Operating Manual
0000848 • Revision A • October 2021
Thermo Scientific Digital Drybath

IMPORTANT! Before using this product, read this entire operation manual carefully. Users should follow all of
the operational guidelines contained in this manual and take all necessary safety precautions while using this
product. Failure to follow these guidelines could result in potentially irreparable bodily harm and/or property
damage.
Caution all internal adjustments and maintenance must be performed by qualified service personnel.
Material in this manual is for information purposes only. Thermo Fisher Scientific is committed to a continuing
program of product development and improvement, and reserves the right to change information, such as
specifications, appearance, and dimensions, described in this document without notice. Thermo Fisher
Scientific makes no representations or warranties with respect to this manual. In no event shall Thermo Fisher
Scientific be held liable for any damages, direct or incidental, arising out of or related to the use of this manual.
No part of this manual may be reproduced or transmitted in any form or by any means, including
photocopying, recording, or using information storage and retrieval systems, for any purpose other than the
purchaser's own use, without the express written permission of the manufacturer.
Any other product names and services identified in this manual are trademarks or registered trademarks of
their respective owners. No such use, or the use of any trade name, is intended to convey endorsement or
other affiliation with Thermo Fisher Scientific.
©2021 Thermo Fisher Scientific. All rights reserved.
All rights reserved. Without prior written consent from Thermo Fisher Scientific, any part of the manual should
not be duplicated, reproduced or translated into any other languages.
Caution: All rights reserved. Thermo Fisher Scientific reserves the right to modify this manual at any time
without notice.
Before the initial use of this instrument, please carefully read this manual.

Contents
Models......................................................................... 1
Safety Information........................................................ 2
Introduction ................................................................. 4
Features....................................................................... 5
Normal Working Conditions...................................... 5
Transportation and Storage Conditions .................... 5
Basic Parameters..................................................... 5
Regulatory Compliance ............................................ 6
Preparation Work......................................................... 8
Structure Diagram.................................................... 8
Display Panel Diagram ............................................. 8
Instructions for Buttons ............................................ 8
Operation Guidance..................................................... 9
Examination Before Startup...................................... 9
Startup..................................................................... 9
Setting Temperature and Heating Time .................... 9
Start and Stop Instrument ........................................ 10
Temperature Measurement and Calibration.............. 10
Maintenance ................................................................ 11
Failure Analysis and Troubleshooting ........................... 12
Modular Block Accessories.......................................... 13
Warranty...................................................................... 15
Frequently Asked Questions ........................................ 16

Digital Drybath Models | 1
Models
This manual covers the models shown below.
Table 1. Models
NA Model EU Model Voltage Description
88870001 N/A 100-120 Vac TS Drybath Stdrd 1 blck 100-120 V
88870002 N/A 100-120 Vac TS Drybath Stdrd 2 blck 100-120 V
88870003 N/A 100-120 Vac TS Drybath Stdrd 4 blck 100-120 V
N/A 88870004 200-240 Vac TS Drybath Stdrd 1 blck 200-240 V
N/A 88870005 200-240 Vac TS Drybath Stdrd 2 blck 200-240 V
N/A 88870006 200-240 Vac TS Drybath Stdrd 4 blck 200-240 V

