THE SHOWER LAB VIEW 19H User manual

10/2021 V 1.1
VIEW 19H Illustration - View 19H
Right Hand
SB1 Stay Bar

10/2021 V 1.1
VIEW 19H
IMPORTANT
•This shower screen / enclosure must be installed by suitably qualified individuals. We
recommend a minimum of two people for safe assembly of certain sections of this screen.
•Ensure all appropriate safety equipment, especially protective footwear, safety glasses
and gloves are used.
•When drilling holes in ceramic tiles, use masking tape to prevent the drill from slipping:
DO NOT use hammer action as this will crack the tiles. Use a high quality drill bit to ensure
a clean, precise hole.
Tighten hinges and brackets to the recommended 15.6N.
•
•
Please leave these instructions with the customer following installation.
PRIOR TO INSTALLATION
•Before disposing of the packaging and prior to commencing assembly, please check all
the components to ensure that they have been supplied correctly and are undamaged.
Subsequent claims for missing or damaged pieces will not be accepted once the
packaging has been disposed of and installation commenced.
•In the event of any queries please contact your supplier quoting the relevant model
information.
•The Tray / Tiled floor on which this screen is to be installed must be level on all sides.
•It may be necessary to use alternate fixings to those supplied, depending on the properties
of the walls to be fixed to.
•Use the protective corners supplied at all times until the glass is moved to its final position.
•Ensure that the glass is installed correctly, taking care to avoid installing the glass upside
down. On certain panels an easy clean coating is applied to one side only, this is clearly
marked with a sticker on the non-coated side. The coated surface is to be fitted inwards
towards the inside (wet side) of the screen.
•Ensure that all surfaces to be sealed are clean and dry prior to applying the silicone
sealant. Use a high grade fungal resistant sealant.
•Allow a minimum of 24 hours after application of the silicone sealant prior to using the
screen.
TOOLS & MATERIALS REQUIRED
Junior Hacksaw
Straight Edge (Steel
Rule)
Fine Tooth File
Set or Roofing
Square
Masking Tape
Modelling Knife
Spirit Level
Pencil
Silicone Gun
Power Drill
Ø6mm Masonry Drill Bit
2x Suction Glass Lifters
High Quality Silicone Sealant
Tape Measure
Pozi-drive
Screwdrivers, PZ1&2
Safety Glasses and
Gloves
CARE AND MAINTENANCE
(please ensure that these instructions are left with the installed unit)
•We recommend routine cleaning of your screen / enclosure with hot water using a soft
cloth, then drying with a dry soft cloth or chamois leather.
Ritec Aftercare for Shower Glass is recomended for best results.
•All glass has been treated with EASY CLEAN glass finish and care must be taken to avoid
any abrasive cleaning products that may damage the special surface protection.
•DO NOT use acidic based de-scaler products or products containing bleaches or solvents.
Digital Torque Wrench

10/2021 V 1.1
VIEW 19H
Supplied Parts
Glass to Glass Hinge
x2
Nylon Block
x1
Spacers
Wall Prole End Cap
x1
Panel A x1
(If bespoke, check labels
for orientation)
Panel B x1
(If bespoke, check labels
for orientation)
Packers

10/2021 V 1.1
VIEW 19H
Supplied Parts
Underframe Wedge Gasket
x2
Underframe
x1
Underframe Gasket
x1
Wall Prole
x1
Wall Prole Soft Seal
x1
Wall Prole Rigid Seal
x1
Bottom Door Seal
x1
Glass to Glass Bi-fold Seal
x1

10/2021 V 1.1
VIEW 19H
These instructions are for the View 19H. An SB1 Stay Bar is used for this illustration.
The following instructions are valid for both the 20mm and 30mm proles. The 30mm prole is
used in the following instructions.
Please use the below diagram to reference the list of parts.
A
B
I
C
H
D
F
E
G
Panel A
Panel B
Wall Prole
Wall Prole Soft Seal
Wall Prole Rigid Seal
Underframe
Underframe Wedge Gasket
Underframe Gasket
JBottom Door Seal
Wall Prole End Cap
M
K
L
Glass to Glass Bi-fold Seal
Glass to Glass Hinge
Staybar (If Included)
B
D
E
C
G
I
F
A
H
J
L
K
M

