Thermo Scientific 3767A User manual

Installation and Operation Manual
Thermo Scientific
General Purpose and Flammable Storage
Laboratory Refrigerators and Freezers

©2010 Thermo Fisher Scientific. All rights reserved.
“Suva®” is a registered trademark of DuPont.
All other trademarks are the property of Thermo Fisher Scientific Inc. and
its subsidiaries.

General Purpose and
Flammable Materials Storage
Refrigerators and Freezers
Cool- ab General Purpose:
3767A, 3767-1A, 3766A, 3766-1A
Flammable Material Storage:
3552-10A, 3552-11A, 3552-11ACN,
3566-10A, 3566-11A, 3566-11ACN
3560-10A, 3560-11A
107774 Rev. A

Table of Contents
Safety Information ..............................................................................................................................................3
Alert Signals..................................................................................................................................................3
Unpacking ..........................................................................................................................................................4
Visible oss or Damage................................................................................................................................4
Concealed oss or Damage ........................................................................................................................4
Performance Characteristics ..............................................................................................................................5
Temperature Ranges ....................................................................................................................................5
Temperature Stability ....................................................................................................................................5
Electrical Requirements................................................................................................................................5
Installation ..........................................................................................................................................................6
Selecting a ocation ....................................................................................................................................6
eveling the Unit ..........................................................................................................................................6
Shelves ........................................................................................................................................................6
Electrical Connection ....................................................................................................................................6
Operation ............................................................................................................................................................8
Initial Startup ................................................................................................................................................8
Temperature Control ....................................................................................................................................8
Condensate Disposal....................................................................................................................................8
Material Compatibility ..................................................................................................................................8
Troubleshooting ................................................................................................................................................10
Maintenance ......................................................................................................................................................11
Cabinet Cleaning ........................................................................................................................................11
Condenser ..................................................................................................................................................11
Warranty ............................................................................................................................................................12

3
Your satisfaction and safety are important to us and a
complete understanding of this unit is necessary to attain
these objectives.
As the ultimate user of this apparatus, it is your responsi-
bility to understand its proper function and operational
characteristics. This instruction manual should be thor-
oughly read and all operators given adequate training
before attempting to place this unit in service. Awareness
of the stated cautions and warnings, and compliance with
recommended operating parameters – together with
maintenance requirements – are important for safe and
satisfactory operation. The unit should be used for its
intended application; alterations or modifications will void
the warranty.
This product is not intended, nor can it be used, as a ster-
ile or patient connected device. In addition, this appara-
tus is not designed for use in Class I, II or III locations as
defined by the National Electrical Code, unless otherwise
noted.
Safety Information
Warn ng
Warnings alert you to a possibility of
personal injury.
Caut on
Cautions alert you to a possibility of
damage to the equipment.
Note
Notes alert you to pertinent facts and
conditions.
Hot Surface
Hot surfaces alert you to a possibility
of personal injury if you come in con-
tact with a surface during use or for a
period of time after use.
Alert Signals
Warn ng
As a routine laboratory precaution,
always wear safety glasses when
working with this apparatus.
DANGER: RISK OF CHI D ENTRAP-
MENT. BEFORE YOU THROW AWAY
YOUR O D REFRIGERATOR OR
FREEZER:
• TAKE OFF DOORS
• EAVE THE SHE VES IN THE
P ACE SO THAT CHI DREN
MAY NOT EASI Y C IMB
INSIDE.

4
Unpacking
Save all packing material if apparatus is received dam-
aged. This merchandise was carefully packed and thor-
oughly inspected before leaving our factory.
Responsibility for its safe delivery was assumed by the
carrier upon acceptance of the shipment; therefore,
claims for loss or damage sustained in transit must be
made upon the carrier by the recipient as follows:
Visible oss or Damage
Note any external evidence of loss or damage on the
freight bill, or express receipt, and have it signed by the
carrierʼs agent. Failure to adequately describe such
external evidence of loss or damage may result in the
carrierʼs refusing to honor your damage claim. The form
required to file such a claim will be supplied by the carrier.
Concealed oss or Damage
Concealed loss or damage refers to loss or damage,
which does not become apparent until the merchandise
has been unpacked and inspected. Should either occur,
make a written request for the carrierʼs agent within 15
days of the delivery date; then file a claim with the carrier
since the damage is the carrierʼs responsibility.
If you follow the above instructions carefully, we will
guarantee our full support of your claim to be compensat-
ed for loss from concealed damage.
DO NOT – FOR ANY REASON – RETURN THIS UNIT
WITHOUT FIRST OBTAINING AUTHORIZATION

