AM437x IDK Evaluation Hardware
User's Guide
SPRUII2–November 2017
AM437x IDK Evaluation Hardware
This document describes the hardware architecture of the AM437x industrial development kit (IDK), part
number TMDSIDK437x, which is based on the AM437x processor from TI.
Contents
1 Introduction ................................................................................................................... 2
2 Functional Block Description ............................................................................................... 3
3 User Interfaces............................................................................................................... 7
4 Pin Use Description ......................................................................................................... 8
5 Board Connectors ........................................................................................................... 8
6 PCB Guideline Deviations................................................................................................. 14
List of Figures
1 AM437x Industrial EVM .................................................................................................... 2
2 AM437x Industrial EVM Block Diagram................................................................................... 3
List of Tables
1 AM437x Power Supplies From Buck Regulators........................................................................ 4
2 Other Power Supplies....................................................................................................... 4
3 AM437X Industrial EVM I2C Bus Addresses............................................................................. 5
4 AM437x Industrial EVM EEPROM Data.................................................................................. 5
5 LEDs........................................................................................................................... 7
6 AM437x EXP0 Host Connector – J16 .................................................................................... 8
7 AM437x EXP1 I/O Connector – J1........................................................................................ 9
8 Micro SD Connector Pin Details.......................................................................................... 10
9 10/100 PRU Ethernet1 Pin Details....................................................................................... 11
10 10/100/1000 Gb Ethernet Pin Details ................................................................................... 11
11 USB Micro AB Connector................................................................................................. 12
12 AM437x Analog Input Connector......................................................................................... 12
13 AM437x Camera Connector .............................................................................................. 12
14 AM437x eQEP Interface Connector ..................................................................................... 13
15 AM437x EN DAT Interface Connector .................................................................................. 13
16 PCB Guidelines Deviations ............................................................................................... 14
Trademarks
Code Composer Studio is a trademark of Texas Instruments.

Introduction www.ti.com
2SPRUII2–November 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
AM437x IDK Evaluation Hardware
1 Introduction
The AM437x IDK is a standalone test, development, and evaluation module (EVM) system that lets
developers write software and develop hardware for industrial communication-type applications. The EVM
is equipped with a AM437x processor, from TI, and a defined set of features, to allow the user to
experience industrial communication solutions using serial or Ethernet-based interfaces. Using standard
interfaces, the IDK can interface to other processors or systems, and act as a communication gateway in
this case. In addition the IDK can directly operate as a standard remote I/O system or simple sensor
connected to an industrial communication network. The embedded emulation logic allows for emulation
and debugging using standard development tools such as Code Composer Studio™, from TI, by using the
supplied USB cable.
The following sections give more details regarding the EVM.
1.1 System View
The system view of the AM437x industrial EVM consists of the main board and camera board. Figure 1
shows the top and bottom views of the Industrial EVM.
Figure 1. AM437x Industrial EVM
1.2 Schematics, Design, and Errata Files
Hardware Documentation – Schematics, design files, and other related hardware documentation.

www.ti.com Functional Block Description
3
SPRUII2–November 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
AM437x IDK Evaluation Hardware
2 Functional Block Description
The complete AM437x industrial EVM is mostly contained within a single board. Figure 2 shows the
functional block diagram of the AM437x industrial EVM.
Figure 2. AM437x Industrial EVM Block Diagram
2.1 Processor
The AM437x processor is the central processor for this EVM. All the resources on the board surround the
AM437x processor to provide development capabilities for hardware and software. See the AM437x data
sheet and TRM for details about the processor. There are system configuration signals (SYSBOOT0 to
SYSBOOT18), that can be set on the EVM using resistors to define some startup parameters on the
AM437x processor. See Section 2.5 for more details.
2.2 Clocks
The main clock for the processor is derived from a 24-MHz crystal. An onboard oscillator in the AM437x
generates the base clock and subsequent module clocks as needed within the AM437x processor. A 32-
kHz clock for the RTC on the AM437x is derived from a 32.768-kHz crystal on the board.