10/2021 V 1.1
VIEW 19H
]GI +<[IY7QGjP +<[IY7QGjP +<[IY7QGjP IQOPj
6ÅÇÈ ÅÈÉÅÊÃ   ÃÁÁÁ
6ÆÇÈ ÆÈÉÆÊÃ   ÃÁÁÁ
6ÇÇÈ ÇÈÉÇÊÃ   ÃÁÁÁ
6ÈÇÈ ÈÈÉÈÊÃ   ÃÁÁÁ
6ÉÇÈ ÉÈÉÊÃÉ   ÃÁÁÁ
6ÊÇÈ ÊÈÉÊÊÃ   ÃÁÁÁ
6ÂÁÇÈ ÂÁÈÉÂÁÊÃ   ÃÁÁÁ
6ÂÂÇÈ ÂÂÈÉÂÂÊÃ   ÃÁÁÁ
6ÂÇÈ ÂÈÃÂÊÃ ÃÁÁÁ
6ÃÇÈ ÃÈÃÃÊÃ ÃÁÁÁ
6ÄÇÈ ÄÈÃÄÊÃ ÃÁÁÁ
6ÅÇÈ ÅÈÃÅÊÃ ÃÁÁÁ
6ÈÂÉ.   ÈÄÃÈÅÇ ÃÁÁÁ
6ÈÇÈ+   ÈÉÂÈÊÆ ÃÁÁÁ
6ÉÇÈ+   ÉÉÂÉÊÆ ÃÁÁÁ
6ÊÇÈ+   ÊÉÂÊÊÆ ÃÁÁÁ
6ÂÁÇÈ+   ÂÁÉÂÂÁÊÆ ÃÁÁÁ
6ÂÂÇÈ+   ÂÂÉÂÂÂÊÆ ÃÁÁÁ
ADJUSTMENT SHEET
Enclosure dimensions to OUTSIDE of Wall Profiles - See spec below
STANDARD ENCLOSURES - 30mm (CH30) Wall Profiles
If you have a Bespoke Enclosure, reference the Install Sheet for the panel specifica�ons of the Enclosure.
CH30 - Bespoke Enclosure Width: Panel + Leaf + 15 = Minimum Width + 14 = Maximum Width
CH20 - Bespoke Enclosure Width: Panel + Leaf + 15 = Minimum Width + 4 = Maximum Width
BESPOKE ENCLOSURES - 30mm (CH30)/ 20mm (CH20) Wall Profiles
LH RH

10/2021 V 1.1
VIEW 19H
01/13
Posi�on the Underframe parallel to
tray edge. If using a raised shower tray,
leave a minimum 3mm gap from the
edge of the tray (5mm is
recommended). This is the lip distance.
DO NOT fix the Underframe channel to
the tray at this stage.
Temporarily fix the Underframe into
the correct posi�on using double sided
tape. Push firmly into posi�on and
ensure that the Underframe is firmly
against the wall where the channel will
be fixed to.
DO NOT use the exis�ng tape. This tape
is for final posi�oning of Underframe.
Place the Underframe Gasket into the
Underframe.
Place the Wall Profile over the
Underframe and up against the wall.
3mm minimum
Shower Tray
No Gap
01 02
03 04

10/2021 V 1.1
VIEW 19H
02/13





















Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
05 
07 08

10/2021 V 1.1
VIEW 19H
03/13
Carefully adjust the Glass Panel to the

Ensure there is adequate glass in the












6mm min
Wall ProleGlass Panel
WARNING
The glass is heavy and may
damage the oor or underframe if
handled incorrectly. It is advisable
to use a suitable non-slip
protective mat or piece of carpet.
Never rest the glass across the
underframe as this may cause
damage.
09 10
11 12

