
In North America, call 1-800-833-9200.
Worldwide, visit www.tek.com to find contacts in your area.

Table of Contents
Important safety information...................................................................................... 1
General safety summary ...................................................................................... 1
Service safety summary....................................................................................... 3
Terms in this manual .......................................................................................... 3
Symbols and terms on the product........................................................................... 4
Compliance information ........................................................................................... 4
EMC compliance .............................................................................................. 4
Environmental considerations................................................................................ 6
Introduction to the TCR801 ....................................................................................... 7
Standard accessories........................................................................................... 7
Product documentation........................................................................................ 8
Front panel...................................................................................................... 8
Rear panel ...................................................................................................... 9
Installation.......................................................................................................... 10
Requirements.................................................................................................. 10
Install OCR application ...................................................................................... 11
Connect and power on instrument .......................................................................... 12
TCR801 Installation and Safety Instructions i
安全性に関する重要な情報............................................................................ 1
安全にご使用いただくために .................................................................... 1
安全に保守点検していただくために ............................................................ 3
本マニュアル内の用語............................................................................. 4
本製品に使用される記号と用語.................................................................. 4
適合性に関する情報 .................................................................................... 5
EMC適合性 .......................................................................................... 5
環境条件 ............................................................................................. 7
TCR801型の概要 ........................................................................................ 8
スタンダード・アクセサリ ....................................................................... 8
製品マニュアル ..................................................................................... 9
前面パネル........................................................................................... 9
後部パネル.......................................................................................... 10
設置 ...................................................................................................... 11
要件.................................................................................................. 11
OCRアプリケーションのインストール ........................................................ 12
機器の接続と起動 ................................................................................. 13

Table of Contents
ii TCR801 Installation and Safety Instructions
중요한 안전 정보 ........................................................................................ 1
일반 안전 사항 요약................................................................................. 1
서비스안전사항요약.............................................................................. 3
본설명서의용어.................................................................................... 3
제품의기호및용어................................................................................. 4
컴플라이언스 정보 ...................................................................................... 4
EMC 컴플라이언스 ................................................................................. 4
환경 고려 사항....................................................................................... 6
TCR801 소개 ............................................................................................. 6
기본 액세서리 ....................................................................................... 7
제품 설명서 .......................................................................................... 8
전면 패널............................................................................................. 8
후면 패널............................................................................................. 9
설치 ...................................................................................................... 10
요구 사항............................................................................................ 10
OCR 애플리케이션 설치........................................................................... 11
장비연결및전원켜기............................................................................ 12
重要安全信息 ............................................................................................ 1
常规安全概要........................................................................................ 1
维修安全概要........................................................................................ 2
本手册中的术语 ..................................................................................... 3
产品上的符号和术语 ............................................................................... 3
合规性信息 ............................................................................................... 4
EMC 合规性.......................................................................................... 4
环境注意事项........................................................................................ 6
TCR801 简介 ............................................................................................. 6
标配附件 ............................................................................................. 7
产品文档 ............................................................................................. 8
前面板 ................................................................................................ 8
后面板 ................................................................................................ 9
安装 ...................................................................................................... 10
要求.................................................................................................. 10
安装 OCR应用程序 ................................................................................ 11
连接仪器并打开仪器电源 ......................................................................... 11

Important safety information
This manual contains information and warnings that must be followed by the user
for safe operation and to keep the product in a safe condition.
To safely perform service on this product, additional information is provided at
the end of this section. (See page 3, Service safety summary.)
General safety summary
Use the product only as specified. Review the following safety precautions to
avoid injury and prevent damage to this product or any products connected to it.
Carefully read all instructions. Retain these instructions for future reference.
This product shall be used in accordance with local and national codes.
For correct and safe operation of the product, it is essential that you follow
generally accepted safety procedures in addition to the safety precautions specified
in this manual.
The product is designed to be used by trained personnel only.
Only qualified personnel who are aware of the hazards involved should remove
the cover for repair, maintenance, or adjustment.
Before use, always check the product with a known source to be sure it is
operating correctly.
This product is not intended for detection of hazardous voltages.
Use personal protective equipment to prevent shock and arc blast injury where
hazardous live conductors are exposed.
While using this product, you may need to access other parts of a larger system.
Read the safety sections of the other component manuals for warnings and
cautions related to operating the system.
When incorporating this equipment into a system, the safety of that system is the
responsibility of the assembler of the system.
To avoid fire or personal
injury
Use proper power cord. Use only the power cord specified for this product and
certified for the country of use.
Do not use the provided power cord for other products.
Ground the product. This product is indirectly grounded through the grounding
conductor of the mainframe power cord. To avoid electric shock, the grounding
conductor must be connected to earth ground. Before making connections to the
input or output terminals of the product, make sure that the product is properly
grounded.
TCR801 Installation and Safety Instructions 1