Functional Block Description www.ti.com
4SPRUII2–November 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
AM437x IDK Evaluation Hardware
2.3 Reset Signals
SYS_RESETn is a reset signal running to several peripherals and the AM437x which performs a reset on
those peripherals. SYS_WARMRESETn is asserted by the push button and used to force a reset of the
AM437x and the other peripherals. The AM437x can also pulldown on the RESET_INOUTn signal to
cause the SYS_RESETn line to go active. The power on reset to the processor is driven from the power
good signal of the power manager.
2.4 Power Supplies
This section describes how the power supplies required for the design are generated.
2.4.1 Power Source
The AM437x Industrial EVM uses an external 24-V power supply. The 24-V power input is converted into
different voltage levels using buck converters, to provide power input to the AM437x and other
peripherals. The power requirements of the processor are handled by the Quad Power Supervisor IC
TPS386000. The power on LED, D2, is on if the 3.3-V power is available. The power sequencing
requirements of the AM437X processor (see the AM437x data sheet) are handled automatically by the
TPS386000 Power Supervisor chip.
2.4.2 Power Management
The AM437x Industrial EVM uses the buck converters and power supervisor IC for power management.
The I2C0 on the AM437x is used to control the TPS62362 buck converter. For the AM437x Industrial
EVM, Table 1 lists the buck regulators that are used.
Table 1. AM437x Power Supplies From Buck Regulators
Buck Regulator AM437x Power Rail Voltage
TPS5402D (1700 mA) VDDSHV1, 2, 3, 5, 6, 7, 8, 9, 10, 11,
VDDA_3P3V_USB0 and
VDDA_3P3V_USB1 (xxxx mA)
3.3 V (rails that are 3.3 V)
TPS5402D (1700 mA) VDDA_TS_ADC, VDDA_MC_ADC,
VDDS_RTC, VDDS_TPM, VDDS_CTM,
VDDS_CLKOUT, VDDS_OSC,
VDDS_SRAM_CORE_BG,
VDDS_SRAM_MPU_BB,
VDDS_PLL_CORE_LCD,
VDDS_PLL_DDR, VDDS_PLL_MPU,
VDDA1P8V_USB0, VDDA1P8V_USB1
(xxxx mA)
1.8 V (rails that are 1.8 V)
TPS5402D (1700 mA) VDD_DDR and Camera (xxxx mA) 1.5 V
TPS5402D (1700 mA) VDD_CORE, VDD_TPM (xxxx mA) 1.1 V
TPS62362 (3000 mA) VDD_MPU (xxxx mA) 1.2 V
2.4.3 Other Power Supplies
Table 2 lists the other power supplies.
Table 2. Other Power Supplies
Regulator Power Rail Voltage
TPS5402D (1700 mA) VCCB for eQEP (xxxx mA) 5.0 V
LM4132 V1_8DADC 1.8 V

www.ti.com Functional Block Description
5
SPRUII2–November 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
AM437x IDK Evaluation Hardware
2.5 Configuration and Setup
2.5.1 Boot Configuration
Various boot configurations can be set using the pullup and pulldown resistor combinations provided on
the SYSBOOT pins (LCD_D0:15, LCD_VSYNC, LCD_HSYNC, and LCD_EN). Boot configuration pins are
latched upon deassertion of the PORz pin. The default settings for the AM437x IDK EVM 1.3A are
000_0100_0000_0001_1000b. This corresponds to a boot sequence of the following:
1. MMC0
2. USB_MS (USB1)
3. USB_CL (USB0)
4. QSPI
See the GP EVM schematic for more details. See the AM437x TRM and data sheet for the definitions of
each of the sysboot signals.
2.5.2 I2C Address Assignments
In the AM437X Industrial EVM, each separate board has an I2C ID memory that contains the details of the
identity of that board such as its configuration. Table 3 provides information on the I2C address
assignments.
Table 3. AM437X Industrial EVM I2C Bus Addresses
AM437x Industrial EVM Function AM437x I2C Port Address
Baseboard ID memory I2C0 0x50
TPS62362 (buck regulator) I2C0 0x60
Clock synthesizer I2C0 0x65
LED driver I2C2 0x60
2.5.3 I2C ID Memory
The Industrial EVM has a dedicated I2C EEPROM which contains specific identity and configuration
information for that board. In addition, there is available space in each memory for user-specific
configuration information. The part number of the memory device is CAT24C256WI-G.
Table 4. AM437x Industrial EVM EEPROM Data
Name Size (bytes) Contents
Header 4 MSB 0xEE3355AA LSB
Board Name 8 Name for the board in ASCII "A33515BB" = AM437x Industrial EVM
Version 4 Hardware version code for the board in ASCII "1.2A" = rev. 01.2A
Serial Number 12 Serial number of the board. This is a 12 character string, WWYY4P16nnnn,
where:
• WW = 2 digit week of the year of production
• YY = 2 digit year of production
• nnnn = incrementing board number
Configuration 32 Codes to show the configuration setup on this board. For the available
EVMs supported, the following codes are used:
• ASCII "SKU#01" = base board for gen purpose EVM
• ASCII "SKU#02" = base board for industrial motor control EVM
Remaining 26 bytes are reserved
Ethernet MAC Address 0 6 MAC Address for AM437x Ethernet MAC 1
Ethernet MAC Address 1 6 MAC Address for AM437x Ethernet MAC 2 or PRU 0
Ethernet MAC Address 2 6 MAC Address for AM437x PRU 1 (if used)
Available 32702 Available space for other nonvolatile codes and data

