Presence detector
EN
1. Product characteristics
•Passive infrared presence detector for ceiling installation
•Circular detection area 360°, up to Ø 24 m (452 m2)
•Restriction of detection area with cover clips
•Automatic presence- and brightness-dependent control
for lighting
•Mixed light measurement suitable for uorescent (FL/
PL/ESL), halogen/incandescent lamps and LEDs
•Channel A light: relay, 230 V
•Choice of fully or semi-automatic operation
•Brightness switching value congurable, teach-in
function
•Reduction of time delay when present briey (short-term
presence)
•Connection option for push buttons or switches for
manual switching with automatic detection of push
button/switch
•Pulse function for staircase light time switch
•Time delay congurable
•Detection sensitivity congurable
•Ready for immediate use due to factory presetting
•Test mode for checking function and detection area
•Ceiling installation with springs
•User remote control „theSenda S“ (option)
•Management remote control „SendoPro“ (option)
•Installation remote control „theSenda P“ (option)
2. Safety
Make yourself familiar with the presence detector, prior
to installation and start-up.
Read these operating instructions.
•The device is maintenance-free. If the device is opened
or penetrated with any objects the guarantee lapses.
3. Proper use
The presence detector is intended for interior installation. The
presence detector is exclusively intended for the use as con-
tractually agreed between the manufacturer and the user. Any
other use is considered to be unacceptable. The manufacturer
does not accept liability for any resulting damages.
4. Function
The presence detector is primarily used in entrance halls,
garages, warehouses, ofces and schools for easy and
energy-efcient control of lighting. The switch contact „light“
switches lighting on with presence and insufcient bright-
ness, and off with absence or sufcient brightness. The light
can also be switched on/off manually using push buttons or
switches.






Function description
Mixed light measurement
Presence detection
 Articial light
Push button for manual lighting control
Incident daylight


Settings on theRonda P360-100
Brightness switching value (lux)
 Lighting time delay
Mechanical safety lock
Channel A light
Switching response is controlled by presence and brightness.
The switch contact of Channel A light closes during darkness
and when someone is present. It opens with a delay when
there is brightness or when no one is present.
Time delay
The time delay enables delayed switching off of lighting after
the room is vacated. The time delay is adjustable in a range
of 10 s to 60 min. If someone goes into an unoccupied room
only briey and leaves it within 30 seconds, then the light
shuts off prematurely after 2 minutes (short-term presence).
Push button control
The lighting can be manually switched at any time via a
push button or switch. If the light is switched on manually, it

2
will remain on for at least 30 minutes providing people are
present. It then switches off when the brightness is adequate.
The light is forced off after a preset time delay if the room
was (previously) vacated. If articial lighting is switched off
manually. the lighting remains switched off as long as the
room is occupied. The lighting switches again automatically
after the time delay has expired.
Fully or semi-automatic
Lighting control via the presence detector operates fully
automatically for increased comfort or semi-automatically for
greater energy savings. In „fully automatic“ the lights switch
on and off automatically. Light switching has to be completed
manually in „semi-automatic mode“. The lighting is always
switched off automatically.
Pulse function
Time delay can be set to pulse for controlling existing stair-
case light timer switch. To do so, the light output produces
every 10 seconds a pulse of 0.5 seconds duration if people
are present or it is dark.
5. Detection area
The circular detection area of theRonda presence detec-
tor covers a large detection area, and permits a good room
coverage with many applications. Note that seated and
moving persons can be detected in differently-sized areas.
The recommended installation height is 2.0 m – 6.0 m. As
installation height increases, the sensitivity of the presence
detector decreases. Walking motions are necessary from ins-
tallation heights of 3.5 m and the detection areas of several
detectors should overlap in the marginal zones. The detection
range is reduced as the temperature increases.
Seated persons:
The details relate to smallest movements at table height
(approx. 0.80 m).
