Texas Instruments ADS125H02 User manual

1-of-4
Decoder
5 V5 V
PGA 24-Bit
ûADC
AINCOM
MUX
AIN0
AIN1
ADS125H02
AVDD DVDD
DGND
VIN = ± 10V
BUF
2.5-V
REF
REF MUX
REFP0 REFP1
Temp
Sensor
Supply
Read
1 nF
1 nF
10 nF
1 k
1 k
MUX509
VSS
-15 V
0.1 F
S1A
S1B
S2A
S2B
S3A
S3B
S4A
S4B
A0
A1
EN
GPIO1
GPIO0
GPIO2
GPIO
CAPP CAPN
AGND
1 nF C0G
DA
DB
GND
VDD
15 V
0.1 F
HV_AVSS
-15 V
0.1 F
HV_AVDD
15 V
0.1 F
1 F
TVS3300TVS3300
0110: 4
0111: 8
1000: 16
1001: 32
1010: 64
1011: 128
0000: 0.125
0001: 0.1875
0010: 0.25
0011: 0.5
0100: 1
0101: 2
PGA Gain Options
Reg. MODE4 - GAIN[3:0]
1 F
REFOUT
1 F10 F
BYPASS
1 F
210
210
1 nF
1 nF
10 nF
1 k
1 k
210
210
1 nF
1 nF
10 nF
1 k
1 k
210
210
1 nF
1 nF
10 nF
1 k
1 k
210
210
Optional
TVS Protection Input Filter
VIN = ± 10V
IIN = 0 to 20 mA
(V = 0 to 5V)
IIN = 0 to 20 mA
(V = 0 to 5V)
250250
+
-
+
-
+
-
+
-
1
SBAA386–December 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
Four-channel, differential input, DAQ front-end circuit with configurable
voltage and current inputs
Analog Engineer's Circuit: Data
Converters
SBAA386–December 2019
Four-channel, differential input, DAQ front-end circuit with
configurable voltage and current inputs
VictorSalomon
Feature Value Units
Number of channels 4 Differential channels
Data rate ≤10 kSPS
Voltage input range ±10.0 Volts
Current input range 0 to 20 mA
Voltage accuracy 0.05 typical | 0.10 maximum %FS
Current accuracy 0.10 typical | 0.20 maximum %FS
Power Supplies
AVDD HV-AVDD HV-AVSS
5.0V 15.0V –15.0V
Design Description
This circuit design describes how to use an ADS125H02 with integrated reference and programmable gain
amplifier (PGA) to make voltage and current measurements on various ranges.
This circuit can be used in applications such as analog input modules for PLCs, avionics remote data
concentrators,lab and field instrumentation, and other factory automation and test and measurement
applications. Thermocouples and RTD are also common temperature sensors used in similar applications.
For more information about making precision ADC measurements with a variety of RTD wiring
configurations, see the A Basic Guide to Thermocouple Measurements Application Report.

www.ti.com
2SBAA386–December 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
Four-channel, differential input, DAQ front-end circuit with configurable
voltage and current inputs
Design Notes
1. Use supply decoupling capacitors for both the analog and digital supplies. For the high-voltage analog
supply (HV_AVDD and HV_AVSS), place a 1.0-µF capacitor between the pins and place 0.1-µF
capacitors from each supply to the ground plane. Connect 0.1-µF and 10-µF capacitors in parallel at
AVDD to the ground plane. Connect a 1.0-µF capacitor from DVDD to the ground plane. Connect a
1.0-µF capacitor from BYPASS to the ground plane. For details on power supply recommendations,
see the ADS125H02 ±20-V Input, 2-Channel, 40- kSPS, 24-Bit, Delta-Sigma ADC With PGA and
Voltage Reference Data Sheet.
2. To minimize input current leakage, connect unused analog inputs to AGND when operating the device
with bipolar supplies, or connect unused inputs to AVDD when operating the device with a unipolar
supply.