Functional Block Description www.ti.com
6SPRUII2–November 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
AM437x IDK Evaluation Hardware
2.6 JTAG
The AM437x Industrial EVM supports embedded, XDS100V2 USB Emulation through the MicroUSB AB
connector. The EVM also has an optional 20-pin, CJTAG connector, from TI, to support the Emulation.
This CJTAG connector is not installed by default.
2.7 Memories Supported
The Industrial EVM supports onboard memories like the DDR3 SDRAM and SPI NOR Flash. The EVM
also supports a microSD card socket.
2.7.1 DDR3L SDRAM
The Industrial EVM design supports up to 8Gbit (2 × 256M × 16) of DDR3L SDRAM memory. The part
number for the DDR3L SDRAM memory used is MT41K256M16HA-125 AIT:E. The package used is a 96-
ball TFBGA package. See the AM437x TRM for memory locations of this memory.
2.7.2 SPI NOR Flash
The Industrial EVM supports a 512-Kbit (128K × 4) SPI flash memory from Macronix (MX66L51235FMI-
10G) in a 16SOIC package. The SPI port of the AM437X device is used to interface with the flash.
2.7.3 Board Identity Memory
Each board contains a 256KB serial EEPROM which contains board specific data that allows the
processor to automatically detect which board is connected and the version of that board. Other hardware-
specific data can be stored on this memory device as well. The part number of the memory device is
CAT24C256WI-G. See Section 2.5 for details on the data in this memory.
2.7.4 SD/MMC0
The SD/MMC connector on the Industrial EVM is a microSD connector, part number SCHA5B0200. This
is a standard SD/MMC Card type of connector. It is connected to the MMC0 port of the AM437x
processor. Check the AM437x data sheet and TRM for supported card types/densities.
2.8 10/100 Ethernet PRU Controlled Ports
The Industrial EVM has two 10/100 Ethernet transceivers (TLK105L) interfaced to connectors J6 and J9.
These Ethernet transceivers are connected to the PRU0 and PRU1 units within the AM437x device. The
reset for the transceivers is driven by the board system reset, SYS_RESETn. A 25-MHz clock drives the
clock signal for the TLK105L.
NOTE: The RJ-45 connectors used on the board have integrated magnetics that are configured in a
NIC configuration which does not support AutoMDIX. When designing a custom board based
on this schematic, be sure to verify whether an AutoMDIX, type RJ-45 connector, is required
for your design.
2.9 Gigabit Ethernet Port
The Industrial EVM has a one Gb (10/100/1000) Ethernet transceiver (KSZ9031RN) interfaced to
connector J4. This gigabit ethernet transceiver is connected to the RGMII 1 unit within the AM437x device.
The reset for the transceiver is driven by the board system reset SYS_RESETn. A 25-MHz clock drives
the clock signal for the KSZ9031RN.
NOTE: The RJ-45 connectors used on the board have integrated magnetics that are configured in a
NIC configuration which does not support AutoMDIX. When designing a custom board based
on this schematic, be sure to verify whether an AutoMDIX, type RJ-45, connector is required
for your design.