Moving persons:
At installation heights of between 5 and 10 m, the extent and
distance between the active and passive zones increase.
t
r
t
r
Installation
height (A)
Moving persons
Frontal (r)
Moving persons
Across (t)
Seated persons:
(s)
2,0 m 28 m2Ø 6 m 380 m2Ø 22 m 16 m2Ø 4,5 m
2,5 m 38 m2Ø 7 m 415 m2Ø 23 m 24 m2Ø 5,5 m
3,0 m 50 m2Ø 8 m 452 m2Ø 24 m 28 m2Ø 6 m
3,5 m 50 m2Ø 8 m 452 m2Ø 24 m 38 m2Ø 7 m
4,0 m 50 m2Ø 8 m 452 m2Ø 24 m – –
5,0 m 50 m2Ø 8 m 452 m2Ø 24 m – –
6,0 m 50 m2Ø 8 m 452 m2Ø 24 m – –
10,0 m 50 m2Ø 8 m 491 m2Ø 25 m – –
All gures are guidance values.
Brightness measurement
The presence detector measures articial light and day-
light that is reected directly below the detector. The light
measurement area maps a rectangle of about 2 x 3.5 m at
table height. The installation site is a reference point for the
lighting level. Direct light inuences the light measurement.
Avoid placing oor lamps or suspended lighting directly below
the detector. If the brightness measurement is deactivated,
the Channel A light only switches depending on the presence
(brightness switching value set to „measurement off“ or
potentiometer brightness switching value set to „on“ via the
remote control).
Innen 2 m Fenster
Suitable lamps
The presence detector is designed for the operation of uore-
scent, compact uorescent, halogen and incandescent lamps
as well as LEDs. The maximum number of switchable lights is
restricted due to the high inrush current levels of the EBs and
LED drivers. The use of an external contactor helps with large
loads. All switched loads must be properly suppressed
6. Installation
Ceiling installation
The installation diameter is 72 mm (drill diameter 73 mm).

3
Connection
•Power supply plug (a)
•Plug for lamp (b)
b
GST
L‘
N
a
WINSTA
N
L
a
GST
N
L
b
WINSTA
L‘
N
7. Switching
The presence detectors can be operated as a master in indivi-
dual switching.
Several push buttons can connected to one control input.
Illuminated push buttons can only be used with neutral con-
ductor connection.
Individual switching
In individual switching, the presence detector as master
detects presence and brightness and controls lighting.
L’
a
b
CAUTION
Push button input S is not led to the plugs. If a push button is
required, please wire separately.
8. Settings
The presence detectors were supplied with basic settings
ready for operation. The reference values for the basic
settings are optimised for typical applications. The „Sendo-
Pro 868-A“ and „theSenda P“ remote controls are optionally
available for start-up. They enable remote adjustment of all
required settings.
Settings Channel A light
Potentiometer brightness switching value „Lux“
The required brightness switching value can be set via the lux
potentiometer. The setting range is around 30 to 1000 lux.
The factory presetting is ca. 300 lux.
Brightness switching values from 30 to 3000 lux can be set
via the management remote control „SendoPro 868-A“.
Teach-in: When the LUX potentiometer is moved to the
teach-in position, the LED starts ashing for 20 seconds. As
soon as the LED stops ashing, the measured brightness
value is accepted as the new brightness switching value.
When the teach-in position is exited, the set value on the LUX
potentiometer is accepted as the new brightness switching
value.
Teach-in can also be carried out using the „SendoPro 868-A“
and „theSenda P“ remote controls. In this case, the currently
measured brightness value is immediately accepted as the
brightness switching value.
The brightness measurement is deactivated at potentiometer
setting „on“. The channel light then switches only depending
on presence.