3. Program unused GPIOs as outputs (default setting). If any GPIOs are programmed as inputs, the
GPIO must not be allowed to float (unconnected), otherwise AVDD power-supply leakage current may
result.
4. Consider adding TVS diodes between the high-voltage supplies (HV_AVDD to HV_AVSS) to provide
overvoltage protection and avoid violating the absolute maximum rating of 38V. A TVS diode such as
the TVS3300 provides a 33.0-V stand-off voltage (VR), which is below the 30.0-V supply required,
minimizing the current leakage of the diode, but has a typical break-down voltage (VBR) and clamping
voltage (VC) of 35.8 V and 38.0 V, respectively (assuming a peak pulse current IPP of 35.0 A),
effectively protecting the ADC from an EOS event. For more details on EOS in ADCs, see TI Precision
Labs: EOS and ESD in ADC.
5. When possible, use C0G (NPO) ceramic capacitors for input filtering. The dielectric used in these
capacitors provides the most stable electrical properties over voltage, frequency, and temperature
changes.
6. Input filtering for the ADC inputs and the reference inputs are selected using standard capacitor values
and 1% resistor values. For an example design and analysis of these filters, see the RTD Ratiometric
Measurements and Filtering Using the ADS1148 and ADS1248 Family of Devices Application Report.
Component Selection
1. Identify the system components:
a. Given the following specifications are:
• Input voltage range ≤±12.0V
• Two voltage input channels, and two current input channels
• Data rate ≤10 kSPS
• 0.05%FS accuracy, or better
• Optimized for cost
b. Products selected:
•ADS125H02 is a 24-bit, ±20-V input, delta-sigma ADC with integrated high-input voltage PGA
and voltage reference. This device meets the input voltage range, accuracy, and data rate
requirements, and it integrates a precision voltage reference, and GPIOs helping in cost
optimization.
•MUX509 is a differential 4:1, 36-V, precision, analog multiplexer. This device enables
expanding to 4-channels using a single ADC for cost optimization.
• Burden resistor:
A burden resistor converts the current to a limited voltage to do measurements in the current
measurement mode, a 250-Ωresistor was selected given the desired current range
measurements (0 to 20mA), and a target burden voltage of 5.0V. Using a precision resistor
ensures that the resistor does not become the limiting factor for system accuracy, the following
specifications can be used as :
– Accuracy ≤0.1%
– Temperature coefficient ≤20 ppm/°C
– Power rating ≥0.5W
• Alternative and similar devices are listed in Design Featured Devices.

±±
= = =
±
= = =
IN _ FSR
Voltage
REF
IN _ FSR
Current
REF
V10V
Gain 0.25V / V
V 2.5V
V5.0V
Gain 0.50V / V
V 2.5V
www.ti.com
3
SBAA386–December 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
Four-channel, differential input, DAQ front-end circuit with configurable
voltage and current inputs
2. Perform error analysis calculations:
A key consideration in the design of an analog input module is the error over the ambient temperature
range resulting from the drift of gain, offset, reference voltage, and linearity error. This example shows
the results of a Total Unadjusted Error (TUE) analysis that assumes an FS voltage of 10V, and that the
initial offset and gain (including reference voltage error) are user calibrated at TA= 25°C, as well as
calibration overtemperature. The following table shows the maximum error, including the drift error of
the ADC over the –20°C to 70°C temperature range, before calibration, and after calibration at room
temperature, as well as overtemperature.