www.ti.com Functional Block Description
7
SPRUII2–November 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
AM437x IDK Evaluation Hardware
2.10 USB
The Micro USB-AB connector port is connected to the upstream port of the USB and to the UART
converter IC (FT2232HL). This is used for USB-to-JTAG and USB-to-UART conversion applications. This
USB port can also be used for XDS100V2 emulation. The ESD device, TPD2E001, is used on the USB
signals before they are connected to the AM437X pins.
2.11 ADC
The industrial EVM uses two ADCs. The input to the ADCs is by default connected to the motor sensing
circuit. These ADC inputs are terminated to the I/O expansion header and Magnetic swipe assembly for
user accessibility.
2.12 Camera
The camera Interface from the AM437x processor is terminated on the 12 × 2 header, J5. The camera
interface is supported using the J5 (AXK7L24223G) connector provided. The custom made Camera
Module, from TI, shall be interfaced with this header.
3 User Interfaces
3.1 LEDs
Two RGY LEDs, U1 and U2, are used in the EVM and it is driven by the LCD signals mentioned in
Table 5.
Table 5. LEDs
Signal Name LED Color
AM437X_LCD_PCLK U1 – Red
AM437X_LCD_AC_BIAS_EN U1 – Green
AM437X_LCD_VSYNC U1 – Yellow
AM437X_LCD_HSYNC U2 – Red
AM437X_CAM1_WEN U2 – Green
AM437X_CAM1_DATA2 U2 – Yellow
3.2 Industrial Inputs
For industrial 24-V digital inputs, a SN65HVS882 serializer is used to accept standard signals (from the
I/O Expander header) in and allow the AM437x device to read them. The serialized output from the
serializer is fed to the SPI1 port of the processor.
3.3 Industrial Output LEDs
An I2C-to-8-bit LED driver, TPIC2810, is used to drive the eight industrial output LEDs D3 to D10. The I2C
interface is connected to the I2C2 port of the AM437x processor. The eight LED driver outputs are also
driven to the I/O Expansion header. All the LEDs are green in color.
3.4 DC Motor Drive
Three phase brushless DC motor driver DRV8313 is used to drive the DC motor. The motor driver is
controlled by AM437x through PWM interface. The power to the motor is derived from the internal 24VDC
or through external power using separate power connector J14. Connector J17 is used for motor
connection.

Pin Use Description www.ti.com
8SPRUII2–November 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
AM437x IDK Evaluation Hardware
4 Pin Use Description
4.1 Functional Interface Mapping
Some signals of the AM437x device are connected to a fixed device on the EVM that cannot be changed.
Some of the signals of the AM437x device, however, are connected to devices on the EVM based on the
profile setting. See the additional columns in the pinmux document, because there are preset profiles
which define what peripherals are connected and able to be used at a given time on the hardware boards.
Pin Use Assignment – Assignment list of pin functions.
4.2 GPIO Definitions
See the updated pinmux documents, which list use-case columns for the GPIOs. Developers can select
and enable pins, based on the selective peripheral pins, as output or input.
5 Board Connectors
These sections list the board connectors.
5.1 Host Expansion Header – J16
Table 6 lists the Host Expansion header, J16, pin descriptions.
Table 6. AM437x EXP0 Host Connector – J16
Pin No. Signal Description
1 V3_3D 3.3-V power
2 V5_0D 5.0-V power
3 SD_CLKOUT SD clock out
4 AM437X_eHRPWM0B PWM 0B signal
5 SD_CLKIN SD clock in
6 AM437X_eHRPWM0_SYNCI PWM sync input
7 SD_DATA_IN0 SD data input 0
8 AM437X_eHRPWM012_TRPZONE PWM trip zone
9 SD_DATA_IN1 SD data input 1
10 AM437X_eHRPWM0_SYNCO PWM sync output
11 SD_DATA_IN2 SD data input 2
12 AM437X_eHRPWM1B PWM 1B signal
13 SD_DATA_IN3 SD data input 3
14 AM437X_eHRPWM2A PWM 2A signal
15 SD_DATA_IN4 SD data input 4
16 AM437X_eHRPWM2B PWM 2B signal
17 SD_DATA_IN5 SD data input 5
18 PR1_EDC_SYNC0_OUT EDC sync 0 out
19 SD_DATA_IN6 SD data input 6
20 PR1_EDC_SYNC1_OUT EDC sync 1 out
21 SD_DATA_IN7 SD data input 7
22 GND Ground
23 SD_DATA_IN8 SD data input 8
24 eHRPWM0A PWM 0A signal
25 SYS_RESETn System reset
26 SPI0_DIN SPI0 data input
27 AM437X_I2C_SCL I2C clock
28 SPI0_DOUT SPI0 data output