Temperature Ranges
Refrigerator: 3° to 13°C (37° to 55°F)
Freezer: -20° to -10°C (-4° to 14°F)
Temperature Stability
@ 4 °C ±4 °C
@ -20 °C ±4 °C
Electrical Requirements
See dataplate attached to unit.
5
Performance Characteristics

6
Selecting a ocation
Choose a location for the refrigerator that will provide at
least four inches of clearance between the cabinet and
any adjacent vertical surface at the sides and four inches
at the rear. Twelve inches of clearance is required above
the top surface of the refrigerated cabinet. Appropriate
electrical power must be available. ocate the refrigerator
within eight feet of the power outlet so that no extension
cord is required.
eveling the Unit
The refrigerator must be level in order to provide ade-
quate condensate drainage as well as proper door align-
ment and operation. The refrigerator should be in its final
operating location and set so that it is firmly positioned on
the floor.
After discarding crating screws and wood base, level the
freezer side-to-side and front to back by adjusting the
supplied leveling feet. The leveling feet can be adjusted
so the front of the unite is slightly higher than the rear –
this will allow the door to close easily if it is left halfway
open.
Shelves
Shipped inside each cabinet are four fixed shelves which
also serve as part of the evaporator coil on freezer mod-
els.
Electrical Connection
Determine the total amount of current presently being
used by other apparatus connected to the circuit that will
be used by this refrigerator. It is critical that this added
current demand and other equipment on this circuit not
exceed the rating of the fuse or circuit breaker in use.
The frequency and nominal voltage requirements for the
unit are specified on the data plate, which is located on
the interiors upper left side. Only plug the unit into a
power source that meets these requirements. ow line
Installation
Caut on
Be sure that the power supply is
the same voltage that is specified
on the refrigeratorʼs data plate.

voltage is often the cause of service complaints. With the
unit running, check that the line voltage is within ±10% of
that specified on the data plate.
The power cord on this product is equipped with a three-
prong (grounding) plug appropriate for the voltage, cur-
rent, and location for which it was designed. The plug will
mate with a standard grounding outlet of the correspon-
ding configuration to minimize the potential of an electrical
shock hazard. It is the customerʼs responsibility to have
the wall receptacle and supply circuit checked by a quali-
fied electrician to verify that they are appropriate for the
power requirements of the product, that they match the
supplied plug, and that they are properly grounded and
have over-current protection.
WARNING: DO NOT under any circumstances cut or
remove the third (ground) prong from the power cord. DO
NOT use a two-prong adapter plug. Where a two-prong
wall receptacle is encountered, it is the personal responsi-
bility and obligation of the user to have it replaced with a
properly grounded three-prong receptacle.
7
INSTALLATION
Warn ng
For personal safety this unit must be
properly grounded.
Caut on
Do not use an extension cord. Use
of an ungrounded cord or an over-
loaded circuit VOIDS the compres-
sor warranty.

Initial Startup
Turn power on and verify that the condenser fan is run-
ning. This model has a condenser fan located on the con-
densing unit on top of the cabinet.
Temperature Control
To adjust the interior temperature down, simply turn the
thermostat knob clockwise. For operation above an alti-
tude of 3000 ft., have the thermostat adjusted by a techni-
cian.
Condensate Disposal
The condensate drain is at the center rear of the interior
floor. The condensate drain tube is connected to this
drain and is attached to the left front bottom of the unit
behind the front sheet metal. Unhook and place the drain
tube into a suitable pan and remove the drain plug. Turn
the power to the unit to the off position (O) and allow the
unit to defrost. NOTE: Model 3766A and 3766-1A are
frost-free un ts.
Material Compatibility
The interior cabinet of this unit is constructed of epoxy-
coated steel. Care must be exercised when determining
which chemicals may be stored in the refrigerator and
freezer sections and which type of storage materials
should be employed.
ABS Plastic deteriorates when exposed to, but not limited
to, the following:
Aliphatic Hydrocarbons; Aromatic Hydrocarbons; Fully
and Partially Halogenated Hydrocarbons; Alcohols
Monohydric; Phenols; Ketones; Esters; Ethers; Organic
Acids (concentrates and dilute); and Concentrated
Oxidizing Acids. This information is taken from Plastics
Edition 8 Thermoplastics and Thermosets published by
D.A.T.A. and The International Plastics Selector, Inc.
Cordura Companies
9889 Willow Creek Road
P.O. Box 26637
San Diego, California 92126
8
Operation
Warn ng
Do not heat any substance above a
temperature which will cause it to emit
toxic fumes—death or severe injury
may result.
Warn ng
If the unit is tilted in excess of 30
degrees, do not apply electrical power
for a minimum of 12 hours.