Maximum Error Before and After Calibration
Specification Data Sheet Value Error (ppm)
Including ΔT = 90°C
Error (ppm)
Assuming Gain and Offset Calibration
Internal VREF initial accuracy (maximum) 0.20% 2000.000 1.325
Internal VREF temperature drift (maximum) 1 ppm/°C 90.000 90.000
Internal VREF temperature hysteresis (70
ppm/105°C) 60 ppm/°C 60.000 60.000
Quantization noise 172.3nVRMS 0.017 0.017
Noise 53μVRMS 5.300 5.300
INL 0.001% 10.000 10.000
Offset 2500μV 250.000 1.325
Offset temperature drift 2000nV/°C 18.000 18.000
Gain error 0.70% 7000.000 1.325
Gain error temperature drift 4 ppm/°C 360.000 360.000
Total error (root sum of squares) [ppm] 7294.124 376.507
Total error (root sum of squares) [%FS] 0.729 0.038
3. Inspecting the data in Maximum Error Before and After Calibration, it is evident that the main
contributors to the system total error calculations before any calibration is performed are the initial
accuracy of the internal voltage reference, the gain error overtemperature, and the offset voltage,
resulting in a total error of 0.729%FS. Assuming gain and offset calibration is performed, reducing the
gain, offset, the initial accuracy of the reference to levels in the noise, resulting in the error similar to
the ADC noise level, 1.325 ppm (assuming average of 16 samples), then the total error can be
calculated to be reduced to 0.038%FS. Calibration overtemperature could be performed to improve the
full scale accuracy even further.
4. Calculating PGA gain required:
The PGA gain required is determined by the reference voltage and the input voltage range, which is:
±10V for the voltage measurements and 5.0V for the current measurements, assuming a burden
resistor of 250Ω.

HV_AVSS
HV_AVDD ±2.5 V
HV_AVSS + 2.5 V
VINP
VINN
VINP
VIN = VINP - VINN
PGA Input PGA First Stage Output
HV_AVDD
PGA Second Stage Output
AVDD
AVDD ±0.5 V
AGND
AGND + 0.5 V
VINN
AVDD/2 + VIN Â*DLQ/ 2
AVDD/2 - VIN Â*DLQ/ 2
AVDD/2
´ - ´ -
+ + < < - -
AINx
V
IN IN
V (Gain 1) V (Gain 1)
HV _ AVSS 2.5 HV _ AVDD 2.5
2 2
www.ti.com
4SBAA386–December 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
Four-channel, differential input, DAQ front-end circuit with configurable
voltage and current inputs
5. Verify PGA input limitations:
As in typical amplifiers the integrated PGA has a maximum allowable input voltage (VAINX), which can
be found in the recommended operating conditions table in the ADS125H02 data sheet, and it is
determined by the PGA gain, the maximum differential input voltage (VIN), and the minimum value of
the high-voltage power supply. Maintain the absolute input voltage (VAINX) within the range as shown in
the following equation; otherwise, an incorrect conversion data can result:
where
• For gain < 1, use value = 1 for gain
• V(AINx) = Input voltage
• VIN = VAINP – VAINN = Maximum expected differential input voltage
In both the voltage and current measurements, since the gain < 1, the absolute input voltage must be:
–12.5V < VAINX < 12.5V
The following image shows the relationship between the PGA input voltage to the PGA output voltage
in attenuation mode. The first PGA stage is configured as a unity-gain follower, the second PGA stage
attenuates the differential input and shifts the signal common-mode voltage to AVDD / 2 to drive the
ADC input.
6. GPIO configuration:
The ADS125H02 device provides four GPIO pins (GPIO0–GPIO4), two GPIOs are available on
dedicated pins and two GPIOs are multiplexed functions with an external reference (REFP1 and
REFN1). The GPIO input and output levels are referred to AVDD and AGND, so in this case the logic
output levels are set to 5.0V. The following bits in registers 3 and 4 are used to control the GPIOs:
• GPIO_CON[3:0] bits set the GPIO connection to the designated pin (1 = connected)
• GPIO_DIR[3:0] bits program the direction of the GPIO as an input (1) or output (0)
• GPIO_DAT[3:0] bits are the data values for the GPIO
In this case, set GPIO_CON[3:0] to '0111', and set GPIO_DIR[3:0] to '1000', while the configuration for
GPIO_DAT[3:0] will be dependant upon which channel is connected at any given time. The MUX509
Truth Table and GPIO_DAT Configuration table shows the configuration of the individual GPIO[x] bits
depending on the input channel selected.