Potentiometer lighting time delay
The following guidance values have proved themselves in
practice and are recommended as settings:
•Transit zones (no work area) approx. 5 min
•Classroom approx. 10 min
•Work areas (ofce, meeting room) approx. 10 min
• „Pulse“: Control staircase light time switch (0.5 s „on“
/ 10 s „off“)
•„test“: Test presence
Parameters via remote control
The following parameters can be queried or changed via
the remote control for support during installation as well as
servicing:
Parameter Description Can be
queried
SendoPro
868-A
Can be
changed
SendoPro
868-A
Can be
changed
theSenda
P
Brightness
switching value
Channel A light
Value range in lux x x x
Measurement off x x

4
Parameter Description Can be
queried
SendoPro
868-A
Can be
changed
SendoPro
868-A
Can be
changed
theSenda
P
Time delay
Channel A light
Value ranges
in seconds /
minutes
x x
Pulse x x
Short presence
Channel A light On / Off x
Conguration
type auto / man x x x
Control input S
Auto / switch /
push button S /
push button O
x
Detection sen-
sitivity (PIR)
Value range in
increments x x
Group address All / I / II / III x
LED display
motion Off / On x
The parameters are sent to the presence detector with the
„SendoPro 868-A“ management remote control or with „the-
Senda P“ installation remote control via infra-red. Changed
parameters are immediately applied and used by the detector.
With the „SendoPro 868-A“ management remote control,
parameters can be queried by sending values level-by-level
to the detector. If the sent values are below the set parame-
ter, the LED illuminates briey. If the sent values are equal or
above the set parameter, the LED ickers for 2 seconds.
Control commands via remote control
Control command Description Can be
triggered
SendoPro
868-A
Can be
triggered
theSenda
P
Teach-in Channel
A light
The currently measured
brightness value is accepted
as the brightness switching
value. Values outside the
permitted range will automati-
cally be set to the appropriate
limit value.
x x
Switch light on/off Lighting group can be swit-
ched on and off. x x
Presence test On / Off x x
Restart Restart detector x x
Factory settings Set all parameters and set-
tings to factory setting. x
Brightness switching value Channel A light
The brightness switching value denes the minimum desired
brightness. The current prevailing brightness is measured
below the presence detector. If the prevailing brightness
is below the switching value, the light switches on when a
presence is detected (in conguration type fully automatic
device).
Value range
Lux values with "SendoPro 868-A" management remote
control
The "theSenda P" installation remote control offers the
following values
(The currently measured brightness value (lux) can
be adopted with the "SendoPro 868-A" management
remote control, with the teach-in control command or
with the "theSenda P" installation remote control via the
teach-in button.)
Values outside the permitted range will automatically be
set to the appropriate limit value.
30 - 3000 lux
300, 500,
800 lux
- Deactivating the brightness measurement (the bright-
ness has no inuence)
- The light channels only switch after presence/absence.
Possible with "SendoPro 868-A" management remote
control or "theSenda P" installation remote control.
Measurement
off
Button
Time delay Channel A light
Value range
Adjustable values with "SendoPro 868-A" manage-
ment remote control
In the "theSenda P" installation remote control, the
following values are available
10 s - 60 min
10 s, 30 s, 60 s, 2
min, 10 min, 20 min,
60 min
Control for staircase light timer switch (0.5 s "on"
/ 10 s "off")
"SendoPro 868-A"
"theSenda P"
Pulse
Button 1
Short-term presence
The time delay of Channel A light can be switched off sooner
if a room is occupied only for a short time. (In fully automatic
and semi-automatic function modes)
The time delay is used according to set parameter. Off
If someone enters an unoccupied room and it is only occupied for
up to 30 seconds, the light goes off 2 minutes early.
On
Conguration type
Fully automatic device: The lighting switches on and off automati-
cally. (due to presence/no presence and brightness)
auto
Semi-automatic: Switch on must always occur manually. Switch off
occurs automatically by the presence detector. (due to presence or
brightness)
man
Control input S
Control input S for manual switch on/off of Channel A light
automatically detects push buttons or switches.
Several push buttons can be connected to control input S
Use light push button only with neutral conductor connector

5
Value range
Automatic detection of push button or switch. A signal that
is present for less than 0.7 s is detected as a push button.
Longer signals are evaluated as a switch.
auto
To adapt to user behaviour, the type
of signal transmitter used can be
set to xed. Automatic detection is
deactivated.
When selecting the push button,
opening contact or NO contact can
also be specied.
Switch
Push button (NO
contact)
Push button (opening
contact)
Switch
Push button
S
Push button
O
Adjustment possible only with „SendoPro 868-A“.