Important safety information
Do not disable the power cord grounding connection.
Power disconnect. The power cord disconnects the product from the power
source. See instructions for the location. Do not position the equipment sothat
it is difficult to operate the power cord; it must remain accessible to the user at
all times to allow for quick disconnection if needed.
Use proper AC adapter. Use only the AC adapter specified for this product.
Observe all terminal ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product. Consult the product manual for further ratings
information before making connections to the product.
Do not apply a potential to any terminal, including the common terminal.
The measuring terminals on this product are not rated for connection to mains or
Category II, III, or IV circuits.
Do not operate without covers. Do not operate this product with covers or panels
removed, or with the case open. Hazardous voltage exposure is possible.
Avoid exposed circuitry. Do not touch exposed connections and components
when power is present.
Do not operate with suspected failures. If you suspect that there is damage to this
product, have it inspected by qualified service personnel.
Disable the product if it is damaged. Do not use the product if it is damaged
or operates incorrectly. If in doubt about safety of the product, turn it offand
disconnect the power cord. Clearly mark the product to prevent its further
operation.
Examine the exterior of the product before you use it. Look for cracks or missing
pieces.
Do not operate in wet/damp conditions. Be aware that condensation may occur if
a unit is moved from a cold to a warm environment.
Do not operate in an explosive atmosphere.
Keep product surfaces clean and dry. Remove the input signals before you clean
the product.
Provide proper ventilation. Refer to the installation instructions in the manual for
details on installing the product so it has proper ventilation.
Slots and openings are provided for ventilation and should never be coveredor
otherwise obstructed. Do not push objects into any of the openings.
Provide a safe working environment. Always place the product in a location
convenient for viewing the display and indicators.
2 TCR801 Installation and Safety Instructions

Important safety information
Avoid improper or prolonged use of keyboards, pointers, and button pads.
Improper or prolonged keyboard or pointer use may result in serious injury.
Be sure your work area meets applicable ergonomic standards. Consult with an
ergonomics professional to avoid stress injuries.
Use only the Tektronix rackmount hardware specified for this product.
Servicesafetysummary
The Servicesafetysummarysection contains additional information required to
safely perform service on the product. Only qualified personnel should perform
service procedures. Read this Service safety summary and the General safety
summary before performing any service procedures.
To avoid electric shock. Do not touch exposed connections.
Do not service alone. Do not perform internal service or adjustments of this
product unless another person capable of rendering first aid and resuscitation is
present.
Disconnect power. To avoid electric shock, switch off the product power and
disconnect the power cord from the mains power before removing any covers or
panels, or opening the case for servicing.
Use care when servicing with power on. Dangerous voltages or currents may exist
in this product. Disconnect power, remove battery (if applicable), and disconnect
test leads before removing protective panels, soldering, or replacing components.
Verify safety after repair. Always recheck ground continuity and mains dielectric
strength after performing a repair.
Terms in this manual
These terms may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
TCR801 Installation and Safety Instructions 3

Compliance information
Symbols and terms on the product
These terms may appear on the product:
DANGER indicates an injury hazard immediately accessible as you read
the marking.
WARNING indicates an injury hazard not immediately accessible as you
read the marking.
CAUTION indicates a hazard to property including the product.
When this symbol is marked on the product, be sure to consult the manual
to find out the nature of the potential hazards and any actions which have to
betakentoavoidthem. (Thissymbolmayalsobeusedtorefertheuserto
ratings in the manual.)
The following symbol(s) may appear on the product:
Compliance information
This section lists the EMC (electromagnetic compliance), safety, and
environmental standards with which the instrument complies. This productis
intended for use by professionals and trained personnel only; it is not designed
for use in households or by children.
Questions about the following compliance information may be directed to the
following address:
Tektronix, Inc.
PO Box 500, MS 19-045
Beaverton, OR 97077, USA
www.tek.com
EMC compliance
EU EMC Directive Meets intent of Directive 2014/30/EU for Electromagnetic Compatibility.
Compliance was demonstrated to the following specifications as listed in the
Official Journal of the European Communities:
EN 61326-1. EMC requirements for electrical equipment for measurement,
control, and laboratory use. 123
4 TCR801 Installation and Safety Instructions

