Tempo Fitness 612T User manual

1
JOHNSON
Issue date
Edition
01
Doc No.
SM-TM-TEM-001
Revision
date
Edition time
01
Page
41
Johnson Industries (Shanghai) Co.,Ltd
Document: 612T&622T Service Manual
Approval
Review
Editor
Eric
Kali/Lucy

2
Product Browse

3

4
Contents
CHAPTER 1: SERIAL NUMBER LOCATION.................................................................................................................. 6
CHAPTER 2: PREVENTATIVE MAINTENANCE
2.1 Preventative Maintenance.......................................................................................................................................... 8
2.2 Tension and Centering the Running Belt.............................................................................................................. 10
CHAPTER 3: CONSOLE INSTRUCTION
3.1 Console Overview.......................................................................................................................................................11
3.1.1 612T Overview......................................................................................................................................................... 11
3.1.2 622T Overview......................................................................................................................................................... 12
3.2 Display Window Indication........................................................................................................................................13
3.3 Getting Started & Selecting a Workout.................................................................................................................. 14
3.4 Program Information.................................................................................................................................................. 15
CHAPTER 4: ENGINEERING MODE
4.1 Engineering Mode.......................................................................................................................................................17
4.2 Engineering Mode Overview.................................................................................................................................... 18
CHAPTER 5: TROUBLESHOTING
5.1 Electrical Diagram....................................................................................................................................................19
5.2 MCB Wiring Instructions.........................................................................................................................................20
5.2.1 Troubleshooting - No Power To The Console...............................................................................................21
5.2.2 Troubleshooting - No Function For Safety Key............................................................................................. 22
5.2.3 Troubleshooting - No Response For Machine(Console & Motor).............................................................23
5.2.4 Troubleshooting - Incline Motor Issues........................................................................................................... 24
5.2.5 Troubleshooting - Noise Issues........................................................................................................................ 25
5.2.6 Troubleshooting - Speaker / Audio Issues..................................................................................................... 27
5.2.7 Troubleshooting - Heart Rate Function Issues..............................................................................................29

5
CHAPTER 6: PART REPLACEMENT GUIDE
6.1 Motor Cover Replacement..................................................................................................................................... 30
6.2 Rear Roller Replacement.......................................................................................................................................31
6.3 Side Rail Replacement........................................................................................................................................... 32
6.4 Running Deck Replacement..................................................................................................................................33
6.5 Front Roller Replacement...................................................................................................................................... 34
6.6 Running Belt Replacement.................................................................................................................................... 35
6.7 Motor Control Board (MCB) Replacement......................................................................................................... 36
6.8 Motor Replacement................................................................................................................................................. 37
6.9 Drive Belt Replacement..........................................................................................................................................38
6.10 Console Replacement.......................................................................................................................................... 39
6.11 Incline Motor Replacement (Only For 622T)................................................................................................... 40
6.12 Heart Rate Board Replacement (Only For 622T)...........................................................................................41

CHAPTER 2: Serial Number Location
6
1.1 SERIAL NUMBER LOCATION
612T

CHAPTER 2: Serial Number Location
7
622T

CHAPTER 2: Preventative Maintenance
8
2.1 PREVENTATIVE MAINTENANCE
Preventative maintenance is the key to smoothly operating equipment, as well as keeping the user’s liability to a minimum.
Equipment needs to be inspected at regular intervals. Defective components must be replaced immediately. Improperly
working equipment must be kept out of use until it is repaired. Ensure that any person(s) making adjustments or
performing maintenance or repair of any kind is qualified to do so.
EVERY DAY (DAILY)
Clean and inspect, following these steps:
• Turn off the treadmill with the ON / OFF switch, then unplug the power cord at the wall outlet.
• Wipe down the running belt, deck, motor cover, and console casing with a damp cloth. Never use solvents, as they can
cause damage to the treadmill.
• Inspect the power cord. If the power cord is damaged, stop using and contact Customer Technical Support.
• Make sure the power cord is not underneath the treadmill or in any other area where it can become pinched or cut.
• Check the tension and alignment of the running belt. Make sure that the treadmill belt will not damage any other
components on the treadmill by being misaligned.
• If any labels are damaged or illegible, contact Customer Technical Support for replacements.
EVERY WEEK (WEEKLY)
Clean underneath the treadmill following these steps:
• Turn off the treadmill with the ON / OFF switch, then unplug the power cord at the wall outlet.
• Fold the treadmill into the upright position, making sure that the lock latch is secured.
• Move the treadmill to a remote location.
• Wipe or vacuum any dust particles or other objects that may have accumulated underneath the treadmill.
• Return the treadmill to its previous position.
EVERY MONTH - IMPORTANT!
• Turn off the treadmill with the ON / OFF switch, then unplug the power cord at the wall outlet.
• Inspect all assembly bolts of the machine for proper tightness.
• Remove the motor cover. Wait for ALL display screens to be off.
• Clean the motor and lower board area to eliminate any lint or dust particles that may have accumulated. Failure to do
so may result in premature failure of key electrical components.
• Vacuum and wipe down the belt with a damp cloth. Vacuum any black / white particles that may accumulate around
the unit. These particles may accumulate from normal treadmill use.