www.ti.com Board Connectors
9
SPRUII2–November 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
AM437x IDK Evaluation Hardware
Table 6. AM437x EXP0 Host Connector – J16 (continued)
Pin No. Signal Description
29 AM437X_I2C_SDA I2C data
30 SPI0_CS0n SPI0 chip select
31 AM437X_PRU0_ENDAT0_CLK PRU0 Data0 clock
32 PRU0_ENDAT1_CLK PRU0 Data1 clock
33 AM437X_PRU0_ENDAT0_OUT PRU0 Data0 out
34 PRU0_ENDAT1_OUT PRU0 Data1 out
35 AM437X_PRU0_ENDAT0_OUTEN PRU0 Data0 out enable
36 PRU0_ENDAT1_OUTEN PRU0 Data1 out enable
37 AM437X_PRU0_ENDAT0_IN PRU0 Data0 in
38 PRU0_ENDAT1_IN PRU0 Data1 in
39 GND Ground
40 GND Ground
41 AM437X_CAM0_DATA6 Cam0 Data6
42 eQEP2_STROBE eQEP2 strobe
43 MTR_FAULT MTR fault
44 eQEP2_INDEX eQEP2 index
45 AM437X_PROFI_TXD Profibus transmit
46 eQEP2A_IN eQEP2A in
47 AM437X_PROFI_RXD Profibus receive
48 eQEP2B_IN eQEP2B in
49 PROF_TXENABLE Profibus transmit enable
50 HDQ HDQ
51 eQEP1_STROBE eQEP1 strobe
52 eQEP0_STROBE eQEP0 strobe
53 eQEP1_INDEX eQEP1 index
54 eQEP0_INDEX eQEP0 index
55 eQEP1B_IN eQEP1B in
56 PRU0_ENDAT2_OUTEN PRU0 Data2 out enable
57 eQEP1A_IN eQEP1A in
58 PRU0_ENDAT2_IN PRU0 Data2 in
59 GND Ground
60 GND Ground
5.2 I/O Expansion Header – J1
Table 7 lists the I/O Expansion header, J1, pin descriptions.
Table 7. AM437x EXP1 I/O Connector – J1
Pin No. Signal Description
1 INDUS INPUT0 Digital input 0
2 V24_0D 24-V power
3 INDUS INPUT1 Digital input 1
4 V24_0D 24-V power
5 INDUS INPUT2 Digital input 2
6 V24_0D 24-V power
7 INDUS INPUT3 Digital input 3
8 V24_0D 24-V power

Board Connectors www.ti.com
10 SPRUII2–November 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
AM437x IDK Evaluation Hardware
Table 7. AM437x EXP1 I/O Connector – J1 (continued)
Pin No. Signal Description
9 INDUS INPUT4 Digital input 4
10 V24_0D 24-V power
11 INDUS INPUT5 Digital input 5
12 V24_0D 24-V power
13 INDUS INPUT6 Digital input 6
14 V24_0D 24-V power
15 INDUS INPUT7 Digital input 7
16 V24_0D 24-V power
17 DGND Ground
18 NC Not connected
19 DRAIN0 Digital output 0
20 DRAIN1 Digital output 1
21 DRAIN2 Digital output 2
22 DRAIN3 Digital output 3
23 DRAIN4 Digital output 4
24 DRAIN5 Digital output 5
25 DRAIN6 Digital output 6
26 DRAIN7 Digital output 7
27 V5_0D 5-V power
28 V5_0D 5-V power
29 DGND Ground
30 DGND Ground
31 AM437X_AIN0 Analog input 0
32 AM437X_AIN4 Analog input 4
33 AM437X_AIN1 Analog input 1
34 AM437X_AIN5 Analog input 5
35 AM437X_AIN2 Analog input 2
36 AM437X_AIN6 Analog input 6
37 AM437X_AIN3 Analog input 3
38 AM437X_AIN7 Analog input 7
39 GNDA_ADC Analog ground
40 GNDA_ADC Analog ground
5.3 SDMMC0 – J19
Table 8 lists the SDMMC0, J19, pin descriptions.
Table 8. Micro SD Connector Pin Details
Pin No. Memory Card PIN No.
uSD#1 DAT2
uSD#2 CD/DAT3
uSD #3 CMD
uSD #4 VDD
uSD #5 CLK
uSD #6 VSS
uSD #7 DAT0
uSD #8 DAT1