Compliance information
CISPR 11. Radiated and conducted emissions, Group 1, Class A
IEC 61000-4-2. Electrostatic discharge immunity
IEC 61000-4-3. RF electromagnetic field immunity
IEC 61000-4-4. Electrical fast transient / burst immunity
IEC 61000-4-5. Power line surge immunity
IEC 61000-4-6. Conducted RF immunity
IEC 61000-4-8. Power frequency magnetic field immunity test
IEC 61000-4-11. Voltage dips and interruptions immunity
EN 61000-3-2. AC power line harmonic emissions
EN 61000-3-3. Voltage changes, fluctuations, and flicker
EMC compliance Meets the intent of Directive 2014/30/EU for Electromagnetic Compatibility
when it is used with the product(s) stated in the specifications table. Refertothe
EMC specification published for the stated products. May not meet the intentof
the directive if used with other products.
1This product is intended for use in nonresidential areas only. Use in residential areas may cause electromagnetic
interference.
2Emissions which exceed the levels required by this standard may occur when this equipment is connected to a
test object.
3For compliance with the EMC standards listed here, high quality shielded interface cables that incorporate low
impedance connection between the cable shield and the connector shell should be used.
Australia / New Zealand
EMC
Complies with the EMC provision of the Radiocommunications Act per the
following standard, in accordance with ACMA:
EN 61326-1. Radiated and Conducted Emissions, Group 1, Class A.
TCR801 Installation and Safety Instructions 5

Compliance information
Environmental considerations
This section provides information about the environmental impact of the product.
Restriction of hazardous
substances
Complies with RoHS2 Directive 2011/65/EU.
Product end-of-life
handling
Observe the following guidelines when recycling an instrument or component:
Equipment recycling. Production of this equipment required the extraction and
use of natural resources. The equipment may contain substances that could be
harmful to the environment or human health if improperly handled at the product’s
end of life. To avoid release of such substances into the environment and to
reduce the use of natural resources, we encourage you to recycle this product in
an appropriate system that will ensure that most of the materials are reused or
recycled appropriately.
This symbol indicates that this product complies with the applicable European
Union requirements according to Directives 2012/19/EU and 2006/66/EC
on waste electrical and electronic equipment (WEEE) and batteries.
For information about recycling options, check the Tektronix Web site
(www.tek.com/productrecycling).
Battery recycling. This product contains a small installed lithium metal button
cell. Please properly dispose of or recycle the cell at its end of life according to
local government regulations.
Perchlorate materials. This product contains one or more type CR lithium
batteries. According to the state of California, CR lithium batteries are
classified as perchlorate materials and require special handling. See
www.dtsc.ca.gov/hazardouswaste/perchlorate for additional information.
6 TCR801 Installation and Safety Instructions

Introduction to the TCR801
Introduction to the TCR801
The TCR801 Optical Clock Recovery is a dual band clock recovery instrument
centered around 26 and 53 GBd. The advanced architecture of the TCR801 allows
you to adjust Phase Lock Loop (PLL) bandwidths to comply with standards, and
is a crucial component in the test and validation of optical designs, when used
with other testing and measuring instruments.
Key features Designed to lock in two ranges:
25.6 to 29 GBd PAM2 / NRZ or PAM4
51.2 to 58 GBd PAM2 / NRZ or PAM4
1250 nm to 1650 nm wavelength
Adjustable PLL bandwidths to configure the “golden PLL” response needed
for standard compliance testing
IEEE Ethernet Control Interface, which runs the instrument remotely
over the network using the standalone PC software or through PI using
VISA/Tek-VISA.
Provides two separate RF clock outputs
Intelligent auto relock capability and manual re-lock functionality available
from the instrument front panel
2 x 20 LCD is used to view network IP address and current lock status,
including the measured symbol rate
Ethernet port for device control
USB Type B port for reset of IP configuration
External 12 V power supply
Standard accessories
Your instrument shipped with the following standard accessories. See the TCR801
datasheet on www.tek.com for a list of optional accessories and other options.
Description Quantity Tektronix part number
Ethernet cable, 2 m (CAT6 GIGE),
double shielded
1 174-7292-00
50%/50% single mode FC-PC
splitter
1 167-4333-00
50 Ωcoaxial SMA terminators 2 015-1022-01
TCR801 Installation and Safety Instructions 7

Introduction to the TCR801
Description Quantity Tektronix part number
12 VDC 5 A AC-DC power supply;
50 to 60 Hz; 100 to 250 VAC
1 119-8726-00
Test lead, banana to banana, 18 in 1 174-7295-00
Product documentation
The following product documentation is available for download from
www.tek.com.
Front panel
Item Connector Description
1 Power button Power button to power unit on/off . Once unit is on, push (and release) to
attempt a relock, or hold >5 sec) to switch unit to standby.
2 Antistatic connection A banana-jack short to ground
3LCD display 61 mm (W) x 12 mm (H), 2 x 20 liquid crystal display (LCD). Used to display
Ethernet Address and system state information
4CLOCK1
5CLOCK2
Clock electrical output (CLK/4 (13 GHz to 14.5 GHz) for a 52 to 58 Gbaud
input, CLK/2 (13 GHz to 14.5 GHz) for a 26 to 29 GBaud signal)
Single-ended, AC coupled, amplitude; Between 900 mVpp to 1.1 Vpp into
50 Ωterminated to ground. When output disabled, Vout RMS <5 mV
Both outputs are disabled/enabled at the same time.
8 TCR801 Installation and Safety Instructions

