Texas Instruments TPS272C45 User manual

User’s Guide
TPS272C45 Evaluation Module
ABSTRACT
The TPS272C45EVM is a hardware evaluation module (EVM) used to enable hardware engineers to evaluate
the full performance and functionality of the TPS272C45 industrial high side switch. The TPS272C45EVM
contains everything needed to test and assess the TPS272C45 before designing it into part of a greater
application's power system. The evaluation module is designed to either be used as a standalone board with an
attached voltage supply and output load or in conjunction with an underlying Texas Instruments microcontroller
by using the standardized BoosterPack headers. A wide range of application features such as current sensing,
multiplexed current limiting, and transient suppression are enabled and visible through use of this evaluation
module.
Table of Contents
1 Introduction.............................................................................................................................................................................2
2 Compatibility Across Silicon Versions................................................................................................................................. 3
3 BoosterPack Operation..........................................................................................................................................................4
4 TPS272C45EVM Schematic................................................................................................................................................... 5
5 Connection Descriptions....................................................................................................................................................... 6
6 TPS272C45EVM Assembly Drawings and Layout............................................................................................................... 7
7 Current Limit Configuration.................................................................................................................................................10
8 Current Sense .......................................................................................................................................................................11
9 Transient Protection............................................................................................................................................................. 12
10 Bill of Materials................................................................................................................................................................... 13
11 Revision History..................................................................................................................................................................15
List of Figures
Figure 4-1. TPS272C45EVM Schematic Drawing....................................................................................................................... 5
Figure 6-1. 3D Representation.................................................................................................................................................... 7
Figure 6-2. Top Layer...................................................................................................................................................................7
Figure 6-3. Power Layer.............................................................................................................................................................. 8
Figure 6-4. Ground Layer............................................................................................................................................................ 8
Figure 6-5. Bottom Layer............................................................................................................................................................. 9
Figure 7-1. Multiplexed Current Limit.........................................................................................................................................10
List of Tables
Table 2-1. EVM Considerations Across Silicon Versions.............................................................................................................3
Table 3-1. Connected BoosterPack Header Pins on TPS272C45EVM....................................................................................... 4
Table 5-1. Connections and Test Points...................................................................................................................................... 6
Table 5-2. Jumper Configurations................................................................................................................................................6
Table 10-1. TPS272C45 Bill of Materials................................................................................................................................... 13
Trademarks
All trademarks are the property of their respective owners.
www.ti.com Table of Contents
SLVUBV4A – DECEMBER 2020 – REVISED DECEMBER 2021
Submit Document Feedback
TPS272C45 Evaluation Module 1
Copyright © 2021 Texas Instruments Incorporated

1 Introduction
The Texas Instruments TPS272C45EVM is an evaluation module that is used to demonstrate and showcase
all of the features of the underlying TPS272C45 industrial high side switch. This evaluation board provides a
seamless way to connect a set of power supplies to the inputs of the TPS272C45, connect loads to the output
channels, and switch on and off the device using the control pins of the chip itself. An on-board 3.3-V LDO
is included on the EVM to simplify controlling signals to the TPS272C45 and easily assert and deassert logic
signals by the use of a set of external hardware jumpers. Additionally this EVM includes BoosterPack headers
allowing the user to easily connect the TPS272C45 high side switch to an underlying microcontroller and write
software to control and configure the device.
Features of the TPS272C45EVM include:
• Multiplexed current limit configuration on ILIM1
• BoosterPack headers allowing power switch to be controlled by external microcontroller
• On-board 3.3-V LDO allowing for control signals to be manipulated by set of jumpers
• Ideal board layout and copper area for thermal performance
• Ability to support versions A, B, C, and D of the TPS272C45
• Optional footprint to populate external inductive clamping diodes (version C of TPS272C45)
• Optional footprint to populate TVS diode for Vdd input (version A of TPS272C45)
Introduction www.ti.com
2TPS272C45 Evaluation Module SLVUBV4A – DECEMBER 2020 – REVISED DECEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

