TESTO 310 Reference guide

testo 310 flue gas analyser
Brief instructions
These brief instructions provide an overview over the most important functions
of the product. Before using the product, you must read and follow the
instruction manual!
The instrument has two configuration menus. The menu that is
opened depends on the instrument status when called up.
Commissioning/instrument configuration menu
Area version, measurement units, time and date can be set.
When the instrument is switched on initially, the configuration menu is
opened automatically.
1. Switch the instrument on: hold down []until all segments are shown on
the display.
2. Open instrument configuration menu: Press right function key [set] during
the initialisation phase.
3. Make settings:
[] switches to the next parameter, while [esc] takes you to the
previous parameter.
Parameter Explanation
ArEA (area
version)
Selecting the area version activates different calculation
formulas and associated measurement parameters.
> Select area version code: [▲] and [▼].
1: USA, HU, IN, KR / 2: GB, RU, DK, AU, JP, CN / 3: NL,
SE, TR, RO / 4: DE, AT, CH, CZ, FR, ES, BE, PL, PT, AR,
BR / 5: IT
> Confirm the entry: [OK].
UnI Only when area version 5 is selected
> Measurement procedure according to UnI norm: activate
[On] / deactivate [OFF].
Pressure,
temperature
> Select the unit: [▲] and [▼], confirm the entry: [OK].

Parameter Explanation
Time, date > Select the parameter: [], set the values: [▲] and [▼],
confirm the entry: [OK].
Measurements configuration menu
Fuels and measurement units can be set.
1. Switch the instrument on: hold down []until all segments are shown on
the display.
2. Open Measurements configuration menu: After the instrument initialisation
phase, press the right function key ([set]).
3. Make settings:
[] switches to the next parameter, while [esc] takes you to the
previous parameter.
Parameter Explanation
Fuel > Select the fuel: [▲] and [▼], switch to the next parameter:
[].
UnI Only when area version 5 is selected
> Measurement procedure according to UnI norm: activate
[On] / deactivate [OFF].
Pressure > Select the unit: [▲] and [▼], switch to the next parameter:
[].
Temperature > Select the unit: [▲] and [▼], confirm the entries: [OK].
Preparing measurements
After switching on the instrument or selecting a flue gas ( ) or ambient CO
probe ( ) measurement, the gas sensors are zeroed and the combustion air
temperature is measured: the flue gas probe must be close to the burner's fresh
air inlet duct!
1. Switch the instrument on: hold down []until all segments are shown on
the display.
2. Select the fuel: [▲] and [▼], confirm the entry: [OK].
Measurement type Explanation
Flue gas > Select :[]→[OK].
Area version 1-4, area version 5 (Uni ON)
1. Start measurement: [Start].

Performing the measurement
Measurement type Explanation
Flue gas > Edit reading display line 1/line 2: [▲] /[▼].
Option for area version 5
> End measurement before the measurement period has
lapsed: [Stop].
- Once the measurement period has lapsed, the
measurement stops automatically.
> Scroll through measurement result line 1/line 2: [▲]/
[▼].
- Display of Uni measurement mean values.
2. End measurement: [Stop].
> Remove flue gas probe from the flue gas duct and
purge with fresh air.
Ambient CO > Select :[]→[OK].
1. Start measurement: [Start].
2. End measurement: [Stop].
Draught > Select :[]→[OK].
- The flue gas probe must be outside the flue.
1. Start measurement: [Start].
2. After zeroing, position the flue gas probe in the centre
of flow.
3. End measurement: [Stop].
Differential pressure > Select :[]→[OK].
1. Open the flue gas probe filter chamber
2. Remove the particle filter.
3. Remove the sealing plug from the holder.
4. Close the gas path with the sealing plug.
5. Check that the sealing plug is fitted tightly.
6. Fit silicone hose on to the flue gas probe shaft. The
probe shaft openings must be closed.
7 Start measurement: [Start].
8. Connect the silicone hose to the sampling point.
9. Pressurise the system.
10 End measurement: [Stop].
[]can be used to send the measurement results to a protocol
printer.

0971 3100 en 02 V01.00