MUX509 Truth Table and GPIO_DAT Configuration
EN | GPIO2 A1 | GPIO1 A0 | GPIO0 State
0 1 1 MUX disabled
1 0 0 Channel 1 ON (Voltage)
1 0 1 Channel 2 ON (Voltage)
1 1 0 Channel 3 ON (Current)
1 1 1 Channel 4 ON (Current)

www.ti.com
5
SBAA386–December 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
Four-channel, differential input, DAQ front-end circuit with configurable
voltage and current inputs
7. Digital filter selection:
Digital low-pass filters are essential to the functionality of a delta-sigma ADC, which relies on
oversampling and noise shaping to push quantization noise out of band. There are a variety of options
for digital filters available in the ADS125H02 device. When choosing a digital filter, consider the
following tradeoffs:
• Slower data rates (higher oversampling ratios) have lower noise bandwidth. They are great for
noise, but not for data throughput or detection of transient events.
• The built-in PGA monitors are able to assist in detecting transient events that may affect the
conversion results; therefore, the digital filter is generally able to be run at a slower data rate for
better noise performance.
• Higher-order SINC filters have slower settlings times when an input step is applied, but they provide
lower noise bandwidth and increased notch width for removing common noise signals, such as
power line noise which in practice may not occur at exactly 50Hz or 60Hz.
• Digital filter notches occur at intervals of the SINCx filter data rate, so data rates of 50 SPS, 60 SPS
or less are recommended for attenuating power line noise.
• The 20 SPS FIR filter is unique from the SINCx filters in that it provides simultaneous rejection of
50- and 60-Hz noise and also settles within a single conversion cycle (like the SINC1 filter).
In this application, TI recommends a low-latency 20 SPS using a SINC1 filter, which is shown in the
pseudocode example in the following section.
For more information about digital filters in the ADS125H02 device, see the following:
• The Digital Filter section of the ADS125H02 Data Sheet
•Digital Filter Types in Delta-Sigma ADCs Application Report
Register Settings
Configuration Register Settings for Voltage and Current Inputs
Register
Address Register Name Field Register Value Description
05h MODE3 GPIO_DAT[3:0] See MUX509 Truth Table and
GPIO_DAT Configuration GPIO state (to control the external MUX)
MODE2 GPIO_DIR[3:0] 1000 GPIO[2:0] outputs, GPIO[3] input
MODE4 GPIO_CON[3:0] 0111 GPI0[2:0] connected GPIO[3] disconnected
10h MODE4 MUX[2:0] 000 Internal MUX
10h MODE4 GAIN[3:0] 0010 or 0011 PGA - Gains for voltage and current
measurements, respectively
02h MODE0 DR[4:0] 00100 Data rate: 20 SPS
02h MODE0 FILTER[2:0] 000 Digital filter: SINC1

www.ti.com
6SBAA386–December 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
Four-channel, differential input, DAQ front-end circuit with configurable
voltage and current inputs
Pseudocode Example
The following pseudocode sequence shows the required steps to set up the device and the microcontroller
that interfaces to the ADC to take subsequent readings from the ADS125H0x device for both voltage and
current measurements. The dedicated DRDY pin indicates the availability of new conversion data.
Pseudocode is shown without the use of the STATUS byte and CRC data verification. Download the
ADS125H02 Example C Code from the ADS125H02 product folder or access it directly with the following
link: ADS125H02 Example C Code.
