THE SHOWER LAB VR01S20 User manual

02/2021 V 1.0
VIEW 01 Illustration - View 01
Right Hand
SB1 Stay Bar

02/2021 V 1.0
VIEW 01
IMPORTANT
•This shower screen / enclosure must be installed by suitably qualified individuals. We
recommend a minimum of two people for safe assembly of certain sections of this screen.
•Ensure all appropriate safety equipment, especially protective footwear, safety glasses
and gloves are used.
•When drilling holes in ceramic tiles, use masking tape to prevent the drill from slipping:
DO NOT use hammer action as this will crack the tiles. Use a high quality drill bit to ensure
a clean, precise hole.
Tighten hinges and brackets to the recommended 15.6N.
•
•
Please leave these instructions with the customer following installation.
PRIOR TO INSTALLATION
•Before disposing of the packaging and prior to commencing assembly, please check all
the components to ensure that they have been supplied correctly and are undamaged.
Subsequent claims for missing or damaged pieces will not be accepted once the
packaging has been disposed of and installation commenced.
•In the event of any queries please contact your supplier quoting the relevant model
information.
•The Tray / Tiled floor on which this screen is to be installed must be level on all sides.
•It may be necessary to use alternate fixings to those supplied, depending on the properties
of the walls to be fixed to.
•Use the protective corners supplied at all times until the glass is moved to its final position.
•Ensure that the glass is installed correctly, taking care to avoid installing the glass upside
down. On certain panels an easy clean coating is applied to one side only, this is clearly
marked with a sticker on the non-coated side. The coated surface is to be fitted inwards
towards the inside (wet side) of the screen.
•Ensure that all surfaces to be sealed are clean and dry prior to applying the silicone
sealant. Use a high grade fungal resistant sealant.
•Allow a minimum of 24 hours after application of the silicone sealant prior to using the
screen.
TOOLS & MATERIALS REQUIRED
Junior Hacksaw
Straight Edge (Steel
Rule)
Fine Tooth File
Set or Roofing
Square
Masking Tape
Modelling Knife
Spirit Level
Pencil
Silicone Gun
Power Drill
Ø6mm Masonry Drill Bit
2x Suction Glass Lifters
High Quality Silicone Sealant
Tape Measure
Pozi-drive
Screwdrivers, PZ1&2
Safety Glasses and
Gloves
CARE AND MAINTENANCE
(please ensure that these instructions are left with the installed unit)
•We recommend routine cleaning of your screen / enclosure with hot water using a soft
cloth, then drying with a dry soft cloth or chamois leather.
Ritec Aftercare for Shower Glass is recomended for best results.
•All glass has been treated with EASY CLEAN glass finish and care must be taken to avoid
any abrasive cleaning products that may damage the special surface protection.
•DO NOT use acidic based de-scaler products or products containing bleaches or solvents.
Digital Torque Wrench

02/2021 V 1.0
VIEW 01
Underframe Wedge Gasket
x2
Underframe
x1
Underframe Gasket
x1
Wall Prole
x1
Wall Prole Soft Seal
x1
Wall Prole Rigid Seal
x1
Supplied Parts
Underframe End Cap
x1
Wall Prole End Cap
x1

02/2021 V 1.0
VIEW 01
Glass Panel
x1
Nylon Block
x1
Supplied Parts
SpacersPackers

02/2021 V 1.0
VIEW 01
These instructions are for the View 01. An SB1 Stay Bar is used for this illustration.
The following instructions are valid for both the 20mm and 30mm proles. The 30mm prole is
used in the following instructions.
Please use the below diagram to reference the list of parts.
A
B
I
C
H
D
F
E
G
Fixed Panel
Wall Prole
Wall Prole End Cap
Wall Prole Soft Seal
Underframe Prole
Underframe End Cap
Underframe Wedge Gasket
Underframe Gasket
JStaybar (If Included)
Wall Prole Rigid Seal
A
J
C
E
B
F
H
I
G
D

02/2021 V 1.0
VIEW 01
  
  
  
