THE SHOWER LAB VIEW 30 User manual

10/2021 V 1.1
VIEW 30 Illustration - View 30
Right Hand

10/2021 V 1.1
VIEW 30
IMPORTANT
•This shower screen / enclosure must be installed by suitably qualified individuals. We
recommend a minimum of two people for safe assembly of certain sections of this screen.
•Ensure all appropriate safety equipment, especially protective footwear, safety glasses
and gloves are used.
•When drilling holes in ceramic tiles, use masking tape to prevent the drill from slipping:
DO NOT use hammer action as this will crack the tiles. Use a high quality drill bit to ensure
a clean, precise hole.
Tighten hinges and brackets to the recommended 15.6N.
•
•
Please leave these instructions with the customer following installation.
PRIOR TO INSTALLATION
•Before disposing of the packaging and prior to commencing assembly, please check all
the components to ensure that they have been supplied correctly and are undamaged.
Subsequent claims for missing or damaged pieces will not be accepted once the
packaging has been disposed of and installation commenced.
•In the event of any queries please contact your supplier quoting the relevant model
information.
•The Tray / Tiled floor on which this screen is to be installed must be level on all sides.
•It may be necessary to use alternate fixings to those supplied, depending on the properties
of the walls to be fixed to.
•Use the protective corners supplied at all times until the glass is moved to its final position.
•Ensure that the glass is installed correctly, taking care to avoid installing the glass upside
down. On certain panels an easy clean coating is applied to one side only, this is clearly
marked with a sticker on the non-coated side. The coated surface is to be fitted inwards
towards the inside (wet side) of the screen.
•Ensure that all surfaces to be sealed are clean and dry prior to applying the silicone
sealant. Use a high grade fungal resistant sealant.
•Allow a minimum of 24 hours after application of the silicone sealant prior to using the
screen.
TOOLS & MATERIALS REQUIRED
Junior Hacksaw
Straight Edge (Steel
Rule)
Fine Tooth File
Set or Roofing
Square
Masking Tape
Modelling Knife
Spirit Level
Pencil
Silicone Gun
Power Drill
Ø6mm Masonry Drill Bit
2x Suction Glass Lifters
High Quality Silicone Sealant
Tape Measure
Pozi-drive
Screwdrivers, PZ1&2
Safety Glasses and
Gloves
CARE AND MAINTENANCE
(please ensure that these instructions are left with the installed unit)
•We recommend routine cleaning of your screen / enclosure with hot water using a soft
cloth, then drying with a dry soft cloth or chamois leather.
Ritec Aftercare for Shower Glass is recomended for best results.
•All glass has been treated with EASY CLEAN glass finish and care must be taken to avoid
any abrasive cleaning products that may damage the special surface protection.
•DO NOT use acidic based de-scaler products or products containing bleaches or solvents.
Digital Torque Wrench

10/2021 V 1.1
VIEW 30
Spacers Wall Prole End Cap
x1
Supplied Parts
Inline Panel
x1
Door
x1
Slider Bracket Template
x1
Nylon Block
x1
Pig Nose Adapter
x1
Packers

10/2021 V 1.1
VIEW 30
Supplied Parts
Underframe Wedge Gasket
x2
Underframe
x1
Underframe Gasket
x1
Wall Prole
x1
Wall Prole Soft Seal
x1
Wall Prole Rigid Seal
x1
Underframe Top
x1
Glass to Wall Seal
x1
Glass to Glass Slider Seal
x1

10/2021 V 1.1
VIEW 30
Slider Door Roller
x2
Slider Panel Fixing
x2
Slider Door Retainer
x2
Slider Door Stop
x1
Slider Wall Bracket
x1
Bottom Door Guide
x1
Supplied Parts
Slider Bar
x1
Slider Bar Insert
x1
Slider Wall Bracket with Stop
x1