Generic Pseudocode
Init:
{Configure microcontroller for SPI master, mode 1 (CPOL = 0, CPHA = 1), SCLK freq = 8 MHz
Configure microcontroller GPIO for /DRDY as a falling edge triggered interrupt input
Set CS1 low;
Send 06h 00h A9h 00h; // RESET command to ensure proper reset after power-up
Set CS1 high;
// DELAY
Set CS1 low;
Send 46h 10h 82h 00h; // WREG to REF: Enable and select the internal 2.5V reference
Set CS1 high;
// NOTE: not necessary to issue a WREG to MODE0 command when using the default register values
Set CS1 low;
Send 42h 24h 5Ah 00h; // WREG to MODE0: Continuous conversion, low-latency filter, 20 SPS
Set CS1 high;
Set CS1 low;
Send 43h 08h 8Bh 00h; // WREG to MODE1: Continuous conversion, 605us conv. start delay
Set CS1 high;
Set CS1 low;
Send 44h 77h 9Ah 00h; // WREG to MODE2: Enable GPIO outputs on GPIO0, GPIO1, and GPIO2
Set CS1 high;
Set channelNumber = 1
Call Gain_Select()
Call Channel_Select()
// (OPTIONAL): For verification read back all register settings
Call Start_New_Conversion()
}
Loop:
{Wait for DRDY falling edge interrupt...
Do you want to switch to the next channel?
{channelNumber = (channelNumber + 1) % 4;
Call Gain_Select()
Call Channel_Select()
Call Start_New_Conversion()
}
Call Read_Data()
}
Channel_Select()
{// NOTE:
// A0, A0 and EN are controlled by GPIO0, GPIO1 and GPIO2 respectively

www.ti.com
7
SBAA386–December 2019
Submit Documentation Feedback Copyright © 2019, Texas Instruments Incorporated
Four-channel, differential input, DAQ front-end circuit with configurable
voltage and current inputs
// STATUS0 byte is always enabled
Set CS1 low;
// WREG to MODE3 register to set GPIO pin levels
If (channelNumber == 1)
Send 45h 44h 16h 00h; // EN=1; A1=A0=0
ElseIf (channelNumber == 2)
Send 45h 45h 11h 00h; // EN=1; A1=0; A0=1
ElseIf (channelNumber == 3)
Send 45h 46h 18h 00h; // EN=1; A1=1; A0=0
ElseIf (channelNumber == 4)
Send 45h 47h 1Fh 00h; // EN=1; A1=A0=1
Set CS1 high;
}
Gain_Select()
{// NOTE:
// Using gain of 0.25 V/V for channels 1 & 2
// Using gain of 0.50 V/V for channels 3 & 4
// Always select AINP = AIN1 and AINN = AIN0 for analog inputs
Set CS2 low;
// WREG to MODE4 register to configure PGA gain
If (channelNumber <= 2)
Send 50h 02h D5h 00h; // Gain = 0.25 V/V
ElseSend 50h 03h D2h 00h; // Gain = 0.50 V/V
Set CS2 high;
}
Start_New_Conversion()
{Set CS1 low;
Send 08h 00h 7Fh 00h; // START command
Set CS1 high;
}
Read_Data()
{Set CS1 low;
Send 12h 00h AAh 00h 00h 00h 00h 00h 00h;
Receive FFh 12h 00h AAh [STATUS] [MSB] [MID] [LSB] [CRC]
Set CS1 high;
// Cast, concatenate, and sign-extend 24-bit data to signed 32-bit datatype
signedValue = (((int32_t) [MSB] << 24) + ((int32_t) [MID] << 16) + ((int32_t) [LSB] << 8)) >>
8;
// Convert ADC value to voltage (LSBsize = 2*VREF/GAIN)
// NOTE:
// Using gain of 0.25 V/V for channels 1 & 2
// Using gain of 0.50 V/V for channels 3 & 4
VoltageReading = (LSBsize * signedValue);
If (channelNumber > 2)
CurrentReading = (VoltageReading / BurdenResistance);
}

www.ti.com
8SBAA386–December 2019
Submit Documentation Feedback
Copyright © 2019, Texas Instruments Incorporated
Four-channel, differential input, DAQ front-end circuit with configurable
voltage and current inputs
Design Featured Devices
Design Featured Devices
Device Key Features Link Other Possible Devices
Analog to Digital Converter (ADC) with Integrated PGA and Voltage Reference
ADS125H02 24-bit, 40-kSPS, 2-channel delta-sigma ADC with ±20-V input, PGA, IDACs, GPIOs, and VREF ti.com/product/ADS125H02 Link to similar devices
ADS125H01 24-bit, 40-kSPS, 1-channel delta-sigma ADC with ±20-mV to ±20-V input ti.com/product/ADS125H01
Programmable Gain Amplifier (PGA)
PGA280 4-channel, zero-drift, high voltage, programmable gain amplifier (PGA) ti.com/product/PGA280 Link to similar devices
PGA281 1-channel, zero-drift, high voltage, programmable gain amplifier (PGA) ti.com/product/PGA281
Analog Multiplexer
MUX509 Differential or dual 4:1, 36.0-V, precision analog multiplexer x`ti.com/product/MUX509
Link to similar devices
MUX36D04 Differential or dual 4:1, 36.0-V, precision analog multiplexer
Lower leakage current
ti.com/product/MUX36D04
TMUX6104 Single-ended 4:1, ±16.5-V, precision analog multiplexer
Lowest leakage current, lowest on-capacitance
ti.com/product/TMUX6104
CD4052 Differential or dual 4:1, ±10.0-V analog multiplexer
Lowest cost
ti.com/product/CD4052B
Design References
See the Analog Engineer's Circuit Cookbooks for TI's comprehensive circuit library.