2 | Safety Information Digital Drybath
Safety Information
Alert Signals
During operation, maintenance and repair of this instrument,
the following basic safety notes should be observed. In case
of failure to follow these instructions, the warnings or notes
indicated herein, the basic protection provided by the
instrument, its safety criteria of design and manufacture, and
its predicted use range would be impaired. If the equipment is
used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.
CAUTION: Important information is contained in
any item and should be carefully read. Failure to
observe the instruction would result in damage or
abnormal function of the instrument.
WARNING: The warning message requires
extremely careful operation of a certain step.
Failure to observe the instruction may result in
serious personal injury.
CAUTION: This instrument is for indoor use.
• The ground connection
To avoid the electric shock, the input power
line must be reliably grounded. The instrument
is equipped with the three-pin plug that has
the third pin (the pin connects the ground),
therefore, the plug should be used with the
grounded power socket only. This is a kind of
safety device. If the plug cannot be plugged
into the power socket, please ask the
electrician to install a correct power socket, so
as to make the grounded plug to work for
safety.
Thermo Fisher Scientific is not responsible for
any injury as a result of the user’s failure to
observe the following requirements.
• Observe voltage/power requirements
Before the instrument is connected to the AC
power source, the voltage of the power
source should be the same with the required
voltage of the instrument (a deviation of ±10%
is allowed). The rated load of the power
socket should not be lower than the
requirements of the instrument.
• The power cord
The instrument should use the power line cord
attached to it. If the power line is destroyed, it
must be replaced but not be repaired. The
replacement should be carried out with the power
line of the same type and same specification
(reach out to technical service team for further
information). No items should be put on the power
cord when the instrument is in operation.
• Connecting and disconnecting to/from
power source
The user should hold the plug to remove from
power source. When connecting the plug, user
should make sure it has been fully plugged in;
when removing the plug, do not pull the power line
forcefully. Do not position the equipment so that it
is difficult to operate the disconnecting device
(plug).
• Placement of the instrument
This instrument should be fixed in a low
RH (≤ 80%) and low dust place away from
water source (e.g. sink or water pipeline) and
the room should be well ventilated, and free of
corrosive gas or interference of strong
magnetic field. The instrument should not be
placed in a wet or dusty location.
The openings on this instrument are for
ventilation circulation and in order to avoid
over-heat of the instrument body they should
not be blocked or covered. When a single set
of instrument is used, the interval between
ventilation opening before and after the
instrument and its nearest object should not
be less than 25 cm. Also, don’t use the
instrument on loose or soft surface, or the air
inlet of instrument bottom might be blocked.

Digital Drybath Safety Information | 3
Excessive temperature will impair
performance or result in failure of the
instrument. This instrument should not be
used in locations subjected to direct sun light.
The instrument should be kept away from hot
gas, oven and all other heat sources. If the
instrument is to be stored for a long time, the
power plug should be withdrawn and the
instrument covered with soft cloth or plastic
film to avoid entrance of dust. The product is
powered by connecting the mains plug to a
standard socket-outlet. Always place the
product in such a way that it is easy for the
operator to disconnect the product from the
mains supply.
• Explanation of symbols
Attention, read user manual before use.
WARNING: There is a sign of
“CAUTION: HOT SURFACE!
ATTENTION: SURFACE HOT” on the
instrument. The metal part (module)
near the sign should not be touched
with any part of the body when the
instrument is operating in a high
temperature state or just finished
operation to avoid burns!
Alternating Current
Protective Conductor Terminal
CAUTION: In any of the following cases,
immediately turn off the power supply, withdraw
the power plug from the power socket, contact the
supplier for service:
• Liquid drops into the inside of the instrument.
• The instrument is rained on or water is spilled
on it.
• The instrument works abnormally, especially
if generating an abnormal sound or odor.
• The instrument is dropped or its casing is
damaged.
• The function of instrument obviously
changes.

4 | Introduction Digital Drybath
Introduction
The product is a dry bath with advanced microcomputer
control, which can be widely applied to sample reservation,
enzyme reservation and reaction, DNA amplification,
electrophoresis degeneration and serum coagulation, etc.
The characteristics of the product are as follows:
• The digital display for control of the temperature.
• Heat blocks help avoid possible contamination while
containing the sample inside a tube.
• The heat blocks are easy to replace, clean and disinfect
and are suitable for various tubes sizes.
• Built-in over-temperature protection device warrants
sample and user safety.
• Temperature deviation adjustment.

Digital Drybath Features | 5
Features
This chapter introduces the usage, transportation, storage
conditions of the instrument, as well as its basic parameters,
performance and functions.
Normal Working
Conditions Transportation and
Storage Conditions
Ambient temperature: -20°C~+55°C
Relative humidity: ≤ 80%
Basic Parameters
Ambient temperature 10°C ~ 30°C
Relative humidity ≤ 80%
Power supply 100-120 V ~ 50/60 Hz or
200-240 V ~ 50/60 Hz
Altitude Up to 2000 m
Pollution Degree 2
Overvoltage category II Indoor use
Mains supply voltage
fluctuations
±10%
CAUTION: Before using the instrument, please
make sure the working condition meets the above
requirements. Especially that the power line is
reliably grounded.
Table 2. 100-120 V
NA Catalog Number 88870001 88870002 8887000303
Model Name Digital 1 block
100-120 V
Digital 2 block
100-120 V
Digital 4 block
100-120 V
Temperature Range Ambient Temperature +5°C ~ 130°C (Ambient Temperature 25°C)
Temperature Uniformity ±1.0°C@37°C
Temperature Accuracy ±0.5°C@37°C
Temperature Fluctuation ±0.5°C
Temperature Rise Time ≤ 20 min (rise from 30°C to 130°C) ≤ 25 min (rise from 30°C to
130°C)
Size (L × W × H) 288 × 200 × 100 mm
11.3 × 7.87 × 3.94 in
318 × 200 × 100 mm
12.5 × 7.87 × 3.94 in
450 × 200 × 100 mm
17.7 × 7.87 × 3.94 in
Weight 2.9 kg (6.39 lbs) 3.3 kg (7.28 lbs) 4.7 kg (10.36 lbs)
Fuse Protector (ø5×20) F 250 V 2.5 A F 250 V 5 A F 250 V 8 A

