SWRU276
September 2011
1/2
CC1180DB Nodes
CC430 Node
Edge Router
(Gateway)
CC430 Node
CC1180EM
Adapter Card
Green LED
Switch S7-2
SD Card slot
CC-6LOWPAN-DK-868 Quick Start Guide
STEP 1 –Introduction
This guide describes how to set up a CC-6LOWPAN-DK-868 development kit using
the pre-programmed devices of the CC-6LOWPAN-DK-868 Kit.
The 6LoWPAN development kit is designed to give a simple
introduction to 6LoWPAN wireless networks in the 868/915MHz bands. The
hardware consists of an OMAP-L138 based Edge Router equipped with
a CC1180EM, 2 CC430F5137 based nodes and 2 CC1180DB nodes.
The CC1180DB boards consist of a network processor (CC1180)
pre-programmed with a 6LoWPAN software stack, and a MSP430F5438A
microcontroller that controls the 6LoWPAN device.
The CC430 based nodes consists of a CC430F5137 SoC (RF+MCU) that
runs both the 6LoWPAN software stack and the controlling application.
The Edge Router board is running Linux and is pre-programmed with
Sensinode Nanorouter 2.0 software, which acts as a bridge between IPv6
and 6LoWPAN. The Edge Router is connected to a PC via Ethernet. The
Edge Router sets up the network and configures the 6LoWPAN network
parameters.
The development kit demonstrates an example of a typical sensor network with a simple Network Analyzer software
running on the nodes. The nodes are automatically given a unique IPv6 address and can be pinged from a PC using
standard tools. Each node in the 6LoWPAN network also has a unique preprogrammed IEEE address.
The battery powered nodes can act as routers that on request report their key data to the Edge Router.
STEP 2 –Install the PC software and connect the Edge Router
Install the Windows IPv6 stack on a Windows XP PC. The IPv6 installation is not needed in Linux and Windows 7, since
IPv6 is already installed.
Open a command prompt and write ipv6 install
Assign the IPv6 address 2001::22 to the PC using the command prompt: (Run in administrator mode in Windows 7)
netsh interface ipv6 add address “Local Area Connection” 2001::22
Set up a default route using the command prompt: (Run in administrator mode in Windows 7)
netsh interface ipv6 add route ::/0 “Local Area Connection”
Note! You must change “Local Area Connection” to the actual name of the Ethernet connection you want to use. You can
get it from Windows Network Connections. The IPv6 address 2001::22 has to be unique on your network.
Plug in the power cable to the Edge Router and connect the Ethernet cable between the Edge Router and the PC. Make
sure that the Edge Router is not powered on.
Insert the SD card into the slot on the Edge Router.
Connect the CC1180EM to the
adapter card and connect an antenna
to the CC1180EM.
Connect the adapter card to the J30
connector on the Edge Router. The
adapter card can be fastened to the
Edge Router by the provided M2
screws.
Make sure that the switch S7-2 is in position ON,
and all other in position OFF.
Power on the Edge Router using the S4 switch.
It will take approximately 40 seconds to boot the Edge Router. When the green LED on the Adapter Card goes ON it
indicates that the Edge Router is up and running. You can connect the provided RS-232 NULL modem cable between
the Edge Router and PC to get debug information, use e.g. Windows HyperTerminal with settings; Baud Rate 115200, 8
Data Bits, No Parity, One Stop Bit and No Flow Control.
SWRU276
September 2011
2/2
Jumper J1
STEP 3 –Connecting the nodes to the 6LoWPAN network
Insert batteries in one or more of the CC1180DB boards and make sure the jumper is connected
between P1-1 and P1-2 to power on the node. It will automatically connect to existing network.
LEDs D1 and D2 are controlled from the CC1180 network processor and gives status on node
connection. When the CC1180DB node is connected to the network the green LED (D2) will be on,
if not connected it will be off. The red LED (D1) blink when node is communicating. LEDs D3 and
D4 are controlled from the host MCU and displays the RSSI value. Both LEDs off: RSSI above -
40dBm, green LED on red LED off: RSSI between -40 and -65dBm, both LEDs on: RSSI between
-65 and -90dBm, green LED off red LED on: RSSI below -90dBm. The red LED toggles with 1 sec
interval if 3 concurrent reply messages were missed or Analyzer is not activated on PC.
Insert batteries in one or more of the CC430F5137 battery packs and connect an antenna. Connect the battery pack
cable to power on the node.
LEDs D1 and D2 are controlled from the 6LoWPAN stack in CC430 and gives status on
node connection. When the CC430 node is connected to the network the green LED
(D1) will be on. The red LED (D2) blink when node is communicating.