Power Supply Reference Designs
The ADS125H02 device requires three analog power supplies (high-voltage supplies HV_AVDD and
HV_AVSS, and low-voltage analog supply AVDD) and a digital power supply (DVDD). This circuit
assumes a bipolar supply (±15.0 V) for HV_AVDD and HV_AVSS, and a 5.0-V supply. The following table
shows there are specifications for three reference designs that could be used to provide the power
supplies from a 24.0 V nominal input voltage.
PMP10532 PMP10516 TIDA-00689
Schematic
Test Results Schematic Test Results Schematic Design Guide
VIN range (V) 19.0–30.0V 20.4–28.8V 16.0–32.0V
Input type DC
VOUT (V) Output 1 15.0
Output 2 –15.0
Output 3 5.00
IOUT(maximum) (A) Output 1 0.200 0.200 0.601
Output 2 0.200 0.060 0.601
Output 3 1.000 0.100 0.200
POUT(maximum) (W) Output 1 3.0 3.0 0.5
Output 2 3.0 0.9
Output 3 5.0 0.5
Isolation ✔ ✔ ✔
Total efficiency at VIN = 24V and Maximum IOUT 86.0% 78.8% 44.0%
Footprint 60.0mm × 30.0mm Approximately 60.0mm × 35.0mm 12.7mm × 40.8mm
Topology Fly-Buck™ Fly-Buck™ + Linear regulator Fly-Buck™ + Split rail
converter
For direct support from TI Engineers use the E2E online support forums
e2e.ti.com
Trademarks
Fly-Buck is a trademark of Texas Instruments.
All other trademarks are the property of their respective owners.

IMPORTANT NOTICE AND DISCLAIMER
TI PROVIDES TECHNICAL AND RELIABILITY DATA (INCLUDING DATA SHEETS), DESIGN RESOURCES (INCLUDING REFERENCE
DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND OTHER RESOURCES “AS IS”
AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD
PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for skilled developers designing with TI products. You are solely responsible for (1) selecting the appropriate
TI products for your application, (2) designing, validating and testing your application, and (3) ensuring your application meets applicable
standards, and any other safety, security, regulatory or other requirements.
These resources are subject to change without notice. TI grants you permission to use these resources only for development of an
application that uses the TI products described in the resource. Other reproduction and display of these resources is prohibited. No license
is granted to any other TI intellectual property right or to any third party intellectual property right. TI disclaims responsibility for, and you
will fully indemnify TI and its representatives against, any claims, damages, costs, losses, and liabilities arising out of your use of these
resources.
TI’s products are provided subject to TI’s Terms of Sale or other applicable terms available either on ti.com or provided in conjunction with
such TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for
TI products.
TI objects to and rejects any additional or different terms you may have proposed. IMPORTANT NOTICE
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2022, Texas Instruments Incorporated
