Thermo Scientific FB1300 User manual

Thermo Scientific 
Thermolyne Furnace 
Small Benchtop Muffle/ 
Type FB1300 and FB1400 
Installation and Operation Manual
LT1256X1 Revision G October 2018

©2018 Thermo Fisher Scientific Inc. All rights reserved.
Thermo Fisher Scientific Inc. provides this document to its customers with a product purchase to use in the
product operation. This document is copyright protected and any reproduction of the whole or any part of this
document is strictly prohibited, except with the written authorization of Thermo Fisher Scientific Inc.
The contents of this document are subject to change without notice. All technical information in this
document is for reference purposes only. System configurations and specifications in this document supersede
all previous information received by the purchaser.
Thermo Fisher Scientific Inc. makes no representations that this document is complete, accurate or error-
free and assumes no responsibility and will not be liable for any errors, omissions, damage or loss that
might result from any use of this document, even if the information in the document is followed
properly.
This document is not part of any sales contract between Thermo Fisher Scientific Inc. and a purchaser. This
document shall in no way govern or modify any Terms and Conditions of Sale, which Terms and Conditions of
Sale shall govern all conflicting information between the two documents.
Release history:
For Research Use Only. Not for use in diagnostic procedures.

Thermo Scientific Small Benchtop Muffle 1
C
Chapter 1 Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Alert Signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
General Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Principles of Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 3 General Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
FB1300 Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
FB1400 Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Environmental Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Chapter 4 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Site Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
FB1300 and FB1400 Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Chapter 6 Operation, All Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Power Switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cycle Light shown on the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Door Safety Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Chapter 7 Single Setpoint Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Eurotherm 3216 Controller Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Buttons and Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
To change the Setpoint . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
To View the Display Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Controller Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Sensor Break Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Contents

Contents
2Small Benchtop Muffle Thermo Scientific
Over – Temperature Protection (OTP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Chapter 8 Single Ramp & Dwell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Program Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
SetPoint Rate Limit Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Running the Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Holding the Program. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Stopping the Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Clearing the Flashing End . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Verifying a Running Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Chapter 9 Furnace Loading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 10 Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
General Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Chapter 11 Maintenance and Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
To Replace Heating Element. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
To Replace Thermocouple. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
To Replace Insulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
To Replace Door Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
To Replace Solid State Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
To Replace Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Chapter 12 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Chapter 13 Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Chapter 14 Ordering Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Chapter 15 Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
FB1400 models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
FB1300 models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Chapter 16 Exploded View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Thermo Scientific Small Benchtop Muffle 3
1
Safety Information
Contents
“Alert Signals” on page 4•
•“Important Information” on page 4
•“Warnings” on page 4
•“Warning” on page 5

1 Safety Information
Alert Signals
4Small Benchtop Muffle Thermo Scientific
Alert Signals
Warnings alert you to a possibility of personal injury.
Cautions alert you to a possibility of damage to the equipment.
Notes alert you to pertinent facts and conditions.
Hot surfaces alert you to a possibility of personal injury if you come in contact with a
surface during use or for a period of time after use.
Important Information
Your Thermo Scientific Thermolyne Type FB1300 Model or FB1400 Model Furnace has been
designed with function, reliability and safety in mind. It is your responsibility to install it in
conformance with local electrical codes. For safe operation, please pay attention to the alert signals
throughout the manual.
This manual contains important operating and safety information.
You must carefully read and understand the contents of this manual prior to the use of this furnace. 
If the equipment is used in a manner not specified by the manufacturer, protection provided by the
equipment may be impaired.
Warnings
To avoid electrical shock, this furnace must:
1. Use a properly grounded electrical outlet of correct voltage and current handling capacity.
2. Be disconnected from the power supply prior to maintenance and servicing.
3. Have the door switch operating properly.
To avoid burns, this furnace must:
Caution: Hot Surface - Avoid Contact. To avoid burns, do not touch the exterior or interior surfaces of
this furnace during use or for a period of time after use.
To avoid personal injury:
1. Do not use in the presence of flammable or combustible materials; fire or explosion may result.
This device contains components which may ignite such material.

1 Safety Information
Warning
Thermo Scientific Small Benchtop Muffle 5
2. Refer servicing to qualified personnel.
3. Always wear safety glasses or a safety shield and high temperature gloves when loading or
unloading the furnace. Long sleeved, fire retardant clothing and a fire retardant apron is also
recommended.
Warning
This warning is presented for compliance with California Proposition 65 and other regulatory agencies
and only applies to the insulation in this product. This product contains refractory ceramic, refractory
ceramic fiber or fiberglass insulation, which can produce respirable dust or fibers during disassembly.
Dust or fibers can cause irritation and can aggravate pre-existing respiratory diseases. Refractory
ceramic and refractory ceramic fibers (after reaching 1000°C) contain crystalline silica, which can cause
lung damage (silicosis). The International Agency for Research on Cancer (IARC) has classified
refractory ceramic fiber and fiberglass as possibly carcinogenic (Group 2B), and crystalline silica as
carcinogenic to humans (Group 1).
The insulating materials can be located in the door, the hearth collar, in the chamber of the product or
under the hot plate top. Tests performed by the manufacturer indicate that there is no risk of exposure
to dust or respirable fibers resulting from operation of this product under normal conditions. However,
there may be a risk of exposure to respirable dust or fibers when repairing or maintaining the insulating
materials, or when otherwise disturbing them in a manner which causes release of dust or fibers. By
using proper handling procedures and protective equipment you can work safely with these insulating
materials and minimize any exposure. Refer to the appropriate Material Safety Data Sheets (MSDS) for
information regarding proper handling and recommended protective equipment. For additional
MSDS copies, or additional information concerning the handling of refractory ceramic products,
please contact the Customer Service Department at 1-800-438-4851.