6 | Features Digital Drybath
Regulatory Compliance
European Union
Product Safety
This product family has been tested to applicable product
safety standards by a Nationally Recognized Test Laboratory
(NRTL) and may bear the NRTL’s mark of safety compliance
to those applicable standards.
Korean Registration
Table 3. 200-240 V
EU Catalog
Number 88870004 88870005 88870006
Model Name Digital 1 block
200-240 V
Digital 2 block
200-240 V
Digital 4 block
200-240 V
Temperature Range Ambient Temperature +5°C ~ 130°C (Ambient Temperature 25°C)
Temperature
Uniformity ±1.0°C
Temperature Accuracy ±0.5°C@37°C
Temperature
Fluctuation ±0.5°C
Temperature Rise
Time ≤ 20 min (rise from 30°C to 130°C) ≤ 25 min (rise from 30°C to 130°C)
Size (L × W × H) 288 × 200 × 100 mm
11.3 × 7.87 × 3.94 in
318 × 200 × 100 mm
12.5 × 7.87 × 3.94 in
450 × 200 × 100 mm
17.7 × 7.87 × 3.94 in
Weight 2.9 kg (6.39 lbs) 3.3 kg (7.28 lbs) 4.7 kg (10.36 lbs)
Fuse Protector (ø5×20) F 250 V 2.5 A F 250 V 2.5 A F 250 V 3.15 A
CAUTION: The instrument is only used for heating
operation: from low temperature to high
temperature.
The European voltage models of this product
meet all the applicable requirements of the
European Directives and therefore display the CE
Marking. These Directives are captured in the EU
Declaration of Conformity which may be obtained
from the manufacturer.
CEEMC EN 61326-1
CE Safety EN 61010-1 CE
Safety EN 61010-2-010
UL 61010-1/CSAC22.2 NO.61010-1
ROHS2.0 2011/65/EU
사용자안내문
이기기는엄무용환경에서사용할
목적으로적함성평가를받은기기
로서가정용환경에서사용하는경우전파
간섬의우려가있습니다
WARNING: EMC Registration is done on this
equipment for business use only. It may cause
interference when the product would be used
in home. This warning statement applies a
product for business use.

Digital Drybath Features | 7
Electromagnetic Compatibility
FCC Statement (USA)
Note: This equipment has been tested and found to comply
with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own
expense.
Canadian ISED IC Notice
• This ISM digital apparatus complies with Canadian ICES-
001, Class A
• Cet appareil ISM est conforme á la norme NMB-001 du
Canada, Classe A
End of Life Care
Some considerations and suggestions are listed below for
proper disposal of this product. While addressing these
actions for safe recycling and disposal, please follow all
guidelines, Safety Data Sheets (SDS), or regulations
applicable to your country and region.
• This product has materials and components that may be
recycled or reused according to local guidelines and
regulations.
• Remove any batteries present before disposal. Batteries,
battery packs, and accumulators should not be disposed
of as unsorted household waste. Please use the public
collection system to return, recycle, or treat them in
compliance with the local regulations.
• Remove all samples and items before defrosting a unit to
room ambient temperatures.
• Clean up any chemical or biological safety hazards using
appropriate methods.
• Have a certified technician remove the Refractory
Ceramic insulation from the unit then dispose properly.
This device complies with Part 15 Subpart B of
the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may cause
undesired operation.
Any changes or modifications not expressly
approved by the manufacturer could void the
user’s authority to operate the equipment.
