Theben thePiccola P360-100 DE User manual

1
thePiccola P360-100 DE WH
2090200
307146 03
Presence detector
EN
1. Basic safety information
Danger of death through electric shock or fire!
 Installation should only be carried out by a
qualied electrician!
WARNING
•The device conforms with EN 60669-2-1 if correctly
installed
2. Proper use
•Presence detector for automatic lighting control depen-
dent on presence and brightness
•Suitable for ceiling installation (false ceilings)
•Suitable for small rooms, corridors, toilets, etc.
Disposal
Dispose of the device in an environmentally sound manner
(electronic waste)
3. Device description
Sensor unit
red LED
Power supply unit
2 potentiometers for setting
the time delay (TIME) and
the brightness switching
value (LUX)
4. Installation and connection
Installing the presence detector
LInstallation height: 2–4 m
LCable length: 45 cm
LPresence detector requires clear line of sight to people
Disconnect power source
Create a ceiling opening of Ø 34–36 mm
Connect power supply unit according to the wiring diagram
Make settings at the potentiometers
Push the power supply unit through the ceiling opening
and attach the sensor with tensioned springs in the ceiling
Ø 34-36 mm
6–8 mm
max. 1 x 2,5 mm2
Connecting the presence detector
Danger of death through electric shock or fire!
 Installation should only be carried out by a
qualied electrician!
WARNING
Disconnect power source
Ensure device cannot be switched on
Check absence of voltage
Earth and bypass
Cover or shield any adjacent live components
The warm-up phase takes approx. 1 min. The LED is perma-
nently red.

2
Individual switching
In individual switching, the presence detector as master
detects presence and brightness and controls lighting.
L’
Parallel switching /Master-Slave
If the detection area covered by a single presence detector
is insufcient (in larger rooms), then several detectors can
be operated in parallel by connecting the S and L‘ terminals.
Presence detection is performed by all detectors together. The
master measures the brightness and controls the lighting. The
other detectors (slaves) only provide presence information via
the L‘ terminal.
At the slave devices set the potentiometer for time delay
(TIME) to 30 s and for switching value (LUX) to or deac-
tive the brightness measurement with remote control, press
button .
LIf the operating voltage remains at the S terminal < 1 sec.,
the master interprets this as a key signal. Operating vol-
tage > 2 sec. is interpreted as a slave signal and executed
correspondingly. For this reason the light does not switch
on until 2 sec. after a movement has been detected by the
slave device.
L’ L’
SlaveMaster
Push button control
The lighting can be manually switched on/off via a button. If
the light is switched on manually, it will remain on as long as
people are present (plus time delay). Then the light goes into
the set automatic mode. If the light is switched off manually,
it will remain off as long as people are present (plus time
delay). Then the light goes back to automatic mode.
Fully or semi-automatic device
Lighting control via the presence detector operates fully
automatically for increased comfort or semi-automatically
for greater energy savings. The lighting switches on and off
automatically as „fully automatic device“. In „Semi automatic“
mode, it must be switched on manually and switches off
automatically. Settings are entered via remote control.
Switching behaviour
Every time the power supply is switched on, the presence
detector runs through two phases that are shown on an LED
and the connected lighting:
1. Warm-up phase (1 min)
•The red LED ashes at one second intervals, the switch
contact is closed (light on).
•The detector does not react to push button commands
and remote control commands.
2. Operation
•The detector is ready for operation (LED off), and when
no one is present, the light switch contact opens (light
off).
Installation instructions and detection area
As the detector reacts to variations in temperature, avoid the
following situations:
Do not point the presence detector at objects with highly-
reective surfaces such as mirrors, etc.
Do not install the presence detector near heat sources such
as heating vents, air conditioners, lamps, etc.
Do not point the presence detector at objects that move in
the wind such as curtains, large plants, etc.
Pay attention to the direction of motion during the test run.
2,5 m
360°
Ø 2 m
Ø 8 m
Lrecommended installation height: 2 – 4 m
LTransverse detection area: 8 m (transversal to the detector)
LFrontal detection area: 2 m (directly approaching the detector)
LDetection area sitting: 2 m
LDetection angle: 360°
5. Walking test
The walking test is used to test the detection area.
Set the time delay potentiometer (TIME) to T (Test). The
presence detector only reacts to movements, brightness
measurement is switched off.
Walk through the detection area. Every detected movement
is indicated by the LED, and the light switch contact closes.
When no one is present the light switch contact opens after
3 seconds.
LIf the walking test is carried out using the slave device, the
walking test must also be activated on the master device.