CHAPTER 2: Preventative Maintenance
9
2.1 PREVENTATIVE MAINTENANCE-CONTINUED
EVERY 6 MONTHS OR 150 MILES
It is necessary to lubricate your treadmill running deck every
six months or 150 miles (240 kilometers) to maintain optimal
performance. Once the treadmill reaches 150 miles (240
kilometers), the console will display the message “LUBE” or
“LUBE BELT”. The treadmill will not operate while the
message is showing. Hold ‘STOP’ for 5 seconds to suspend
message for 5 miles.
Your treadmill came with a bottle of lubricant which can be
used for two applications.
● Turn off the treadmill with the on/off switch, then unplug the
power cord at the wall outlet.
● Loosen both the rear roller bolts. (for best results, place two
removable marks on both sides of the frame and note roller
position). Once the belt is loosened, take the bottle of
lubricant and apply it to the entire top surface of the
running deck. Tighten both rear roller bolts (matching up the marks for proper position) to original position. After you
have applied lubricant, plug in the power cord, insert the safety key, start the treadmill and walk on the belt for two
minutes to spread the lubricant.
● Lubricate the air shocks with Teflon based spray.
● Once lubrication is complete, hold “elevation ▲ & Stop” both keys 5 seconds then the message will be clean.

CHAPTER 2: Preventative Maintenance
10
2.2 TENSIONING & CENTERING THE RUNNING BELT
If you can feel a slipping sensation when running on the treadmill, the running belt must be tightened. In most cases, the
belt has stretched from use, causing the belt to slip. This is a normal and common adjustment. To eliminate this slipping,
turn the treadmill off and tension both the rear roller bolts using the supplied Allen wrench, turning them ¼ turn to the right
as shown. Turn the treadmill on and check for slipping. Repeat if necessary, but never turn the roller bolts more than ¼
turn at a time. Belt is properly tensioned when the slipping sensation is gone.
The running belt has been properly adjusted at the factory before it was shipped. At times the belt can move off-center
during shipment. Before operating the treadmill, make sure the belt is centered and remains centered to maintain smooth
operation.
If the running belt is too far to the right side: With the treadmill
running at 1 mph, turn the left adjustment bolt counter-clockwise
¼ turn at a time (using the supplied Allen wrench). Check the belt
alignment. Allow belt to run a full cycle to gauge if more
adjustment is needed. Repeat if necessary, until the belt remains
centered during use.
If the running belt is too far to the left side: With the treadmill
running at 1 mph, turn the right adjustment bolt counter-clockwise
¼ turn at a time (using the supplied Allen wrench). Check the belt
alignment. Allow belt to run a full cycle to gauge if more
adjustment is needed. Repeat if necessary, until the belt remains
centered during use.

CHAPTER 3: Console Instruction
11
3.1 CONSOLE OVERVIEW
3.1.1 612T Console Overview
Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.
A) MONITOR DISPLAY: Speed, Time, Heart Rate, Distance, and Calories.
B) STOP: Press to pause/end your workout. Hold for 3 seconds to reset the treadmill.
C) Start: Simply press to begin exercising starts your program and also changes the display.
D) SPEED ARROW KEYS: Used to adjust speed in small increments.
E) SAFETY KEY POSITION: Enables treadmill when safety key is engaged.
F) QUICK PROGRAM & SPEED KEYS: Press key to select program. Once in a program, press key to select speed.
G) THUMB SENSOR: Monitors heart rate.
H) WATER BOTTLE / CD / MP3 HOLDERS: Holds personal workout equipment.
Note: Thumb pulse may be inaccurate when used in low-light environments.