1 Safety Information
Warning
6Small Benchtop Muffle Thermo Scientific

Thermo Scientific Small Benchtop Muffle 7
2
Introduction
Contents
“Intended Use” on page 8•
•“General Usage” on page 8
•“Principles of Operation” on page 8

2 Introduction
Intended Use
8Small Benchtop Muffle Thermo Scientific
Intended Use
The Type FB1300 Model and FB1400 furnaces are general purpose laboratory and heat treating
furnaces. For optimum element life, we recommend observing these temperature ranges: from 100°C
(212°F) to 982°C (1800°F) for continuous use, or from 982°C (1800°F) to 1100°C (2012°F) for
intermittent use. Continuous use is operating the furnace for more than 3 hours and intermittent use is
operating the furnace for less than 3 hours.
The unit consists of a heating chamber and a digital controller.
General Usage
Do not use this product for anything other than its intended usage.
Principles of Operation
The furnace chamber is heated by a single three section resistant heater which is embedded in a
refractory material. The chamber is insulated with ceramic fiber insulation. The temperature is
controlled by an electronic control. The temperature is measured by a thermocouple and is registered
on a digital display. For safety, door switches are incorporated to remove power from the heating
elements when the door is opened. The furnace is supported by the control section which also houses
the electrical connections.

Thermo Scientific Small Benchtop Muffle 9
3
General Specification
FB1300 Models
Dimensions: (handle not included)
Chamber: 4” W x 3.75” H x 4.5” D (10.2 x 9.5 x 11.4 cm)
Overall : 7.9” W x 13.8” H x 8.5” D (20.0 x 34.9 x 21.6cm)
Chamber volume: 76 cu. in. (1.3 liters)
Weight: 15.7 lb. (7.1 kg)
Electrical Ratings:
Model # Volts Amps Watts Phase Frequency
FB1310 220-240 4.4 1060 150/60
FB1310M-26 220-240 4.4 1060 150/60
FB1310M-33 220-240 4.4 1060 150/60
FB1310M-33CN 220-240 4.4 1060 150/60
FB1310M-33CH 220-240 4.4 1060 150/60
FB1310M-33UK 220-240 4.4 1060 150/60
FB1314M 100 10.6 1060 150/60
FB1315M 120 8.9 1060 150/60
FB1318M 208 5.1 1060 150/60
Temperature: Operating Range (continuous): 982°C; (intermittent): 1100°C.

3 General Specification
FB1400 Models
10 Small Benchtop Muffle Thermo Scientific
FB1400 Models
Dimensions: (handle not included)
Chamber: 5.00” W x 4.25” H x 6.00” D (12.7 x 10.8 x 15.2 cm)
Overall: 9.7” W x 15.8” H x 11.1” D (24.6 x 39.0 x 28.3cm)
Chamber volume: 129 cu. in. (2.1 liters)
Weight: 23 lb. (10.4 kg)
Electrical Ratings:
Model # Volt s Amps Watts Phase Frequency
FB1410 220-240 6.3 1520 150/60
FB1410M-26 220-240 6.3 1520 150/60
FB1410M-33 220-240 6.3 1520 150/60
FB1410M-33CN 220-240 6.3 1520 150/60
FB1410M-33CH 220-240 6.3 1520 150/60
FB1410M-33UK 220-240 6.3 1520 150/60
FB1414M 100 14.5 1520 150/60
FB1415M 120 12 1520 150/60
FB1418M 208 7.3 1520 150/60
Temperature: Operating Range (continuous): 982°C; (intermittent): 1100°C.
Environmental Conditions
Operating: 17°C to 27°C; 20% to 80% relative humidity, non-condensing. Installation Category II
(overvoltage) in accordance with IEC 664. Pollution degree 2 in accordance with IEC 664.
Altitude Limit: 2,000 meters.
Storage: -25°C to 65°C; 20% to 80% relative humidity.

Thermo Scientific Small Benchtop Muffle 11
4
Unpacking
1. Visually check for any physical damage to the shipping container.
2. Inspect the equipment surfaces that are adjacent to any damaged area.
3. Open the furnace door and remove the packing material from inside the furnace chamber.
4. Vacuum the chamber prior to use to remove the insulation dust due to shipment.
5. Retain the original packaging material if reshipment is foreseen or required.

