THE SHOWER LAB VIEW 19F User manual

Illustration - View 19F
Right Hand
VIEW 19F
07/2019 V 2.2

IMPORTANT
•This shower screen / enclosure must be installed by suitably qualified individuals. We
recommend a minimum of two people for safe assembly of certain sections of this screen.
•Ensure all appropriate safety equipment, especially protective footwear, safety glasses
and gloves are used.
•When drilling holes in ceramic tiles, use masking tape to prevent the drill from slipping:
DO NOT use hammer action as this will crack the tiles. Use a high quality drill bit to ensure
a clean, precise hole.
Tighten hinges and brackets to the recommended 15.6N.
•
•
Please leave these instructions with the customer following installation.
PRIOR TO INSTALLATION
•Before disposing of the packaging and prior to commencing assembly, please check all
the components to ensure that they have been supplied correctly and are undamaged.
Subsequent claims for missing or damaged pieces will not be accepted once the
packaging has been disposed of and installation commenced.
•In the event of any queries please contact your supplier quoting the relevant model
information.
•The Tray / Tiled floor on which this screen is to be installed must be level on all sides.
•It may be necessary to use alternate fixings to those supplied, depending on the properties
of the walls to be fixed to.
•Use the protective corners supplied at all times until the glass is moved to its final position.
•Ensure that the glass is installed correctly, taking care to avoid installing the glass upside
down. On certain panels an easy clean coating is applied to one side only, this is clearly
marked with a sticker on the non-coated side. The coated surface is to be fitted inwards
towards the inside (wet side) of the screen.
•Ensure that all surfaces to be sealed are clean and dry prior to applying the silicone
sealant. Use a high grade fungal resistant sealant.
•Allow a minimum of 48 hours after application of the silicone sealant prior to using the
screen.
TOOLS & MATERIALS REQUIRED
Junior Hacksaw
Straight Edge (Steel
Rule)
Fine Tooth File
Set or Roofing
Square
Masking Tape
Modelling Knife
Spirit Level
Pencil
Silicone Gun
Power Drill
Ø6mm Masonry Drill Bit
2x Suction Glass Lifters
High Quality Silicone Sealant
Tape Measure
Pozi-drive
Screwdrivers, PZ1&2
Safety Glasses and
Gloves
CARE AND MAINTENANCE
(please ensure that these instructions are left with the installed unit)
•We recommend routine cleaning of your screen / enclosure with hot water using a soft
cloth, then drying with a dry soft cloth or chamois leather.
Ritec Aftercare for Shower Glass is recomended for best results.
•All glass has been treated with EASY CLEAN glass finish and care must be taken to avoid
any abrasive cleaning products that may damage the special surface protection.
•DO NOT use acidic based de-scaler products or products containing bleaches or solvents.
Digital Torque Wrench
VIEW 19F
07/2019 V 2.2

Supplied Parts
Panel A - R
x1
Panel B - P
x1
Glass to Glass Bracket
x2
Surface Channel
x3
SB1 Stay Bar
x1
(If no stay bar is supplied,
no stay bar is needed)
Spacers
1mm/3mm
End Cap
x1
90° Glass to Wall Bracket
x2
(Each bracket includes
2x screws and wall plugs)
Square Alignment Jig
x1
VIEW 19F
07/2019 V 2.2

These instructions are for a xed walk in enclosure. This view shows the right handed option.
Please use the below diagram to reference the list of parts.
A
B
C
D
F
E
Panel A - R
Panel B - P
Glass to Wall Bracket
Stay Bar (If included)
Surface Channel
GChannel End Cap
Glass to Glass Bracket
A
C
B
D
D
E
E
F
F
F
G
VIEW 19F
07/2019 V 2.2

Measure the length of the shower tray.
Take off the recommended 3-8mm for
a lip.
Measure the width of Panel A,
- Add 16mm to this dimension. This is
the shortest the screen can be.
- Or add 24mm to this dimension. This
is the longest the screen can be.
Insert the square alignment jig to
locate the wall channel. Using a spirit
level, ensure the wall channel is
ver�cal.
Mark the pre-drilled holes.
12
3 4
Measure and trim the base channel
from the mitred end to your desired
length.
Fix the channel to the tray with the
pads supplied with the 3-8mm lip from
the edge.
01/11
Remove the wall channel.
Using a 6mm high quality drill bit for a
clean and precise hole, drill the marked
areas, fully insert the wall plugs
and fix the channel.
3-8mm
Shower Tray
Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
X
VIEW 19F
07/2019 V 2.2