CHAPTER 3: Console Instruction
12
3.1.2 622T Console Overview
Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use.
A) MONITOR DISPLAY: Speed, Time, Heart Rate, Distance, Incline, and Calories.
B) STOP: Press to end your workout. Hold for 3 seconds to reset the treadmill.
C) START: Simply press to begin exercising or starts/pauses your program.
D) ENTER / CHANGE DISPLAY: Used to confirm selection and scroll between workout information.
E) QUICK ADJUST INCLINE / SPEED KEYS: Used to reach desired incline and/or speed more quickly. Select after pressing PRESS
TO SET INCLINE or PRESS TO SET SPEED KEY.
F) PRESS TO SET INCLINE KEY: Used to confirm chosen incline. Press before selecting INCLINE.
G) INCLINE ARROW KEYS: Used to adjust incline in small increments.
H) PRESS TO SET SPEED KEY: Used to confirm speed change. Press before selecting SPEED.
I) SPEED ARROW KEYS: Used to adjust speed in small increments.
J) QUICK PROGRAM KEYS: Press key to select program.
K) QUICK TIME KEYS: Press key to select time.
L) SAFETY KEY POSITION: Enables treadmill when safety key is engaged.
M) WATER BOTTLE / CD / MP3 HOLDERS: Holds personal workout equipment.

CHAPTER 3: Console Instruction
13
3.2 DISPLAY WINDOWS INDICATION
•SPEED: Shown as km/h. Indicates how fast your walking or running surface is moving.
•TIME: Shown as minutes and seconds. View the time remaining or the time elapsed in your workout.
•PULSE: Shown as beats per minute. Used to monitor your heart rate (displayed when contact is made with the pulse grips
or thumb pulse sensor).
•Distance: Shown as km. Indicates distance traveled during your workout.
•INCLINE (622T ONLY): Shown as percent. Indicates the incline of your walking or running surface.
•CALORIES: Total calories burned during your workout.
QUICK KEY OPERATION
Once you have started your program you can quickly change your speed or incline level.
612T: To change your speed, press one of the four quick speed keys: easy (5 km/h), moderate (8 km/h), hard (12 km/h) or
sprint (16 km/h). The treadmill will adjust accordingly.
622T: Press the press to set speed or press to set incline key and then press a number (0-9). This confirms that this is the
speed or incline you want and the treadmill will adjust accordingly.
CLEAR CURRENT SE LECTION
To clear the current program selection or screen, hold the stop button for 5 seconds.
CHANGE VIEWING SCREENS
612T: Press the START button during your workout to change the display between time/distance and heart rate/ calories.
622T: To have the display rotate continuously (time, incline and pulse; distance, speed and calories), hold the
ENTER/CHANGE DISPLAYS button for 5 seconds.
TO RESET CONSOLE
Hold STOP key for 3 seconds.
FINISHING YOUR WORKOUT
When your workout is complete, the monitor display will flash and beep. Your workout information will stay displayed on
the console for 30 seconds and then reset.

CHAPTER 3: Console Instruction
14
3.3 GETTING STARTED & SELECTING A WORKOUT
3.3.1 612T GETTING STARTED
1) Check to make sure no objects are placed on the belt that will hinder the movement of the treadmill.
2) Plug in the power cord and turn the treadmill ON.
3) Stand on the side rails of the treadmill.
4) Attach the safety key clip to part of your clothing.
5) Insert the safety key into the safety keyhole in the console.
6) You have two options to start your workout:
A) QUICK START
Simply press the start key to begin working out. Or...
B) SELECT A PROGRAM
1. Press a PROGRAM key to select a program.
2. Use the ARROW keys to select time.
3. Press START to begin.
3.3.2 622T GETTING STARTED
1) Check to make sure no objects are placed on the belt that will hinder the movement of the treadmill.
2) Plug in the power cord and turn the treadmill ON.
3) Stand on the side rails of the treadmill.
4) Attach the safety key clip to part of your clothing.
5) Insert the safety key into the safety keyhole in the console.
6) You have two options to start your workout:
A) QUICK START UP
Simply press the START key to begin working out. Or...
B) SELECT A PROGRAM
1. Press a PROGRAM key to select a program.
2. Press a TIME SETTINGS key to select time (use ARROW keys to adjust time setting up and down).
3. Press START to begin.

CHAPTER 3: Console Instruction
15
3.4 PROGRAM INFORMATION

CHAPTER 3: Console Instruction
16

CHAPTER 4 : Engineering Mode
17
4.1 ENGINEERING MODE

CHAPTER 4 : Engineering Mode
18
4.2 ENGINEERING MODE OVERVIEW

CHAPTER 5: Troubleshooting
19
5.1.1 612T Electrical Diagram
5.1.1 622T Electrical Diagram

CHAPTER 5: Troubleshooting
20
5.2 TROUBLESHOOTING-MCB WIRING INSTRUCTIONS
MCB wiring instructions
CN1 ------- AC motorcable socket
CN2
-------
ACpower cable socket
CN3 ------- Elevation motor cable socket
CN4 ------- Console set cable socket
CN5
-------
Transfer board