4 Unpacking
12 Small Benchtop Muffle Thermo Scientific

Thermo Scientific Small Benchtop Muffle 13
5
Installation
Contents
“Site Selection” on page 14•
•“Electrical Connections” on page 14
•“FB1300 and FB1400 Models” on page 14

Be sure ambient temperature does not exceed 40°C (104°F). The recommended
ambient temperature is 17°C - 27°C. Ambient above this level may result in damage
to the controller.
Allow at least six inches of space between the furnace, at least 40 inches above the
furnace and any combustible surface. This permits the heat from the furnace case to
escape so as not to create a possible fire hazard.
To avoid electrical shock, this furnace must always use a properly grounded outlet of
correct voltage and current handling capacity.
5 Installation
Site Selection
14 Small Benchtop Muffle Thermo Scientific
Site Selection
Install furnace on a sturdy surface and allow space for ventilation.
Electrical Connections
1. The electrical ratings are located on the specification plate on the back of the furnace. Consult
customer service if your electrical service is different than those listed on the specification plate. Be
sure the front power switch is in the OFF position before connecting the furnace to your electrical
supply.
FB1300 and FB1400 Models
Electrical Conditions for operating the furnaces in the EU:
The furnaces are intended for use at a network supply with a maximum system impedance of Zmaxat
the point of connection, according to EN 61000-3-11 clause 6.2.2. The user has to ensure that the
device is operated on a network supply that meets these requirements. If necessary, the system
impedance can be confirmed by the energy supplier.
The system impedance at the point of connection is typically less than 0.2 Ohm.
Unit Zmax [?]
FB1310M-33 0,28
FB1310M-33CN 0,28
FB1310M-33CH 0,28
FB1310M-33UK 0,28
FB1410M-33 0,34
FB1410M-33CN 0,34
FB1410M-33CH 0,34
FB1410M-33UK 0,34

Thermo Scientific Small Benchtop Muffle 15
6
Operation, All Models
Contents
“Power Switch” on page 16•
•“Cycle Light shown on the display” on page 16
•“Door Safety Switch” on page 16

To avoid personal injury do not use in the presence of flammable or combustible
chemicals; fire or explosion may result. This device contains components which may
ignite such materials.
Caution: Avoid Contact. To avoid burns, this furnace must not be touched on the
exterior or interior surfaces during use or for a period of time after use.
Always wear safety glasses or a safety shield and high temperature gloves when
loading or unloading the furnace. Long sleeved, fire retardant clothing and a fire
retardant apron is also recommended.
To avoid electrical shock, the door safety switch must be operating properly.
6 Operation, All Models
Power Switch
16 Small Benchtop Muffle Thermo Scientific
Power Switch
Both the ON/OFF power switch and the digital display will illuminate when power is switched ON.
The furnace will begin to heat to its controller's current setpoint. (See the instructions for your type of
controller for information on checking and setting the setpoint.)
Cycle Light shown on the display
The cycle light will illuminate whenever the power is being applied to the heating elements. The cycle
light will turn on and off as the furnace reaches the setpoint.
Door Safety Switch
The door safety switch removes power from the heating elements when the door is opened. Open and
close the door a few times; Note an acoustic click of the switch during opening and closing of the door.
If this condition is not true, consult the Troubleshooting section before proceeding. This check must
be done when the furnace is heating and the cycle light on the display is illuminated.

Thermo Scientific Small Benchtop Muffle 17
7
Single Setpoint Controller
Contents
“Eurotherm 3216 Controller Operation” on page 18•
•“Basic Operation” on page 18
•“Buttons and Indicators” on page 19
•“To change the Setpoint” on page 19
•“To View the Display Units” on page 19
•“Controller Parameters” on page 19
•“Alarms” on page 20
•“Sensor Break Protection” on page 20
•“Over – Temperature Protection (OTP)” on page 20
•“Tuning” on page 21

7 Single Setpoint Controller
Eurotherm 3216 Controller Operation
18 Small Benchtop Muffle Thermo Scientific
Eurotherm 3216 Controller Operation
The single setpoint model w/OTP furnace controller is a single setpoint controller, which provides a
single digital display to indicate the current chamber temperature or setpoint temperature.
This temperature controller features sensor break protection, self-tuning capability and over
temperature protection (OTP) with an additional OTP relay device.
Basic Operation
When the controller is turned ON it will perform a short self-test and then display a default page. The
measured value (process value) is found in the upper display and the setpoint is found in the lower
display.
Alarm Beacon
Output(s) Status Beacon
"OP1" indicates that the
heating elements are
active
PAGE Button
Unit of Measure
4 Digit
Process Value
(PV) Display
SetPoint (SP)
Display and
Scolling Text
Messages
UP ARROW Button
DOWN ARROW ButtonSCROLL Button
If at any time you want to return to the HOME DISPLAY, press PAGE button.