10/2021 V 1.1
VIEW 30
These instructions are for the View 30.
The following instructions are valid for both the 20mm and 30mm proles. The 30mm prole is
used in the following instructions.
Please use the below diagram to reference the list of parts.
A
B
I
C
H
D
F
E
G
Door Panel
Inline Fixed Panel
Wall Prole
Wall Prole Soft Seal
Wall Prole Rigid Seal
Underframe Wedge Gasket
Underframe
Underframe Gasket
JUnderframe Top
Wall Prole End Cap
N
M
K
L
Bottom Door Guide
Glass to Wall Bubble Seal
Glass to Glass Slider Seal
Slider Bar
OSlider Bar Insert
PSlider Door Stop
QSlider Wall Bracket
RSlider Door Roller
SSlider Door Retainer
TSlider Panel Fixing
USlider Wall Bracket (with Adjustable Stop)
O
R
P
U
B
D
E
C
I
K
J
F
L
A
G
H
M
T
N
S
Q

10/2021 V 1.1
VIEW 30
]GI 7QGjP $dI[Q[O<d $pIgY<d IQOPj
6.ÄÁ/ÂÂÁ ÂÁÄÁÂÁÈÁ ÅÄÄÅÈÄ ÈÁÄÁ ÃÁÁÁ
6.ÄÁ/ÂÃÁ ÂÂÄÁÂÂÈÁ ÅÉÄÆÃÄ ÈÁÄÁ ÃÁÁÁ
6.ÄÁ/ÂÄÁ ÂÃÄÁÂÃÈÁ ÅÉÄÆÃÄ ÈÁÄÁ ÃÁÁÁ
6.ÄÁ/ÂÅÁ ÂÄÄÁÂÄÈÁ ÆÉÄÇÃÄ ÈÁÄÁ ÃÁÁÁ
6.ÄÁ/ÂÆÁ ÂÅÄÁÂÅÈÁ ÆÉÄÇÃÄ ÈÁÄÁ ÃÁÁÁ
6.ÄÁ/ÂÇÁ ÂÆÄÁÂÆÈÁ ÇÉÄÈÃÄ ÈÁÄÁ ÃÁÁÁ
ADJUSTMENT SHEET
STANDARD ENCLOSURES - 30mm (CH30) Wall Profile
If you have a Bespoke Enclosure, reference the Install Sheet for the panel specifica�ons of the Enclosure.
CH30 - Bespoke Enclosure Width: Door Panel + Inline Panel - 54 = Minimum Width + 54 = Maximum Width
CH20 - Bespoke Enclosure Width: Door Panel + Inline Panel - 54 = Minimum Width + 44 = Maximum Width
BESPOKE ENCLOSURES - 30mm (CH30)/ 20mm (CH20) Wall Profiles
LH RH

10/2021 V 1.1
VIEW 30
01/13
Ensure the base is level.
Measure the width of the opening

Mark this measurement on the

It is recommended to use masking tape
on the Underframe to mark your
measurement.
Cut squarely using a chop saw.

burrs, be careful not to damage the


tray edge.
If using a raised shower tray, leave a
minimum 3mm gap from the edge of
the tray (5mm is recommended). This is
the lip distance.

the tray at this stage.

Plate into the T Slot of the Underframe.
3mm minimum
Shower Tray
X
01 02
03 04
IMPORTANT STEP

10/2021 V 1.1
VIEW 30
02/13
Fix the Underframe into the correct











05 06
07 08

10/2021 V 1.1
VIEW 30
03/13

















Wet Side
Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.





(No 8) Prole - Wall
(No 6) Prole - Top Cap
09 10
11 12

10/2021 V 1.1
VIEW 30
04/13
Remove and replace the Panel adding

level the Panel (to a maximum height
of 5mm inside the Underframe).
Check the Panel is level using a Spirit
Level.

Inline Glass Panel, move on to step 17.




needs to be trimmed.

recommended to mark on masking
tape.




careful not to damage the channel







the back.
Re-install the Glass.
Silicone the
inside corner
13 14
15 16

10/2021 V 1.1
VIEW 30
05/13
Measure and check the distance from
the Inline Panel to the opposite wall

equal.
To centre the panel, add 1mm Packers

Underframe.