Aluminum Alloys are susceptible to corrosion when
exposed to but not limited to most inorganic acids, bases
and salts with a pH outside of their passive range of pH 4
to 9. It is also important to recognize that the compatibili-
ty of aluminum alloys with mixtures of organic compounds
cannot always be predicted from their compatibility with
each of the compounds. For example, some aluminum
alloys are corroded severely in mixtures of carbon tetra-
chloride and methyl alcohol, even though they are resist-
ant to each compound alone. This information is taken
from Corrosion and Corrosion Protection Handbook
Second Edition
Published by
Marcel Dekker, Inc.
270 Madison Ave.
New York, NY 10016
9
OPERATION

This table is intended to assist in resolving user-correctable refrigerator problems by relating symptoms to
their likely causes. If service beyond the scope of this table is required, contact Customer Service at
1-800-438-4851.
10
Troubleshooting
Symptom Probable Cause Act on
Does Not Run Unit Unplugged Plug in Unit
Blown fuse or tripped circuit Check fuse or circuit breaker at
breaker breaker box
Runs Continuously Frost buildup on refrigeration coils Defrost unit
Clicking Sound The compressor is equipped Unplug unit for 1 hr. Plug in and try
with a thermal protector. running again. If the unit doesnʼt
This device shuts off the begin to run, call for service.
compressor when it
becomes too hot. A clicking
sound occurring about
every 30 seconds indicates
this protector is working
Insufficient Cooling Thermostat set too high Reduce thermostat setting
Unit frosted Defrost unit

Cabinet Cleaning
The cabinet interior should be cleaned frequently. Any
spilled liquid should be wiped off immediately. Stains
resulting from some spills can be permanent if not quickly
removed. The most convenient time to clean the interior
is after defrosting. The cabinet exterior should be cleaned
occasionally. A mild detergent and lukewarm water or a
solution of bicarbonate of soda (1 tablespoon per gallon
of water) is recommended for cleaning the interior and
exterior of the cabinet. All surfaces should be rinsed and
thoroughly dried.
Condenser
The condenser coil is located behind the sides and rear
exterior panel. These surfaces may be warm to the touch.
This is necessary to the operation of the refrigeration
equipment and is normal.
11
Maintenance
Caut on
Do not use any type of abrasive
such as steel wool, or fluids such
as gasoline, Naphtha, and thinner.
These materials could be harmful to
aluminum, plastic materials, door
gasket, and painted surfaces.
Warn ng
When servicing the unit, disconnect
from the electrical power source.

One Year imited Warranty
This Thermo Scientific product is warranted to be free of defects in materials and workmanship for one (1)
year from the first to occur of (i) the date the product is sold by the manufacturer or (ii) the date the product is
purchased by the original retail customer (the “Commencement Date”). Except as expressly stated above, the
MANUFACTURER MAKES NO OTHER WARRANTY, EXPRESSED OR IMP IED, WITH RESPECT TO THE
PRODUCTS AND EXPRESS Y DISC AIMS ANY AND A WARRANTIES, INC UDING BUT NOT IMITED
TO, WARRANTIES OF DESIGN, MERCHANT ABI ITY AND FITNESS FOR A PARTICU AR PURPOSE.
An authorized representative of the manufacturer must perform all warranty inspections. In the event of a
defect covered by the warranty, we shall, as our sole obligation and exclusive remedy, provide free replace-
ment parts to remedy the defective product. In addition, for products sold within the continental United States
or Canada, the manufacturer shall provide free labor to repair the products with the replacement parts, but
only for a period of ninety (90) days from the Commencement Date.
The warranty provided hereunder shall be null and void and without further force or effect if there is any (i)
repair made to the product by a party other than the manufacturer or its duly authorized service representa-
tive, (ii) misuse (including use inconsistent with written operating instructions for the product), mishandling,
contamination, overheating, modification or alteration of the product by any customer or third party or (iii) use
of replacement parts that are obtained from a party who is not an authorized dealer of Thermo Scientific prod-
ucts.
Heating elements, because of their susceptibility to overheating and contamination, must be returned to the
factory and if, upon inspection, it is concluded that failure is due to factors other than excessive high tempera-
ture or contamination, the manufacturer will provide warranty replacement. As a condition to the return of any
product, or any constituent part thereof, to the factory, it shall be sent prepaid and a prior written authorization
from the manufacturer assigning a Return Materials Number to the product or part shall be obtained.
IN NO EVENT SHA THE MANUFACTURER BE IAB E TO ANY PARTY FOR ANY DIRECT, INDIRECT,
SPECIA , INCIDENTA , OR CONSEQUENTIA DAMAGES, OR FOR ANY DAMAGES RESU TING FROM
OSS OF USE OR PROFITS, ANTICIPATED OR OTHERWISE, ARISING OUT OF OR IN CONNECTION
WITH THE SA E, USE OR PERFORMANCE OF ANY PRODUCTS, WHETHER SUCH C AIM IS BASED ON
CONTRACT, TORT (INC UDING NEG IGENCE), ANY THEORY OF STRICT IABI ITY OR REGU ATORY
ACTION.
For the name of the authorized Thermo Scientific product dealer nearest you or any additional information, contact us
www.thermofisher.com
1-866-9-THERMO