3
LThe walking test can also be activated with theSenda P
and SendoPro 868-A remote controls, see chapter 7.
3 sec
6. Setting
The presence detector has 2 potentiometers for setting time
delay (TIME) and brightness switching value (LUX).
Setting the brightness switching value (LUX)
You can set different brightness values with the potentiome-
ter for the brightness switching value (LUX).
If you want to change the preset brightness
Set the potentiometer to the desired brightness
(5 – 1000 lux = ).
or want a specic brightness value to be learned using the
teach-in function
At the desired brightness, set the potentiometer to . The
LED ashes for 20 s, afterwards the measured brightness
value is accepted as the new brightness switching value.
Leave the potentiometer at position .
Brightness measurement
The presence detector measures the surrounding brightness
below the detector. The installation location is the reference
point for the lighting level. If the brightness measurement is
deactivated by using the remote control, the switch contact
light only switches depending on presence (with SendoPro
868-A: brightness switching value set to «measurement off»
via the remote control; with theSenda P: button „Lux On“
activated).
LThe brightness measurement value is inuenced by the
installation location, incidence of light, position of the
sun, weather conditions, the reection properties of the
room, and the furniture. Therefore, the lux values are guide
values.
Setting the time delay (TIME)
If the presence detector detects no further movement, it swit-
ches off after the set time delay.
If you want to change the preset time
Set the potentiometer to the desired time (30 s – 30 min).
If you want to use the pulse function (e.g. for a staircase light
timer switch)
Set the potentiometer to . Presence detector for „stair-
case light timer switch“ operation is on for 0.5 s and off for
10 s
7. Settings with remote control
You can also make the settings with remote controls the-
Senda S, theSenda P, and Sendo Pro 868-A.
30
1
6
5
8
9
10
11
12
13
14
15
23
22
21
20
19
18
17
16
26
27
25
2
3
2
Off On
LIf the command sent from the presence detector is accep-
ted, the red LED ashes briey twice. If the command is
rejected, the red LED ashes briey once.

4
Settings by using theSenda S
theSenda S can only be used to switch the presence detector
on or off ( 3and 2).
Settings by using theSenda P
Setting the teach-in function
At the desired brightness, press the button (25 ). The
measured brightness value will be accepted as the new
brightness switching value.
Setting the test function
Press the 1button. The presence detector directly goes
into the test function (see walking test). The test function
ends after 10 min.
Setting fully or semi-automatic device function
Fully automatic: The lighting switches automatically on and
off (neither on the basis of presence/absence nor on the
basis of brightness).
Press button 5.
Semi automatic: The lighting must always be switched on
manually. Lights are automatically switched off by the pre-
sence detector (due to absence or brightness).
Press button 27 .
New start of detector
Press button 30 .
The detector performs a new start (see switch-on behaviour).
The brightness switching value (LUX) and time delay (TIME)
are reset to the preset values on both potentiometers.
Back to automatic mode
Press button 2.
The detector ends the walking test or manual override with
the pressing of a button and goes into normal operation
mode.
The following parameters or functions functions can be set
with theSenda P:
1Test Test mode, ends after 10 min
2Auto Back to automatic mode
5A Operation as fully automatic device
6On Switch on light
815 lux Brightness setpoint value 15 lux
910 lux Brightness setpoint value 10 lux
10 Lux On Deactivation of
Brightness measurement
11 800 lux Brightness setpoint value 800 lux
12 60 s Lighting time delay 60 s
13 30 s Lighting time delay 30 s
14 max. Time max. lighting time delay, 30 min
15 20 min Lighting time delay 20 min
16 10 min Lighting time delay 10 min
17 2 min Lighting time delay 2 min
18 min. Time min. lighting time delay, 10 s
19 Pulse 1 s Pulse function
20 500 lux Brightness setpoint value 500 lux
21 300 lux Brightness setpoint value 300 lux
22 5 lux Brightness setpoint value 5 lux
23 min. lux min. brightness setpoint value, 1 lux
25 Teach-in Teach in of the brightness setpoint value
26 Off Switch off lighting
27 Manuell Semi-automatic operation
30 Reset Restart of the detector
Settings with Sendo Pro 868-A
Parameters
•Brightness switching value: 5 – 1000 lux; measurement
off (deactivation of the brightness measurement)
•Time delay: 30 s – 30 min; pulse (control of staircase
light timer switch)
•Conguration type: auto (fully automatic device); man
(semi-automatic)
Control commands
•Teach-in (teach in brightness value)
•Switching light (on/off light)
•Presence test (walking test)
•Restart (restart of the detector)
See also operating manual for Sendo Pro 868-A.
8. Technical data
Operating voltage 110–240 V AC +10 % /–15 %
Frequency 50-60 Hz
Upstream protection device 10 A
Standby output < 0.5 W
Switching capacity max. 10 A (at 240 V AC, cos ϕ= 1)
Switching capacity min. 100 mA/24 V AC/DC
Protection rating IP 21 (sensor unit), IP 20 (power
supply unit) in accordance with
EN 60529
Protection class II
Operating temperature –20 °C … +50 °C
Brightness setting range 5 – 1000 lx
Duty cycle range 30 s – 30 min
Detection angle 360°
Detection area transversal: min. 8 m (+/– 1 m);
frontal: min. 2 m (+/– 1 m)
Installation height 2 – 4 m
Max. cable length 50 m
Contact μ contact 240 V AC (NO contact)
Incandescent lamp load 2000 W
Halogen lamp load 2000 W
Fluorescent lamps (LLB low-loss
ballasts):
uncompensated
series compensated
parallel compensated
2000 VA
2000 VA
1300 W (140 µF)
Fluorescent lamps (EB – Electronic
Ballasts)
1200 W
Compact uorescent lamps (EB) 300 W

5
LED lamps (< 2 W) 55 W
LED lamps (2 W – 8 W) 180 W
LED lamps (> 8 W) 200 W
9. Contact
Theben AG
Hohenbergstr. 32
72401 Haigerloch
GERMANY
Phone [phone]
Fax [phone]
Hotline
Phone [phone]
[email protected]
Addresses, telephone numbers, etc.
www.theben.de