Detection sensitivity
The detector has 5 sensitivity increments. The basic setting is
the middle increment (3).
By selecting the test presence operation mode, the set sensi-
tivity increment is not changed.
With the „SendoPro 868-A“ management remote control,
levels 1 to 5 can be selected and sent to the detector.
With the „theSenda P“ installation remote control, the sen-
sitivity can be reduced or increased by one level with every
button press.
Increment Sensitivity
1 very insensitive
2 insensitive
3 standard
4 sensitive
5 very sensitive
Group address Channel A light
This parameter is applied when using the „theSenda P“ user
remote control.
A group address can be assigned to the Channel A light.
The „SendoPro 868-A“ or „theSenda S“ can be used to pro-
gram the group addresses in the detector.
Group address value range
Adjustable values "SendoPro 868-A" I, II , III , All
Adjustable values "theSenda S" I, II
LED display motion
The motion detection can be displayed via the LED.
Value range
No display of motion detection. Off
The LED is switched on when motion is detected, otherwise
switched off.
On
Adjustment possible only with „SendoPro 868-A“.
Factory settings
The theRonda P360-100 presence detector is supplied with
the following parameter values:
Parameter Value
Brightness switching value Channel A light ca. 300 lux
Time delay Channel A light 10 min
Short presence Channel A light On
Conguration type auto
Control input S auto
Detection sensitivity (PIR) Increment 3
Group address T
LED display motion Off
9. Start-up
Switching behaviour
Every time the power supply is switched on, the motion
detector rst runs through a start-up phase of 30 s, and then
switches to normal operation. An LED displays the current
status:
1. Start-up phase (30 s)
•The red LED ashes at one second intervals, the switch
contact is closed (light on). The wiring is therefore also
checked automatically.
•The detector does not react to some remote control
commands.
•When no one is present, the switch contact opens after
30 seconds.
2. Operation
The detector is ready for operation (LED off).
Test presence
The test presence operation is used for checking the detec-
tion area and the wiring. The test presence operation can be
activated with the „SendoPro 868-A“ management remote
control and with the „theSenda P“ installation remote control
or via the lighting time delay potentiometer.
Setting test presence operation with the remote control
•The detector goes directly into test operation when the
test operation is set via the remote control:
--Every movement is indicated by the LED.
-- The light switch contact closes upon motion.
-- When no one is present the light switch contact opens after
10 seconds.
-- Brightness measurement deactivates, detector does not react
to brightness.
--The detector reacts as in fully automatic conguration type
even if semi-automatic is set.
-- Teach-in cannot be activated in test operation.
•Test operation ends automatically after 10 min. The
detector performs a new start (see switch-on behaviour).

6
10. Technical data
Operating voltage 110-230 V AC + 10 % / - 15%
Frequency 50-60 Hz
Upstream protection device: 13 A
Power consumption approx. 0.1 W
Type of installation Ceiling installation
Installation height 2,0 – 6,0 m / max. 10 m
Minimum height > 1.7 m
Detection area horizontal
vertical
360°
150°
Maximum range Ø 8 m (Mh. 3 m) / 50 m2radially
moving
Ø 24 m (Mh. 3 m) / 452 m2tan-
gentially moving
Light measurement approx. 10 – 3000 Lux
Setting range brightness switching
value
30 – 3000 lux
Lighting time delay 10 s – 60 min / Pulse
Channel A light Relay 230 V / 10 A, µ-contact
Max. switching capacity cos ϕ1
resistive 2300 W
Max. switching capacity cos ϕ0.5 1150 VA
Max. switching capacity LED
Guide values
see manufacturer concerning cos ϕ
< 2 W : 60 W / > 2 W : 180 W
Guidance value max. inrush current
level
800 A / 200 µs
Maximum number EBs T5/T8 16 x 54/58 W, 24 x 35/36 W
8 x 2 x 54/58 W
12 x 2 x 35/36 W
Connection type Terminal screws
Max. cable cross-section max. 2 x 2.5 mm²
Flush-mounted box size Size 1, Ø 55 mm (NIS, PMI)
Protection rating IP 54 (installed)
Ambient temperature -15 °C – 50 °C
CE Declaration of Conformity This device conforms to the safety
regulations of the EMC direc-
tive 2014/30/EU and of NSR
2014/35/EU.