Introduction to the TCR801
Item Connector Description
6OPTICAL INPUT 1250-1650 nm single mode optical input with variable gain optical to
electrical conversion for high dynamic range. FC/PC
7Status LEDs Three LED's on the front panel to display Power (Hold), Lock (Push), and
Output On status.
Green = Locked
Orange = Unlocked
Orange Blinking = attempting to lock
Output on: Light indicator should be green when either Clock1 or Clock2
outputs are enabled. LED is turned off when output disabled.
Rear panel
Item Connector Description
1USB USB Type B. Can be used to set static IP address
2LAN Base-T Ethernet (10/100/1000)
312V DC input Line 90-264 VAC power input
TCR801 Installation and Safety Instructions 9

Installation
Installation
The TCR801 hardware can be installed as follows under the listed performance
conditions and power specifications. Ensure the performance conditions listed
here can be met before installing and powering on the instrument.
The Tektronix Optical Clock Recovery (OCR) software application you use to
control the instrument should be installed onto a Microsoft Windows OS PC. You
can also control the instrument without the application by using PI commands.
Requirements
The following requirements must be met to install the OCR application and to
connect and use the instrument.
PC requirements for
OCR software application
installation
Microsoft Windows 7 and above OS
Power specifications 12 V DC input
Line 90-264 VAC power input
Key environmental and
physical specifications
Characteristic Specification
Temperature
Operating 0°C to +40°C, with 15°C/hour maximum gradient, non-condensing, derated 1.0 °C per 300
meters above 1,500 meters altitude.
Non-operating -20°C to +60°C, with 30°C/hour maximum gradient
Humidity
Operating 5% to 95% relative humidity ( RH) at up to +30°C,
5% to 45% RH above +30°C up to +45°C, non-condensing, and as limited by a Maximum
Wet-Bulb Temperature of +29°C (derates relative humidity to 32% RH at +45°C)
Non-operating 5% to 95% RH at up to +30°C,
5% to 45% RH above +30°C up to +60°C, non-condensing, and as limited by a Maximum
Wet-Bulb Temperature of +29°C (derates relative humidity to 20% RH at +60°C)
Altitude
Operating Up to 3,000 meters, derate maximum operating temperature by 1°C per 300 meters above
1,500 meters altitude.
Non-operating Up to 12,000 meters
10 TCR801 Installation and Safety Instructions

Installation
Characteristic Specification
Weight 4.5 kg (10 lbs), instrument only
Height 56 mm (2.20 in), including feet
Width 206 mm (8.11 in)
Depth 561 mm (22.08 in)
Clearance Rear: 5.08 cm (2 in)
Sides: 5.08 cm (2 in)
Bottom: Cooling inlets on the bottom require that the instrument rests on a flat surface with the
feet providing sufficient clearance.
Performance conditions This instrument must have been calibrated at an ambient temperature between
+20° C and +30° C.
The instrument must have had a warm-up period of at least 10 minutes.
The instrument must be in an environment with temperature, altitude, and
humidity within the operating limits.
Install OCR application
Complete the following steps to download and install the latest OCR application
software. You must have a Microsoft Windows 7 or above OS on the computer
onto which you want to install the software.
1. Go to www.tek.com.
2. Click Downloads. In the Download menu, select Software as the
DOWNLOAD TYPE, enter Optical Clock Recovery in the MODEL OR
KEYWORD field, and click SEARCH.
3. Select the latest version of software and follow the instructions to download
the application.
4. Double-click the executable and follow the on-screen instructions to install
the application.
TCR801 Installation and Safety Instructions 11

Installation
Connect and power on instrument
How you connect the instrument to other devices depends on your use case and
desired setup. Regardless of your setup, the following steps apply. An connection
diagram is provided at the end of this procedure as an example of one possible
setup.
1. Connect an Ethernet cable to the LAN connector on the rear panel of the
TCR801.
2. Connect supplied 12 V power adapter to the rear panel of the TCR801 and
to the power source.
3. Press the Power button on the front panel to turn on the instrument.
4. Launch the OCR application that is installed on the PC.
5. Select Utility >IP Configuration.
6. Select Silicon Labs COM as the port. Set the IP configuration as needed for
your computer and network through USB or Ethernet.
If the TCR01 is already connected, select the Socket radial button and enter
the IP address in Current IP. If not, proceed to the next step.
12 TCR801 Installation and Safety Instructions

Installation
7. Select File >Connect.
TCR801 Installation and Safety Instructions 13

Installation
8. The Connect pop-up window will appear. Enter the IP address of the TCR801
to which you want to connect and click Connect. The IP address will show
on the front panel display.
14 TCR801 Installation and Safety Instructions