the Nylon Block to protect the Glass

=
=
6mm min
Wall ProleGlass Panel
Flush
Rigid Seal
Glass Panel
17 18
19 20

10/2021 V 1.1
VIEW 30
06/13
Remove Packers and feed the
Underframe Wedge Gasket into the
archway gap of the Fixed Panel and
trace along the Glass on both sides.
Spray water on Glass Panel and use
Nylon Block to help feed Gasket.
Trim both of the Wall Profile seals at
the top face of the Wall Profile using a
blade.
Measure the distance from the wall to
the nearest fixing hole on the Inline
Panel. Ensure this measurement is truly
horizontal.
Subtract 15mm to get your final
dimension.
x - 15mm
Trim the Wedge Gaskets at the edge of
the Inline Panel.
21 22
23 24

10/2021 V 1.1
VIEW 30
07/13
Use the Slider Rail Bracket Template to
mark the hole posi�ons for the Slider
Rail Bracket on the Wall Profile side of
the enclosure.
Using a Ø6mm high quality drill bit for
a clean and precise hole, drill all holes
and fully insert the wall plugs.
Fix the Slider Wall Bracket in place
using the supplied screws.
Trace the Wall Profile on the door side
wall. Use the Spirit Level against the
Inline Panel to accurately trace the
Profile.
Align the Slider Rail Bracket Template
to the sketch and mark the holes.
Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
Fixing Holes
Mark the final dimension on the Slider
Bar on the fixing hole side.
Cut squarely using a chop saw and
finish the edge.
SLIDER BAR IS STAINLESS STEEL
x - 15mm
25 26
27 28

10/2021 V 1.1
VIEW 30
x - 30mm
Slider Bar Insert
Fixing Holes
x
Mark the final dimension on the Slider
Bar on the opposite side of the Slider
Bar.
Cut squarely using a chop saw and
finish the edge.
SLIDER BAR IS STAINLESS STEEL
08/13
Using a Ø6mm high quality drill bit for
a clean and precise hole, drill all holes
and fully insert the wall plugs.
Fix the Slider Wall Bracket in place
using the supplied screws.
Measure the wall to wall distance.
Ensure this measurement is truly
horizontal.
Subtract 30mm to get your final
dimension.
Insert the Slider Bar Insert into the
Slider Bar and ensure that the threaded
holes in the Slider Bar Insert align with
the clearance holes on the Slider Bar.
29 30
31 32

10/2021 V 1.1
VIEW 30
Door Stop
Slide the Collar over the Wall Bracket


and orientated as shown before


FIXED PANEL
09/13




Enclosure and securely rest the Panel














PZ1 Screws
33 34
35 36

10/2021 V 1.1
VIEW 30
10/13

Rollers to the Door.


the Slider.
Ensure that the Door is level by

Use two allen keys and the supplied Pig
Nose Adapter to adjust.

place using the supplied Grub Screws.



Use the supplied Pig Nose Adapter to

Adjust the Retainers under the Slider

37 38
39 40

10/2021 V 1.1
VIEW 30
Outside of
enclosure
x
Door Stop
11/13
Adjust the Door Stop to ensure that the
Door does not travel too far. Pay












the Door.




41 42
43 44

10/2021 V 1.1
VIEW 30
12/13
Push both Ver�cal Seals down as far as
they can go. With a straight edge, mark
where the Seals will be trimmed.
Mark the Glass to Glass Slider Seal just
below the Slider Bar.
Remove the Seals and trim with a fine
toothed hacksaw.
Replace the Seals.
Push both Ver�cal Seals down as far as
they can go. With a straight edge, mark
where the Seals will be trimmed.
Mark the Glass to Glass Slider Seal just
below the Slider Bar.
Remove the Seals and trim with a fine
toothed hacksaw.
Replace the Seals.
Apply the Wall Profile End Cap to the
top of the Wall Profile and fix in place
using self tapping screws.
Underframe
Wall Channel
Silicone
Apply silicone sealant along the wall
and floor, all around the outside of the
Underframe and Wall Profiles.
Silicone
45 46
47 48

10/2021 V 1.1
VIEW 30
13/13
Apply silicone to the edges of the
Underframe Top where it meets the
Glass Inline Panel and the wall.
Check silicone has been applied to all
the below outside areas.
Silicone
Silicone
Check silicone has been applied to all
the below inside areas.
Let the silicone sealant cure for 24
hours.
Silicone
49 50
51
