THE SHOWER LAB VIEW 02 VR02S59 User manual

10/2021 V 1.1
VIEW 02 Illustration - View 02
H1 Handle
Right Hand
Open Out

10/2021 V 1.1
VIEW 02
IMPORTANT
•This shower screen / enclosure must be installed by suitably qualified individuals. We
recommend a minimum of two people for safe assembly of certain sections of this screen.
•Ensure all appropriate safety equipment, especially protective footwear, safety glasses
and gloves are used.
•When drilling holes in ceramic tiles, use masking tape to prevent the drill from slipping:
DO NOT use hammer action as this will crack the tiles. Use a high quality drill bit to ensure
a clean, precise hole.
Tighten hinges and brackets to the recommended 15.6N.
•
•
Please leave these instructions with the customer following installation.
PRIOR TO INSTALLATION
•Before disposing of the packaging and prior to commencing assembly, please check all
the components to ensure that they have been supplied correctly and are undamaged.
Subsequent claims for missing or damaged pieces will not be accepted once the
packaging has been disposed of and installation commenced.
•In the event of any queries please contact your supplier quoting the relevant model
information.
•The Tray / Tiled floor on which this screen is to be installed must be level on all sides.
•It may be necessary to use alternate fixings to those supplied, depending on the properties
of the walls to be fixed to.
•Use the protective corners supplied at all times until the glass is moved to its final position.
•Ensure that the glass is installed correctly, taking care to avoid installing the glass upside
down. On certain panels an easy clean coating is applied to one side only, this is clearly
marked with a sticker on the non-coated side. The coated surface is to be fitted inwards
towards the inside (wet side) of the screen.
•Ensure that all surfaces to be sealed are clean and dry prior to applying the silicone
sealant. Use a high grade fungal resistant sealant.
•Allow a minimum of 24 hours after application of the silicone sealant prior to using the
screen.
TOOLS & MATERIALS REQUIRED
Junior Hacksaw
Straight Edge (Steel
Rule)
Fine Tooth File
Set or Roofing
Square
Masking Tape
Modelling Knife
Spirit Level
Pencil
Silicone Gun
Power Drill
Ø6mm Masonry Drill Bit
2x Suction Glass Lifters
High Quality Silicone Sealant
Tape Measure
Pozi-drive
Screwdrivers, PZ1&2
Safety Glasses and
Gloves
CARE AND MAINTENANCE
(please ensure that these instructions are left with the installed unit)
•We recommend routine cleaning of your screen / enclosure with hot water using a soft
cloth, then drying with a dry soft cloth or chamois leather.
Ritec Aftercare for Shower Glass is recomended for best results.
•All glass has been treated with EASY CLEAN glass finish and care must be taken to avoid
any abrasive cleaning products that may damage the special surface protection.
•DO NOT use acidic based de-scaler products or products containing bleaches or solvents.
Digital Torque Wrench

10/2021 V 1.1
VIEW 02
Supplied Parts
Door Handle
(Option dependant)
x1
Door
x1
Underframe
x1
Underframe Top
x1
Glass to Wall Bubble Seal
x1
Bottom Door Seal
x1
Glass to Wall Seal
x1

10/2021 V 1.1
VIEW 02
Supplied Parts
Glass to Wall Hinge
(Option Dependant)
x2
(Each Hinge Includes
3x Screws and Wall Plugs)
Open Out
Open In
Hinge Template
x1
Glass Support
x2

10/2021 V 1.1
VIEW 02
These instructions are for the View 02.
Please use the below diagram to reference the list of parts.
A
B
C
H
D
F
E
G
Door Panel
Glass to Wall Hinge
Glass to Wall Seal
Underframe Top
Bottom Door Seal
Handle (H1 Shown)
Glass to Wall Bubble Seal
Underframe
B
C
D
E
H
A
F
G

10/2021 V 1.1
VIEW 02
]GI 7QGjP IQOPj
6.ÁÃ/ÆÊ ÆÊÃ ÃÁÁÁ
6.ÁÃ/ÇÁ ÇÁÉ ÃÁÁÁ
6.ÁÃ/ÇÆ ÇÆÁ ÃÁÁÁ
ADJUSTMENT SHEET
STANDARD ENCLOSURES
LH RH
If you have a Bespoke Enclosure, reference the Install Sheet for the panel specifica�ons of the Enclosure.
Bespoke Enclosure Width: Panel + 15 = Width (0mm Adjustment)
BESPOKE ENCLOSURES

10/2021 V 1.1
VIEW 02
01/06
Ensure the base is level.
Measure the width of the opening

Mark this measurement on the

It is recommended to use masking tape
on the Underframe to mark your
measurement.
Cut squarely using a chop saw.

burrs, be careful not to damage the


tray edge.
If using a raised shower tray, leave a
minimum 3mm gap from the edge of
the tray (5mm is recommended). This is
the lip distance.
Fix the Underframe into the correct

from the self adhesive tape and push


point.
3mm minimum
Shower Tray
X
01 02
03 04

Outside enclosure
Outside enclosure
OUTWARD Opening
INWARD Opening
10/2021 V 1.1
VIEW 02
02/06
Loosely assemble the two 90° Glass to
Wall Hinges onto the door. Take note of
which way your Hinges move.

should be located inside the enclosure.

Plates. Adjust Clamping Plate to Suit.

Gaskets are just "nipping" the glass.
Place the Door Supports evenly over
the Frame.


With one person inside the enclosure,

Supports as indicated.
First, check there is a gap of 9mm


Mark the accessible holes where the

It is recommended to use masking tape

Hole “B”
See step 09
9
05 06
07 08

10/2021 V 1.1
VIEW 02
03/06


















Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
Outside of
enclosure
Flush
09 10
11 12

10/2021 V 1.1
VIEW 02
Trim the aps
Notch
Tray
Trim the aps
Notch
Tray
04/06
Measure the width of the Door and


















Outside of
enclosure
13 14
15 16

10/2021 V 1.1
VIEW 02
Cut
Cut
05/06




















Trim
17 18
 

10/2021 V 1.1
VIEW 02
06/06
Apply silicone sealant as shown below
between the Underframe and the tray
(floor tiles).
Check silicone has been applied to all
the below outside areas.
Underframe
Silicone
Check silicone has been applied to all
the below inside areas.
Let the silicone sealant cure for 24
hours.
23
Silicone
Silicone
21 22