  
  
  
  
  
  
  
  
  
  
  
  
  
ADJUSTMENT SHEET
STANDARD ENCLOSURES
Please Note
Only Standard Enclosures are shown above. If you have a Bespoke Enclosure, reference the delivery
note for the panel specificaons of the Enclosure.
BESPOKE ENCLOSURES
LH RH

02/2021 V 1.0
VIEW 01
01/13
Posion the Underframe parallel to
tray edge. If using a raised shower tray,
leave a minimum 3mm gap from the
edge of the tray (5mm is
recommended). This is the lip distance.
DO NOT fix the Underframe channel to
the tray at this stage.
Temporarily fix the Underframe into
the correct posion using double sided
tape. Push firmly into posion and
ensure that the Underframe is firmly
against the wall where the channel will
be fixed to.
DO NOT use the exisng tape. This tape
is for final posioning of Underframe.
Place the Underframe Gasket into the
Underframe.
Place the Wall Profile over the
Underframe and up against the wall.
3mm minimum
Shower Tray
No Gap
01 02
03 04

02/2021 V 1.0
VIEW 01
02/13
Ensure the Wall Profile is vercal by
using a spirit level.
Mark the posions of the pre-drilled
holes.
Remove the Wall Profile and drill holes
with a 6mm high quality drill bit for a
clean and precise hole.
Fully insert the wall plugs and fix the
Wall Profile in place.
Take the Wall Profile So Seal and push
the seal into place on the vercal Wall
Profile to cover the screws.
Ensure the fin is on the inside (wet
side). Use the Nylon Block to help.
Using purpose built "Glass Liers",
posion and sit the glass on to the
Underframe Gasket and push against
the Wall Profile.
Note the orientaon and posion of
the Panel, this can be determined by
any holes or aached labels.
Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
05 06
07 08

02/2021 V 1.0
VIEW 01
03/13
Carefully posion the Glass Panel using
the measurements below:
x = End Cap (3mm) + Lip Distance
Ensure there is adequate glass in the
Wall Profile. (6mm is recommended)
Mark/scribe the Underframe at the top
face of the Glass Panel.
If required, mark/scribe the vercal
Wall Profile also to the end face of the
Glass Panel.
DO NOT trim the Profiles at this stage.
Carefully li the Glass Panel out and
put to one side. Remove the Wall
Profile, Wall Profile So Seal,
Underframe Gasket, and Underframe
Profile and set to one side.
WARNING
The glass is heavy and may
damage the oor or underframe if
handled incorrectly. It is advisable
to use a suitable non-slip
protective mat or piece of carpet.
Never rest the glass across the
underframe as this may cause
damage.
6mm min
Wall Prole
Lip
Distance
x Glass Panel
Underframe
09 10
11 12

02/2021 V 1.0
VIEW 01
04/13
Trim the Underframe profile using a
chop saw.
If necessary, trim the Wall Profile on
the opposite side of the archway.
Use a fine file to remove any burrs. Be
careful not to damage the channel
finish.
Pre drill the screws in to the Wall
Profile to create the thread to ease
later steps.
Remove screws aer drilling.
Remove all tape from the underside of
the Underframe. Carefully place the
Underframe back into posion. Ensure
that the trimmed end is bued up
against the wall.
Place the Underframe Gasket back into
the Underframe. Trim excess Gasket.
Carefully reinstall the vercal Wall
Profile, Wall Profile So Seal and Glass
Panel. Align the Glass Panel flush to the
end of the Underframe.
WARNING
The glass is heavy and may
damage the oor or underframe if
handled incorrectly. It is advisable
to use a suitable non-slip
protective mat or piece of carpet.
Never rest the glass across the
underframe as this may cause
damage.
13 14
15 16