Product overview
Type of
installation
Channel Operating
voltage
Colour Type Item
number
Ceiling
installation
Light 110-
230 V AC
White theRonda
P360 -100
GST
2080010
Ceiling
installation
Light 110-
230 V AC
White theRonda
P360 -100
WINSTA
2080015
Troubleshooting
Fault Potential cause
Light does not switch on
and/or off if presence is
detected and in darkness
Lux value is set too low; detector set on semi-
automatic; light was switched off manually via
push button or theSenda S; person not within
detection range; obstruction(s) interrupting
detection; time delay set too short
Light stays on with detec-
tion of presence despite
sufcient brightness
Lux value is set too high; light was briey
switched on manually via push button or with
theSenda S (wait 30 min.); detector is in test
mode
Light does not switch off
and/or light switches on
spontaneously when no
one is present
Wait for time delay (self-learning);
thermal sources of interference in the detection
area: fan heaters, incandescent lamps/halo-
gen spotlights, moving objects (e.g. curtains
hanging in an open windows);
Load (EBs, relays) not cleared
Push button does not
function
Device still in the start-up phase; illumina-
ted push button was used without neutral
conductor;
Push button is not connected.
Light cannot be switched
off with the push button
Push button not fed to the detector. Check
wiring to the push button.
Error ashing
(4 x per second)
Error in self-test;
Device not properly functional!
LED display
LED Description
Flashing at one
second intervals
The presence detector is in the start-up phase.
Flickering for 2 s The command sent from the remote control via infra-
red was accepted by the presence detector.
Lights up briey The command sent from the remote control via
infrared was rejected by the presence detector. The
command is not valid. Check the detector type or para-
meter selected in the SendoPro.
Fast ashing Error ashing; The presence detector has found an
error.
Flickering for
20 s
Teach-in via potentiometer is activated.
Lights or ickers
irregularly
The presence detector is in presence test operation or
"LED display movement" is activated. The LED displays
detection of movement.
Guarantee
ThebenHTS presence detectors are manufactured with the
utmost care and using state-of-the-art technology and are
quality-tested. Theben HTS AG therefore guarantees perfect
operation when used correctly. Should a fault occur, Theben
HTS AG will full the guarantee within the scope of the gene-
ral terms and conditions.
Please note in particular:
•that the guarantee period lasts 24 months from the date
of manufacture.
•that the guarantee is invalidated if you, or a third party,
make changes or undertake repairs to the devices.
•that, insofar as the presence detectors are connected
to a software-controlled system, the guarantee for this
connection is only valid when the indicated interface
specication is complied with.
We undertake to repair or place as quickly as possible all
components of the delivered device that have become
defective or unusable through demonstrably poor material,
faulty construction or incomplete delivery up to the end of the
guarantee period.
Returns
In the event of a guarantee claim, please return the device to
the relevant dealer together with the delivery note and a brief
description of the fault.
Industrial property rights
The design as well as hardware and software of these devices
are protected by copyright.

7
Dimensional diagrams
11. Accessories
Covering clip for area restriction
Item No. 9070921
Details> www.theben.de/www.theben-hts.ch
SendoPro 868-A
Item No. 9070675
Details> www.theben.de/www.theben-hts.ch
theSenda S
Item No. 9070911
Details> www.theben.de/www.theben-hts.ch
theSenda P
Item No. 9070910
Details> www.theben.de/www.theben-hts.ch
12. Contact
Switzerland
ThebenHTS AG
Im Langhag 7b
8307 Effretikon
SWITZERLAND
Phone [phone]
Fax [phone]
Hotline
Phone [phone]
[email protected]
www.theben-hts.ch
All countries except Switzerland
Theben AG
Hohenbergstraße 32
72401 Haigerloch
GERMANY
Phone: [phone]
Fax: [phone]
Hotline
Phone: [phone]
[email protected]
www.theben.de