10/2021 V 1.1
VIEW 19H
04/13



















(No 8) Prole - Wall
(No 6) Prole - Top Cap






Silicone the
inside corner
13 14
15 

10/2021 V 1.1
VIEW 19H
05/13
To centre the panels, add 1mm Packers
on both sides of the Inline Panel in the
Underframe.
Apply the rigid seal to dry side of the
Wall Profile star�ng from the archway
of the Wall Profile up to the top.
Gently tap the Wall Profile Rigid Seal
into place using a rubber mallet with
the Nylon Block to protect the Glass
and the Wall Profile.
Remove Packers and feed the
Underframe Wedge Gasket into the
archway gap of the Fixed Panel and
trace along the Glass on both sides.
Spray water on Glass Panel and use
Nylon Block to help feed Gasket.
Flush
Rigid Seal
Glass Panel
17 18
19 20

10/2021 V 1.1
VIEW 19H
06/13
Trim both Underframe Gasket Seals as
close to the edge as possible using a
blade.
Trim both of the Wall Profile seals at
the top face of the Wall Profile using a
blade.
Check if your screen has been supplied
with a stay bar. If it has, please read on.
If no Stay Bar supplied, please skip
these steps and move on to step 24.
Config A - SB1 Page 07
No Stay Bar Page 10
21 22
23

X
X - 6.5mm
10/2021 V 1.1
VIEW 19H
07/13
Measure the distance from the inside
face (wet side) of the panel to the wall
opposite. Ensure this measurement is
truly horizontal.
Subtract 6.5mm to get your final
dimension.
Mark the final dimension on the Stay
Bar Tube, wrapped with some masking
tape. Carefully use a fine toothed
junior hacksaw and fine file to cut and
finish the edge.
STAY BAR CONFIGURATION A - SB1
A1 A2

10/2021 V 1.1
VIEW 19H
08/13
Assemble the Glass Clamp to the Stay
Bar as shown.
Secure the Glass Clamp over the panel
making sure the glass is fully inserted
into the groove.
Ensure the Stay Bar is square and level.
Mark the end loca�on on the wall.
Remove the Stay Bar.
STAY BAR CONFIGURATION A - SB1
With masking tape applied, place the
supplied Stay Bar Jig firmly at the
trimmed end of the Stay Bar and mark
the 2 holes with a pen.
Drill holes using a 5mm drill bit.
Drill 1 side only
A3 A4
A5 A6

10/2021 V 1.1
VIEW 19H
09/13








Professional Tip
If drilling ceramic tiles, place
masking tape on the tiles before
marking and drill through the
tape to prevent the drill bit from
skidding.
DO NOT use Hammer Action as
this will break the tiles.
STAY BAR CONFIGURATION A - SB1



A7 A8
A9

10/2021 V 1.1
VIEW 19H
Inside enclosure
21mm
Outside
Inside
10/13
Loosely assemble the Glass to Glass
Hinges to the Main Panel. Evenly






















Cover Plate
 
 
Clamping Plate

10/2021 V 1.1
VIEW 19H
13mm
Outside
Inside
11/13
Notch only the sides of the “U” Seal for












28 29
30 31

10/2021 V 1.1
VIEW 19H
12/13
Using a sharp modelling knife, trim any
excess gasket material from the Hinges
that may have squeezed out when
�ghtening.
Take care not to scratch the glass
surface.
Apply the Wall Profile End Cap to the
top of the Wall Profile and fix in place
using self tapping screws.
Trim
Underframe
Wall Channel
Silicone
Apply silicone sealant along the wall
and floor, all around the outside of the
Underframe and Wall Profiles.
Silicone
32 33
34

10/2021 V 1.1
VIEW 19H
13/13
Check silicone has been applied to all
the below outside areas.
Check silicone has been applied to all
the below inside areas.
Let the silicone sealant cure for 24
hours.
Silicone
Silicone
35 36