WEEE Compliance
WEEE Compliance. This product is required to comply with the European
Union’s Waste Electrical & Electronic Equipment (WEEE) Directive 2002/96EC.
It is marked with the following symbol. Thermo Fisher Scientific has contracted
with one or more recycling/disposal companies in each EU Member State, and this
product should be disposed of or recycled through them. Further information on
Thermo Fisher Scientific compliance with these Directives, the recyclers in your
country, and information on Thermo Scientific products which may assist the
detection of substances subject to the RoHS Directive are available at
www.thermo.com/
WEEE Konformittät. Dieses Produkt muss die EU Waste Electrical & Electronic
Equipment (WEEE) Richtlinie 2002/96EC erfüllen. Das Produkt ist durch
folgendes Symbol gekennzeichnet. Thermo Fisher Scientific hat Vereinbarungen
getroffen mit Verwertungs/Entsorgungsanlagen in allen EU-Mitgliederstaaten und
dieses Produkt muss durch diese Firmen widerverwetet oder entsorgt werden.
Mehr Informationen über die Einhaltung dieser Anweisungen durch Thermo
Fisher Scientific, die Verwerter und Hinweise die Ihnen nützlich sein können, die
Thermo Scientific Produkte zu identifizieren, die unter diese RoHS.
Anweisungfallen, finden Sie unter www.thermo.com/
Conformità WEEE. Questo prodotto deve rispondere alla direttiva dell’ Unione
Europea 2002/96EC in merito ai Rifiuti degli Apparecchi Elettrici ed Elettronici
(WEEE). È marcato col seguente simbolo.Thermo Fisher Scientific ha stipulato
contratti con una o diverse società di riciclaggio/smaltimento in ognuno degli Stati
Membri Europei. Questo prodotto verrà smaltito o riciclato tramite queste
medesime. Ulteriori informazioni sulla conformità di Thermo Fisher Scientific con
queste Direttive, l’elenco delle ditte di riciclaggio nel Vostro paese e informazioni
sui prodotti Thermo Scientific che possono essere utili alla rilevazione di sostanze
soggette alla Direttiva RoHS sono disponibili sul sito www.thermo.com/
Conformité WEEE. Ce produit doit être conforme à la directive européenne
(2002/96EC) des Déchets d’Equipements Electriques et Electroniques (DEEE). Il
est marqué par le symbole suivant. Thermo Fisher Scientific s’est associé avec une
ou plusieurs compagnies de recyclage dans chaque état membre de l’union
européenne et ce produit devraitêtre collecté ou recyclé par celles-ci. Davantage
d’informations sur laconformité de Thermo Fisher Scientific à ces directives, les
recycleurs dans votre pays et les informations sur les produits Thermo Scientific
qui peuvent aider le détection des substances sujettes à la directive RoHS sont
disponibles sur www.thermo.com/
Great Britain
Deutschland
Italia
France

Important
For your future reference and when contacting the factory, please have the
following information readily available:
Model Number:
Serial Number:
Date Purchased:
The above information can be found on the dataplate attached to the
equipment. If available, please provide the date purchased, the source of
purchase (manufacturer or specific agent/rep organization), and purchase
order number.
IF YOU NEED ASSISTANCE:
SALES DIVISION
Phone: [phone]
800/252-7100
FAX: [phone]
LABORATORY PARTS and SERVICE
Phone: [phone]
FAX: [phone]
TECHNICAL SUPPORT
Phone: [phone]

Thermo Fisher Scientific Inc.
275 Aiken Road
Asheville, NC 28804
United States
www.thermofisher.com
107774Rev. A