02/2021 V 1.0
VIEW 01
05/13
To centre the panels, add 1mm Packers
on both sides of Inline Panels in the
Underframe.
Apply the Rigid Seal to dry side of the
Wall Profile starng from the archway
of the Wall Profile up to the top face of
the Wall Profile.
Gently tap the Wall Profile Rigid Seal
into place using a rubber mallet with
the Nylon Block to protect the Glass
and the Wall Profile.
Remove Packers and feed the Wedge
Gasket into the archway gap and trace
along the Glass on both sides.
Spray water on Glass Panel and use
Nylon Block to help feed Gasket.
Flush
Rigid Seal
Glass Panel
17 18
19 20

02/2021 V 1.0
VIEW 01
06/13
Trim both Underframe Gasket Seals as
close to the edge as possible using a
blade.
Trim both of the Wall Profile seals at
the top face of the Wall Profile using a
blade.
Install the Stay Bar if supplied.
Check which Stay Bar configuraon
your screen has been supplied with and
refer to the relevant instrucons below.
(You can find this out at the front of
these instrucons).
If no Stay Bar supplied, please skip
these steps and move on to step 23.
Config A - SB1 Page 07
Config B - SB2 Page 10
21 22
23

X
X - 6.5mm
02/2021 V 1.0
VIEW 01
07/13
Measure the distance from the inside
face (wet side) of the panel to the wall
opposite. Ensure this measurement is
truly horizontal.
Subtract 6.5mm to get your final
dimension.
Mark the final dimension on the Stay
Bar Tube, wrapped with some masking
tape. Carefully use a chop saw and fine
file to cut and finish the edge.
STAY BAR CONFIGURATION A - SB1
A1 A2

02/2021 V 1.0
VIEW 01
08/13
With masking tape applied, place the
supplied Stay Bar Jig firmly at the
trimmed end of the Stay Bar and mark
the 2 holes with a pen.
Drill holes using a 5mm drill bit.
Assemble the Glass Clamp to the Stay
Bar as shown.
Secure the Glass Clamp over the panel
making sure the glass is fully inserted
into the groove.
Ensure the Stay Bar is square and level.
Mark the end locaon on the wall.
Remove the Stay Bar.
STAY BAR CONFIGURATION A - SB1
Drill 1 side only
A3 A4
A5 A6

02/2021 V 1.0
VIEW 01
Fix Glass Clamp over the Glass and
aach the Stay Bar to the Wall
Connector with screws provided.
09/13
Posion the Stay Bar Connector central
to the marking. Mark the holes for
drilling. Use masking tape on the les
to help.
Using a 5mm high quality drill bit for a
clean and precise hole, drill the marked
areas, fully insert the wall plugs and fix
the Connector to the wall.
Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
STAY BAR CONFIGURATION A - SB1
A7 A8
A9

02/2021 V 1.0
VIEW 01
10/13
Assemble the Glass Clamp to the Stay
Bar.
Secure the Glass Clamp over the panel,
ensuring it is flush against the wall
(le).
STAY BAR CONFIGURATION B - SB2
B1 B2

02/2021 V 1.0
VIEW 01
11/13
Ensure the Stay Bar is level and square.
Mark the locaon on the wall and
remove the Stay Bar.
Posion the Stay Bar Connector central
to the marking. Mark the holes for
drilling.
Use masking tape on the les to help.
Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
STAY BAR CONFIGURATION B - SB2
Fix Glass Clamp over the Glass and
aach the Stay Bar to the Wall
Connector with screws provided.
B3 B4
Using a 5mm high quality drill bit for a
clean and precise hole, drill the marked
areas, fully insert the wall plugs and fix
the Connector to the wall.
B5 B6

02/2021 V 1.0
VIEW 01
12/13
Apply the Wall Profile End Cap to the
top of the Wall Profile and fix in place
using self tapping screws.
Install the Underframe End Cap.
Underframe
Wall Channel
Silicone
Apply silicone sealant along the wall
and floor all around the outside of the
Underframe and Wall Profiles.
24 25
26

02/2021 V 1.0
VIEW 01
13/13
Check silicone has been applied to all
the below inside areas.
Check silicone has been applied to all
the below outside areas.
Let the silicone sealant cure for 24
hours.
Silicone
Silicone
27 28