When nodes are powered on they connect automatically to the 6LoWPAN network,
either directly to the Edge Router or via other nodes (Routers) in the network. Upon
request from the Edge Router they send messages including network information to the
Edge Router.
STEP 4 –Installing and Using NodeView Network Analyzer software
Node View can be used to interact with the nodes in the network. It has several powerful
features such as Network Analyzer, message logs, running demo applications and to send
custom data to nodes.
Download and install the latest Java runtime engine from
www.java.com to your Windows PC.
Minimum version of Java to run NodeView is 1.6.0
Extract the provided NodeView package to C:\NodeView
NodeView package can be found via link on www.ti.com
Start NodeView by double-clicking the extracted
NodeViewProDyn.jar file in C:\NodeView
Connect to your Edge Router by selecting File -> Add
NanoRouter IPv6 in the RouterView tab.
Enter the IPv6 address of the Edge Router which is
2001::11
The connected Edge Router is then shown in the Routers
field.
The connected nodes are shown in the Nodes field. You
can now use standard network tools to communicate with
the nodes. To ping a node right-click a node and copy the IPv6 address of the node. Open a command prompt on your
Windows XP PC and write: ping6 –n 10 [IPv6 address] Replace [IPv6 address] with the copied IPv6 address of
the node you want to ping. This example will ping the node 10 times. Use the ping command on Linux and Windows 7.
You can also view the network topology in the NodeView tab Network analyzer.
STEP 5 –Next steps and more Information
Extensive examples are provided to help you get started. Building and running each example is recommended to
become acquainted with the devices. Refer to the examples’ wiki page for more information.
For detailed information about the sample applications please see the following resources:
CC-6LOWPAN-DK-868 wiki page: http://processors.wiki.ti.com/index.php/CC-6LoWPAN
CC-6LOWPAN-DK-868 product web page: http://www.ti.com/6lowpan
The Low Power RF Online Community has forums, blogs and videos. Use the forums to find information, discuss
and get help with your design. Join us at www.ti.com/lprf-forum
Important note: The CC-6LOWPAN-DK-868 kit is an educational tool that allows developers to get familiar with basic
6LoWPAN networks. It is not intended as a 6LoWPAN reference design.
IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements,
and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should
obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are
sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.
TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standard
warranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except where
mandated by government requirements, testing of all parameters of each product is not necessarily performed.
TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products and
applications using TI components. To minimize the risks associated with customer products and applications, customers should provide
adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right,
or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information
published by TI regarding third-party products or services does not constitute a license from TI to use such products or services or a
warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual
property of the third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied
by all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptive
business practice. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additional
restrictions.
Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids all
express and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is not
responsible or liable for any such statements.
TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI product would reasonably
be expected to cause severe personal injury or death, unless officers of the parties have executed an agreement specifically governing
such use. Buyers represent that they have all necessary expertise in the safety and regulatory ramifications of their applications, and
acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products
and any use of TI products in such safety-critical applications, notwithstanding any applications-related information or support that may be
provided by TI. Further, Buyers must fully indemnify TI and its representatives against any damages arising out of the use of TI products in
such safety-critical applications.
TI products are neither designed nor intended for use in military/aerospace applications or environments unless the TI products are
specifically designated by TI as military-grade or "enhanced plastic."Only products designated by TI as military-grade meet military
specifications. Buyers acknowledge and agree that any such use of TI products which TI has not designated as military-grade is solely at
the Buyer's risk, and that they are solely responsible for compliance with all legal and regulatory requirements in connection with such use.
TI products are neither designed nor intended for use in automotive applications or environments unless the specific TI products are
designated by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated
products in automotive applications, TI will not be responsible for any failure to meet such requirements.
Following are URLs where you can obtain information on other Texas Instruments products and application solutions:
Products Applications
Audio www.ti.com/audio Communications and Telecom www.ti.com/communications
Amplifiers amplifier.ti.com Computers and Peripherals www.ti.com/computers
Data Converters dataconverter.ti.com Consumer Electronics www.ti.com/consumer-apps
DLP®Products www.dlp.com Energy and Lighting www.ti.com/energy
DSP dsp.ti.com Industrial www.ti.com/industrial
Clocks and Timers www.ti.com/clocks Medical www.ti.com/medical
Interface interface.ti.com Security www.ti.com/security
Logic logic.ti.com Space, Avionics and Defense www.ti.com/space-avionics-defense
Power Mgmt power.ti.com Transportation and Automotive www.ti.com/automotive
Microcontrollers microcontroller.ti.com Video and Imaging www.ti.com/video
RFID www.ti-rfid.com
OMAP Mobile Processors www.ti.com/omap
Wireless Connctivity www.ti.com/wirelessconnectivity
TI E2E Community Home Page e2e.ti.com
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright ©2011, Texas Instruments Incorporated