6









5
7





02/11
8

Align
Surface Channel
Glass Panel
WARNING
The glass is heavy and may
damage the oor or underframe if
handled incorrectly. It is advisable
to use a suitable non-slip
protective mat or piece of carpet.
Never rest the glass across the
underframe as this may cause
damage.
20mm
Glass to Glass
Bracket holes
6mm
6mm
VIEW 19F
07/2019 V 2.2

Remove and replace the panel adding
or subtrac�ng spacers as necessary to
level the panel (to a maximum height
of 14mm inside the base channel).
Check the panel is level using a Spirit
Level.
Place spacers into the return surface
channel evenly. Begin with 6mm
Spacers. (2x 3mm spacers)
NOTE: There must be a minimum set of
1mm spacers used under the glass
panel.
910
11 12
Fix Panel B base channel on the shower
tray / floor squarely up against Panel A
base channel as indicated using a set
square.
03/11
Carefully place Panel B onto the
spacers and slide to the front of the
channel leaving no gap. Check that the
top of the panels are level.
Remember not to stack higher than
14mm. If the difference is greater than
14mm, it may be necessary to lower
Panel A first.
6mm
6mm
No Gap
Surface Channel
Panel A
Panel B
VIEW 19F
07/2019 V 2.2

13 14
15 16
Loosely assemble the 90° glass to glass








your measurements.
04/11












VIEW 19F
07/2019 V 2.2

17 18
19 20
Carefully seperate the two panels.
Leaving the brackets on the panels, li�
the glass out and put to one side.
Note and leave the spacers in the
base channels.
Check there are no spacers stuck
underneath the panel.
Carefully remove the channels and
trim using a fine toothed junior
hacksaw.
Use a fine file to remove any burrs.
Be careful not to damage the channel
finish.
05/11
Using a 6mm high quality drill bit for a
clean and precise hole, drill the marked
areas and fully insert the wall plugs.
Spacer
Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
6mm
6mm
6mm
VIEW 19F
07/2019 V 2.2














21 22
23 24





06/11









Silicone
WARNING
The glass is heavy and may
damage the oor or underframe if
handled incorrectly. It is advisable
to use a suitable non-slip
protective mat or piece of carpet.
Never rest the glass across the
underframe as this may cause
damage.
VIEW 19F
07/2019 V 2.2

Mark the final dimension on the stay
bar tube, wrapped with some masking
tape. Carefully use a fine toothed
junior hacksaw and fine file to cut and
finish the edge.
DO NOT discard the off cut.
A1 A2
Stay Bar Conguration A - SB1
Measure the distance from the inside
face (wet side) of the panel to the wall
opposite. Ensure this measurement is
truly horizontal.
Subtract 6mm to get your final
dimension.
07/11
X
Wall
Outside Enclosure
VIEW 19F
07/2019 V 2.2

Align the off cut to the new end.
Use a set square to locate the new
holes.
With a 4mm drill bit, carefully drill
through one side of the stay bar tube.
Ensure the stay bar is square and level.
Mark the end loca�on on the wall.
Remove the stay bar.
A3 A4
A5 A6
Stay Bar Conguration A - SB1
Assemble the glass clamp to the stay
bar as shown.
Secure the glass clamp over Panel A
making sure the glass is fully inserted
into the groove.
08/11 07/2019 V 2.2

A7 A8
Stay Bar Conguration A - SB1
09/11
Using a 5mm high quality drill bit for a
clean and precise hole, drill the marked
areas, fully insert the wall plugs and fix
the connector to the wall.
Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
Posi�on the stay bar connector central
to the marking. With a small drill bit
mark the holes for drilling.
Use masking tape on the �les to mark.
07/2019 V 2.2

26 27
28 29
10/11
Fix glass clamp over the glass and






Take care not to scratch the glass











Floor
Wall
Channel
Glass
Silicone
Silicone
Channel
Trim
VIEW 19F
07/2019 V 2.2

11/11
32 Check silicone has been applied to all
the below outside areas.
Let enclosure cure for 48 hours.
31 Check the silicone has been applied to
all the below inside areas.
Silicone
Silicone
30 Run a fillet of silicone down the join
between the inline panel and return
panel on the inside (wet side) of the
screen.
Silicone
Silicone Silicone
Silicone