2 Compatibility Across Silicon Versions
The TPS272C45EVM is compatible across all versions of the TPS272C45. This compatibility includes the
TPS272C45A with the external Vdd rail (A version), the TPS272C45B version without the Vdd rail (B version),
the TPS272C45C with support for the external inductive loading diode (C version), and the TPS272C45D with
fault output for individual channel (D version). By default, the A version of the silicon is populated on the EVM.
The footprints among the A, B, C, and D versions of the TPS272C45 silicon are footprint compatible and can be
interchanged by unpopulating the A version that ships default on the EVM and soldering, populating the desired
version of the silicon.
The A, C and D version of the device includes the ability to power the digital logic of the TPS272C45 from an
external Vdd pin. While the Vdd input pin exists on the A version of the TPS272C45 it does not exist in the B
versions. When using the B versions of silicon on this EVM, disconnect the Vdd line (and associated jumper,
J17) and ground the pin as this pin is classified as GND for B versions of the TPS272C45. Additionally with the
A, C and D version of the silicon it is possible to solder a TVS diode to D6 to filter out transients to the Vdd line.
This TVS diode must have a reverse standoff voltage equal to the logic level of the voltage rail being fed into
Vdd. For example, if the logic level is 5 V, then a SMAJ5.0CA diode is appropriate to filter any transients above 5
V.
When using the C version of the device, populate D2, D3, D8, and D9 with the relevant diodes required for
inductive loading. TI recommends the SMC series of diodes due to their ability to dissipate large energies
and handle current required for discharging charged inductors during switch turn-off. These diodes must be
chosen so that reverse standoff voltage falls within the nominal operating supply voltage of the device and
anything above the breakdown voltage is considered a transient. The SMCJ48A-TR, for example, is able the
absolute device max rating of 48 V and filter any transients above this level. More information about the transient
protections provided by the EVM can be found in Transient Protection.
When using the D version of the device, make sure jumper J23 is connected to the FLT1_IC position to get the
Fault output for each channel.
A table of the versions of TPS272C45 and considerations that have to be taken can be found in Table 2-1.
Table 2-1. EVM Considerations Across Silicon Versions
TPS272C45 Version Considerations
ADefault version populated on EVM. Follow desired settings from Connection
Descriptions.
B
Unable to use external Vdd.
Do not plug supply into J6.
Do not populate J17.
Do no populate TVS diode on D6.
CFollow same guidance of A version.
Populate inductive loading discharge diode on D2, D3, D8, and D9.
DFollow same guidance of A version.
Populate J23 with jumper in position of FLT2_IC.
www.ti.com Compatibility Across Silicon Versions
SLVUBV4A – DECEMBER 2020 – REVISED DECEMBER 2021
Submit Document Feedback
TPS272C45 Evaluation Module 3
Copyright © 2021 Texas Instruments Incorporated

3 BoosterPack Operation
While the TPS272C45EVM can be used as a standalone evaluation board without the need of any external
microcontroller, the EVM also comes populated with BoosterPack headers (J1, J2, J3, J4) to enable easy
interface with a Texas Instruments microcontroller. The 40-pin headers of the BoosterPack headers are used,
however all signals can be accessed using headers J1 and J2 enabling use with the 20-pin header. Additionally
by populating jumper J19 the user has the ability to power the underlying LaunchPad through the integrated
3.3-V LDO on the TPS272C45EVM. A list of pins connected to the BoosterPack header can be seen below in
Table 3-1:
Table 3-1. Connected BoosterPack Header Pins on TPS272C45EVM
BoosterPack Pin Function Note
J1-1 3.3-V power rail Disconnect J19 if powering LaunchPad via USB.
J1-2 Current sensing through the SNS pin Populate a Zener diode on D7 if it is required to limit analog
signal of pin
J1-5 DIA_EN pin used to enable diagnostics Can be used to multiplex multiple TPS272C45 switches to one
analog pin
J1-8 SEL pin used to change measurement reported on
SNS pin
J2-11 LATCH pin used to change fault behavior
J2-12 ILIM1 pin used to enable a10-kΩ resistor R13 for
ILIM1 Active high. Do not enable at same time as J2-13.
J2-13 ILIM2 pin used to enable a 4.99-kΩ resistor R14 for
ILIM1 Active high. Do not enable as same time as J2-12.
J2-17 FLT pin used to detect faults Open drain input. Pull-up source can be controlled using
jumper J18.
J2-18 EN2 to enable VOUT2 Active high. Can be connected to PWM.
J2-19 EN1 to enable VOUT1 Active high. Can be connected to PWM.
J2-20 Module GND Do not connect to IC ground if ground network is used
Note that for all IO and analog signals being attached to the BoosterPack, the relevant 4.7-kΩ protection
resistors are populated in series with the pin.
To power the attached LaunchPad from the on-board LDO of the TPS272C45EVM, connect the jumper J19.
Note that this feeds the output of the 3.3-V LDO on the TPS272C45EVM into the 3.3-V rail on the LaunchPad.
If there is another power supply trying to power the LaunchPad (such as the integrated USB power on the
LaunchPad itself) this can potentially cause issues with the separate power sources fighting for contention.
Jumpers J8 through J12 are used to manually configure the control signals going into the TPS272C45.
When using a microcontroller to control these signals these jumpers must be unpopulated to allow for the
microcontroller to drive them high or low. Additionally the header labeled J18 can be used to configure how
the FAULT pin is pulled up. This pin is an open drain output used to report faults on the TPS272C45 such as
overcurrent or open load. If J18 is connected to the pin marked BP on the silkscreen the FAULT pin is pulled
up through the 1-kΩ resistor R9 to the 3.3-V rail of the BoosterPack. Similarly if the jumper labeled J17 is
connected to the BP pin the Vdd rail of the TPS272C45 is connected to the 3.3-V rail of the BoosterPack. If J17
is populated to be fed from the LDO or BoosterPack, it cannot be supplied externally from the J6 banana jack.
Note that one useful feature of the TPS272C45 EVM is the ability to sense the from the SNS pin of the
TPS272C45 through the analog input of the microcontroller attached to the BoosterPack headers. A 1.0-kΩ
resistor is connected to convert the current coming out of the SNS pin to a voltage, however care must be
given to ensure that this value does not violate the input maximum of the microcontroller's analog input. To
mitigate, a Zener diode can be soldered to D7 (do not populate by default) to regulate the voltage going into the
microncontroller's analog input.
BoosterPack Operation www.ti.com
4TPS272C45 Evaluation Module SLVUBV4A – DECEMBER 2020 – REVISED DECEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated
